AMEC NK-80 User manual

Alltek Marine Electronics Corp.
www.alltekmarine.com
NMEA 2000 Adaptor
NK-80
- Quick Start Guide -

NK-80 NMEA 2000 Adaptor Quick Start Guide
1
1. Installation Precautions
1. Installation should proceed in a safe environment and should not
have direct contact with rain or splashing water.
2. Do not place or install the equipment beneath or near any container
that filled with water or liquid.
3. Do not place or install the equipment where it is easily tripped,
stepped on, or kicked at.
4. Do not place or install the equipment near any generator or engine.
2. Installation Procedures
Step 1: Ensure all items are in the package
Description
Qty
AMEC NK-80 NMEA 2000
adaptor
1
Screw M4
4
Manual
1
CD
1

NK-80 NMEA 2000 Adaptor Quick Start Guide
2
Step 2: Use 4 screws to mount NK-80 in a flat surface between NMEA
0183 device and T-connector.
Step 3: Connect NK-80 Micro-C male port to T-connector Micro-C
female port. If the provided cable length 0.1M is not enough,
use an extension cable with proper length for connection.
T-connecto
r
NK-80
NMEA 0183
device
NMEA 2000
Network
Micro-C female
port
Micro-C male
port
NMEA
2000
Network
NMEA
2000
Network

NK-80 NMEA 2000 Adaptor Quick Start Guide
3
Step 3: Ensure NK-80 NMEA 0183 wiring information
Step 4: Connect NK-80 NMEA 0183 cable to NMEA 0183 device with
proper wiring.
NOTE: Please ensure the external device is fully NMEA 0183
compliant.
Step 5: Verify the 2 onboard LED indicators. If they start flashing in blue
and green color, the device is operating normally. If not, please
verify connection again or check manual for explanation.
NOTE:
LED 1 indicates receiving NMEA
2000 messages with blue flash
light. LED 2 indicates receiving
NMEA 0183 messages with
green flash light.
NK-80 NMEA 0183 wiring information
Pin
Wire color
Name
Function
1
RED
TXP
Positive(＋); NMEA 0183 Data output
2
GREEN
TXN
Negative (－); NMEA 0183 Data output
3
BLACK
RXP
Positive(＋); NMEA 0183 Data input
4
BLUE
RXN
Negative (－); NMEA 0183 Data input
5
SHIELD
GND
Ground
LED 2
LED 1
TXP
TXN
RXP
RXN
RXP
RXN
TXP
TXN
NK-80 NMEA 0183
External NMEA 0183/RS-422
device
