AMEC Cypho-150 User manual

I
General Information Manual Edition 1.04
i. Copyright
The entire contents of this instruction manual, including any future
updates, revisions, and modifications, shall remain the property of
AMEC at all times. Unauthorized copies or reproduction of this
manual, either in part or whole, in any form of print and electronic
media, is prohibited. The contents herein can only be used for the
intended purpose of this manual.
ii. Disclaimer
AMEC is devoted to publish and maintain this product manual. As
we continue to improve our AIS products to satisfy all customers’
needs, information in this document is subject to change without
notice. AMEC does not make any representations or warranties
(implied or otherwise) regarding the accuracy and completeness of
this document and shall in no event be liable for any loss of profit or
any commercial damage, including but not limited to special,
incidental, consequential, or other damage.

II
iii. Safety Warning
It is important to know that AIS is designed for the
purpose of anti-collision and serves as a
complement to navigation. It is not the absolute
navigational equipment and does not replace any
navigational system installed on board.
Any AIS device cannot guarantee monitoring and
receiving signals from all vessels in the surroundings
unless those vessels are equipped with AIS devices.
ELECTRICAL SHOCK HAZARD
Improper disassemble or modification could cause
electrical shocks, fire, or personal injury.
Only qualified personnel could work on the interior
of the equipment.
MAKE SURE THE POWER SOURCE AND THE POWER
INPUT ARE MATCH
Incorrect power sources will damage the equipment
and may even result in fire.
Please ensure the correct power input on the
adaptor before installation.

III
AVOID DIRECT CONTACT WITH RAIN OR SPLASHING
WATER
Electrical shock or fire could be resulted if water
leaks into the equipment.
NOTE/INFORMATION
Important notices and information will be noted in
this Installation and Operation Manual
iv. Product Category
This product is categorized as “protected” in accordance with the
requirements as defined in IEC 60945.
v. Declaration of Conformity
Hereby, Alltek Marine Electronics Corp declares that this CYPHO-150
series is in compliance with the essential requirements and other
relevant provisions of R&TTE Directive 99/5/EC.

IV
vi. Disposal Instruction
Do not dispose of this device with unsorted waste.
Improper disposal may be harmful to the environment and human
health. Please refer to your local waste authority for information on
return and collection systems in your area.
vii. Contact Information
For sales, services, and technical supports, please contact your local
AMEC representatives or Alltek Marine Electronics Corp at
[email protected] or [e-mail]

i
Table of Content
1INTRODUCTION 1
1.1 CYPHO-150 Overview........................................................ 1
1.2 Comparison of CYPHO-150 Series..................................... 3
1.3 Type of AIS ........................................................................ 4
1.4 AIS Message Type.............................................................. 5
1.5 About This Manual............................................................ 7
1.6 Important Notice............................................................... 8
2GETTING STARTED 9
2.1 Items in the Package ......................................................... 9
2.2 Power ON / OFF .............................................................. 11
2.3 CYPHO-150 LED Indicators .............................................. 12
2.4 CYPHO-150S LED Indicators ............................................ 14
2.5CYPHO-150WS LED Indicators......................................... 16
3INSTALLATION 18
3.1 CYPHO-150 Connection Interface ................................... 18
3.2 CYPHO-150 S Connection Interface ................................ 19
3.3 CYPHO-150 WS Connection Interface ............................. 20
3.4 Installation Precautions................................................... 21
3.5 Mounting Instructions .................................................... 21
3.6 Wiring Instructions.......................................................... 24
3.7 VHF Antenna Installation ................................................ 25
3.8 Wi-Fi Antenna Installation (CYPHO-150WS model only) 27
3.9 Antenna Cabling.............................................................. 28
3.10 USB Driver Installation .................................................... 29
3.11 CYPHO Configuration Software....................................... 31

ii
3.11.1 Software Installation ....................................... 31
3.11.2 Configuration .................................................. 35
3.11.3 Diagnosis ......................................................... 39
3.12 NMEA 0183 Multiplexer.................................................. 43
3.13 AMEC AIS Viewer Software Installation .......................... 45
4APPENDIX 46
4.1 Product Specifications..................................................... 46
4.2 Dimensions ..................................................................... 49
4.3 Accessories (Optional) .................................................... 50
4.4 NMEA 2000 PGN Information (150WS Model only) ....... 51
5AMEC WORLDWIDE WARRANTY ...........................................53
6FCC INTERFERENCE STATEMENT ............................................55
7DECLARATION OF CONFORMITY ............................................56
8ACRONYMS 57

1
1INTRODUCTION
1.1 CYPHO-150 Overview
The AMEC CYPHO-150X (any CYPHO-150 model) is an AIS receiver. It
receives AIS navigation data from AIS-equipped vessels nearby and
improves navigation safety. CYPHO-150X is designed to inter-operate
with AIS Class A or Class B transponders, and any other AIS station
operating on the AIS VHF data link.
CYPHO-150X is built with two parallel AIS receivers in one box
monitoring the default marine VHF AIS channels, i.e. 161.975 and
162.025 MHz with optimized sensitivity. Having CYPHO-150X AIS
receiver on board, not only can you monitor the status of the vessels
in the surrounding area, but also receive the dynamic information
(position, speed, SOG, etc.), static information (ship name, MMSI, call
sign, etc.), and voyage related information (cargo type, destination,
etc.) from any vessels nearby that are equipped with AIS
transponders.

2
Equipped with standard USB and NMEA0183, CYPHO-150X allows
connectivities to most available peripherals in the market. Through
USB, users are able to view AIS information on their preferred PC
based navigation systems.
CYPHO-150X is IPX2 water resistant providing acceptable protection
against water. Complying with latest international standards,
CYPHO-150X is your best choice to ensure a safe journey with fun!
Figure 1 CYPHO-150

3
1.2 Comparison of CYPHO-150 Series
Comparison of CYPHO-150, CYPHO-150S, and CYPHO-150WS.
Description
CYPHO-150
CYPHO-150S
CYPHO-150WS
Number of
AIS Channels
2
2
2
USB port
1
1
1
NMEA 0183
Independent
1 input,
1 output
Independent
1 input,
1 output
Independent
1 input,
1 output
Built-in AIS
splitter
Yes
Yes
NMEA 2000
Yes
Wi-Fi
Yes

4
1.3 Type of AIS
Different types of AIS devices are described below. The CYPHO-150X
is an AIS receiver.
Class A AIS
Transponder
‧Transmits and receives AIS signal.
‧Intended for vessels meeting the requirements
of IMO AIS carriage requirement.
‧It is mandatory for all commercial vessels that
exceed 300 tons to be equipped with Class A AIS.
Class B AIS
Transponder
‧Transmits and receives AIS signal.
‧Not necessarily in full accord with IMO AIS
carriage requirements.
‧It is not mandatory for vessels to be equipped
with Class B AIS.
‧Suitable for recreational vessel, in enhancing its
safety at sea.
AIS Receiver
‧Only receives AIS signal.
‧Does not have transmitter to send out AIS signal.
‧Suitable for recreational vessel that does not
want to send out its vessel information.

5
1.4 AIS Message Type
The CYPHO-150X can receive AIS messages from both Class A and
Class B AIS transponders as well as from AIS Base Station, AIS AtoN,
and AIS SART/MOB. The message types are listed as below table. The
messages in gray color are transmitted only from class A AIS device.
Type of Message
Data Details
Static Data
Maritime Mobile Service Identity (hereinafter
called “MMSI”) number
IMO number
Call sign and name
Type of ship
Length and beam
GPS Antenna location
Voyage Related
Data
Draught of the ship
Cargo information
Destination
Estimate Time of Arrival (hereinafter called
“ETA”)

6
Dynamic Data
Position of the vessel
Coordinated Universal Time (hereinafter called
“Time in UTC”.)
Course Over Ground (hereinafter called “COG”)
Speed Over Ground (hereinafter called “SOG”)
Heading
Rate of turn
Navigational status
Dynamic Reports
Speed of the ship
Status of the ship
SRM
Alarm
Safety

7
1.5 About This Manual
The manual contains installation instructions and operating
information for different CYPHO-150 models. While most of the
installation can be performed by the owner or the crew, a final
commissioning can be done by your local agent/dealer when needed
or required. AMEC and the local agent/dealer will not bear any
responsibilities over any damages resulted in improper installation by
unauthorized agent/dealer.

8
1.6 Important Notice
The intended use of the AMEC CYPHO-150 Series Automatic
Identification System Receiver is to enhance the safety of vessels at
sea. However, a few points must be addressed:
Under certain regulations, some specified vessels are
compulsory to be installed with AIS. However, this does NOT
mean that all vessels will be equipped with AI. Any AIS will NOT
guarantee to monitor and to receive signals from every ship in
the surroundings.
AIS acts as aids to navigation in the purpose of decreasing or
preventing the possibility of vessel collision. It is not the
absolute navigational equipment and does not replace any
navigational system installed on board.
This product is a marine AIS receiver intended for worldwide
use on NON SOLAS vessels.

9
2GETTING STARTED
2.1 Items in the Package
Please contact your supplier immediately if there is any item missing.
No.
Diagram
Description
Qty
1
150
CYPHO-150X
AIS Receiver
1
150S
150WS

10
2
Power/USB/
NMEA0183 Cable, 1m
(Wired to the unit)
1
3
User’s Manual
1
4
CD-ROM
(User’s manual in
digital format,
Configuration Utility,
USB driver )
1
5
Mounting screws 4
M3.5x25
4
6
150WS only
Wi-Fi antenna
1
7
150S, 150WS only
VHF cable, 1m
(with PL-259 male
connectors)
1

11
2.2 Power ON / OFF
All CYPHO-150 models are designed having no physical On/Off switch.
Thus, the vessel’s operation determines the unit’s power status.
If PC could not recognize USB connection after a
power restart on CYPHO-150, please re-plug the USB
connector.

12
2.3 CYPHO-150 LED Indicators
Figure 2 CYPHO-150 LED Indicators
Power
Error
AIS Rx

13
LED INDICATIONS
Indicator
Indication
Description
Power
Normal Steady Green
Device in normal operation
Error
Flashing Red
Error is detected by the
onboard system
AIS Rx
Flashing Green
Receiving of AIS message in
either AIS Channel 1 or
Channel 2
