H69
© 2008 AS America Inc.
SCALA CORNER™
WHIRLPOOL AND BATHING POOL
HIGH GLOSS
Revised 2/08
SCALA CORNER™ WHIRLPOOL AND
BATHING POOL
❏ 2664.218C Whirlpool featuring System I,
Left-hand drain outlet
❏ 2664.118C Whirlpool featuring System I,
Right-hand drain outlet
• Acrylic with berglass reinforcement
• EverClean® System
• Pre-leveled tub bottom
• Integral 2-sided tile/water retention ange
• Dual, molded lumbar back rests
• 1.25 HP single speed, self-draining pump/motor
• Factory installed power cord with plug
• Six multi-directional and ow-adjustable jets
• Deck-mounted air switch On/Off
• Two air volume controls
• Factory installed and tested whirlpool system
❏ 2664.218 Whirlpool, Left-hand Drain Outlet
❏ 2664.118 Whirlpool, Right-hand Drain Outlet
• Same as above except without the EverClean®
System
❏ 2664.202 Bathing Pool only, Left-hand
Drain Outlet
❏ 2664.102 Bathing Pool only, Right-hand
Drain Outlet
Nominal Dimensions:
1524 x 1524 x 502mm
(60" x 60" x 19-3/4")
Compliance Certications -
Meets or Exceeds the Following Specications:
• Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
American Standard whirlpools with EverClean®
incorporate a patented silver-ion additive right
into the circulation piping to protect the pipes
from mold, mildew, algae and fungus that could
cause deterioration or staining of the pipes.
SEE REVERSE FOR PRODUCT DIMENSIONS
AND SPECIFICATIONS
To Be Specied - Required:
❏ Color:
❏ Bath Filler: (specify nish)
❏ Bath Drain: 1583.470 (specify nish)
To Be Specied - Optional:
❏ Jet Trim Ring Kit: 9860.200-two per kit (specify nish)
for Body Massage Jets only
For color/nish availability and other faucet choices, please
see the Product Selector and Pricing Guide.

H70
© 2008 AS America Inc.
SCALA CORNER™
WHIRLPOOL AND BATHING POOL
HIGH GLOSS
Revised 2/08
552mm
(21-3/4)
140mm (5-1/2)
1080mm
(42-1/2)
1524mm
(60) TYP.
1041mm
(41)
775mm
(30-1/2)
PROVIDE ACCESS
FOR SERVICING
PUMP & CONTROLS
216mm
(8-1/2)
406mm
(16)
25mm (1)
INTEGRAL TILE
FLANGE (2) SIDES
19mm(3/4)
CUTOUT DIMENSION
1632mm
(64-1/4)
1505mm (59-1/4) TYP.
254mm X 254mm
(10 X 10) DRAIN
OUTLET CUTOUT
1600mm
(63-1/2)
1356mm
(53-3/8)
OF DRAIN OUTLET
C
L
ROUGH
FLOOR
502mm
(19-3/4)
464mm
18-1/4
38mm
(1-1/2)
13mm (1/2)
INTEGRAL
TILE FLANGE
1-1/2" O.D. TAILPIECE
INTEGRAL
FEET
SUPPORT
LEVELING
STRINGER
(NOT FOR
SUPPORT)
1-1/2" N.P.T.M. THREADS
60mm
(2-3/8)
124mm
4-7/8
95mm
(3-3/4)
724mm (28-1/2)
ON/OFF
SWITCH
RECOMMENDED FITTING LOCATION
64 X 279mm (2-1/2 X 11)
1041mm
(41)
775mm
(30-1/2)
552mm
(21-3/4)
140mm (5-1/2)
1080mm
(42-1/2)
1524mm
(60) TYP.
216mm
(8-1/2)
406mm
(16)
25mm (1)
INTEGRAL TILE
FLANGE (2) SIDES
19mm(3/4)
CUTOUT DIMENSION
1632mm
(64-1/4)
1505mm(59-1/4) TYP.
254mm X 254mm
(10 X 10) DRAIN
OUTLET CUTOUT
1600mm
(63-1/2)
1356mm
(53-3/8)
OF DRAIN OUTLET
C
L
ROUGH
FLOOR
502mm
(19-3/4)
464mm
18-1/4
38mm
(1-1/2)
13mm (1/2) INTEGRAL
TILE FLANGE
1-1/2" O.D. TAILPIECE
INTEGRAL
FEET
SUPPORT
LEVELING
STRINGER
(NOT FOR
SUPPORT)
1-1/2" N.P.T.M. THREADS
60mm
(2-3/8)
124mm
4-7/8
95mm
(3-3/4)
724mm(28-1/2)
RECOMMENDED FITTING LOCATION
64 X 279mm (2-1/2 X 11)
60 x 60 x 19-3/4 In. (1524 x 1524 x 502mm)
114 Lbs. ( 51 Kg.)
781 Lbs. (351 Kg.)
80 Gal. (303 L)
58 Gal. (220 L)
42 x 28 In. (1067 x 711mm)
60 x 40 In. (1524 x 1016mm)
14 In. (356mm)
37 Lbs./Sq.Ft. (182 Kgs./Sq.m)
41.7
68.5
GENERAL SPECIFICATIONS FOR 2664 WHIRLPOOL
1.25 HP, 9.9 AMPS,120V.
WHIRLPOOL ELECTRICAL SPECIFICATIONS
SYSTEM I PUMP
INSTALLED SIZE
WEIGHT
WEIGHT w/WATER
GAL. TO OVERFLOW
WHIRLPOOL MIN. OPERATING VOL.
BATHING WELL AT SUMP
BATHING WELL AT RIM
WATER DEPTH TO OVERFLOW
FLOOR LOADING
(PROJECTED AREA)
PTS.
CUBE (FT3)
60 x 60 x 19-3/4 In.
(1524 x 1524 x 502mm)
94 Lbs. (42 Kg.)
761 Lbs. (342 Kg.)
80 Gal. (303 L)
42 x 28 In. (1067 x 711mm)
60 x 40 In. (1524 x 1016mm)
14 In. (356mm)
36 Lbs./Sq.Ft. (177 Kgs./Sq.m)
41.7
68.5
GENERAL SPECIFICATIONS FOR 2664 BATHING POOL
INSTALLED SIZE
WEIGHT
WEIGHT w/WATER
GAL. TO OVERFLOW
BATHING WELL AT SUMP
BATHING WELL AT RIM
WATER DEPTH TO OVERFLOW
FLOOR LOADING
(PROJECTED AREA)
PTS.
CUBE (FT3)
NOTES:
BATH CAN BE INSTALLED EITHER ABOVE OR BELOW FLOOR LINE AS PIER, ISLAND, OR PENINSULA TYPE INSTALLATION. SUMP OF
BATH IS SUPPORTED BY INTEGRAL FEET. NO ADDITIONAL SUPPORT REQUIRED. ENCLOSING MATERIAL BY OTHERS.
■ REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH WHIRLPOOL FOR ADDITIONAL INFORMATION.
CONCEALED PIPING NOT INCLUDED.
FITTINGS NOT INCLUDED AND MUST BE ORDERED SEPARATELY.
● IF INSTALLING A DECK-MOUNTED FITTING, BEFORE DRILLING ANY HOLES: CHECK FOR INTERFERENCE WITH CIRCULATING
SYSTEM PIPING, DRAIN OVERFLOW, AND APRON INSTALLATION. MOUNTING HOLES DRILLED BY INSTALLER.
PROVIDE SUITABLE REINFORCEMENT FOR ALL SUPPORTS.
IMPORTANT: Dimensions of xtures are nominal and may vary within the range of tolerances established by ANSI Standard Z124.1. These
measurements are subject to change or cancellation. No responsibility is assumed for use of superseded or voided pages.
