American Standard ANSI Z 124.1.2 Operating and safety instructions

30” x 51” Walk-In
Soaking Tub, Air Spa And Whirlpool
High Gloss
Walk-in Bath 30” x 51” Soaking Tub, Air Spa And Whirlpool
3051.110.SXX Soaking Tub
•Acrylic with fiberglass reinforcement.
•Free standing metal support frame with five
adjustable leveling feet
•Easy access, powder coated aluminum door system
•Contoured, built-in seat.
•Built-in grab bar and textured bottom.
•Faucet / accessory deck areas.
•Color match cable driven drain assembly.
3051.110.WXX Whirlpool system
•Electronic control with timer.
•1 HP variable flow pump system.
•12 adjustable massage jets with
•Automatic Tub Cleaning System - Ozone.
3051.110.AXX Air Spa system
•Electronic control with timer.
•1 HP variable flow heater blower.
•Multiple seat and floor air injectors.
•Automatic purge cycle
3051.110.CXX Combo system
•Combines Whirlpool And Air System
Nominal Dimensions
30” x 51” x 37 1/2”
Compliance Certifications
•ETL – INTERTEK SEMKO
•IAPMO - USPC
•ANSI Z 124.1.2 –for Plastic Bathtubs
•ASME A112.19.7 – Whirlpool Appliances
•ASME A112.19.15 –for Walk-in Bathtubs
•CSA B-45.5 – Canadian Plumbing Fixtures
To Be Specified – Required:
Drain Configuration: Left (L) Or Right (R)
Color: White (W) Or Linen (L)
Faucet
Quick Drain™: 9QUD
Whirlpool Heater*: 9ILH (Whirlpool System Only)
Chromatherapy: 9CTP
Neck Rest: 9NR
Tub Extender: 9EXT
(
s
p
ecif
y
color
)
SEE REVERSE FOR ROUGHING –IN
DIMENSIONS AND PRODUCT SPECIFICATIONS
* NOTE: The whirlpool heater is designed to
maintain water temperature during operation.
It will not heat cold water to desired bathing
temperature

30” x 51” Walk-In
Soaking Tub, Air Spa And Whirlpool
High Gloss
NOTES:
TUB IS SUPPORTED BY THE FRAME AND FIVE
INTEGRATED ADJUSTABLE FEET, NO ADDITIONAL
SUPPORT IS REQUIRED.
REFER TO INSTALLATION INSTRUCTIONS SUPPLIED
WITH TUB FOR ADDITIONAL INFORMATION.
FIXTURES NOT INCLUDED AND MUST BE ORDERED
SEPARATELY.
PROVIDE SUITABLE REINFORCEMENT TO SUB
FLOOR FOR ALL SUPPORTS.
IMPORTANT:
Dimensions of fixtures are nominal, may vary and are
subject to change or cancellation. No responsibility is
assumed for use of
superseded or voided leaflet
GENERAL SPECIFICATIONS FOR 3051.110.XXX
WALK-IN BATH TUB
INSTALLED SIZE___________51 x 30-1/2 x 37-1/2 In. (1295 x 775 x 950 mm)
WEIGHT _____________________________________________190 Lbs. (86 kg)
WEIGHT w/ WATER __________________________________690 Lbs. (313 kg)
OPERATING GAL. _____________________________________60 Gal. (227 L.)
FLOOR LOADING _______________________64 Lbs/Sq. Ft (312 Kgs/Sq. m.)
(PROJECTED AREA)
CUBE (FT³) _____________________________________________________33.8
