American Standard Cadet 2099.016 User manual

K17
Revised 2/08
© 2008 AS America Inc.
CADET™
ROUND FRONT ONE-PIECE TOILET
VITREOUS CHINA
CADET™ ROUND FRONT ONE-PIECE TOILET
❑ 2099.016
• Vitreous china
• Low-consumption (6.0 Lpf/1.6 gpf)
• One-piece design
• Round front siphon action jetted bowl with
2" trapway
• Rim height at 381mm (15")
• Color-matched trip lever
• 2 bolt caps
• Internal trapway area fully glazed
• 100% factory ush tested
• Seat not included
Nominal Dimensions:
711 x 457 x 679mm
(28" x 18" x 26-3/4")
Fixture only, seat and supply by others
Compliance Certications -
Meets or Exceeds the Following Specications:
• ASME A112.19.2M for Vitreous China Fixtures -
includes Flush Performance, Ball Pass Diameter,
Trap Seal Depth and all Dimensions
NOTES:
THIS TOILET IS DESIGNED TO ROUGH-IN AT A MINIMUM DIMENSION OF
305MM (12") FROM FINISHED WALL TO C/L OF OUTLET.
SUPPLY NOT INCLUDED WITH FIXTURE AND MUST BE ORDERED
SEPARATELY.
* DIMENSION SHOWN FOR LOCATION OF SUPPLY IS SUGGESTED.
IMPORTANT: Dimensions of xtures are nominal and may vary within the
range of tolerance established by ANSI Standard A112.19.2
These measurements are subject to change or cancellation. No responsibility
is assumed for use of superseded or voided pages.
711mm
(28)
206mm
(8-1/8)
16 ± 6mm
(5/8 ± 1/4)
375mm
(14-3/4)
324mm
(12-3/4)
159mm
(6-1/4)
679mm
(26-3/4)
397mm
(15-5/8)
457mm
(18)
79mm
(3-1/8)
FINISHED WALL
422mm
(16-5/8)
C/L OF SEAT
POST HOLES
140mm (5-1/2)
CENTERS
305mm
(12) C/L OF OUTLET
16mm
(5/8)
FINISHED
FLOOR
244mm
(9-5/8)
140mm
(5-1/2)
SUPPLY AS
REQ'D
*133mm
(5-1/4)
*FINISHED
FLOOR
To Be Specied:
❑ Color:
❏ White ❏ Bone ❏ Linen ❏ Silver
❏ Silver ❏ Black
❑ Trip Lever: 047242-XXX0A
❑ Color-matched (supplied)
❑ 002 Chrome
❑ 099 Polished Brass
❑ 295 Satin Nickel
❏ Supply with Stop:
❏ Seat:
