Ametek SPS A Series User manual

M470008-01 Rev A www.programmablepower.com
SPSSeriesAPanel
MediumPower
DCPowerSupplies
Operation Manual

i
About AMETEK
AMETEK Programmable Power, Inc., a Division of AMETEK, Inc., is a global leader in the design
and manufacture of precision, programmable power supplies for R&D, test and measurement,
process control, power bus simulation and power conditioning applications across diverse
industrial segments. From bench top supplies to rack-mounted industrial power subsystems,
AMETEK Programmable Power is the proud manufacturer of Elgar, Sorensen, California
Instruments, AMREL and Power Ten brand power supplies.
AMETEK, Inc. is a leading global manufacturer of electronic instruments and electromechanical
devices with annualized sales of $2.5 billion. The Company has over 11,000 colleagues working
at more than 80 manufacturing facilities and more than 80 sales and service centers in the United
States and around the world.
Trademarks
AMETEK is a registered trademark of AMETEK, Inc.
Other trademarks, registered trademarks, and product names are the property of their respective
owners and are used herein for identification purposes only.
Notice of Copyright
SPS A Series DC Power Supplies Operation Manual © October 2010 AMETEK Programmable
Power, Inc. All rights reserved.
Exclusion for Documentation
UNLESS SPECIFICALLY AGREED TO IN WRITING, AMETEK PROGRAMMABLE POWER, INC.
(“AMETEK”):
(a) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY
TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER
DOCUMENTATION.
(b) ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSSES, DAMAGES, COSTS OR
EXPENSES, WHETHER SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL OR INCIDENTAL,
WHICH MIGHT ARISE OUT OF THE USE OF SUCH INFORMATION. THE USE OF ANY SUCH
INFORMATION WILL BE ENTIRELY AT THE USER’S RISK, AND
(c) REMINDS YOU THAT IF THIS MANUAL IS IN ANY LANGUAGE OTHER THAN ENGLISH,
ALTHOUGH STEPS HAVE BEEN TAKEN TO MAINTAIN THE ACCURACY OF THE
TRANSLATION, THE ACCURACY CANNOT BE GUARANTEED. APPROVED AMETEK CONTENT
IS CONTAINED WITH THE ENGLISH LANGUAGE VERSION, WHICH IS POSTED AT
WWW.PROGRAMMABLEPOWER.COM.
Date and Revision
August 2011 Revision A
Part Number
M470010-01
Contact Information
Telephone: [phone] (toll free in North America)
858 450 0085 (direct)
Fax: [phone]
Email: [e-mail]
[email protected]
Web: www.programmablepower.com

ii
This page intentionally left blank.

iii
Important Safety Instructions
Before applying power to the system, verify that your product is configured properly for your
particular application.
WARNIN
G
Hazardous voltages may be present when covers are removed. Qualified
personnel must use extreme caution when servicing this equipment.
Circuit boards, test points, and output voltages also may be floating above
(below) chassis ground.
WARNIN
G
The equipment used contains ESD sensitive ports. When installing
equipment, follow ESD Safety Procedures. Electrostatic discharges might
cause damage to the equipment.
Only qualified personnel who deal with attendant hazards in power supplies, are allowed to perform
installation and servicing.
Ensure that the AC power line ground is connected properly to the Power Rack input connector or
chassis. Similarly, other power ground lines including those to application and maintenance
equipment must be grounded properly for both personnel and equipment safety.
Always ensure that facility AC input power is de-energized prior to connecting or disconnecting any
cable.
In normal operation, the operator does not have access to hazardous voltages within the chassis.
However, depending on the user’s application configuration, HIGH VOLTAGES HAZARDOUS TO
HUMAN SAFETY may be normally generated on the output terminals. The customer/user must
ensure that the output power lines are labeled properly as to the safety hazards and that any
inadvertent contact with hazardous voltages is eliminated.
Guard against risks of electrical shock during open cover checks by not touching any portion of the
electrical circuits. Even when power is off, capacitors may retain an electrical charge. Use safety
glasses during open cover checks to avoid personal injury by any sudden component failure.
Neither AMETEK Programmable Power Inc., San Diego, California, USA, nor any of the subsidiary
sales organizations can accept any responsibility for personnel, material or inconsequential injury,
loss or damage that results from improper use of the equipment and accessories.
SAFETY SYMBOLS

iv
This page intentionally left blank.

v
Product Family: SPS A Series DC Power Supplies
Warranty Period: Three Years
WARRANTY TERMS
AMETEK Programmable Power, Inc. (“AMETEK”), provides this written warranty covering the
Product stated above, and if the Buyer discovers and notifies AMETEK in writing of any defect in
material or workmanship within the applicable warranty period stated above, then AMETEK may,
at its option: repair or replace the Product; or issue a credit note for the defective Product; or
provide the Buyer with replacement parts for the Product.
The Buyer will, at its expense, return the defective Product or parts thereof to AMETEK in
accordance with the return procedure specified below. AMETEK will, at its expense, deliver the
repaired or replaced Product or parts to the Buyer. Any warranty of AMETEK will not apply if the
Buyer is in default under the Purchase Order Agreement or where the Product or any part
thereof:
•is damaged by misuse, accident, negligence or failure to maintain the same as
specified or required by AMETEK;
•is damaged by modifications, alterations or attachments thereto which are not
authorized by AMETEK;
•is installed or operated contrary to the instructions of AMETEK;
•is opened, modified or disassembled in any way without AMETEK’s consent; or
•is used in combination with items, articles or materials not authorized by AMETEK.
The Buyer may not assert any claim that the Products are not in conformity with any warranty
until the Buyer has made all payments to AMETEK provided for in the Purchase Order Agreement.
PRODUCT RETURN PROCEDURE
1. Request a Return Material Authorization (RMA) number from the repair facility (must be
done in the country in which it was purchased):
•In the USA, contact the AMETEK Repair Department prior to the return of the
product to AMETEK for repair:
Telephone: [phone], ext. 2295 or ext. 2463 (toll free North America)
858-450-0085, ext. 2295 or ext. 2463 (direct)
•Outside the United States, contact the nearest Authorized Service Center
(ASC). A full listing can be found either through your local distributor or our
website, www.programmablepower.com, by clicking Support and going to the
Service Centers tab.
2. When requesting an RMA, have the following information ready:
•Model number
•Serial number
•Description of the problem
NOTE: Unauthorized returns will not be accepted and will be returned at the shipper’s expense.
NOTE: A returned product found upon inspection by AMETEK, to be in specification is subject to
an evaluation fee and applicable freight charges.

vi
This page intentionally left blank.

M550129-01 Rev A
i
FCC NOTICE
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own
expense.

M550129-01 Rev A
ii
ABOUT THIS MANUAL
This manual has been written expressly for the AMREL SPS-A Series of
power supplies that have been designed and certified to meet the Low
Voltage and Electromagnetic Compatibility Directive Requirements of the
European Community.
These models have been designed and tested to meet the Electromagnetic
Compatibility directive (European Council directive 2004/108/EC; generally
referred to as the EMC directive) and to the requirements of the Low Voltage
directive (European Council directive 2006/95/EC, 93/68/EEC, dated 22 July
1993). In addition these models have been found compliant with FCC 47
CFR Part 15, Subpart B 107(e) Class A, 109(g) Class A.
Since the Low Voltage Directive is to ensure the safety of the equipment
operator, universal graphic symbols have been used both on the unit itself
and in this manual to warn the operator of potentially hazardous situations
(see Safety Notice page).

M550129-01 Rev A iii
CONTENTS
SECTION 1 OVERVIEW..........................................1-1
1.1 General Description ...................................................................................................1-1
1.2 Specifications.............................................................................................................1-1
1.2.1 Environmental Characteristics..................................................................................1-2
1.2.2 Electrical Characteristics...........................................................................................1-2
1.2.3 SPS-A Series Voltage and Current Specifications ...................................................1-4
1.2.4 Physical Characteristics............................................................................................1-5
INSTALLATION.....................................................1-1
2.1 Inspection...................................................................................................................1-1
2.2 Contents of Shipment ................................................................................................1-1
2.3 Location and Mounting...............................................................................................1-2
2.3.1 Rack..........................................................................................................................1-3
2.3.2 6U Chassis Removal from Rack...............................................................................1-3
2.4 Input/Output Connections ..........................................................................................1-4
2.5 Wire selection ............................................................................................................1-6
2.5.1 Wire Size...................................................................................................................1-6
2.6 Load Considerations..................................................................................................1-9
2.6.1 Inductive Loads.........................................................................................................1-9
2.7 Outline Drawings........................................................................................................1-9
2.8 Installation Drawings................................................................................................1-12
OPERATION ..........................................................3-1
3.1 Introduction................................................................................................................3-1
3.2 Controls and Indicators..............................................................................................3-1
3.2.1 Front Panel ...............................................................................................................3-1
3.2.2 Shaft Lock (Option)...................................................................................................3-8
3.3 Local Operation..........................................................................................................3-9

CONTENTS AMREL SPS-A Series
iv M550129-01 Rev A
3.3.1 Floating and Polarized Output..................................................................................3-9
3.3.2 Initial Setup.............................................................................................................3-10
3.3.3 Voltage Mode Operation ........................................................................................3-10
3.3.4 Current Mode Operation.........................................................................................3-11
3.3.5 Overvoltage Protection...........................................................................................3-12
3.3.6 Analog Control Connector (J1)...............................................................................3-13
3.4 Remote Current Programming .................................................................................3-17
3.4.1 Remote Current Programming Using Resistance:.................................................3-17
3.4.2 Remote Current Programming Using a 0-5 or 0-10 VDC Voltage Source.............3-18
3.5 Remote Voltage Programming.................................................................................3-19
3.5.1 External Voltage Programming Using Resistance.................................................3-19
3.5.2 External Voltage Programming Using a 0-5 or 0-10 VDC Voltage Source...........3-20
3.6 Remote Sensing.......................................................................................................3-21
3.7 Remote Output ON/OFF Control..............................................................................3-23
3.7.1 Remote Output ON/OFF by Contact Closure.........................................................3-23
3.7.2 Remote Output ON/OFF Control by an External 12 to 240 VAC or 6 to 120 VDC or
TTL/CMOS Source.................................................................................................3-23
3.8 Remote Overvoltage Setpoint ..................................................................................3-24
3.9 Remote Shutdown (S/D) ..........................................................................................3-25
3.10 Parallel and Series Operation ..................................................................................3-26
3.10.1 Parallel Operation...................................................................................................3-26
3.10.2 Series Operation ....................................................................................................3-27
MAINTENANCE .....................................................4-1
4.1 Introduction.................................................................................................................4-1
4.2 Preventive Maintenance.............................................................................................4-1
4.3 Fuses..........................................................................................................................4-3
LIST OF TABLES
Table 2–1. 5kW to 15kW and 20kW to 30kW Series Input/Output Connectors............1-5
Table 2–2. Input Connections.......................................................................................1-5
Table 2–3. Output Connections....................................................................................1-5
Table 2–4. Minimum Wire Size.....................................................................................1-7
Table 2–5. Wire Resistance and Voltage Drop.............................................................1-7
Table 2–6. Maximum AC Current Ratings....................................................................1-8
Table 2–7. Recommended Lugs...................................................................................1-8
Table 2–8. Recommended Sense Connector Tools.....................................................1-8
Table 3–1. ANALOG CONTROL Connector (J1), Designations and Functions.........3-16
Table 4–1. Recommended Annual Inspection..............................................................4-2

Sorensen SGA Series CONTENTS
M550129-01 Rev A v
LIST OF FIGURES
Figure 1-1. Model Number Decoding ...............................Error! Bookmark not defined.
Figure 2-1. Diode Connection....................................................................................... 1-9
Figure 2-2. SPS-A Dimensions, 3U Model, 5kW to 15kW (40V-800V) ...................... 1-10
Figure 2-3. SPS-A Dimensions, 3U Model, 4kW to 15kW (10V-30V) ...Error! Bookmark
not defined.
Figure 2-4. SPS-A Dimensions, 6U Models, 20kW to 30kW...................................... 1-11
Figure 2-5. Rear Panel Input-Output Connector Locations, Models 40V-600V.......... 1-12
Figure 2-6. Rear Panel Input-Output Connector Locations, Models 10V-30V............ 1-13
Figure 2-7. 800V Rear Panel Input-Output Connector Locations............................... 1-14
Figure 2-8. SPS-A Detailed Chassis Dimensions for Installation, Models 40V-600V. 1-15
Figure 2-9. SPS-A Detailed Chassis Dimensions for Installation, Models 10V-30V... 1-16
Figure 2-10 SPS-A 800V Detailed Chassis Dimensions for Installation..................... 1-17
Figure 2-11. Instructions for Assembly of AC and DC Covers ................................... 1-18
Figure 3-1. SPS-A Front Panel Controls and Indicators (3U model shown)................. 3-1
Figure 3-2. SG Rear Panel with GPIB Option (40V-800V)........................................... 3-3
Figure 3-3. SG Rear Panel with GPIB Option (10V-300V)........................................... 3-3
Figure 3-4. SG Rear Panel with Ethernet Option (40V-800V)...................................... 3-5
Figure 3-5. SG Rear Panel with Ethernet Option (10V-30V)........................................ 3-5
Figure 3-6. SPS-A 6U Rear Panel with GPIB/RS232 Option Connectors.................... 3-7
Figure 3-7. Shaft Lock.................................................................................................. 3-8
Figure 3-8. ANALOG CONTROL Connector (J1) Pin-out ..........................................3-13
Figure 3-9. Remote Current Programming Using Resistance.................................... 3-17
Figure 3-10. Remote Current Programming Using 0-5 or 0-10 VDC Voltage Source 3-18
Figure 3-11. Remote Voltage Programming Using Resistance.................................. 3-19
Figure 3-12. Remote Voltage Programming Using 0-5 or 0-10 VDC Voltage Source 3-20
Figure 3-13. Local/Remote Voltage Sensing.............................................................. 3-21
Figure 3-14. Remote Sensing Operation at the Load................................................. 3-22
Figure 3-15. Remote Output ON/OFFControl by Contact Closure............................. 3-23
Figure 3-16. Remote Output ON/OFF Using Isolated AC or DC Voltage Source ...... 3-23
Figure 3-17. Remote Output ON/OFF Using Isolated TTL/CMOS Voltage Supply.... 3-24
Figure 3-18. Remote Overvoltage Set Using DC Voltage Source.............................. 3-24
Figure 3-19. Remote Shutdown Using DC Voltage Source........................................ 3-25
Figure 3-20. Parallel and Remote/Local Sense Connections..................................... 3-27

CONTENTS AMREL SPS-A Series
vi M550129-01 Rev A
This page intentionally left blank.

M550129-01 Rev A 1-1
SECTION 1
OVERVIEW
1.1 GENERAL DESCRIPTION
The AMREL SPS-A Series power supplies are general–purpose power
supplies designed specifically for laboratory test and systems applications
requiring variable DC sources with good ripple and regulation
characteristics. These power supplies are constant current/constant
voltage supplies with an automatic crossover feature.
A variety of user interfaces are available, ranging from manual front–panel
control and standard non–isolated remote analog control, to optional GPIB,
Ethernet or isolated remote analog control.
1.2 SPECIFICATIONS
The following subsections provide environmental, electrical, and physical
characteristics for the SPS-A Series power supplies.
Note: Specifications are subject to change without notice.
Note: The SPS-A Series power supplies are intended for indoor use only. Please
refer to Section 2.3 for use/location requirements.

Overview AMREL SPS-A Series
1-2 M550129-01 Rev A
1.2.1 ENVIRONMENTAL CHARACTERISTICS
Parameter Specification
Temperature
Coefficient 0.02%/°C of maximum output voltage rating for voltage set point.
0.03%/°C of maximum output current rating for current set point.
Ambient Temperature
Operating 0 to 50°C
Storage -25°to 65°C
Cooling Internal fans; vents on sides and rear. (Units may be stacked without
clearance above or below).
Humidity 95% maximum, non-condensing, 0 to 50°C; 45°C maximum wet-bulb
temperature.
Altitude Operating full power available up to 5,000 feet (1,524m),
derate 10% of full power for every 1,000 feet higher
non-operating to 40,000 feet (12,192m)
Agency Approvals CE Mark to the Low Voltage and EMC directives
NRTL approved to UL 1012, UL 61010, EN 61010, IEC 61010
1.2.2 ELECTRICAL CHARACTERISTICS
The voltage accuracy specifications are valid only with remote sense connected.
Parameter Specification
Input Power
Voltage (Standard) 208/230 VAC±10% (tested to 187-253 VAC)
Voltage (Options) 380/400 VAC±10% (tested to 342-440 VAC)
440/480 VAC±10% (tested to 396-528 VAC)
Frequency 47 to 63 Hz, 400 Hz
Phases 3–phase, 3–wire plus ground. Not phase rotation sensitive.
Neutral not used.
Front Panel Meter Accuracy
Voltage ±0.5% of full-scale + 1 digit
Current ±0.5% of full-scale + 1 digit
Load Regulation (Specified at no load to full load, nominal AC input)
Voltage 0.02% of maximum output voltage (40V – 800V)
0.05% of maximum output voltage (10V – 30V)
Current 0.1% of maximum output current
Line Regulation (Specified ±10% of nominal AC input, constant load)
Voltage 0.05% of maximum output voltage (10V – 30V)
0.01% of maximum output voltage (40V – 800V)
Current 0.05% of maximum output current
Transient Response A 50% step load will recover to within 0.75% of original value

AMREL SPS-A Series Overview
M550129-01 Rev A 1-3
Parameter Specification
within 1 ms.
Down Programming With no load the output will program from 100 to 10% in less
than 1.5 seconds
Stability ±0.05% of set point over 8 hours at fixed line, load, and
temperature, using remote sense and after 30 minute warm-up
Remote Control/Monitor On/Off control via contact closure, 6-120 VDC or 12-240 VAC,
and TTL or CMOS switch, output voltage and current monitor,
OVP limit set, summary fault status
Power Factor
>0.9 typical for 208/220VAC input (10V – 800V)
>0.78 typical for 380/400VAC input (40V – 800V)
>0.9 typical for 380/400VAC input (10V – 30V)
>0.7 typical for 440/480VAC input (40V – 800V)
>0.9 typical for 440/480VAC input (10V – 30V)
Efficiency 87% typical at full load, nominal line
Analog Remote Programming
Accuracy
Constant Voltage ±0.25% of full-scale output for 0-5V range (±0.5% 0-10V range)
Constant Current ±0.8% of full-scale output (±1% 0 – 10V range for 10V – 30V)
Overvoltage Protection (OVP) ±1% of full-scale output
Resistive
Constant Voltage (0-100%) 0–5 kΩ
Constant Current (0-100%) 0–5 kΩ
Voltage
Constant Voltage (0-100%) 0–5 VDC or 0–10 VDC
Constant Current (0-100%) 0–5 VDC or 0–10 VDC
OvervoltageProtection(OVP)(5-110%) 0.25–5.5 VDC
Remote Sensing
Terminals are provided to sense output voltage at point of load.
Maximum line drop 5% of rated voltage per line for 40-100V
models, line drop 1V of rated voltage per line for 10-20V
models, 1.5V for 30V models, 2% of rated voltage per line for
models 160V and greater. (Greater line drop is allowed, but
output regulation specifications no longer apply).

Overview AMREL SPS-A Series
1-4 M550129-01 Rev A
Parameter Specification
ISOLATED ANALOG CONTROL (OPTION)
Isolated Analog Control Input (J1) to
Output Isolation
600 V
Compliant with maximum terminal float voltage. Recommended
operation under SELV normal conditions.
(Standard Analog Control Input (J1) signals are referenced to
the negative output terminal and are therefore not isolated from
the output.)
1.2.3 SPS-A SERIES VOLTAGE AND CURRENT SPECIFICATIONS
Presented here are the voltage and current specification first for the 10V to 30V models
and then for the 40V to 800V models.
Amperage
Noise**
RMS Noise* P–P
Voltage 4 kW 5 kW 8 kW 10 kW 12 kW 15 kW
0-10V†† 0-400A N/A 0-800A N/A 0-1200A N/A 20 mV 50 mV
0-15V†† 267A N/A 534A N/A 801A N/A 20 mV 50 mV
0-20V†† N/A 250A N/A 500A N/A 750A
20 mV 60 mV
0-30V†† N/A 167A N/A 334A N/A 501A
20 mV 60 mV
