Amazon CK315 User manual

Smart Speaker With Alexa
User Manual
Model: CK315

1
CONTENTS
Introduction
Features
Includes
Overview
Speaker Controls & Inputs
LED Operation
Start with CK315
Download the SameSay APP
Connecting your device to the internet
Alternative Connection
Multi-room play
Play with Air Play
Use Android DLNA to play
Bluetooth mode
AUX IN mode
Services
Troubleshooting
Contact Information
FCC Warnings

2
Introduction
The CK315 is a hands-free speaker that you can control with your voice. With the CK315 speaker, you can ask
Alexa to play music, read the news, check weather, and control your smart home and more. Amazon Alexa is built
in the cloud, so it is always getting smarter. The more you use Alexa, the more it adapts to your speech patterns,
vocabulary, and preferences with new features continually being added. With the CK315 speaker, you can pair up
to 6 speakers together on Wi-Fi for whole home audio or use Bluetooth/Aux In when listening on-the-go.
Features
Far-field voice control
Supports Alexa Voice Service(AVS)
Multi-room and multi-user capable
Free SmaeSay APP download
Built-in Wi-Fi
Supports Bluetooth Wireless-range 33 ft.
Aux In (3.5mm audio input)
Built-in rechargeable battery - up to 3.5 hours of playtime
Micro-USB port for battery recharge
Includes
User manual
Power adapter: 5V 1A
Micro-USB to USB power cable
Overview
Speaker Controls & Inputs
AUX IN：3.5mm audio input
Press to mute the microphones /press and hold to begin
searching for WiFi networks.
Press to play or pause / press and hold to change audio source
Press to adjust the volume up
Press and hold to power on/off /press to talk in WiFi mode
Press to adjust the volume down
LED indicator
DC 5V Micro-USB power port

3
LED Operation
Start with CK315
Download the SameSay APP
Download and install the SameSay APP to your phone. Then the APP
will guide you to setup your device to the network. If you want to get
more Alexa skills and more information, go to the Amazon Alexa APP.
Both SameSay APP and Amazon Alexa APP are available on App Store
and Google Play.
Android IOS
Note: The QR code of android need to be opened from browser.
Speaker State
LED Indication
Power off
LED off
Alexa idle mode
LED off
Alexa mode (active listening)
Cyan
Bluetooth mode
Blue
Aux mode
Green
Alexa connecting
Cyan flashing
Alexa thinking
Blue/cyan alternating fast flashing
Alexa speaking
Blue/cyan alternating slow flashing
Alexa mode error
Orange flashing
Microphone off
Red
Setup mode (WPS + BT pairing)
White flashing
Charging
Red
Fully charged
LED off
Operation Status LED Ring
DC Connector LED

4
Connecting your device to the internet
Make sure your CK315 speaker was powered on, then open the SameSay APP on your mobile. The app will guide
you through the process, just follow the on-screen instructions and have your network password ready. SameSay
APP screens one-by-one are showed as below(IOS system as sample).
02
Change network to
CK315_XXXX
03
04
05
06
01
Then back to
SAMESAY APP
Select CK315_XXXX
Select an Internet and
input pass word
below, then continue.

5
Amazon account
Password
07
08
09
10
11
12
Setting Amazon account

6
Add device
Audio channel
Speaker settings
Play all connented
devices
More services
Amazon login
Line in mode
BT mode
third-party
services
Music on your
mobile device
Music have
saved
17
16
18
If you go to this page, please go
to you Phone’s Wi-Fi settings to
make sure your phone and
device are on the same network.
If you find new version, please
upgrade.
13
14
15

7
Alternative Connection
After the initial connection, the speaker will remember the Wi-Fi network and automatically connect to it when it
is in Wi-Fi Mode. If the speaker should become disconnected or will not connect normally, repeat the steps below
or try the Alternative Connection Method .
Save favorites
Current playlist
Play controls
Go main menu
Play controls
Go to reset device
19
20
21
22
Back to SameSay APP
Select your CK315’s Wi-Fi
23

8
Tip: If you are still experiencing issues, consult the Troubleshooting section or send us feedback.
Multi-room play
Add devices to DEVICE LIST in your APP, then long press and drag slave device up to main device until they are
in same room to play in sync. You can both control main device or slave devices.(eg, Fig23-24)
Then, steps are
the same as
step 07to17.
24
Select your Wi-Fi
Your Wi-Fi password
Back to your mobile Wi-Fi
Select your Wi-Fi
Back to SameSay APP
25
26
27
28
25
29

9
Play with Air Play
When CK315 speaker network connected, IOS
users can use Air Play to achieve wireless music!
1. IOS 10 & IOS 11 users：Slide up from the
bottom of the device to open the Control
Center and find the "Play in" screen in the
horizontal direction，click ，then
select your CK315_XXXX. (eg, Fig29-30)
2. IOS 9 & IOS 8 users：Slide up from the
bottom of the device to open the Control
Center ， Smoothes along the horizontal to
find the "Play" screen，click ，then
select your CK315_XXXX.
Use Android DLNA to play
When CK315 speaker network connected, Android users can use DLNA to play.
Open the phone or tablet comes with DLNA function of the music player software, click on the playback interface,
click the push icon, then select your CK315_XXXX device to play music.
Tips：
·Make sure your WiFi is 2.4G Wi-Fi and the CK315 does not support the 5G currently.
·It is recommended that you use the router do not connect multiple internet devices, so as not to take up too much
bandwidth and affect user’s experience.
·Do not use in a complex Wi-Fi network environment (eg, office, hotel, multiple routers bridged, too many routers
around, etc.) to avoid unrestricted connection, play cardon, connection failure, inability to use, etc.
Bluetooth mode
Long press mode switch button“ ” and select Bluetooth mode，or select Bluetooth mode on the SameSay APP.
Then top LED will turn into blue and flashing. Pairing CK315’s Bluetooth with your device (Such as: smart
30

10
phones, tablet PCs, PC, Mac and so on). If CK315 Bluetooth connected, top LED stop flashing, also with a
warning sound, then you can play content.
AUX IN mode
Long press mode switch button “ ” and select AUX mode， also you can select AUX mode on the SameSay APP.
While equipments (such as: smart phones, tablet PCs, PC, Mac, etc.) are connected by cable to the AUX, you can
play your content.
Tips：
The line in cable shall be inserted with a relatively fast speed for software change mode needed.
Services
The CK315 now is available third-party services TuneIn, iHeartRadio, TIDAL and Napster. Subsequent increases
will be updated directly to the SameSay APP .
Troubleshooting
PROBLEM
POSSIBLE SOLUTION
Cannot complete
Wi-Fi network setup
» Make sure the speaker has power and is charged.
» Make sure you are connecting to the correct Wi-Fi network.
» If using a dual band wireless router, be sure to use the 2.4GHz band.
» Be sure to enable Wi-Fi on your mobile device.
» Test your internet connection by loading/reloading a web page. If you cannot load the page,
you may need to restart your router.
» Use the alternate connection method .
» Uninstall then reinstall the app, power the speaker OFF, then ON, and restart setup.
Please download the latest user manual from our website, and operate accordingly.
http://www.samesay.com/product/alexa-speaker-ck315#download
Intermittent audio/Audio
doesn’t play
» Make sure the volume on the speaker or your connected device is not too low.
» Interference or weak Wi-Fi signal may be interrupting reception (possible sources could be
microwaves, cell phone signals, etc.). Move the system to another location to test.

11
» Stop other applications that may be streaming media from the internet.
Bluetooth won’t play or
fails to connect
» Make sure the volume on your Bluetooth device is turned up to an audible level.
» Make sure the speaker has power and is charged.
» Make sure both the speaker and your device are in Bluetooth mode.
» Stay within 3 ft. of the speaker when pairing.
Aux In won’t play
» Make sure the audio cable is firmly connected to the audio ports of both devices.
» Make sure the volume on the speaker or your connected device is not too low.
» Press the Mode button to manually switch to Aux In mode.
White noise/Speaker will
not function properly
» Power the speaker OFF, then ON again.
Contact Information
Website: www.samesay.us
Email Support: [e-mail]
FCC Warnings
WARNING: To assure continued operation, follow the attached installation instructions and use only shield
cables when connecting to other devices. Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
This product specifications and design are subject to change without notice!
