CADET ELITE™6’x 42”
WHIRLPOOLS BY AMERICAN STANDARD
HIGH GLOSS ACRYLIC
CADET ELITE™6’X 42”WHIRLPOOL
Comfortable bathing design with form-fitted
backrest and molded in armrests
❏2774E (specify White 020, Bone 021, or
Linen 222)
•Acrylic with fiberglass reinforcement
•2.0 HP self-draining pump/motor
with dry run seal
•Eight multi-directional and flow adjustable jets
including:
Two high performance Ideal-flow™Jets
Six interchangeable Flex-jets™
•Two silent air volume controls
•Deck-mounted On/Off control
•Complete factory installed and tested
whirlpool system
❏2774EC (specify White 020, Bone 021, or
Linen 222)
•Same as above with the StayClean™
whirlpool system featuring Antimicrobial
AlphaSan®
Nominal Dimensions:
72”x 42”x 19-3/4"
(1829 x 1067 x 502mm)
© 2003 American Standard Inc. HD-009
SPS 2774E
Revised 6/03
Compliance Certifications -
Meets or Exceeds the Following Specifications:
•Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
•ASME A112.19.7M for Whirlpool Appliances
•ANSI Z124.1 for Plastic Bathtubs
•ASTM E162 for Flammability
•NFPA 258 for Smoke Density
* See American Standard Faucet Selector
NOTE: Roughing-in dimensions and product
specifications shown on reverse side of page.
Components Needed:
❏Bath Filler*: (specify finish)
❏Bath Drain: BATH-DRAIN
(specify Chrome 002, Polished Brass 099,
or Satin 295)
Custom Accessories Available:
❏Pulse Jet Kit: PULSE-JET (two per kit, specify
White 020, Bone 021, or Linen 222)
❏Soft Jet Kit: SOFT-JET (two per kit, specify
White 020, Bone 021, or Linen 222)
❏Six Foot Apron: 6FT-APRON (specify White
020, Bone 021, or Linen 222)
❏E-Z-Install™Whirlpool Heater - EZHEAT-100
❏Tile Bead Kit: TILE-BEAD
NOTE: E-Z-Install™Whirlpool Heater is designed to
maintain water temperature during operation. It will not
heat cold water to desired bathing temperature.

CADET ELITE™6’x 42”
WHIRLPOOLS BY AMERICAN STANDARD
HIGH GLOSS ACRYLIC
© 2003 American Standard Inc.
NOTES:
BATH CAN BE INSTALLED EITHER ABOVE OR BELOW FLOOR LINE AS PIER, ISLAND, OR PENINSULA
TYPE INSTALLATION. SUPPORT OF BATH BY SUMP BEDDING. SUPPORT AND ENCLOSING MATERIAL
BY OTHERS.
REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH WHIRLPOOL FOR ADDITIONAL
INFORMATION.
OPTIONAL 3 WALL TILING BEAD KIT No. TILE-BEAD AND APRON No. 6FT-APRON AVAILABLE AND
MUST BE ORDERED SEPARATELY.
FITTINGS NOT INCLUDED AND MUST BE ORDERED SEPARATELY.
PROVIDE SUITABLE REINFORCEMENT FOR ALL SUPPORTS.
IMPORTANT:
Dimensions of fixtures are nominal and may vary within the range of tolerances established by ANSI
Standard Z124.1
These measurements are subject to change or cancellation. No responsibility is assumed for use of
superseded or voided leaflet.
■
72 x 42 x 19-3/4 In.
(1829mm x 1067 mm x 502mm)
137 Lbs. (62 Kg.)
821 Lbs. (372 Kg.)
82 Gal. (310 L.)
66 Gal. (256 L.)
50 x 27 In. (1270 mm x 686 mm)
65 x 33 In. (1651 x 838mm)
13 In. (330 mm)
42 Lbs./Sq. Ft. (203 Kgs/Sq. m.)
27.8
55.5
GENERAL SPECIFICATIONS FOR 2774E WHIRLPOOL
INSTALLED SIZE
WEIGHT
WEIGHT w/WATER
GAL. TO OVERFLOW
MIn. OPERATING GAL.
BATHING WELL AT SUMP
BATHING WELL AT RIM
WATER DEPTH TO OVERFLOW
FLOOR LOADING
(PROJECTED AREA)
PTS.
CUBE (FT3)
WHIRLPOOL ELECTRICAL SPECIFICATIONS
2.1 HP, 14.4 AMPS, 120V.PUMP
RECOMMENDED FITTING LOCATION
64 X 330mm (2-1/2 x 13")
FOR PIER OR ISLAND
INSTALLATIONS ONLY
ALT. FITTING
LOCATION #1
1829 mm
(72)
1067mm
(42)
OUTLINE OF CUTOUT
1791mm x 1029mm
(70-1/2 X 40-1/2)
533mm
(21)
464 mm
(18-1/4)
38mm
(1-1/2)
502mm
(19-3/4)
1-1/2 O.D.TAILPIECE
■ LEVELING
STRINGER
NOT FOR
SUPPORT
ROUGH
FLOOR
229mm
(9)
305 mm
(12)
57mm
(2-1/4) (8) JETS
89mm
(3-1/2)
CUTOUT IN FLOOR
FOR DRAIN
PUMP
FINISHED
WALL
305mm
(12)
OPTIONAL TO
FINISHED FLOOR
USUALLY BETWEEN
1651 & 1981mm
(65 & 78) C/L OF
OVERFLOW
102mm
(4)
C/L OF
SPOUT
C/L OF
VALVES
C/L OF
SHOWER ARM
70 mm
(2-3/4) 117 mm
(4-5/8)
1-1/2 N.P.T.M.
THREADS
19 mm
(3/4)
229 mm
(9)
C/L OF
SUPPLIES
C/L OF DRAIN
SEE FITTING
SPECS FOR
DIMENSIONS
(2) AIR VALVES
ON/OFF
SWITCH
PROVIDE ACCESS TO PUMP FOR
SERVICING ON ALL INSTALLATIONS
INTEGRAL
SUPPORT
FEET
IN-LINE HEATER
REMOVABLE
BLANK
