American Standard Skyline Champion 4 Elongated Right Height Toilet... User manual

K29
Revised 2/08
© 2008 AS America Inc.
SKYLINE CHAMPION® 4
ELONGATED RIGHT HEIGHT™ TOILET
VITREOUS CHINA
To Be Specied:
❏ Color: 020 White
❏ Seat: (please specify color)
 ❏ Champion® Slow Close
Elongated #5325.010
 ❏ Rise & Shine Elongated #5324.019
 ❏ Laurel Elongated #5311.012
❏ Supply with stop:
FINISHED WALL
32mm ± 6mm
(1-1/4 ± 1/4)
419mm
(16-1/2)
FINISHED
FLOOR
305mm
(12)
772mm
(30-3/8)
C/L OF OUTLET
83mm
(3-1/4)
235mm
(9-1/4)
470mm
(18-1/2)
C/L OF SEAT POST HOLES
140mm (5-1/2 CENTERS)
362mm
(14-1/4)
264mm
(10-3/8)
16mm
(5/8)
873mm
(34-3/8)
498mm
(19-5/8)
SUPPLY
AS
REQ'D
254mm
(10)
152mm
(6)
254mm
(10)
356mm
(14)
*
NOTES:
THIS TOILET IS DESIGNED TO ROUGH-IN AT A MINIMUM DIMENSION OF
305MM (12") FROM FINISHED WALL TO C/L OF OUTLET.
SUPPLY NOT INCLUDED WITH FIXTURE AND MUST BE ORDERED
SEPARATELY.
* DIMENSION SHOWN FOR LOCATION OF SUPPLY IS SUGGESTED.
IMPORTANT: Dimensions of xtures are nominal and may vary within the range
of tolerances established by ANSI Standard A112.19.2.
These measurements are subject to change or cancellation. No responsibility is
assumed for use of superseded or voided page
SKYLINE CHAMPION® 4
ELONGATED RIGHT HEIGHT™ TOILET
❏ 2067.014
• Vitreous china
• EverClean® surface inhibits the growth of stain
and odor causing bacteria, mold and mildew on
the surface
• Low-consumption (6.0 Lpf/1.6 gpf)
• Features Champion® 4 Flushing System
performance platform
• 4" non-adjustable, piston action Accelerator™
ush valve
• 16-1/2" rim height for accessible applications
• Elongated siphon action jetted bowl
• 2-3/8" fully-glazed trapway
• Speed Connect® tank/bowl coupling system
• Chrome-plated trip lever
• Sweeping pier on bowl
• 100% factory ush tested
• 2 bolt caps
• 10 year warranty
❏ 3225.016 Elongated Right Height™ Bowl
❏ 4077.014 Tank
Nominal Dimensions:
30-3/8" x 19-5/8" x 34-3/8"
(772 x 498 x 873mm)
Fixture only, seat and supply by others
Compliance Certications -
Meets or Exceeds the Following Specications:
• ASME A112.19.2M for Vitreous China Fixtures
- includes Flush Performance, Ball Pass
Diameter, Trap Seal Depth and all Dimensions
• Los Angeles Department of Water and Power
Supplementary Purchase Specication for Non-
Adjustability - July, 2003 revision
