CADET ELITE™5’x 36”
WHIRLPOOLS BY AMERICAN STANDARD
HIGH GLOSS ACRYLIC
CADET ELITE™5’X 36”WHIRLPOOL
Comfortable bathing design with form-fitted
backrest and molded-in armrests
❏2771E (specify White 020, Bone 021, or
Linen 222)
•Acrylic with fiberglass reinforcement
•1.5 HP self-draining pump/motor
with dry run seal
•Eight multi-directional and flow adjustable jets
including:
Two high performance Ideal-flow™Jets
Six interchangeable Flex-jets™
•Two silent air volume controls
•Deck-mounted On/Off control
•Complete factory installed and tested
whirlpool system
❏2771EC (specify White 020, Bone 021, or
Linen 222)
•Same as above with the StayClean™
whirlpool system featuring Antimicrobial
AlphaSan®
Nominal Dimensions:
60”x 36”x 19-3/4"
(1524 x 914 x 502mm)
© 2003 American Standard Inc. HD-014
SPS 2771E
Revised 6/03
Compliance Certifications -
Meets or Exceeds the Following Specifications:
•Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
•ASME A112.19.7M for Whirlpool Appliances
•ANSI Z124.1 for Plastic Bathtubs
•ASTM E162 for Flammability
•NFPA 258 for Smoke Density
* See American Standard Faucet Selector
NOTE: Roughing-in dimensions and product
specifications shown on reverse side of page.
Components Needed:
❏Bath Filler*: (specify finish)
❏Bath Drain: BATH-DRAIN
(specify Chrome 002, Polished Brass 099,
or Satin 295)
Custom Accessories Available:
❏Pulse Jet Kit: PULSE-JET (two per kit,
specify White 020, Bone 021, or Linen 222)
❏Soft Jet Kit: SOFT-JET (two per kit, specify
White 020, Bone 021, or Linen 222)
❏Five Foot Apron: 5FT-APRON (specify White
020, Bone 021, or Linen 222)
❏E-Z-Install™Whirlpool Heater - EZHEAT-100
❏Tile Bead Kit: TILE-BEAD
NOTE: E-Z-Install™Whirlpool Heater is designed to
maintain water temperature during operation. It will not
heat cold water to desired bathing temperature.

CADET ELITE™5’x 36”
WHIRLPOOLS BY AMERICAN STANDARD
HIGH GLOSS ACRYLIC
© 2003 American Standard Inc.
NOTES:
BATH CAN BE INSTALLED EITHER ABOVE OR BELOW FLOOR LINE AS PIER, ISLAND, OR PENINSULA TYPE
INSTALLATION. SUPPORT OF BATH BY SUMP BEDDING. SUPPORT AND ENCLOSING MATERIAL BY OTHERS.
REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH WHIRLPOOL FOR ADDITIONAL INFORMATION.
OPTIONAL 3 WALL TILING BEAD. KIT No. TILE-BEAD AND APRON No. 5FT-APRON AVAILABLE AND MUST BE
ORDERED SEPARATELY.
FITTINGS NOT INCLUDED AND MUST BE ORDERED SEPARATELY.
PROVIDE SUITABLE REINFORCEMENT FOR ALL SUPPORTS.
IMPORTANT:
Dimensions of fixtures are nominal and may vary within the range of tolerances established by ANSI Standard Z124.1
These measurements are subject to change or cancellation. No responsibility is assumed for use of superseded or
voided leaflet.
■
RECOMMENDED FITTING LOCATION
64 X 330mm (2-1/2 x 13")
FOR PIER OR ISLAND
INSTALLATIONS ONLY
ALT. FITTING
LOCATION #1
464 mm
(18-1/4)
38 mm
(1-1/2)
502 mm
(19-3/4)
1-1/2 O.D.TAILPIECE
■ LEVELING
STRINGER
NOT FOR
SUPPORT
SAFE-T- HEATER
REMOVABLE
BLANK
ROUGH
FLOOR
1524 mm
(60)
914 mm
(36)
OUTLINE OF CUTOUT
1486 mm x 876 mm
(58-1/2 X 34-1/2)
457 mm
(18)
235 mm
(9-1/4)
305 mm
(12)
57 mm
(2-1/4) (8) JETS
67mm
(2-5/8)
CUTOUT IN FLOOR
FOR DRAIN PUMP
FINISHED
WALL
305 mm
(12)
OPTIONAL TO
FINISHED FLOOR
USUALLY BETWEEN
1651 & 1981mm
(65 & 78) C/L OF
OVERFLOW
102 mm
(4)
C/L OF
SPOUT
C/L OF
VALVES
C/L OF
SHOWER ARM
70 mm
(2-3/4) 117 mm
(4-5/8)
1-1/2 N.P.T.M.
THREADS
19 mm
(3/4)
229 mm
(9)
C/L OF
SUPPLIES
C/L OF DRAIN
S
EE FITTING
S
PECS FOR
D
IMENSIONS
(2) AIR VALVES
ON/OFF
SWITCH
SERVICING
ON
ALL
INSTALLATIONS
INTEGRAL
SUPPORT
FEET
60 x 36 x 19-3/4 In.
(1524mm x 914 mm x 502mm)
95 Lbs. (43 Kg.)
587 Lbs. (267 Kg.)
59 Gal. (224 L.)
48 Gal. (182 L.)
40 x 22 In. (1016mm x 559mm)
52 x 29 In. (1321mm x 737mm)
13-1/4 In. (337mm)
39 Lbs./Sq. Ft. (188 Kgs/Sq. m.)
23.8
44.5
GENERAL SPECIFICATIONS FOR 2771E WHIRLPOOL
INSTALLED SIZE
WEIGHT
WEIGHT w/WATER
GAL. TO OVERFLOW
MIN. OPERATING GAL.
BATHING WELL AT SUMP
BATHING WELL AT RIM
WATER DEPTH TO OVERFLOW
FLOOR LOADING
(PROJECTED AREA)
PTS.
CUBE (FT3)
WHIRLPOOL ELECTRICAL SPECIFICATIONS
1.6 HP, 9.7 AMPS, 120V.PUMP
