American Standard Chandler Front Apron (w/Recess for Tile) Double Bowl Sink... User manual

G13
© 2008 AS America Inc. Revised 6/06
CHANDLER™ FRONT APRON
(w/Recess for Tile) DOUBLE BOWL SINK
DUPONT CORIAN®
CHANDLER™ FRONT APRON (w/Recess for Tile)
DOUBLE BOWL KITCHEN SINK
• Dupont Corian® surface
• Double bowl design
• Front apron panel - recessed for tile
• Top mount
• Shown with 4771.702 Hampton faucet with
porcelain cross handles (not included)
• Silicone sealant supplied
• Available in center hole only, 3, or 4 faucet
hole conguration
❏ 7048.301 Center hole only
❏ 7048.303 3 hole
❏ 7048.304 4 hole
Nominal Dimensions:
914 x 559 x 254mm
(36" x 22" x 10-1/2")
Bowl sizes:
Right Hand: 359mm (14-1/8") wide
16-1/4" (413mm) front to back
203mm (8") deep
Left Hand: 432mm (17") wide
476mm (18-3/4") front to back
254mm (10") deep
Compliance Certications -
Meets or Exceeds the Following Specications:
• ANSI Z124.6 for Non-Metallic Sinks
* See faucet section for available models
To Be Specied:
❏ Color:
❏ Faucet*:
❏ Faucet Finish:
❏ Basket Strainer: 4331.013
❏ Soap Dispenser: 4503.115, Color:
❏ Traps: NOTES:
* FOR COUNTERTOP CUTOUT SEE INSTALLATION INSTRUCTIONS
SUPPLIED WITH SINK.
TILE RECESS AREA DESIGNED FOR FOUR (4) 6" x 6" x 5/16" THICK
CERAMIC TILES. TILES NOT INCLUDED. BE SURE TO USE TILES
THAT FIT RECESS.
FITTINGS NOT INCLUDED AND MUST BE ORDERED SEPARATELY.
PROVIDE SUITABLE REINFORCEMENT FOR ALL WALL AND
COUNTERTOP SUPPORTS.
IMPORTANT: Dimensions of xtures are nominal and may vary within the
range of tolerances established by ANSI Standard Z124.6
These measurements are subject to change or cancellation. No responsibility
is assumed for use of superseded or voided leaet.
7-1/8"
(181mm)
TILE RECESS AREA
6-3/16" x 24-1/2" x 3/8"
(157 x 822 x 10mm DEEP)
(2) 1-1/2" O.D.
TAILPIECE
257mm
(10-1/8")
146mm
(5-3/4")
248mm
(9-3/4")
Y
COUNTERTOP
(BY OTHERS)
CABINET
FASCIA
5-3/4"
(146mm) 36" (914mm)
SUGGESTED
FINISHED
FLOOR
8-1/8"
(206mm)
3/8"
(10mm)
4"
(102mm)
HOT COLD
FINISHED WALL OR
SPLASH BACK
4"
(102mm)
3-1/2"
(89mm) DIA.
2-3/4"
(108mm)
4"
(102mm)
11"
(279mm)
18"
(457mm)
1-3/8"(35mm) DIA.
HOLES TYP.
7048.301
1 HOLE
VARIATION
8-3/4"
(222mm)
C/L
SPRAY
7048.304
4 HOLE
VARIATION
7048.303
3 HOLE
VARIATION
1-3/4"
(44mm) DIA.
2"
(51mm) OPTIONAL
22"
(559mm)
CUTOUT
NOTE
*
1-1/2" REF.
(38mm)
SEALING
COMPOUND
36"
(914mm)
4-1/2"
(114mm)
2" (51mm)
FRONT OF
APRON
9-1/2"
(241mm)
1" (25mm)
RAD. TYP.

G14
© 2008 AS America Inc.
