COLONY SOFT
TWO-HANDLE CENTERSET LAVATORY FAUCET
GENERAL DESCRIPTION:
Centerset lavatory faucet on 4" centers. 1/4 turn washerless
ceramic disc valve cartridges. Durable cast brass waterways
with one-half inch male inlet shanks. Metal body. Color
matched underbody. Lever handles. 20" (500mm) long flexible
stainless steel drain cable is pre-assembled to faucet body.
Metal Speed Connect®drain body with 1-1/4 inch (32mm) tail
piece, (2275.509). Non-Metallic Speed Connect drain body with
1-1/4 inch (32mm) tail piece, (2275.503). 1.5 gpm/5.7L/min.
maximum flow rate.
SUGGESTED SPECIFICATION:
Two-handle 4" centerset lavatory faucet shall feature a cast brass waterway. Shall also feature 1/4 turn washerless ceramic
disc valve cartridges. Shall also feature a drain body with stainless steel cable actuation. Fitting shall be American Standard
Model # 2275.____.____.
2275.500 Shown
MODEL NUMBER:
2275.503 Colony Soft 2 Handle Centerset
Lever Handles. Non-metalic Speed Connect®
Pop-up drain.
2275.509 Colony Soft 2 Handle Centerset
Lever Handles. Metal Speed Connect Pop-up drain.
PRODUCT FEATURES:
Cast Brass Waterways with “City Shanks”: Strong and
durable. Integral tabs on casting provide a wobble-free
installation.
Ceramic Disc Valve Cartridges: Assures a lifetime of
drip-free performance.
Low Lead: Meets NSF Standard 61/Section 9 & Prop 65 lead
requirements.
Longer Spout: Provides extended reach into lavatory.
Exclusive Speed Connect Metal Drain:
• Fewer parts. Installs in less time.
• No adjustments required - seals the first time, every time.
• Flexible stainless steel cable - installs effortlessly in tight spaces.
Simple Installation: Fast and easy one person installation.
Faucet drops in from top. Quick spin nuts secure faucet in
place.
CODES AND STANDARDS
These products meet or exceed the following
codes and standards:
ANSI A117.1
ASME A112.18.1
CSA B125
NSF 61/Section 9
Product
Number Description
Finish Options
PVD
Satin
Nickel
295
Polished
Chrome
002
Meets the American Disabilities Act Guidelines
and ANSI A117.1 Requirements for the
physically challenged.
2275.503 Colony Soft 2 Handle Centerset. Lever Handles.
Non-metalic Speed Connect®Pop-up drain..
2275.509 Colony Soft 2 Handle Centerset. Lever Handles.
Metal Speed Connect Pop-up drain.
102mm
(4")
154mm
(6-1/16")
107mm
(4-3/16")
107mm
(4-3/16")
41mm
(1-5/8")
22mm
(7/8")
1/2 NPSM
HOLE
SIZE
29mm
(1-1/8")
28mm
(1-1/16")
32mm OD
(1-1/4 OD)
FLOW RATE*
GALLONS PER MINUTE
INLET PRESSURE (PSI)
*Flow rates shown are for mixed hot and cold.
0.0
0.5
1.0
1.5
2.0
10080604020
