American Standard LIBERATION User manual

1
OWNER’S
MANUAL

2
Congratulations!
You are now the owner of a walk-in bath from the
most trusted name in plumbing.
We know you have a choice in which walk-in bath
you have in your home and want to welcome you
to the Liberation by American Standard family.
We feel honored that you have chosen Liberation
by American Standard to supply and install your
walk-in bath. We specialize in providing the safest
bathing experience without sacrificing luxury.
Your satisfaction is our guarantee.
Should you have any questions regarding your
walk-in bath, please do not hesitate to contact
our customer support center at
855.225.2183
Thank you for your purchase. Your Liberation
by American Standard walk-in bath is a true
investment in your health and peace of mind.

3
Table of Contents
Liberation Walk-In Bath 4
Control Panel Functions 6
Open & Close Walk-In Bath Door 7
Quick Drain® 8
Self Cleaning Sanitary System 9
RevitaJet™ Whole Body Hydrotherapy 10
Chromatherapy 14
Aromatherapy 15
Important Safety Instructions 16
Cleaning and Maintenance 18
Exclusive Limited Lifetime Warranty 19
Trouble Shooting 20

4
Liberation
Walk-In Bath
1
2
5
4
9
15
7
14
6
12
17
19
8
3
20
16
10
11
18
13

5
Liberation
Walk-In Bath
Construction
1. 100% Premium Cast Acrylic Material
2. Freestanding Metal Support
3. Patented, Leak Proof Door System
4. Quick Drain® Fast Water Removal System
5. Premium Faucet with Hand Shower
6. Textured Bath Floor
7. Low Threshold
8. 17” Chair Height Seat
9. Built-In Chrome Grab Bar
10. Easy Access Panel
RevitaJet™ Whole Body Hydrotherapy
Other Innovative Features
11. Deluxe Upper Body Massage
12. Ultimate Leg Therapy
13. Legs-Only Therapy Diverter
14. Ultra Foot Massage
15. Wrist and Hand Massage
16. Variable Speed Heater Blower and Whirlpool Pump
17. Chromatherapy Lights - Including Integrated Lights
in 6 Water Jets
18. Aromatherapy
19. In-line Heater
20. Self-Cleaning Sanitary System

6
Control Panel
Functions
Lights: There are 7 light
options that are available with
the Liberation walk-in bath.
Push the button to select the
desired color. The last setting
will scroll through each color
automatically.
Drain: If your walk-in bath is
equipped with the Quick Drain®,
open the traditional drain
system (turn the overflow) and
then press the Drain button to
activate the drain. When the
water falls below the suction
guard, press the button again
to turn off. The Quick Drain® will
automatically shut off after 3
minutes as a safety feature.
Jets: Push this button once to
activate the water jets. If the
leg valve is turned off, all of the
jets will expel water. Once the
leg valve is turned on, only the
lower jets will expel water. Push
once more to turn off.
Air: Push this button once to
activate the heated blower
at high speed. To adjust the
speed to medium or low, push
and hold the button. Push
again to turn the air jets off.
Control Panel Operation

7
Open & Close
Walk-In Bath Door
To enter your Liberation walk-in bath, reach into the inside of the bath
and pull the handle until it is vertical with the side of the bath. Push
the door open and enter carefully. To close the door securely, simply
close the door and place the lever in the down position. Do not apply
excessive pressure when placing the handle in the close position. Fill
the bath above the highest jet before activating the whirlpool pump (if
equipped). Do not put weight on the door when entering and exiting the
walk-in bath. It is recommended to leave the door in the open position
when the walk-in bath is not in use.
Close
Open
How to Open and Close the Door

8
Cable Driven Drain
Quick Drain® Operation
The Quick Drain® drains water from your tub
quickly. This patent-pending system comes
equipped with a pump, safety suction and
on/off electronic control that allows you to
activate the drain with the touch of a button.
Quick Drain® is not a standard feature on the
soaker bath.
To operate the Quick Drain®, turn the Cable
Driven Drain clockwise to open and then
press the Quick Drain® on/off switch to
activate the drain. When the water falls below
the suction guard, press the on/off switch to
turn the drain system off.
Cable Driven Drain Operation
To open and close the
Cable Driven Drain,
turn clockwise and
counterclockwise to
open and close.
Quick Drain®
On/Off Button for
Jet Model
Quick Drain® On/Off
Button for the Soaker
model
Quick Drain®
Suction Guard
is located at the
base of the seat

9
Eliminate the Maintenance
Say “good-bye” to the maintenance needed to enjoy a clean whirlpool
system. Included with jet and dual massage systems, Ozone is the most
effective cleaning system available for bathing environments today.
A study by the EPA through West Virginia University states that:
• Ozone is more effective than chlorine in destroying bacteria and
viruses.
• Ozone is pure Oxygen (O2) with an extra Oxygen atom (O3)
• Because of the extra atom, after Ozone destroys disease-causing
microorganisms, it reverts back to pure Oxygen (O2). Therefore,
it doesn’t leave any harmful residue behind.
Approved by the NSF, FDA and EPA and required in all commercial bathing
environments, this safe and effective sanitation system automatically
oxidizes and eliminates disease-causing microorganisms in the bath
when the whirlpool system is activated. Bleach is not necessary or
recommended when cleaning the walk-in bath. The Ozone Disinfection
System requires no user participation. Turn on the whirlpool system,
and ozone bubbles are automatically
injected into water.
All Ozone Generators are equipped
with a preset vacuum switch which
will not turn on if the pump is not
running with water flowing through
the whirlpool system. The Ozone
Generator includes an exclusive
High Limit Switch and will not false
trip from tap water. If your whirlpool
is equipped with adjustable jets,
or other flow control systems, the
pre-set vacuum may not activate
the generator. To assure proper
operation, all jets may need to be
fully open with the pump operating
at or near maximum flow.
Ozone Disinfection System
Self Cleaning
Sanitary System

10
RevitaJet™Whole
Body Hydrotherapy
The treatment of illness and injury through the use of water; both hot
and cold. The four most popular ailments people use hydrotherapy to
treat are: arthritis, lower back pain, insomnia and diabetes.
Arthritis
Warm water treatments help by dilating blood
vessels in the body, relieving pain and easing the
tension in muscles.
Lower Back Pain
Studies have shown that people who use
hydrotherapy experience marked reductions in
pain and use fewer pharmaceuticals to control
their pain.
Insomnia Warm baths have been shown to improve both
the ability to fall asleep and the quality of sleep.
Diabetes
In a study published by the New England Journal
of Medicine, people with Type 2 Diabetes soaked
in hot tubs for 30 minutes a day, 6 days a week.
Doctors noticed that the patients had an easier
time controlling their weight and plasma glucose
levels.
Whirlpool: Push this button once to activate the
water jets. If the legs-only valve is open, all of the
jets will operate. Once the legs-only valve is closed,
only the lower jets will operate. Push once more to
turn off.
Air System: Push this button once to activate the
heated blower at high speed. Push again to adjust
the speed to medium, low and one last time to turn
the air jets off. If you push and hold the button, the
air blower will turn on high and gradually lower in
speed.
Source: Petrofsky; Nance

11
RevitaJet™Whole
Body Hydrotherapy
44 RevitaJet™ Whole Body Hydrotherapy
28 Air Massage Jets
16 Whirlpool Jets
Includes both the Whirlpool and Air massage jets, which can be operated
independently or at the same time for the ultimate therapeutic massage.
Features advanced back, wrist/hand and leg therapy, with an innovative
legs-only massage feature to create a targeted and warm deep-tissue
massage.
Create thousands of air bubbles bouncing throughout the bath for a
relaxing champagne-like massage.

12
RevitaJet™Whole
Body Hydrotherapy
Deluxe Upper Body Massage
The Deluxe Upper Body Massage package uses targeted lumbar water
jets and massaging air jets for focused lower back relief.
Back pain is the #2 reason in the United States for doctor visits. Studies
conducted over the last ten years have shown that people who suffer from
back pain and who use hydrotherapy as a treatment experience marked
reductions in pain versus those people who do not use hydrotherapy. In
addition, people who treat their back pain with hydrotherapy use fewer
medications to control their pain.
Wrist Massage
Warm water from the side jets
focus on hands and wrists to
help sooth muscles and help
relieve tension associated with
arthritic conditions, decreasing
pain and inflammation.
Source: Petrofsky

13
RevitaJet™Whole
Body Hydrotherapy
Ultimate Leg Therapy
The Ultimate Leg Therapy package uses water and air jets to focus on
relieving pain in the lower extremities of the body.
Studies have shown that hydrotherapy helps relax tired muscles, promote
better circulation and relieve pain in the knees, legs and ankles.
4 air jets positioned on the floor of the bath focus on pain in heel spurs
and arches of the feet.
Legs-Only Massage
The legs-only massage operates with
the tub half full for quick, energizing leg
massage. The Legs-Only Massage valve
on the door side of the bath must be
closed when filling the tub half-way and
operating the whirlpool. Failure to close
the valve will result in water shooting
out of the jets above the seat when the
pump is activated. (If equipped)

14
Chromatherapy
Chromatherapy is the use of color and light that is believed to have a
positive effect on both health and mental well-being.
Light: Push this button once to turn on chromatherapy
lights. Push again to turn off. Push a third time to access
the next color and so forth. 6 colors are available in the
following order: Light Blue, Purple, Dark Blue, Yellow,
Green, Red and the 7th setting scrolls through all of the
colors.
Purple – Romance
evokes romantic and nostalgic feelings
Light Blue and Dark Blue – Calming and Relaxing
associated with depth and fulfillment; represents the night
Yellow – Happy
cheery and uplifting
Green – Restful
the color of nature and helps to feel comfortable, relaxed
and calm
Red – Energizing
suggests passion, strength and vitality

15
Aromatherapy
Stimulate your senses with the power of scent. Choose the experience
you wish to create and the corresponding bead pouch.
Air Systems: Push this button to activate the
aromatherapy beads.
Insert the bead pouch into aromatherapy
compartment on the back corner of the walk-in
bath.
Tranquility
Relax with the sweet, peaceful fragrance of
Chamomile. Chamomile is thought to calm the
spirit, promote good health and relieve stress.*
Relaxing
Sooth your senses with the sweet aroma of
Lavender. Lavender is a wonder to experience. It
has been used to assist in treating depression,
headache, insomnia and other stress related
conditions.*
Romance
Unwind and escape with the beautiful scents of
Rose, Ylang Ylang and Sage.*
Energy
Refresh and rejuvenate with the aromas of
peppermint and eucalyptus. These scents are
said to clear the head and sooth the emotions.*
* Information supplied by Balboa Water Group

16
Important Safety
Instructions
INSTRUCTIONS PERTAINING TO RISK OF
FIRE, ELECTRICAL SHOCK OR
INJURY TO PERSONS
WHEN USING THIS UNIT, BASIC PRECAUTIONS SHOULD ALWAYS BE
FOLLOWED.
• WARNING: Risk of personal injury. Use this unit for its intended
use as described in this manual. DO NOT use attachments not
recommended by the manufacturer.
• WARNING: Risk of personal injury. To avoid injury, exercise caution
when entering or exiting your walk-in bath.
• WARNING: Risk of personal injury. To reduce risk of injury, do not
permit children or persons with infirmities to use this product unless
they are closely supervised.
• WARNING: Risk of hyperthermia and possible drowning. People
using medications, herbal remedies, sleep aids and/or having adverse
medical history should consult a physician before using this product.
• WARNING: Risk of personal injury. Water temperatures over 100°F
(38°C) may be hazardous to your health. Check and adjust water
temperature for your personal comfort.
• WARNING: No food or alcoholic beverages. Use of your bathtub
immediately after meals is not recommended. Avoid alcohol
consumption before or during bathing. Alcoholic beverages can
cause drowsiness or hyperthermia resulting in loss of consciousness
or even drowning.
• WARNING: Pregnancy. If you are or think you are pregnant, consult
your doctor before using the bathtub.
• WARNING: Risk of personal injury. Risk of electrical shock; do not
permit electric appliances (such as hair dryer, lamp telephone, radio
or television) within four feet of this bathtub.
• WARNING: Risk of personal injury. Never drop or insert objects into
any openings.
• WARNING: Risk of personal injury. Do not operate this unit without
the guard over the suction fittings.

17
Important Safety
Instructions
The unit must be connected only to a supply circuit that is protected
by a ground-fault circuit-interrupter (GFCI). Such a GFCI should be
provided by the installer and should be tested on a routine basis.
To test the GFCI, push the test button. The GFCI should interrupt
power. Push the reset button. Power should be restored. If the
GFCI fails to operate in this manner, there may be a ground current
flowing, indicating the possibility of an electric shock. DO NOT
USE this massage bathtub. Disconnect the whirlpool bathtub and
have the problem corrected by a qualified service representative
before using.
To reduce risk of electrical shock, the dedicated electrical supply
circuit(s) must be grounded. To do this, connect the third leg of the
3-conductor wiring cable to the grounding terminal of the electrical
service panel and run continuously to the green ground screw on
the GFCI or electrical receptacle in the wiring compartment.
Purge Cycle
In-line Heater
All air blowers are equipped with a purge cycle to remove residual
water from the lines. The purge cycle will begin approximately
20 minutes after the unit is initially turned off. Do not be alarmed
when the cycle begins.
The in-line heater will operate only when the pump is on. Note: the
in-line heater is designed to keep your water warmer longer but is
not designed to increase the water temperature. Heat settings are
not adjustable. The in-line heater is not available on soaker baths.

18
Cleaning and
Maintenance
Pump and pipe circulation systems should be flushed before first use
and on a monthly basis when product is under normal use. Below are the
recommended procedures for cleaning:
Do not run whirlpool dry. Fill the tub with hot water 2-3 inches above
the jets and add 2-3 teaspoons of low foaming detergent such as
dishwashing machine detergent.
• Turn on whirlpool system and run for 10 minutes.
• Drain tub completely.
• Fill tub with cold water above jets.
• Turn on whirlpool system and run for 15 minutes.
• Drain tub completely.
• Cleaning the “suction cover:” Clean and remove any hair or lint from
the suction cover. On a monthly basis, unscrew the suction cover and
clean away any hair, lint or debris from the cover and housing, then
remount the cover in place. Suction covers with visible screws from
inside the tub can be removed. Some suctions are intended not to
be removed and have no visible fasteners. This style of suction cover
does not need to be removed for cleaning. Never operate the unit
with the safety suction cover o.
Do not use abrasive cleaners as they will scratch and dull the surface.
Use a mild liquid household detergent cleaner such as Clorox Soft Scrub®.
Plaster can be removed using a wooden stick. DO NOT USE METAL
SCRAPERS, WIRE BRUSHES, WATER BARRIER WALLBOARD OR
OTHER HARSH ABRASIVE TOOLS.
Usually mild detergent will remove construction debris. More stubborn
debris may be removed with denatured alcohol or Clorox Soft Scrub®
cleaner.
Light scratches and dulled areas may be restored to original luster by
rubbing with an automotive type cleaning compound such as DuPont
White Polishing Compound®.

19
Exclusive Limited
Lifetime Warranty
Your new Liberation Walk-In Bath includes an Exclusive Limited Lifetime Warranty on the bath,
bath components and installation. This includes Free In-Home Repair for Life.
Door Seal Lifetime
Bath + Components Lifetime
Installation Lifetime
WARRANTY LIMITATIONS
Safety Tubs® Company LLC warrants to the original consumer purchaser that this product and any
of its parts will be free of manufacturing defects and that the installation of this product will be
free of workmanship defects under normal residential use and maintenance as long as the home
where the product is installed is owned by the original consumer purchaser, subject to the other
terms and conditions contained in this document. The warranty for commercial installations is
three (3) years.
To submit a claim, a copy of this document and a copy of the original sales contract must be
submitted in writing by mail to Safety Tubs with a brief explanation of the claim. If after inspection,
Safety Tubs determines that a valid claim exists, Safety Tubs will repair, re-install, replace, or refund
the purchase price of the failing product or service, at Safety Tubs’ option. If Safety Tubs determines
to replace any or all product(s), and if such product(s), as originally installed, is no longer available,
Safety Tubs shall have the right to substitute product(s) designated by Safety Tubs to be of equal
quality.
This warranty is granted by Safety Tubs and only materials purchased from and installed by Safety
Tubs are covered by this warranty. All warranties assume normal and reasonable use of products
or components. These warranties do not cover damage caused by occurrences beyond the control
of Safety Tubs, such as settlement of the building, failure of the structure (including foundations
and walls), use of incompatible accessories, removal, repair, or re-installation of any products
or components by other than Safety Tubs, which will also void this warranty, intentional acts,
unreasonable use or failure to provide reasonable maintenance as and when necessary, or damages
due to or arising from the identification, detection, abatement, encapsulation or removal of mold,
asbestos, lead-based products, or other hazardous substances inside or outside of the structure
being improved.
This warranty is the only express warranty provided by Safety Tubs. IN NO EVENT SHALL
THE DURATION OF ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE BE LONGER THAN THE DURATION OF OWNERSHIP AND OCCUPATION
BY THE ORIGINAL OWNER OF THE HOME ON WHICH THE PRODUCT IS INSTALLED. SOME
STATES DO NOT PERMIT ANY LIMITATION ON THE LENGTH OF AN IMPLIED WARRANTY,
AND THEREFORE THE IMMEDIATELY PRECEDING SENTENCE MAY NOT APPLY. SAFETY TUBS’
LIABILITY TO OWNER UNDER THIS WARRANTY IS LIMITED TO THE AMOUNTS RECEIVED BY
SAFETY TUBS FOR SERVICES RENDERED UNDER THE ORIGINAL SALES CONTRACT. IN NO
EVENT SHALL SAFETY TUBS BE OBLIGATED OR LIABLE FOR INCIDENTAL, SPECIAL, INDIRECT,
OR CONSEQUENTIAL DAMAGES OF ANY KIND FOR THE BREACH OF ANY EXPRESS OR IMPLIED
WARRANTY OF SAFETY TUBS SERVICES. SOME STATES DO NOT ALLOW EXCLUSION OR
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, AND THEREFORE SOME OR ALL
OF THE IMMEDIATELY PRECEDING SENTENCE MAY NOT APPLY. THESE WARRANTIES PROVIDE
SPECIFIC LEGAL RIGHTS, AND YOU MAY HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO
STATE.

20
Troubleshooting
Should you experience any problems with your Liberation by
American Standard walk-in bath, please do not hesitate to call our
customer service center. A customer service representative will be
able to walk you through any minor issues that do not involve the
components of the walk-in bath. If the issue becomes more serious,
they will be able to schedule a representative to visit your home to
inspect the bath.
855.225.2183
Liberation by American Standard™ is a licensed brand and product of
Safety Tubs Company, LLC. Safety Tubs Company, LLC is an affiliated
company of American Standard Brands.
