American Standard ACRYLUX 6030Y1.102 Operating and safety instructions

H123
© 2008 AS America Inc.




❑ 
❑ 

• High-gloss acrylic-capped ABS with
berglass reinforcement
• Integral apron
• Integral three-sided, tiling/water
retention ange
• Integral lumbar support
• Pre-leveled tub bottom
❑ 
❑ 

• 1.25 hp, single-speed pump motor
• 6 whirlpool jets
– 4 adjustable jets
– 2 mini-jets in the lumbar area
• Deck mounted air on/off switch
• Removable access panel

59-7/8" x 30" x 15"
(1521 x 762 x 381mm)

• 6030Y1.BW Bath Wall Set
• 6030Y1.BWT Bath Tile Wall Set
• Tub can also be installed without Acrylux
wall set


• UL 1795 for Hydromassage Bathtubs
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
6030Y1.102
6030Y1.218
Revised 5/08

H124
© 2008 AS America Inc.
GENERAL SPECIFICATIONS FOR 6030Y1 BATHING POOL
60 x 30 x 15 In. (1524 x 762 x 381mm)
51 Lbs. (23 Kg.)
384 Lbs. (174 Kg.)
40 Gal. (151 L)
46 In. L (1168mm L)
53 In. L (1346mm L)
11 in (279mm L)
31 Lbs./Sq.Ft. (150 Kgs./Sq.m)
7.3
18.91ft3
INSTALLED SIZE
WEIGHT
WEIGHT w/WATER
GAL. TO OVERFLOW
BATHING WELL AT SUMP
BATHING WELL AT RIM
WATER DEPTH TO OVERFLOW
FLOOR LOADING
(PROJECTED AREA)
PTS.
CUBE (FT3)
GENERAL SPECIFICATIONS FOR 6030Y1 WHIRLPOOL
60 x 30 x 15 In. (1524 x 762 x 381mm)
73 Lbs. (33 Kg.)
415 Lbs. (188 Kg.)
41 Gal. (155 L)
29 Gal. (110 L)
46 In. L (1168mm L)
53 In. L (1346mm L)
11 in (279mm L)
33 Lbs./Sq.Ft. (162 Kgs./Sq.m)
7.3
18.91ft3
1.25 HP, 9.7 AMPS ,120V.WHIRLPOOL PUMP
WHIRLPOOL ELECTRICAL SPECIFICATIONS
INSTALLED SIZE
WEIGHT
WEIGHT w/WATER
GAL. TO OVERFLOW
WHIRLPOOL MIN. OPERATING VOL.
BATHING WELL AT SUMP
BATHING WELL AT RIM
WATER DEPTH TO OVERFLOW
FLOOR LOADING
(PROJECTED AREA)
PTS.
CUBE (FT3)

BATH CAN BE INSTALLED EITHER ABOVE OR BELOW FLOOR LINE AS PIER, ISLAND OR PENINSULA TYPE INSTALLATION. SUMP
OF BATH IS SUPPORTED BY INTEGRAL FEET. NO ADDITIONAL SUPPORT REQUIRED. ENCLOSING MATERIALS BY OTHERS.
■ REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH WHIRLPOOL FOR ADDITIONAL INFORMATION.
● FITTINGS NOT INCLUDED AND MUST BE ORDERED SEPARATELY.
PROVIDE SUITABLE REINFORCEMENT FOR ALL SUPPORTS.
● IF INSTALLING A DECK-MOUNTED FITTING, BEFORE DRILLING ANY HOLES: CHECK FOR INTERFERENCE WITH CIRCULATING
SYSTEM PIPING AND DRAIN OVERFLOW. MOUNTING HOLES DRILLED BY INSTALLER.
 Dimensions of xtures are nominal and may vary within the range of tolerances established by ANSI Standard Z124.1.
These measurements are subject to change or cancellation. No responsibility is assumed for use of superseded or voided leaet.
10"
STUD LAYOUT
59-7/8"
(1521mm)
31-1/2"
(800mm)
60"
(800mm)
(254mm)
10"
6" (154mm)
14" (355mm)
8"
(203mm)
Drain C
Floor Cut Out
6"x 10"(154 x 254mm)
= Stud Location
L
30"
(762mm)
15"
(381mm)
Revised 5/08
