American Standard CADET 3 FloWise 2829.128 User manual

K79
© 2008 AS America Inc. Revised 2/08
To Be Specied:
❏ Color: ❏ White ❏ Bone ❏ Silver ❏ Linen ❏ Black
❏ Seat: #5330.010 Round front Champion® Slow Close
solid plastic seat and cover with easy lift off feature
❏ Seat: #5284.016 Elongated EverClean® solid plastic
seat and cover
❏ Seat: #5320.110 EverClean® Right Front Seat with
Slow Close Snap-Off Hinges
❏ Supply with stop:
NOTES:
THIS TOILET IS DESIGNED TO ROUGH-IN AT A MINIMUM DIMENSION OF
305MM (12") FROM FINISHED WALL TO C/L OF OUTLET.
SUPPLY NOT INCLUDED WITH FIXTURE AND MUST BE ORDERED
SEPARATELY.
* DIMENSION SHOWN FOR LOCATION OF SUPPLY IS SUGGESTED.
IMPORTANT: Dimensions of xtures are nominal and may vary within the range
of tolerances established by ANSI Standard A112.19.2.
These measurements are subject to change or cancellation. No responsibility is
assumed for use of superseded or voided pages.
CADET® 3 FloWise® ROUND FRONT TOILET
❑ 2829.128
• Vitreous china
• Meets denition for HET (High Efciency Toilet)
• High efciency (4.8 Lpf/1.28 gpf)
• Certied in EPA Water Sense Program
• Qualies in LEEDS Program
• EverClean® surface inhibits the growth of
stain- and odor-causing bacteria, mold,
and mildew on the surface
• Featuring the Cadet® 3 Flushing System
• Elongated siphon action jetted bowl
• Fully-glazed 2-1/8" trapway
• Generous 9" x 8" water surface area
• Close-coupled tank with at tank cover for
superior storage
• Oversized 3" ush valve with chemical
resistant apper
• Chrome trip lever
• Speed Connect® tank-to-bowl coupling system
• Sanitary dam on bowl with four point
tank stabilization
• 2 color-matched bolt caps
• 100% factory ush tested
• 5 year warranty
❑ 3011.128 Round Front Bowl
❑ 4021.128 Tank
Nominal Dimensions:
718 x 438 x 733mm (28-1/4" x 17-1/4" x 28-7/8")
Fixture only, seat and supply by others
Alternative Tank Congurations Available:
❑ 4021.513 Tank complete with Aquaguard Liner
❑ 4021.613 Tank complete with tank cover
locking device
❑ 4021.713 Tank complete with Aquaguard Liner
and tank cover locking device
❑ 4021.813 Tank complete with trip lever located
on right side
❑ 4021.913 Tank complete with tank cover locking
device and trip lever located on right side
❑ 4021.953 Tank complete with Aquaguard Liner,
tank cover locking device and trip lever located
on right side
Compliance Certications -
Meets or Exceeds the Following Specications:
• ASME A112.19.2M for Vitreous China Fixtures -
includes Flush Performance, Trap Seal Depth
and all Dimensions
• Los Angeles Department of Water and Power
Supplementary Purchase Specication for
Non-Adjustability
• Certied in EPA WaterSense HET program
CADET® 3 FloWise®
ROUND FRONT TOILET
VITREOUS CHINA
Certified by
IAPMO R&T
SEE REVERSE FOR ADDITIONAL ROUGHING-IN
DIMENSIONS

K80
Revised 2/08
© 2008 AS America Inc.
NOTES:
THIS TOILET IS DESIGNED TO ROUGH-IN AT A MINIMUM DIMENSION OF
305MM (12") FROM FINISHED WALL TO C/L OF OUTLET.
SUPPLY NOT INCLUDED WITH FIXTURE AND MUST BE ORDERED
SEPARATELY.
* DIMENSION SHOWN FOR LOCATION OF SUPPLY IS SUGGESTED.
IMPORTANT: Dimensions of xtures are nominal and may vary within the range
of tolerances established by ANSI Standard A112.19.2.
These measurements are subject to change or cancellation. No responsibility is
assumed for use of superseded or voided pages.
FINISHED WALL
FINISHED
FLOOR
C/L OF OUTLET
SUPPLY
AS
REQ'D.
216mm
(8-1/2)
718mm
(28-1/4)
25mm ± 6mm
(1 ± 1/4)
102mm
(4)
416mm
(16-3/8)
438mm
(17-1/4)
733mm
(28-7/8)
*381mm
(15)
*203mm
(8)
305mm
(12)
333mm
(13-1/8)
216mm
(8-1/2)
C/L OF SEAT POST HOLES
140mm (5-1/2 CENTERS)
352mm
(13-7/8)
*152mm
(6)
235mm
(9-1/4)
CADET® 3 FloWise®
ROUND FRONT TOILET
VITREOUS CHINA
Certified by
IAPMO R&T
