American Standard Cadet w/ Integral Apron Whirlpool and Bathing Pool... User manual

H65
© 2008 AS America Inc.
CADET™ 5' x 32" w/INTEGRAL APRON
WHIRLPOOL AND BATHING POOL
HIGH GLOSS
Revised 2/08
CADET™ 5' x 32" with INTEGRAL APRON
WHIRLPOOL AND BATHING POOL
❏ 2776.218W Whirlpool featuring System I,
Left Hand Outlet
❏ 2776.118W Whirlpool featuring System I,
Right Hand Outlet
Product Features:
• Acrylic with berglass reinforcement
• Integral apron with removable access panel
• Integral 3-sided tile/water retention ange
• Form-tted back rest
• Dual, molded in arm rests
• 1.25 HP single speed, self-draining pump/motor
• Factory installed power cord with plug
• Eight multi-directional and ow-adjustable
jets including:
- Two foot jets
- Four body massage jets
- Two recessed back-rest jets
• Deck-mounted air switch On/Off
• Two silent air volume controls
• Factory installed and tested whirlpool system
EverClean® Whirlpool Massage featuring System I
❏ 2776.218WC Whirlpool featuring System I,
Left Hand Outlet
❏ 2776.118WC Whirlpool featuring System I,
Right Hand Outlet
• Same as above except with the EverClean®
System
❏ 2776.102 Bathing Pool, Right Hand Outlet
❏ 2776.202 Bathing Pool, Left Hand Outlet
Nominal Dimensions:
1521 x 813 x 508mm
(59-7/8" x 32" x 20")
American Standard whirlpools and air baths with
EverClean® incorporate a patented silver-ion
additive right into the circulation piping to protect
the pipes from mold, mildew, algae and fungus that
could cause deterioration or staining of the pipes.
To Be Specied - Required:
❏ Color:
❏ Bath Filler: (specify nish)
❏ Bath Drain: 1583.470 (specify nish)
To Be Specied - Optional:
❏ Bath Caddie: 9533.100 (in Chrome only)
❏ Jet Trim Ring Kit: 9860.200-two per kit (specify nish)
For color/nish availability and other faucet choices, please
see the Product Selector and Pricing Guide.
Compliance Certications -
Meets or Exceeds the Following Specications:
• Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
SEE REVERSE FOR PRODUCT DIMENSIONS
AND SPECIFICATIONS

H66
© 2008 AS America Inc.
CADET™ 5' x 32" w/INTEGRAL APRON
WHIRLPOOL AND BATHING POOL
HIGH GLOSS
Revised 2/08
19-3/4
(502mm)
7/8 WATER
RETENTION
FLANGE
(3 SIDES)
20
(508mm)
1-1/2 O.D.TAILPIECE
BATH
SUPPORT
MATERIAL
ROUGH
FLOOR
FINISHED
WALL
TOP OF
DECK
59-7/8
(1521mm)
32
(813mm)
WATER
RETENTION
FLANGE
(3 SIDES)
7-3/4
(197mm)
12
(305mm)
2-3/8
(60mm) (8) JETS
2-3/4
(70mm)
CUTOUT IN FLOOR
FOR DRAIN
PUMP
FINISHED
WALL
OPTIONAL TO
FINISHED FLOOR
USUALLY BETWEEN
65 & 78
(1651 & 1981mm)
C/L OF
OVERFLOW
C/L OF
SPOUT
C/L OF
VALVES
C/L OF
SHOWER ARM
2-3/4
(70mm) 4-5/8
(117mm)
1-1/2 N.P.T.M.
THREADS
3/4
(19mm)
9
(229 mm)
C/L OF
SUPPLIES
C/L OF DRAIN
SEE FITTING
SPECS FOR
DIMENSIONS
(2) AIR VALVES
ON/OFF
SWITCH
ACCESS TO PUMP/MOTOR
THROUGH REMOVABLE
FRONT ACCESS PANEL
UNDERSIDE
OF DECK
14-3/4
(375mm)
LEVELING
STRINGER
NOT FOR
SUPPORT
TILING
FLANGE
12
(305mm)
OPT. 4
(102mm)
14-3/4
(375mm)
WATER
RETENTION
FLANGE
(3 SIDES)
UNDERSIDE
OF DECK
19-3/4
(502mm)
7/8 WATER
RETENTION
FLANGE
(3 SIDES)
20
(508mm)
1-1/2 O.D.TAILPIECE
BATH
SUPPORT
MATERIAL
LEVELING STRINGER
NOT FOR SUPPORT
ROUGH
FLOOR
TOP OF
DECK
59-7/8
(1521mm)
32
(813mm)
7-3/4
(197mm)
12
(305mm)
2-3/8
(60mm)
2-3/4
(70mm)
CUTOUT IN FLOOR
FOR DRAIN
FINISHED
WALL
12
(305mm) OPT.
OPTIONAL TO
FINISHED FLOOR
USUALLY BETWEEN
65 & 78
(1651 & 1981mm)
C/L OF
OVERFLOW
4
(102 mm)
C/L OF
SPOUT
C/L OF
VALVES
C/L OF
SHOWER ARM
2-3/4
(70mm) 4-5/8
(117mm)
1-1/2 N.P.T.M.
THREADS
3/4
(19mm)
9
(229 mm)
C/L OF
SUPPLIES
C/L OF DRAIN
SEE FITTING
SPECS FOR
DIMENSIONS
FINISHED
WALL
SYSTEM I PUMP
GENERAL SPECIFICATIONS FOR 2776 WHIRLPOOL
WHIRLPOOL ELECTRICAL SPECIFICATIONS
1.25 HP, 9.9 AMPS,120V.
59-7/8 x 32 x 20 (1521 x 813 x 508mm)
115 Lbs. (52 Kg.)
574 Lbs. (258 Kg.)
55 Gal. (208 L.)
45 Gal. (171 L.)
20 x 40 (508 x 1016mm)
26 x 53-1/2 (660 x 1359mm)
14-1/2 (368mm)
43 Lbs./Sq.Ft. (208 Kgs./Sq.m)
20.8
35.3
INSTALLED SIZE
WEIGHT
WEIGHT w/WATER
GAL. TO OVERFLOW
WHIRLPOOL MIN. OPERATING VOL.
BATHING WELL AT SUMP
BATHING WELL AT RIM
WATER DEPTH TO OVERFLOW
FLOOR LOADING
(PROJECTED AREA)
PTS.
CUBE (FT3)
GENERAL SPECIFICATIONS FOR 2776 BATHING POOL
59-7/8 x 32 x 20 (1521 x 813 x 508mm)
75 Lbs. (34 Kg.)
525 Lbs. (236 Kg.)
54 Gal. (205 L.)
20 x 40 (508 x 1016mm)
26 x 53-1/2 (660 x 1359mm)
14-1/2 (368mm)
39 Lbs./Sq.Ft. (191 Kgs./Sq.m)
20.8
35.3
INSTALLED SIZE
WEIGHT
WEIGHT w/WATER
GAL. TO OVERFLOW
BATHING WELL AT SUMP
BATHING WELL AT RIM
WATER DEPTH TO OVERFLOW
FLOOR LOADING
(PROJECTED AREA)
PTS.
CUBE (FT3)
NOTES:
BATH TO BE INSTALLED ABOVE FLOOR LINE AS A RECESS INSTALLATION. SUPPORT OF BATH BY SUMP BEDDING. SUPPORT AND
ENCLOSING MATERIAL BY OTHERS.
■ REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH WHIRLPOOL FOR ADDITIONAL INFORMATION.
LEFT HAND OUTLET SHOWN, RIGHT HAND REVERSE DIMENSIONS (2776.118).
FITTINGS NOT INCLUDED AND MUST BE ORDERED SEPARATELY.
PROVIDE SUITABLE REINFORCEMENT FOR ALL SUPPORTS.
IMPORTANT: Dimensions of xtures are nominal and may vary within the range of tolerances established by ANSI Standards Z124.1 and
A112.19.7. These measurements are subject to change or cancellation. No responsibility is assumed for use of superseded or voided pages.
