Ametek JOFRA IPI Mk. II User manual

User Manual
Industrial Pressure Indicator
AMETEK JOFRA IPI Mk. II

Contents
1.0 Introduction ..............................................1
1.1 Contacting Ametek ...........................................1
1.2 Standard Equipment ..........................................1
1.3 Safety information ...........................................1
Hazard Location Information/Approvals ..............................2
1.5 Special Conditions for Safe Use: ................................3
2.0 IPI Mk. II Display and Controls ...............................4
3.0 Operation ................................................4
4.0 Supervisory Mode .........................................6
5.0 Normal Operation..........................................7
6.0 Changing the Batteries .....................................8
7.0 Cleaning .................................................8
8.0 Specifications ............................................9
9.0 Service Center Calibration or Repair ........................10
10.0 Available Ranges and Resolution by Engineering Unit.........11
11.0 IPI Mk. II Serial Interface Instructions ......................12
Initiating Communication ........................................12
List of Commands..............................................12
12.0 Warranty ...............................................14

1
1.0 Introduction
The IPI Mk. II combines the high accuracy of digital electronics with the
convenience and ease of use of an analog test gauge. Accurate to ± 0.05%
FS, the IPI Mk. II can be used as a calibration reference, or in any
application where high accuracy pressure measurement is required.
Many user configurable functions have been designed into the IPI Mk. II
including sampling rate, TARE, damping, auto shut off, and min-max. Once
the gauge is configured, settings can be locked and password protected to
prevent unauthorized changes to configuration.
Optional data logging software.
IPILOG Software extends the functions of the JOFRA IPI Mk.II.
The Software lets you:
• Set up data logging configuration in IPI Mk.II
• Upload logged data from IPI Mk.II, including export of run data to text,
comma separated values (CSV), and Excel files
• Clear logged data in IPI Mk.II
1.1 Contacting Ametek
Sales & Service Offices:
AMETEK MCT (North America)
Tel: [phone] • [email protected]
AMETEK Singapore Pte. Ltd. (Singapore)
Tel: [phone] • [email protected]
AMETEK Inc. Beijing Rep. Office (China)
Tel: [phone] • [email protected]
AMETEK GmbH (Germany)
Tel: [phone] • [email protected]
AMETEK Lloyd Instruments (UK)
Tel: [phone] • uk-far[email protected]
1.2 Standard Equipment
Check to see that your IPI Mk. II has arrived intact. Batteries are factory
installed. Save the packing materials at least until you have verified that
there is no concealed damage.
1.3 Safety information
A Warning identifies conditions and actions that pose hazard(s) to the user;
a Caution identifies conditions and actions that may damage the Calibrator
or the equipment under test.

2
1.4 Symbols Used
The following table lists the International Electrical Symbols. Some or all of
these symbols may be used on the instrument or in this manual.
Symbol Description
Power OFF
Power ON
Earth ground
Risk of Danger. Important information. Refer to manual.
Battery
Hazardous Voltage
Conforms to ATEX requirements
Certified by CSA as conforming to relevant Canadian and USA standards
Conforms to relevant European Union directives.
Wheeled bin, conforms to EC directive 2002/96/EC
Hazard Location Information/Approvals
Ex Hazardous Areas
An Ex-hazardous area as used in this manual refers to an area made hazardous
by the potential presence of flammable or explosive vapors. These areas are also
referred to as hazardous locations, see NFPA 70 Article 500.
®LR110460 II 3 G EEx nA IIB T6
Class I, Div. 2, Groups A-D KEMA 06ATEX0014 X
Ta=–10°C... +55°C

3
1.5 Special Conditions for Safe Use:
Misuse
Should the IPI Mk. II be exposed to overpressure or sudden physical shock
(i.e. being dropped) it should be examined for any damage that may cause
a safety concern. If in doubt please return the unit for evaluation to Ametek.
Please refer to the Customer Service Section for contact information.
WARNING
The IPI Mk. II is not intended for use with flammable substances and is
intended for installation only in locations providing adequate protection
against the entry of solid foreign objects or water capable of impairing
safety.
Caution
To avoid possible damage to calibrator or to equipment under test:
• If the message changes to "OL" the range limit is exceeded and the
pressure source must immediately be removed from the IPI Mk. II to
prevent damage to the pressure transducer inside.
• Maximum torque allowed is 13,5 Nm = 10 ftlbs. NEVER exceed the
torque allowed.

4
2.0 IPI Mk. II Display and Controls
3.0 Operation
Power: The standard IPI Mk. II is supplied with 3 AA batteries installed.
Push the power button momentarily to turn the unit on. Push it again to turn
it off.
Set-up and configuration:
Push the CONFIG button to access the user-settable functions on the
gauge. Each time the CONFIG button is pressed; the display advances to
the next function. Once a function has been set, press ENTER to exit the
configuration menu, or CONFIG to continue with further configuration. In
order, the configuration menu and operation is as follows:
1. Engineering Units set. The unit is shipped configured to display PSI.
By pressing the ▲and ▼(ZERO and MAX/MIN) keys you can scroll
forward and backwards through the 18 standard engineering units plus
a one custom unit/scale. When the desired unit is displayed, press
ENTER or CONFIG. Pressure will now be displayed in the chosen
engineering units.
See the Specifications section of this manual for a list of available
engineering units. See the Supervisory Mode section for details on
setting up custom units.
Pressure display
Engineering Units
0 - 100% bar graph
Selects an action in
configuration.
Also turns the
back-light on/off
Turns Power on/off
Enters set-up and
configuration menus
Zeros the display,
Scrolls forward through
menu displays
Recalls min and max
readings.
Scrolls backwards
through menu displays
JOFRA IPI MK.II
Industrial Pressure Indicator MK.II
CALIBRATION INSTRUMENTS

5
2. Set Auto Off. The auto-shut off can be set in 1 minute increments from
1 to 30 minutes or “off” (continuous operation). The unit is shipped set
for 30 minutes. Use the ▲and ▼keys to set the desired interval. The
“off” setting is at the low end of the choices, below 1 minute.
3. Display battery voltage. Actual voltage and a percent of life bargraph
indicate battery condition
4. Display actual temperature. The IPI Mk. II is temperature
compensated, this displays the temperature measured by the internal
sensor. The value can be set to degrees F or degrees C using the arrow
keys.
5. Set damping. Choices are “on” and “off” set with the ▲and ▼keys.
Turning damping on will smooth readings from pulsating pressure
sources.
6. Set sample rate: This determines how often pressure is sampled and
the display is updated. Choices are 0.5, 1, 3, and 10 samples/
second. Note that 10/sec provides the fastest response time.
7. Set TARE. This allows you to set a constant offset value, which is then
subtracted from the measured pressure. For example if a TARE is set at
30 PSI, and the measured pressure is 37 PSI, the displayed value will be
7 PSI.
A pressure of 27 PSI would be displayed as –3 PSI.
The tare value is set manually with the ▲and ▼keys, and is based on
the engineering units and resolution selected for display. TARE value
can be set to the maximum range of the gauge.
The bar graph will always display the actual pressure based on the full
range of the gauge regardless of the tare setting. This is done for safety
to insure that even with a “0” reading that pressure is being applied to
the gauge.
8. Function Lock: Access to each of the settable parameters above can
be turned “off” once set, to prevent unauthorized changes to
configuration. This is accomplished through a password protected
“supervisory mode”. Press ENTER to access the supervisory mode, or
CONFIG to return to normal operation.

6
4.0 Supervisory Mode
Push the CONFIG button to access the user-settable functions on the
indicator. Each time the CONFIG button is pressed; the display advances to
the next function. Press CONFIG repeatedly until “FUnC LOCK” is
displayed.
Press ENTER when “FUnC LOCK” is displayed, PWRD will be displayed on
the gauge. The password to enter supervisory mode is 101, set using the ▲
and ▼keys. Holding a key continuously will cause the display to advance
more quickly for faster setting. The password is factory set and cannot be
changed.
1. Your IPI Mk. II is shipped from the factory with all setting access
“unlocked” or available to be changed.
2. In supervisory mode each of the parameters can be locked or unlocked
using the ▲and ▼keys. Select LOC (lock) for those parameters you
do not want to be accessible, and UnLOC (unlock) for those can be
accessed.
3. In order, the functions that can be unlocked, locked or accessed are:
• Zero function (enable/disable)
• Set pressure units (enable/disable)
• Auto shutdown adjustment (enable/disable)
• Damping settings (enable/disable)
• Sample rate setting (enable/disable)
• Tare setting (enable/disable)
• Custom engineering units (set scale factor)
4. Use the CONFIG key to scroll through the above choices, and the ▲
and ▼keys to lock and unlock features. Press CONFIG to continue
scrolling through the parameters, pressing ENTER at any point saves
your settings and returns the gauge to normal operation.
When a function is “locked”, it cannot be accessed or changed from its
current state. To change a locked function, enter the supervisory mode,
and unlock the function. Once it is changed, you may enter supervisory
mode to lock access again.
5. Setting a custom engineering unit or scale: The last menu choice in
supervisory mode is SET FACTR. This allows you to set a multiplier
factor from 0.001 to 100, creating a custom scale. The set factor will be
multiplied by the PSI measured, the result will be displayed.
For example: 40 PSI is the equivalent of 1000 lbs of product in a tank.
You want to display the product weight , using a 100 PSI gauge. By
setting a factor of 25, a 40 PSI pressure would display as 1000 (40 x 25).
The engineering unit displayed on the IPI Mk. II will be “Cust”.

7
5.0 Normal Operation
Turning the backlight on and off: Press the ENTER button.
Zeroing the display: Press and hold the ZERO button.
Note: For absolute versions of the gauge pressing the zero key will prompt
the user to enter a barometric reference pressure. Use the ▲and ▼arrow
to adjust the reading as required. Then press ENTER.
MAX/MIN: The IPI Mk. II stores minimum and maximum pressure values in
memory. Pressing the MAX/MIN button once will display the minimum
pressure from memory. Pressing the MAX/MIN button again will display the
maximum pressure from memory. After about 2 seconds, the gauge returns
to normal (live display) operation. To clear the MAX/MIN memory registers,
press and hold the MAX/MIN button for 2 or more seconds until “CLr” is
displayed.
The analog bar graph at the bottom of the display indicates the applied
pressure level relative to the full range of the gauge. Keep in mind that if a
TARE value has been programmed into the gauge, the displayed pressure
will not reflect the true pressure applied.

8
6.0 Changing the Batteries
WARNING
Explosion hazard
Batteries must only be changed in an area known
to be non-hazardous.
Loosen the captive screw on the battery door, then remove the battery door
to expose the 3 AA batteries. Replace the batteries as required and then
reinstall the battery door and tighten the captive screw.
+

Battery life
Battery life is about 1500 hours (60 days) of continuous use with the
backlight off. With intermittent use, batteries could last a year or more.
There is a low battery icon in the upper left of the display. It will appear when
battery level is low. Replace batteries per recommendations found in the
specifications section of this manual.
RS-232 Interface
An RS-232 interface is standard on the IPI Mk. II. Serial communication can
be used for configuration, calibration, and to transfer measurement data
from the gauge.
WARNING
The RS-232 interface must not be used in hazardous areas.
7.0 Cleaning
To clean the IPI Mk. II use a cloth with a mild cleaning solution.

9
8.0 Specifications
All specifications cover the temperature range from 0°C to +50°C, unless
otherwise noted.
Available Input Ranges
See page 13 for a table of available ranges in PSI plus equivalent ranges
and resolution for all engineering units
Accuracy
Positive Pressure: ±0.05% FS
Vacuum:
100, 300, 500 PSI indicator / 7, 21, 35 bar indicator: ±0.25% F.S.
Vacuum:
30 PSI / 2 bar indicator: ±0.1% F.S.
Over Pressure Protection:
Ranges from 15 PSI to 500 PSI/1 to 35 bar: 3X input pressure range
1,000, 3,000, and 5,000 PSI/70 to 350 bar ranges: 2X input pressure range
10,000 PSI/700 bar: 1.5X input pressure range
Overload Alarm (indicate OL on display): 1.2X input pressure range
Temperature Compensation
Full temperature compensated:
0 °C to +50 °C (32 °F to +122 °F) to rated accuracy
Note: For temperatures from –10 °C to 0 °C and 50 °C to 55 °C add .005%
F.S./°C
Standard Engineering Units
PSI, Bar, kg/cm2, inH2O (4 °C, 20 °C or 60 °F),
ftH2O (4 °C, 20 °C or 60 °F), cmH2O (4 °C and 20 °C), mH2O (4 °C and 20
°C), KPa, mBAR, inHg, mmHg, Torr
One custom unit (user programmable)
Media Compatibility
Liquids and gases compatible with 316 stainless steel
Environmental
Operating Temperature: -10 °C to +55 °C
Storage: -20 °C to +70 °C (-4 °F to +158 °F)

10
Humidity: 10% to 95% RH Non-condensing
Pollution: Degree II
Mechanical
Dimensions: 11.4 x 12.7 (cm), depth = 3.7 cm (4.5 x 5 (in), depth= 1.5 in)
Pressure Connection: ¼” NPT Male
Housing: cast ZNAL, meets NEMA 4/IP65
Display
5-1/2 Digits, 0.65” (16.53 mm) high
20-Segment bar graph, 0 to 100%
Power
Battery: three (3), size AA alkaline batteries
Battery Life: 1,500 hours without backlight, 2,000 hours at slow sample rate
Low Battery Indicator icon is displayed near the end of battery life
9.0 Service Center Calibration or Repair
Only qualified service personnel should perform calibration, repairs, or
servicing not covered in this manual. If the calibrator fails, check the
batteries first, and replace them if needed.
Verify that the calibrator is being operated as explained in this manual. If the
calibrator is faulty, send a description of the failure with the calibrator. Be
sure to pack the calibrator securely, using the original shipping container if it
is available.

11
10.0 Available Ranges and Resolution by Engineering Unit
Engineering Unit Factor 1 15 30 1100 300 500 1000 2000 3000 5000 10000 Burst Pressure 50 500 500 1000 2000 2000 10000 10000 10000 10000 15000 Proof Pressure 5 30 60 200 600 1000 2000 3000 6000 10000 15000 psi 1 1.0000 15.000 30.000 100.00 300.00 500.00 1000.0 2000.0 3000.0 5000.0 10000 bar 0.06894757 0.0689 1.0342 2.0684 6.8948 20.684 34.474 68.948 137.90 206.84 344.74 689.48 mbar 68.94757 68.948 1034.2 2068.4 6894.8 20684 34474 68948 * * * * kPa 6.894757 6.8948 103.42 206.84 689.48 2068.4 3447.4 6894.8 13790 20684 34474 68948 Mpa 0.00689476 0.0069 0.1034 0.2068 0.6895 2.0684 3.4474 6.8948 13.790 20.684 34.474 68.948 kg/cm20.07030697 0.0703 1.0546 2.1092 7.0307 21.092 35.153 70.307 140.61 210.92 351.53 703.07 mmHg @ 0°C 51.71508 51.715 775.73 1551.5 5171.5 15515 25858 51715 * * * * inHg @ 0°C 2.03602 2.0360 30.540 61.081 203.60 610.81 1018.0 2036.0 4072.0 6108.1 10180 20360 cmH2O @ 4°C 70.3089 70.309 1054.6 2109.3 7030.9 21093 35154 70309 * * * * cmH2O @ 20°C 70.4336 70.434 1056.5 2113.0 7043.4 21130 35217 70434 * * * * mmH2O @ 4°C 703.089 703.09 10546 21093 70309 * * * * * * * mmH2O @ 20°C 704.336 704.34 10565 21130 70434 * * * * * * * mH2O @ 4°C 0.703089 0.7031 10.546 21.093 70.309 210.93 351.54 703.09 1406.2 2109.3 3515.4 7030.9 mH2O @ 20°C 0.704336 0.7043 10.565 21.130 70.434 211.30 352.17 704.34 1408.7 2113.0 3521.7 7043.4 inH2O @ 4°C 27.68067 27.681 415.21 830.42 2768.1 8304.2 13840 27681 55361 83042 * * inH2O @ 20°C 27.72977 27.730 415.95 831.89 2773.0 8318.9 13865 27730 55460 83189 * * inH2O @ 60°F 27.70759 27.708 415.61 831.23 2770.8 8312.3 13854 27708 55415 83123 * * Torr 51.71508 51.715 775.73 1551.5 5171.5 15515 25858 51715 * * * *
1. Also applies to -15 to +30 PSI compound range. 2. Cells noted with * will not be displayed due to limitations on display resolution. In all cases, resolution is limited to 100,000 counts.

12
11.0 IPI Mk. II Serial Interface Instructions
Warning
To prevent possible electrical shock, fire, or personal injury,
do not use the RS-232 interface in hazardous areas.
Initiating Communication
The terminal communications can be setup using terminal communication
software on a PC. The terminal settings need to be set as follows:
• Bits per second: 9600
• Data bits: 8
• Parity: None
• Stop bits: 1
• Flow control: None
• Local echo on
List of Commands
Command Description
CAL_START Puts the calibrator in calibration mode
*CLS Clears the error queue.
FAULT? Returns an error code from the error queue
*IDN? Identification query. Returns the manufacturer, model
number, and firmware revision level of the Calibrator.
TARE Tares the offset pressure of the reading on the
calibrator
TARE? Returns the current tare value
PRES_UNIT? Returns the pressure unit for the upper display.
PRES_UNIT Sets the pressure unit for the display
ZERO_MEAS Zeros pressure of the calibrator
ZERO_MEAS? Returns the current zero offset value
MINMAX_RST Resets the minimum and maximum recorded values.
MIN? Returns the minimum recorded value
MAX? Returns the maximum recorded value
HC_OFF Turns unit off
HC_DFLT Sets auto off defaults
TEMP? Returns temperature in the chosen units
HC_COMP_OFF Turns temperature compensation off.

13
HC_COMP_ON Turns temperature compensation on.
HC_COMP? Returns state of temperature compensation.
HC_RD_2410? Return 2410 ADC counts.
HC_SI_OFF Turns SI mode off.
HC_SI_ON Turns SI mode on.
CAL_STORE Stores calibration data.
HC_AUTO_OFF Turns auto shutdown off
HC_AUTO_ON Turns auto shutdown on
CUST_MULT? Sets the multiplier for the custom unit type
STREAM_OFF Turns streaming data off
STREAM_ON Turns streaming data on
HC_TEMP? Same as TEMP?
VAL? Returns the measured pressure value in selected units
HC_CMD_LIST Prints out a command list
TEMP_UNIT Used to set temperature unit
TEMP_UNIT? Returns temperature unit
Parameter Units
Units Meaning
Psi Pressure in pounds per square-inch
Bar Pressure in bars
mBar Pressure in millibars
Kg/cm2 Pressure in kilograms per centimeter squared
InH2O4C Pressure in inches of water at 4°C
InH2O20C Pressure in inches of water at 20°C
InH2O60F Pressure in inches of water at 60°F
mH2O4C Pressure in meters of water at 4°C
MH2O20C Pressure in meters of water at 20°C
cmH2O4C Pressure in centimeters of water at 4°C
cmH2O4C Pressure in centimeters of water at 20°C
ftH2O4C Pressure in feet of water at 4°C
ftH2O20C Pressure in feet of water at 20°C
ftH2O60F Pressure in feet of water at 60°F
Inhg0C Pressure in inches of mercury at 0°C

14
mmhg0C Pressure in millimeters of mercury at 0°C
kpal Pressure in kilopascals
Far Temperature in Farenhiet
Cel Temperature in Celcius
Error Codes
Error Description
101 A non-numeric entry was received where it should be
a numeric entry
102 Too many significant digits entered
103 Invalid units or parameter value received
105 Entry is above the upper limit of the allowable range
106 Entry is below the lower limit of the allowable range
108 A required command parameter was missing
109 An invalid pressure unit was received
117 An unknown command was received
120 The serial input buffer overflowed
121 Too many entries in the command line
122 Pressure module not connected
12.0 Warranty
According to current terms of sale and delivery.
This warranty only covers defects in manufacture and becomes void if the
instrument has been subject to unauthorised intervention and/or misuse.
AMETEK Denmark’s liability ceases if:
parts are replaced/repaired using spare parts, which are not identical to
those recommended by the manufacturer.
non-original parts are used in any way when repairing the instrument.
AMETEK Denmark’s liability is restricted to errors that originated from the
factory.
When returning the calibrator to the manufacturer for service, please enclose
a fully completed service information form. Simply copy the form on the
following page and fill in the required information. The calibrator should be
returned in the original packing.
WARNING
Substitution of components may impair suitability for hazardous locations.

15
Service info
Customer data: Date:
Customer name and address:___________________________________________
Attention and Dept.:___________________________________________________
Fax no./Phone no.:____________________________________________________
Your order no.:_______________________________________________________
Delivery address:_____________________________________________________
Distributor name:_____________________________________________________
Instrument data:
Model and Serial no.:__________________________________________________
Warranty claimed Yes:____ No:_____ Original invoice no.:_________________
___________________________________________________________________
Temp. Sensor Service request: This instrument is sent for
calibration input (please tick off):
___ Calibration as left ___ Check
___ Calibration as found and as left ___ Service
___ Accredited calibration as left ___ Repair
___ Accredited calibration as found and as left.
___________________________________________________________________
Diagnosis data/cause for return:
Diagnosis/Fault description:_____________________________________________
___________________________________________________________________
Special requests:_____________________________________________________
___________________________________________________________________
Safety precautions: if the product has been exposed to any hazardous substances, it must be
thoroughly decontaminated before it is returned to AMETEK. Details of the hazardous substances and
any precautions to be taken must be enclosed.

SPK-IPI-004 0200044 Rev. A ATEX 10/12

Information in this document is subject to change without notice. ©2012, by AMETEK, Inc., www.ametek.com. All rights reserved.
AMETEK Calibration Instruments
is one of the world’s leading manufacturers
and developers of calibration instruments for
temperature, pressure and process signals as well
as for temperature sensors both from a commercial
and a technological point of view.
JOFRA Temperature Instruments
Portable precision thermometers. Dry-block and
liquid bath calibrators: 5 series, with more than 25
models and temperature ranges from -90° to 1205°C
/ -130° to 2200°F. All featuring speed, portability,
accuracy and advanced documenting functions with
JOFRACAL calibration software.
JOFRA Pressure Instruments
Convenient electronic systems ranging from -25
mbar to 1000 bar (0.4 to 15,000 psi) - multiple
choices of pressure ranges, pumps and accuracies,
fully temperature-compensated for problem-free and
accurate field use.
JOFRA Signal Instruments
Process signal measurement and simulation for
easy control loop calibration and measurement
tasks - from handheld field instruments to laboratory
reference level bench top instruments.
JOFRA / JF Marine Instruments
A complete range of calibration equipment for
temperature, pressure and signal, approved for
marine use.
FP Temperature Sensors
A complete range of temperature sensors for
industrial and marine use.
M&G Pressure Testers
Pneumatic floating-ball or hydraulic piston dead
weight testers with accuracies to 0.015% of reading.
M&G Pumps
Pressure generators from small pneumatic “bicycle”
style pumps to hydraulic pumps generating up to
1,000 bar (15,000 psi).
www.jofra.com
UK
Lloyd Instruments Ltd
Tel [phone]
uk-far[email protected]
France
AMETEK S.A.S.
Tel [phone]
[email protected]
Germany
AMETEK GmbH
Tel [phone]
info[email protected]
Denmark
AMETEK Denmark
Tel [phone]
[email protected]
USA
AMETEK MCT
Tel [phone]
chatillon.fl[email protected]
India
AMETEK Instruments India Pvt Ltd.
Tel [phone]
[email protected]
Singapore
AMETEK Singapore Pte Ltd
Tel [phone]
[email protected]
China
AMETEK Inc. - Shanghai
Tel [phone]
AMETEK Inc. - Beijing
Tel [phone]
AMETEK Inc. - Guangzhou
Tel [phone]
[email protected]
