AmazonBasics B074DDJFTH User manual

created by: Impala Services Ltd.Page size: 139.7 x 107.95 mm
B074DDJFTH
Digital Air Compressor
Compresseur d’Air Numérique
Digitaler Luftkompressor
Compressore d’Aria Digitale
Compresor De Aire Digital
デジタルエアコンプレッサー
数字充气泵
B074DDJFTH-AmazonBasics-Digital 12V Tire Inflator-IM-V03 (EU).indb 1 11/17/17 3:12 PM

English ..................................... 3
Français ................................... 9
Deutsch.................................. 15
Italiano................................... 21
Español.................................. 27
日本語 ..................................... 33
中文 ........................................ 39
B074DDJFTH-AmazonBasics-Digital 12V Tire Inflator-IM-V03 (EU).indb 2 11/17/17 3:12 PM

3
Welcome Guide •English
Digital Air Compressor
Contents:
Before getting started, ensure the package contains the following components:
LED light and flash warning light 12V Cigarette Lighter
Air compressor ON/OFF switch Set button
LED light and flash light switch Pressure setting button(decrease)
Hose Pressure setting button(increase)
Thread connection Ball / balloon adaptors
WARNING
Please carefully read the manual included with this product. Misuse of the unit could cause
property /equipment damage and/or personal injury.
Caution: Do not touch hot parts (The connector of Air hose) by hand during the use.
B074DDJFTH-AmazonBasics-Digital 12V Tire Inflator-IM-V03 (EU).indb 3 11/17/17 3:12 PM

4
High-Pressure Applications
• Car tires
• Bicycle tires
• Basketballs
• Sporting equipment
• Party balloons
Safety and Compliance
Before using this product,read this manual and follow all its safety rules and operating
instructions. When using this air compressor,basic safety precautions should always be
followed to reduce this risk of fire, electric shock and personal injury.
1. Do not overinflate products beyond manufacturer’s recommendations.
2. Do not allow the compressor or its components to get wet.
3. Do not leave the air compressor unattended while in operation.
4. Do not allow children to handle or operate this compressor.
5. Do not use this product for other than its intended use.
6. Do not disassemble or tamper with this compressor.
7. If the air compressor emits abnormal sounds or overheats, turn it off immediately and let it cool
off for at least 30 minutes.
8. Inspect air compressor before use. If cracked, broken or damaged parts are found, qualified
technicians should repair damaged parts.
9. Never expose the air compressor to rain, frost or temperatures above 30 oC or below -30 oC.
10. Never use on people or animals.
11. Make sure the cord is not exposed to hot objects, oil or sharp edges.
12. Warning! For your own safety, you should only use accessories and parts specified in the
instructions, or recommended for use by the manufacturer.
B074DDJFTH-AmazonBasics-Digital 12V Tire Inflator-IM-V03 (EU).indb 4 11/17/17 3:12 PM

5
Operation
This product is equipped with an auto shut-off digital pressure gauge. The digital gauge can be
used to monitor air pressure when inflating your desired objects, and can automatically shut off
once pre-set desired pressure is reached.
IMPORTANT
• The product records latest pre-set pressure. For example, if your pre-set pressure
gauge is 35 psi, the product records the pre-set pressure at 35 psi for the next time.
• If the pressure in the tire is higher than the set pressure the compressor will not
start. If this happens, back off the thread connection to release air from the tire
until the pressure is lower than the set pressure or increase the set pressure higher
than in the tire.
• Allow air compressor to cool for 10 minutes after 10 minutes of continuous operation.
• After using, disconnect the 12 V adaptor from the power outlet and store the 12 V cord in the
compartment area.
• To reduce risk of damage to cigarette lighter connector and cord, pull by cigarette lighter
connector rather than cord.
• Make sure cord is located so that it will not be stepped on, tripped over, or otherwise
subjected to damage or stress.
Pressure Pre-set
• The pre-set pressure is at 35 PSI when manufactured.
Inflating A Car Tire And Bicycle Tire
1. Turn on the car engine and roll out the 12 V cord and connect the 12 V adaptor to the outlet.
2. Screw the thread connector onto tire’s valve stem.
3. Adjust your desired pressure by pressing button ‘ ’/ ‘ ’. Press button ‘ ’ to increase the
pressure gauge and press button ‘ ’ to decrease the pressure gauge. Once the desired
pressure is reached, the displayed figure will flicker for several times, then return to 0.0 PSI.
That means the pressure is pre-set successfully. The product is ready for inflating.
4. Press the button ‘set’ to display pressure in PSI/BAR.
5. Remove the thread connector from the tire and disconnect the 12 V adaptor from the power
outlet.
Note: To avoid over-inflation of tires, please check the recommended car tire pressure in the
vehicle’s owner’s manual. For bicycle tires, please check the tire marking.
B074DDJFTH-AmazonBasics-Digital 12V Tire Inflator-IM-V03 (EU).indb 5 11/17/17 3:12 PM

6
Inflating Sporting Equipment (i.e. basketball, football)
1. Turn on the car engine and roll out the 12 V cord and connect the 12 V adaptor to the outlet.
2. Screw the ball/balloon adaptor into the thread connector.
3. Insert the ball/balloon adaptor into the valve of the object to be inflated.
4. Adjust your desired pressure by pressing button ‘ ’/ ‘ ’. Press button ‘ ’ to increase the
pressure gauge and press button ‘ ’ to decrease the pressure gauge. Once the desired
pressure is reached, the displayed figure will flicker for several times, then return to 0.0 PSI.
That means the pressure is pre-set successfully. The product is ready for inflating.
5. Press the button ‘set’ to display pressure in PSI/BAR.
6. Remove ball/balloon adaptor from the inflated object’s valve and unscrew ball/balloon adapter
from the thread connector.
7. Disconnect the 12 V adaptor from the outlet and store the 12 V cord in the compartment area.
How To Replace The Fuse In The 12 V Plug
1. To replace the fuse in the plug, twist off the upper cover.
2. Remove the faulty fuse and insert a new 15 A fuse.
3. Twist the cover back on the plug.
B074DDJFTH-AmazonBasics-Digital 12V Tire Inflator-IM-V03 (EU).indb 6 11/17/17 3:12 PM

7
Instructions on Environment Protection
Do not dispose of this product in the usual household garbage at the end of its life
cycle; hand it over at a collection point for the recycling of electrical and electronic
appliances. The symbol on the product, the instructions for use or the packing will
inform about the methods for disposal.
The materials are recyclable as mentioned in its marking. By recycling, material recycling or
other forms of re-utilization of old appliances, you are making an important contribution to
protect our environment.
Specications
Working Voltage: DC 12 V
Cylinder: 28 mm cylinder
Max. pressure: 150 PSI
Fuse: 15 A
Warranty Information
To obtain a copy of the warranty for this product:
Visit amazon.com/AmazonBasics/Warranty
— or —
Contact Customer Service at 1-866-216-1072
B074DDJFTH-AmazonBasics-Digital 12V Tire Inflator-IM-V03 (EU).indb 7 11/17/17 3:12 PM

8
Feedback
Love it? Hate it?
Let us know with a customer review.
AmazonBasics is committed to delivering customer-driven products that live up to your high
standards. We encourage you to write a review sharing your experiences with the product.
Please visit: amazon.com/review/review-your-purchases#
For further services:
Visit amazon.com/gp/help/customer/contact-us
— or —
Contact Customer Service at 1-866-216-1072
B074DDJFTH-AmazonBasics-Digital 12V Tire Inflator-IM-V03 (EU).indb 8 11/17/17 3:12 PM

9
Guide de Bienvenue •Français
Compresseur d’Air Numérique
Contenu:
Avant de commencer, veuillez vous assurer que l’emballage contient les composants suivants:
Voyant LED et voyant
d'avertissement clignotant
Allume-cigare de 12 V
Commutateur ON/OFF du
compresseur d’air
Bouton Set
Commutateur du voyant LED et
du voyant clignotant
Bouton de réglage de la pression (réduire)
Tuyau Bouton de réglage de la pression (augmenter)
Raccord fileté Adaptateurs pour balles/ballons
AVERTISSEMENT
Veuillez lire attentivement le manuel livré avec ce produit. Toute mauvaise utilisation de
l'appareil est susceptible d’entraîner des dommages matériels, d’endommager l’appareil
et/ou de provoquer des blessures corporelles.
Attention: Ne pas toucher les parties chaudes (le connecteur du tuyau d’air) avec vos
mains pendant d’utilisation.
B074DDJFTH-AmazonBasics-Digital 12V Tire Inflator-IM-V03 (EU).indb 9 11/17/17 3:12 PM

10
Applications à Haute Pression
• Pneus de voiture
• Pneus de vélo
• Ballons de basket
• Équipement de sport
• Ballons de fête
Sécurité et Conformité
Avant d'utiliser ce produit, veuillez lire le présent manuel, puis suivez toutes ses consignes
de sécurité ainsi que ses instructions d'utilisation. Lors de l'utilisation de ce compresseur
d'air, il convient de toujours respecter certaines mesures de sécurité de base, afin de
réduire tout risque d'incendie, d'électrocution et de blessures corporelles.
1. Ne pas surgonfler les produits au-delà des recommandations du fabricant.
2. Ne pas laisser le compresseur ou ses composants prendre l’humidité.
3. Ne pas laisser le compresseur d’air sans surveillance pendant son utilisation.
4. Ne pas laisser des enfants manipuler ou utiliser ce compresseur.
5. Ne pas utiliser ce produit à d’autres fins que celles prévues.
6. Ne pas démonter ou altérer ce compresseur.
7. Si le compresseur d'air émet des sons anormaux ou surchauffe, mettez-le immédiatement
hors tension, puis laissez-le refroidir pendant au moins 30 minutes.
8. Examinez le compresseur d’air avant utilisation. Si des composants sont fissurés, cassés ou
endommagés, ceux-ci doivent être réparés par des techniciens qualifiés.
9. Ne jamais exposer le compresseur d'air à la pluie, au gel ou à des températures supérieures à
30°C ou inférieures à -30°C.
10. Ne jamais utiliser sur des personnes ou des animaux.
11. Assurez-vous que le cordon n’est pas exposé à de l’huile et à des objets chauds ou à des
bords coupants.
12. Avertissement! Pour votre propre sécurité, utilisez exclusivement les accessoires et les
composants indiqués dans les instructions, ou recommandés par le fabricant.
B074DDJFTH-AmazonBasics-Digital 12V Tire Inflator-IM-V03 (EU).indb 10 11/17/17 3:12 PM
