CADET 6' X 42" ELITE
WHIRLPOOL
Model No. 2774E
PUMP
SUCTION
COUPLING
O-RING
1-1/2" RIGID
PVC TUBING
SUCTION FITTING
ELBOW
SUCTION
GUARD
SUCTION
FITTING
FLEX JET
NOZZLE
ASSEMBLY
1" RIGID
PVC TUBING
O-RING
PUMP
DISCHARGE
COUPLING
FLEX JET
ESCUTCHEON
ASSEMBLY
1/2" RIGID
PVC TUBING FLEX
JET BODY
ASSEMBLY
SILENT
AIR CONTROL
VALVE
DESCRIPTION PKG QTY
PART NUMBER
Pump Suction Coupling
O-Ring
Pump Discharge Coupling
Silent Air Control Valve
Flex Jet Nozzle Assembly
Flex Jet Escutcheon Assembly
Flex Jet Body Assembly
Idealflow Nozzle Assembly
Idealflow Escutcheon Assembly
Idealflow Body Assembly
Suction Guard
Suction Fitting
Suction Fitting Elbow
Discharge Tee
Pump (2.1 H.P.)
Air Switch
Air Actuator Cap and Body
Air Actuator Tubing
Safety Suction Device 8 Lb.
047186-0070A
047187-0070A
047186-0070A
752855-XXX0A
752851-XXX0A
752850-XXX0A
752849-0070A
752407-XXX0A
752408-XXX0A
752409-0070A
047463-XXX0A
047550-XXX0A
751186-0070A
047438-0070A
752857-0070A
752388-0070A
752439-XXX0A
047602-0070A
752205-1000A
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
3 ft.
1
AIR
ACTUATOR
CAP
AND BODY
PUMP
Product names listed herein are trademarks of American Standard Inc.
American Standard Inc. 2001
C
DISCHARGE
TEE
IDEALFLOW JETS
SEE DETAIL "A"
IDEALFLOW
NOZZLE
ASSEMBLY
IDEALFLOW
BODY
ASSEMBLY
IDEALFLOW
ESCUTCHEON
ASSEMBLY
DETAIL "A"
SAFETY
SUCTION
DEVICE
NOTE: Schedule 40 Rigid PVC Piping available through local plumbing supply outlets.
Replace XXX with Fixture Color Code, YYY with Trim Finish
HEATER
BLANK
Replace XXX with
Fixture Color Code,
YYY with Trim Finish
Removal/installation requires tool part no. 752905-0070A
Removal/installation requires tool part no. 752906-0070A
