American Standard Cadet 3 Round Front Rough-In Toilet 2384.012 Operating and safety instructions

K67
Revised 2/08
© 2008 AS America Inc.
CADET® 3 ROUND FRONT
ROUGH-IN TOILET
VITREOUS CHINA
NOTES:
THIS TOILET IS DESIGNED TO ROUGH-IN AT A MINIMUM DIMENSION OF
305MM (12") FROM FINISHED WALL TO C/L OF OUTLET.
SUPPLY NOT INCLUDED WITH FIXTURE AND MUST BE ORDERED
SEPARATELY.
* DIMENSION SHOWN FOR LOCATION OF SUPPLY IS SUGGESTED.
IMPORTANT: Dimensions of xtures are nominal and may vary within the range
of tolerances established by ANSI Standard A112.19.2.
These measurements are subject to change or cancellation. No responsibility is
assumed for use of superseded or voided pages.
CADET® 3 ROUND FRONT TOILET
❑ 2384.012
• Vitreous china
• Low-consumption (6.0 Lpf/1.6 gpf)
• EverClean® surface inhibits the growth of
stain- and odor-causing bacteria, mold,
and mildew on the surface
• Features the Cadet® 3 Flushing System
• Space saving round front siphon action
jetted bowl
• Fully-glazed 2-1/8" trapway with 2" ball pass
• Generous 9" x 8" water surface area
• Close-coupled tank with at tank cover for
superior storage
• Oversized 3" ush valve with chemical
resistant apper
• Chrome trip lever
• Speed Connect® tank-to-bowl
coupling system
• Sanitary dam on bowl with four point
tank stabilization
• 2 color-matched bolt caps
• 100% factory ush tested
• 5 year warranty
❑ 3011.016 Round Front Bowl
❑ 4021.016 Tank
Nominal Dimensions:
718 x 438 x 733mm (28-1/4" x 17-1/4" x 28-7/8")
Fixture only, seat and supply by others
Alternative Tank Congurations Available:
❑ 4021.500 Tank complete with Aquaguard Liner
❑ 4021.600 Tank complete with tank cover
locking device
❑ 4021.700 Tank complete with Aquaguard Liner
and tank cover locking device
❑ 4021.800 Tank complete with trip lever located
on right side
❑ 4021.900 Tank complete with tank cover locking
device and trip lever located on right side
❑ 4021.950 Tank complete with Aquaguard liner,
tank cover locking devise, and trip lever on
right side
Compliance Certications -
Meets or Exceeds the Following Specications:
• ASME A112.19.2M for Vitreous China Fixtures -
includes Flush Performance, Ball Pass Diameter,
Trap Seal Depth and all Dimensions
• Los Angeles Department of Water and Power
Supplementary Purchase Specication for
Non-Adjustability
To Be Specied:
❏ Color: ❏ White ❏ Bone ❏ Silver ❏ Linen ❏ Black
❏ Seat: #5330.010 Round front Champion® Slow Close
solid plastic seat and cover with easy lift off feature
❏ Seat: #5282.011 Round Front EverClean® solid
plastic seat and cover
❏ Seat: #5320.110 EverClean® Round Front Seat with
Slow Close Snap-Off Hinges
❏ Supply with stop:
SEE REVERSE FOR ADDITIONAL ROUGHING-IN
DIMENSIONS

K68
Revised 2/08
© 2008 AS America Inc.
CADET® 3 ROUND FRONT
ROUGH-IN TOILET
VITREOUS CHINA
NOTES:
THIS TOILET IS DESIGNED TO ROUGH-IN AT A MINIMUM DIMENSION OF
305MM (12") FROM FINISHED WALL TO C/L OF OUTLET.
SUPPLY NOT INCLUDED WITH FIXTURE AND MUST BE ORDERED
SEPARATELY.
* DIMENSION SHOWN FOR LOCATION OF SUPPLY IS SUGGESTED.
IMPORTANT: Dimensions of xtures are nominal and may vary within the range
of tolerances established by ANSI Standard A112.19.2.
These measurements are subject to change or cancellation. No responsibility is
assumed for use of superseded or voided pages.
FINISHED WALL
FINISHED
FLOOR
C/L OF OUTLET
SUPPLY
AS
REQ'D.
216mm
(8-1/2)
718mm
(28-1/4)
25mm ± 6mm
(1 ± 1/4)
102mm
(4)
416mm
(16-3/8)
438mm
(17-1/4)
733mm
(28-7/8)
*381mm
(15)
*203mm
(8)
305mm
(12)
333mm
(13-1/8)
216mm
(8-1/2)
C/L OF SEAT POST HOLES
140mm (5-1/2 CENTERS)
352mm
(13-7/8)
*152mm
(6)
235mm
(9-1/4)
