AmbiCom WL1100B-AP Installation instructions

11 Mbps Wireless LAN Access Point
Model: WL1100B-AP
Product Specifications
Rev. 02
Model Number WL1100B-AP
Description Wave2Net IEEE 802.11b Wireless LAN Access Point
Radio Specifications
Radio Type Direct Sequence Spread Spectrum (DSSS)
Data Rate 1, 2, 5.5, 11 Mbps Per Channel
Antenna Dual Dipole Antenna with Diversity Functions
Frequency Band (ISM Band)
and Operating Channels
(IEEE 802.11b Compliant)
N. America/FCC: 2.412 ~ 2.462 GHz (11 channels)
Europe CE/ETSI: 2.412 ~ 2.472 GHz (13 channels)
Japan: 2.457 ~ 2.484 GHz (14 channels)
France: 2.457 ~ 2.472 GHz (4 channels)
Spain: 2.457 ~ 2.462 GHz (2 channels)
Type of Modulation BPSK: 1 Mbps
QPSK: 2 Mbps
CCK: 5.5 and 11 Mbps
Receiver Sensitivity
-80 dBm (Typically @ 25?C + 5?C)
(Less than 8% of FER packet sizes are 1024 bytes)
Operating Range
Confined Environment 164 ft. (50M) @ 11 Mbps
262 ft. (80M) @ 5.5 Mbps
394 ft. (120M) @ 2 Mbps
492 ft. (150M) @ 1 Mbps
Open Environment 820 ft. (250M) @ 11 Mbps
1,148 ft. (350M) @ 5.5 Mbps
1,312 ft. (400M) @ 2 Mbps
1,640 ft. (500M) @ 1 Mbps
Transmit Power 2.7v to 3.0v: 13dBm ~ 20 dBm
Operation Humidity 0% to 95% Non-condensing
Operation Temperature 32?F to 131?F (0?C to 55?C)
Storage Temperature -2?F to 176?F (-20?C to 80?C)
Power Consumption 5.1 VDC, 1.0A
Encryption 128-bit WEP, RC4 Wireless Data Encryption
Power Consumption 5.1 VDC, 1.0A
Function Supported Roaming or Infrastructure
Port One 10BaseT RJ-45
Maximum Clients 256 (15-20 recommended)
Remote Configuration USB SNMP Configuration Utility
Ethernet Wired Interface IEEE 802.3 (10BaseT)
Physical Specifications
Size 5.5 x 3.5 x 1.5 inches (140 x 90 x 40 mm)
Weight 8 oz. (250 g)
LED Power, TX/RX, and Ethernet
Standard Conformance IEEE 802.11b, IEEE 802.3 10BaseT
USA: FCC, Part 15, Sections 15.247, 15.107 and 15.109
Europe: CE, Class B Japan: RCR STD-33
Warranty 1-Year Limited
