AMC KX Series User guide

1
www.amcelettronica.com KX series v.1.70
KX SERIES
ALARM CONTROL UNIT
INSTALLER MANUAL
EN 50131-1
EN 50131-3
EN 50131-6
EN 50136-1
EN 50136-2
CLASS II

2
www.amcelettronica.com KX series v.1.70
IMPORTANT NOTES
• The following manual has been prepared to provide assistance to users who use the system. All those who
use the systems listed in this manual must be authorized.
• The information contained in this document are property of AMC Elettronica s.r.l.
• All information contained in this document is subject to change without notice.
• Every part of this manual should be interpreted and used only for the purposes for which it was drafted, the
use other than as prescribed must be authorized by AMC Elettronica srl, under penalty of forfeiture of the
guarantee.
• All trademarks, symbols and examples contained in this manual belong to their respective owners.
GUARANTEE
AMC Electronics s.r.l. ensures that products are free from defects in workmanship.
The product is not installed by the manufacturer and can be used with other products not manufactured by AMC
Elettronica srl, the manufacturer does not guarantee or be held responsible for damage and / or theft or other
types of issues caused by an incorrect installation and / or configuration of the system.
Is not guaranteed to:
- improper use of the panel
- programming errors
- manipulation and vandalism
- wear and tear
- lightning, floods, fire.
AMC Electronics s.r.l. reserves the right to repair or replace the defective product within the limits established
for 24 months.
A different use from that stated in this manual will void the warranty.
The installation must be performed in a workmanlike manner by qualified personnel.
COMPLIANCE
AMC Electronics s.r.l. declares that the X and K series alarm control unit are provisions of Directive 1999/5 /CE
On our web site www.amcelettronica.com
STANDARDS:EN 50136-1 + EN 50136-2 ( GSM and PSTN alarm transmission)
All products mentioned in this manual are in accordance with the rules:
EN 50131-1 + EN 50131-3 + EN 50131-6 (control and indicating equioment for alarm system)
EN 50136-1 + EN 50136-2 ( GSM and PSTN alarm transmission)
Certifier: IMQ – Sistemi di sicurezza Grade: 2 Class:2
Following is the list of normed products:
K4P: control unit (plastic box)
K8P: control unit (plastic box)
K8plusP: control unit (plastic box)
X412P: control unit (plastic box)
X824P: control unit (plastic box)
X864P: control unit (plastic box)
K4M: control unit (plastic box)
K8M: control unit (plastic box)
K8plusM: control unit (Metal box)
X412M: control unit (Metal box)
X824M: control unit (Metal box)
X864M: control unit (Metal box)
PSTN carrier ATS type B on board K4 e K8 (ATS2: D2-M2-T2-S0-I0)*
KLCD: keypad
KLight: keypad
KLight plus: keypad with 2 in/out terminal
KXIN: inputs expansion
KXOUT: outputs
Transformer 25VA
Transformer 30VA
Xgprs/gsm: gsm - gprs module
IP1: IP module
* D2:transmission time 60sec. M2:max transmission time 120sec. T2:time of control information transmission 25h
- S0:no bearing replacement I0: no protection of the information.

3
www.amcelettronica.com KX series v.1.70
AMC Elettronica s.r.l.
Via Pascoli 359
22040 Alzate Brianza
Como
Italy
Tel. +39031632780
Fax +39031632781
www.amcelettronica.com
MANUFATURER
CONTENT OF THE PLASTIC & METAL BOX
In the carton box there is:
- Metal or plastic box with inside:
- Panel board
- Tranformer
- Earth cable
- housing fuse
- Balancing resistors (8 of 1K - 8 of 2K2)
- plastic bag with screws and plastic turrets for fix all parts and close the box
- Adesive data label
- user manual
The packaging does not contain:
- kit Tamper for antiopening and removal (mandatory for EN approval)
- Installation Manual
- backup battery
- programming Software InstallDBExplorer
- fisher for fix on the wall the palstic box
The material not included in the box can be purchased except:
the programming software and Installation manual can be downloaded from our site: www.amcelettronica.com

4
www.amcelettronica.com KX series v.1.70
INTRODUCTION
X an K series are security control panel for building protection with certifification*
EN 50131-1 + EN 50131-3 + EN 50131-6 (control and indicating equiment for alarm system) +
EN 50136-1 + EN 50136-2 2013 (LAN - GPRS - GSM and PSTN alarm transmission)
Certifier IMQ – Sistemi di sicurezza.
The control panel are equipped of 4/8 zones, expandable to 16/32/64 with remote modules.
It is possible to obtain more zones by doubble and triple EOL split line, this configuration is not certified to EN 50131
ALARM COMUNICATION
X K series are able to notify one or more situations of ALARM, ROBBERY, TAMPERING AN TROUBLE with different carriers:
- PSTN LINE ON BOARD type ATS3/SP3 refered to EN 50136-2:2013 **
- GSM/GPRS optional module type ATS3/SP3 refered to EN 50136-2:2013 **
- IP module optional type ATS3/SP3 refered to EN 50136-2:2013 **
The programmming can be via local keypad or a PC with specific software.
* after specific programming and by enable the automatic EN configurator in panel (see description below)
** to ensure the classification SP3 the periodic test call must be programmed for work every 30’ minutes, or for
have classification SP2, the periodic test call can be programmed for work every 25h.
See the table with option below
NOTIFICATION EQUIPMENT DESCRIPTION AND CONFIGUARATION
Option A program 2 outs internal siren + SP2 comunication device (PSTN or GSM/GPRS or LAN)
Option B Autopowered Siren + SP2 comunication device (PSTN or GSM/GPRS or LAN)
Option D SP3 comunication device (PSTN or GSM/GPRS or LAN) with life test call every 30’
The notifications of alarm, robbery, intrusion, fault, manipultion, and other conditions must be signaled by ATS and Siren, in accor-
dance with the requirements specified in Tables to ensure the certification EN 50131-1:2013 and the grade certified.
LEVELS OF ACCESS
The standard EN 50131 defines the following access levels:
Level 1: access by any person (no code require)
Level 2: User Access by code. Level 2 is the access of person that will use the system like ARM/DISARM and all operation that the
rules of EN 50131 approval permitted. This level allows the entry of the code level 3 (installer)
Level 3: Intsaller. This level is the person or gorup of persons that will program all function of panel according with rules of EN
approval and in according with specific needs of Final user LEVEL 2.Another important function of Level 3 is teach to the user level
2 how to use the system when is already programmed.
Level 4: this is the manufactorer level, this access allow to modify the internal function of system. This level has the obligation to
build and design the system following the current standards.
EVENT STORAGE SYSTEM
The system has a memory for storage all events produced from panel, the number of these events is 1000, when the system will
arrive at the end of the number of events storable, will proceed to delete the old one of the1000 registered.
All events are stored in EEPROM components, and therefore not erasable and remain always stored, also in case
of absence of main power.
The delete of events can be made only by the manufacturer.
DEVICES FOR CONTROL OF THE SYSTEM
There are 2 type of device for control of panel:
Type A: Klcd and Klight
Type B: Klight plus
see the explanation in this manual

5
www.amcelettronica.com KX series v.1.70
SPECIFICATIONS X412 X824
zones 4 -16 wired/ doubble,triple EOL 8 -32 wired/ doubble,triple EOL
wireless zones 64 zones 64 zones
outputs 5 on board - espandible to 8 (with 1 expansion) 5 on board - espandible to 8 (with 1 expansion)
user code/tag/
remote
32 users 32 users
partitions 4 4
group 4 4
keypad 4 4
tag reader 4 4
event memory 1000 1000
phone numbers 8 for SMS + 8 for protocols 8 for SMS + 8 for protocols
carriers PSTN on board, GSM/GPRS module, IP module PSTN on board, GSM/GPRS module, IP module
other inputs TAMPER line / mechanical antiopening tamper TAMPER line / mechanical antiopening tamper
PC software yes yes
remote manage-
ment
IP - GPRS
HTML page
apps (Apple - Android )
HTML page
apps (Apple - Android)
timers 4 per day week 4 per day week
SPECIFICATIONS X 864
zones 8 -64 wired/ doubble,triple EOL
wireless zones 64 zones
outputs 5 on board - espandible to 17 (with 4 expansion)
user code/tag/
remote
64 users
partitions 8
group 4
keypad 8
tag reader 8
event memory 1000
phone numbers 8 for SMS + 8 for protocols
carriers PSTN on board, GSM/GPRS module, IP module
other inputs TAMPER line / mechanical antiopening tamper
PC software yes
remote manage-
ment
IP - GPRS
HTML page
apps (Apple - Android)
timers 8 per day week
The main features are:

6
www.amcelettronica.com KX series v.1.70
SPECIFICATIONS K4 K8
zones 4 -16 wired/split/ doubble,triple EOL 8 -32 wired/split doubble,triple EOL/
wireless zones 64 zones 64 zones
outputs 2 on board - espandible to 8 2 on board - espandible to 8
user code/tag/remote 32 users 32 users
partitions 4 4
group 4 4
keypad 4 4
tag reader 4 4
event memory 1000 1000
phone numbers sms/calls 8 for SMS and private calls 8 for SMS and private calls
phone for digital protols 4 numbers with another 4 for backup 4 numbers with another 4 for backup
carriers PSTN on board, GSM/GPRS module, IP module PSTN on board, GSM/GPRS module, IP module
other inputs TAMPER line / mechanical antiopening tamper TAMPER line / mechanical antiopening tamper
PC software yes yes
remote management
IP - GPRS
HTML page
apps (Apple - Android - Win phone)
HTML page
apps (Apple - Android - Win phone)
timers 4 per day week 4 per day week
SPECIFICATIONS K8PLUS
zones 8 -64 wired/radio/split doubble,triple EOL
outputs 2 on board - espandible to 17 (with expansion and keypad)
user code/tag/remote 64 users
partitions 8
group 4
keypad 8
tag reader 8
event memory 1000
phone numbers SMS and private call 8 numbers
phone numbers digital protocols 4 numbers with another 4 for backup
carriers PSTN on board, GSM/GPRS module, IP module
other inputs TAMPER line / mechanical antiopening tamper
PC software yes
remote management
IP - GPRS
HTML page
apps (Apple - Android)
timers 4 per day week

7
www.amcelettronica.com KX series v.1.70
ELECTRIC SPECIFICATIONS X412M X824M X864M
power supply 230 VAC -15% + 10% 50Hz
protection fuse F500mAL 250V
out voltage 13.8 V
Voltage range 9 - 16 V
Max consuption 0.1A 0.1A 0.1A
board consuption 87mA@18V ~ 90mA@18V ~ 90mA@18V ~
max current out 1.1A 1.5A
Max volatge ripple 400mV
max recharge bettery current 500mA
back up battery 12V 7Ah 12V 17Ah
max curret on Load terminal 500mA 0.9A
power supply type (en 50131) type A
Dimensions H = 255mm - L = 300mm - P = 88mm
weight 1.5kg
ENVIRONMENTAL CONDITIONS K4 - K8 - K8PLUS - X412 - X828 - X864
Environmental Class class II
Temperature -10 °C - + 40 °C
Maximum Humidity 75% (non-condensing)
ENVIRONMENTAL CONDITIONS KLight - KLight plus - KXIN - KXOUT - Xgprs - IP1
Environmental Class class II
Temperature -10 °C - + 40 °C
Maximum Humidity 75% (non-condensing)
METAL BOX SPECIFICATION
ELECTRIC SPECIFICATIONS K4M K8M K8PLUS M
power supply 230 VAC -15% + 10% 50Hz
protection fuse F500mAL 250V
out voltage 13.8 V
Voltage range 9 - 16 V
Max consuption 0.1A 0.1A 0.1A
board consuption 87mA@18V ~ 90mA@18V ~ 90mA@18V ~
max current out 1.1A 1.5A
Max volatge ripple 400mV
max recharge bettery current 500mA
back up battery 12V 7Ah 12V 17Ah
max curret on Load terminal 500mA 0.9A
power supply type (en 50131) type A
Dimensions H 255 - L 300 - P 88 mm H 300 - L 400 - P 90 mm
weight 2.2kg 4.7kg

8
www.amcelettronica.com KX series v.1.70
PLASTIC BOX SPECIFICATION
ELECTRIC SPECIFICATIONS X412P X824P X864P
power supply 230 VAC -15% + 10% 50Hz
protection fuse F500mAL 250V
out voltage 13.8 V
Voltage range 9 - 16 V
Max consuption 0.1A 0.1A 0.1A
board consuption 87mA@18V ~ 90mA@18V ~ 90mA@18V ~
max current out 1.1A 1.1A
Max volatge ripple 400mV
max recharge bettery current 500mA
back up battery 12V 7Ah 12V 17Ah
max curret on Load terminal 500mA 0.9A
power supply type (en 50131) type A
Dimensions H = 255mm - L = 300mm - P = 88mm
weight 1.5kg
ELECTRIC SPECIFICATIONS K4P K8P K8PLUS P
power supply 230 VAC -15% + 10% 50Hz
protection fuse F500mAL 250V
out voltage 13.8 V
Voltage range 9 - 16 V
Max consuption 0.1A 0.1A 0.1A
board consuption 87mA@18V ~ 90mA@18V ~ 90mA@18V ~
max current out 1.1A 1.1A
Max volatge ripple 400mV
max recharge bettery current 500mA
back up battery 12V 7Ah 12V 17Ah
max curret on Load terminal 500mA 0.5A
power supply type (en 50131) type A
Dimensions H = 255mm - L = 300mm - P = 88mm
weight 1.5kg
ENVIRONMENTAL CONDITIONS K4 - K8 - K8PLUS - X412 - X828 - X864
Environmental Class class II
Temperature -10 °C - + 40 °C
Maximum Humidity 75% (non-condensing)
ENVIRONMENTAL CONDITIONS KLight - KLight plus - KXIN - KXOUT - Xgprs - IP1
Environmental Class class II
Temperature -10 °C - + 40 °C
Maximum Humidity 75% (non-condensing)

9
www.amcelettronica.com KX series v.1.70
WALL MOUNTING PLASTIC BOX
The control panel is housed in BOX compound based on Acrylonitrile-Butadiene-Styrene (ABS).
UL94 V-0, with brominated flame retardant, without PBB / PBDE.
with dimensions: H = 255mm - L = 300mm - P = 88mm
For the installation of the panel on the wall, choose not easy accessible place to unknown person.
For the drilling of the wall, use the figure that represents the measurements of the distances of the holes of plastic box (fig below)
IMPORTANT: drill the place for install the tamper
Drill, taking care not to damage any piping in the back of the wall.
Insert for each hole, 1 fisher with dimater of 6mm
Slide the cables through provided holes
Fix the box on the wall with the right screw for fisher
-
Fix the plastic blade for tamper with the right screw for 6mm fisher (see fig)
The tamper is made for protect the panel from open and remove the box.
I figure below is shown how to mounted the protection tamper:
- Fix on wall the plastic slat with a 6 mm diatmeter dowels (fisher) Fig.6
- Fix the tamper switch into the slot Fig1 and Fig.2
- Connect the terminal tamper to the socket on the panel board
- Remove the plastic tower from the bottom of the box Fig.4
- Connect the tower to the socket on the cover Fig.5
In this way the system is protected from open and remove
Tamper plastic blade
hole for main power
TAMPER PROTECTION

10
www.amcelettronica.com KX series v.1.70
When the box is fixed on the wall proceed for main power cabling:
The power of the panel must be separate, and must be taken from the main power panel of the place.
The power line must be protected by devices of sectioning and protection in accordance with local regulations.
Must be connect after 16A circuit breaker device with operating curve type C, with supply conductors, (including earth), minimum
section of 1.5 mm2.
Wiring connection in the panel box must be like in figure below:
- Connect phase, neutral and earth to the fuse housing like in figure
- make sure that the earth connection is like the fig in next page
1 2 3
4 5
A
A
6
IMPORTANT: Pay max attention during the cabling
IMPORTANT: to avoid electric shock, wiring system without power
WIRING MAIN POWER AND EARTH

11
www.amcelettronica.com KX series v.1.70
Wiring the earth like figure below:
An example of wiring of the system:

12
www.amcelettronica.com KX series v.1.70
The box of panel allows the housing of 7Ah Lead-acid batteries with UL94-HB flammability or higher.
BACKUP BATTERY
Battery housing
7Ah Lead-acid batteries
with UL94-HB flammability
or higher.
For connect the battery use the black and red terminal from panel like in figure (red: positive - black:negative)
The battery is the second source of main power of the system, and will work in case of absence of main power 230V.
The system check the status of battery every 10sec. , when the level of battery go down 10.4V the system will notify the discharge
battery with a led alert in keypad. When the voltage exceeds 11.4V the system will notify the correct charge of battery.

13
www.amcelettronica.com KX series v.1.70
WALL MOUNTING METAL BOX
The control panel is housed in metal box with dimensions:
H = 255mm - L = 300mm - P = 88mm (battery 7Ah)
H = 300mm - L = 400mm - P = 90 mm (battery 17Ah)
For the installation of the panel on the wall, choose not easy accessible place to unknown person.
For the drilling of the wall, use the figure that represents the measurements of the distances of the holes of plastic box (fig below)
IMPORTANT: drill the place for install the tamper
Drill, taking care not to damage any piping in the back of the wall.
Insert for each hole, 1 fisher with dimater of 6mm
Slide the cables through provided holes
Fix the box on the wall with the right screw for fisher
metal box for battery 7ah

14
www.amcelettronica.com KX series v.1.70
metal box for battery 17ah

15
www.amcelettronica.com KX series v.1.70
TAMPER PROTECTION
In metal box the tamper is used for opnening protection.
In figure is shown how to work:
- fix the tamper switch (1) to the metal blade (2)
- Connect the terminal tamper to the socket on the panel board (3)
(1)
(2)
1 2 3
4 5
A
A
6
(3)
Tamper closed
(1)
(3)

16
www.amcelettronica.com KX series v.1.70
When the box is fixed on the wall proceed for main power cabling:
The power of the panel must be separate, and must be taken from the main power panel of the place.
The power line must be protected by devices of sectioning and protection in accordance with local regulations.
Must be connect after 16A circuit breaker device with operating curve type C, with supply conductors, (including earth), minimum
section of 1.5 mm2.
Wiring connection in the panel box must be like in figure below:
- Connect phase, neutral and earth to the fuse housing like in figure
- make sure that the earth connection is like the figure
- The erath is bring to the panel by metal box, the connection is made from screw of fuse housing and metallic turrets on panel
WIRING MAIN POWER AND EARTH
metal turret for bring earth to the board
screw for connnect the earth box
For bring the earth on closing lid of the box, use the faston
terminal (see fig.)
battery place

17
www.amcelettronica.com KX series v.1.70
The box of panel allows the housing of 17Ah Lead-acid batteries with UL94-HB flammability or higher.
For connect the battery use the black and red terminal from panel like in figure (red: positive - black:negative)
The battery is the second source of main power of the system, and will work in case of absence of main power 230V.
The system check the status of battery every 10sec. , when the level of battery go down 10.4V the system will notify the discharge
battery with a led alert in keypad. When the voltage exceeds 11.4V the system will notify the correct charge of battery.
BACKUP BATTERY & WIRING VIEW
Battery housing
17Ah Lead-acid batteries
with UL94-HB flammability
or higher.
metal box for 17ah battery view
Important: attach biadhesives under the battery compartment, for fix battery and and avoid vibrations.

18
www.amcelettronica.com KX series v.1.70
metal box for 7ah battery view
Important: attach biadhesives under the battery compartment, for fix battery and and avoid vibrations.
Battery housing
7Ah Lead-acid batteries
with UL94-HB flammability
or higher.

19
www.amcelettronica.com KX series v.1.70
MAIN BOARD K4 - K8 - K8PLUS
The main board is the core of the system, all modules are be connected to it, plug the card directly or via RS-485 serial bus.
The following characteristics:
K4
BOARD DESCRIPTION
ERRORE:MfgAppDate
UNLESS OTHERWISE SPECIFIED:
CHECKED
SIZE
APPLICATION
TITLE:
PROPRIETARY AND CONFIDENTIAL
INTERPRET GEOMETRIC
TOLERANCING PER:
Q.A.
ERRORE:DrawnBy
ERRORE:QAApproval
FINISH
ERRORE:QAAppDate
ERRORE:COMPANYNAME
DWG. NO.
DATE
USED ON
A
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
ANGULAR: MACH
BEND
TWO PLACE DECIMAL
THREE PLACE DECIMAL
ERRORE:Revision
NEXT ASSY
MATERIAL
NAME
REV
DO NOT SCALE DRAWING
SCALE: 1:1
K4
ENG APPR.
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
<INSERT COMPANY NAME HERE>. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
<INSERT COMPANY NAME HERE> IS
PROHIBITED.
ERRORE:EngineeringApproval
ERRORE:CheckedBy
COMMENTS:
ERRORE:ManufacturingApproval
DRAWN
ERRORE:CheckedDate
ERRORE:DrawnDate
ERRORE:EngAppDate
MFG APPR.
SHEET 1 OF 1
2 1
A
B
A
B
12
<COMPANY NAME>
BATTERY + - = battery recharge terminals
L1 - L2 = ATS2 phone line terminal outs (carrier out)
T1 - T2 = terminals for internal local telephones (home telephones user)
AC = main power by transformer 18Vac (available 25VA - 30VA)
Z1-Z2-Z3-Z4 = zones
COM = negative reference for zones
PC = adpater socket for programming pc software
AP = Tamper line with negative reference
LOADS (+ -) = power supply AUX 13.8 Vcc for external device (eg. sirens)
A B = (RS 485) = bus terminals for peripheral connection (see chapter fo bus connection)
ALARM (nc - no - com) = terminal for siren, free relay contact
OUT1 = PGM programmable open-collector output 100mA max current
EXP = socket for plug modules (XGSM, GPRS, IP boards)
TAMPER connector = for mechanical antiopening tamper (option)
Led on board:
HOOK LED = red color led is in ON when panel take PSTN line (PSTN HOOK on)
PSTN STATUS LED:
- STEADY YELLOW: phone line in standby stautus (no problems)
- FLASHING YELLOW : PSTN calling status
K4 TERMINALS
JP1 AND JP2 JUMPER ON BOARD
These jumpers must remain open
Are used for updating the firmware and total reset of the parameters. The guide for these is in the tool for upgrade FW panel.

20
www.amcelettronica.com KX series v.1.70
K8 - K8PLUS
ERRORE:MfgAppDate
UNLESS OTHERWISE SPECIFIED:
CHECKED
SIZE
APPLICATION
TITLE:
PROPRIETARY AND CONFIDENTIAL
INTERPRET GEOMETRIC
TOLERANCING PER:
Q.A.
ERRORE:DrawnBy
ERRORE:QAApproval
FINISH
ERRORE:QAAppDate
ERRORE:COMPANYNAME
DWG. NO.
DATE
USED ON
A
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
ANGULAR: MACH
BEND
TWO PLACE DECIMAL
THREE PLACE DECIMAL
ERRORE:Revision
NEXT ASSY
MATERIAL
NAME
REV
DO NOT SCALE DRAWING
SCALE: 1:2
K8
ENG APPR.
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
<INSERT COMPANY NAME HERE>. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
<INSERT COMPANY NAME HERE> IS
PROHIBITED.
ERRORE:EngineeringApproval
ERRORE:CheckedBy
COMMENTS:
ERRORE:ManufacturingApproval
DRAWN
ERRORE:CheckedDate
ERRORE:DrawnDate
ERRORE:EngAppDate
MFG APPR.
SHEET 1 OF 1
2 1
A
B
A
B
12
<COMPANY NAME>
BATTERY + - = battery recharge terminals
L1 - L2 = ATS2 phone line terminal outs (carrier out)
T1 - T2 = terminals for internal local telephones (home telephones user)
AC = main power by transformer 18Vac (available 25VA - 30VA)
Z1-Z2-Z3-Z4-Z5-Z6-Z7-Z8 = zones
COM = negative reference for zones
PC = adpater socket for programming pc software
AP = Tamper line with negative reference
LOADS (+ -) = power supply AUX 13.8 Vcc for external device (eg. sirens)
A B = (RS 485) = bus terminals for peripheral connection (see chapter fo bus connection)
ALARM (nc - no - com) = terminal for siren, free relay contact
OUT1 = PGM programmable open-collector output 100mA max current
0UT2 = Free conatct relay programmable output (30Vcc - 2A max)
EXP = socket for plug modules (XGSM, GPRS, IP boards)
TAMPER connector = for mechanical antiopening tamper (option)
Led on board:
HOOK LED = red color led is in ON when panel take PSTN line (PSTN HOOK on)
PSTN STATUS LED:
- STEADY YELLOW: phone line in standby stautus (no problems)
- FLASHING YELLOW : PSTN calling status
K8 - K8 PLUS TERMINALS
JP1 AND JP2 JUMPER ON BOARD
These jumpers must remain open
Are used for updating the firmware and total reset of the parameters. The guide for these is in the tool for upgrade FW panel.
Table of contents
Other AMC Controllers manuals
Popular Controllers manuals by other brands

Anaheim Automation
Anaheim Automation BSCKB1-120081 user guide

EMC
EMC 880 user manual

Eaton
Eaton CJAU-01/04 Series Instruction leaflet

Store It Cold
Store It Cold CoolBot PRO quick start guide

Siemens
Siemens SIRIUS 3RT203 S Series Original operating instructions

KSB
KSB DYNACTAIR 200 Installation Manintenance
