Ametek LANDSCAN LSP-HD Installation guide

Landscan LSP-HD Infrared Linescanners
i
QUALITY CUSTOMER SOLUTIONS
LANDSCAN LSP-HD
SYSTEM INSTALLATION OVERVIEW
PUBLICATION NO811372
LANGUAGE: ENGLISH

Health and Safety Information
Read all of the instructions in this booklet - including all the WARNINGS and CAUTIONS
- before using this product. If there is any instruction which you do not understand, DO
NOT USE THE PRODUCT.
Safety Signs
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in death or
personal injury.
CAUTION
Indicates a potentially hazardous situation which, if not avoided, could result in minor or
moderate injury to the user or users, or result in damage to the product or to property.
NOTE
Indicates a potentially hazardous situation which, if not avoided, could result in damage or the loss of
data.
Signs and Symbols used on equipment and Documentation
Caution, risk of electric shock.
Caution, attention to possibility of risk of damage to the product, process or surroundings. Refer
to instruction manual.
Caution, hot surface.
Protective Conductor Terminal.
Observe precautions for handling electrostatic discharge sensitive devices.
Equipment Operation
Use of this instrument in a manner not specied by Land Instruments International may be hazardous.
Read and understand the user documentation supplied before installing and operating the equipment.
The safety of any system incorporating this equipment is the responsibility of the assembler.
Protective Clothing, Face and Eye Protection
It is possible that this equipment is to be installed on, or near to, machinery or equipment operating at
high temperatures and high pressures. Suitable protective clothing, along with face and eye protection
must be worn. Refer to the health and safety guidelines for the machinery/equipment before installing
this product. If in doubt, contact Land Instruments International.
Electrical Power Supply
Before working on the electrical connections, all of the electrical power lines to the equipment must
be isolated. All the electrical cables and signal cables must be connected exactly as indicated in these
operating instructions. If in doubt, contact Land Instruments International.
Storage
The instrument should be stored in its packaging, in a dry sheltered area.
Unpacking
Check all packages for external signs of damage. Check the contents against the packing note.
Lifting Instructions
Where items are too heavy to be lifted manually, use suitably rated lifting equipment. Refer to the
Technical Specication for weights. All lifting should be done as stated in local regulations.
IMPORTANT INFORMATION - PLEASE READ

Health and Safety Information
Read all of the instructions in this booklet - including all the WARNINGS and CAUTIONS
- before using this product. If there is any instruction which you do not understand, DO
NOT USE THE PRODUCT.
Safety Signs
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in death or
personal injury.
CAUTION
Indicates a potentially hazardous situation which, if not avoided, could result in minor or
moderate injury to the user or users, or result in damage to the product or to property.
NOTE
Indicates a potentially hazardous situation which, if not avoided, could result in damage or the loss of
data.
Signs and Symbols used on equipment and Documentation
Caution, risk of electric shock.
Caution, attention to possibility of risk of damage to the product, process or surroundings. Refer
to instruction manual.
Caution, hot surface.
Protective Conductor Terminal.
Observe precautions for handling electrostatic discharge sensitive devices.
Equipment Operation
Use of this instrument in a manner not specied by Land Instruments International may be hazardous.
Read and understand the user documentation supplied before installing and operating the equipment.
The safety of any system incorporating this equipment is the responsibility of the assembler.
Protective Clothing, Face and Eye Protection
It is possible that this equipment is to be installed on, or near to, machinery or equipment operating at
high temperatures and high pressures. Suitable protective clothing, along with face and eye protection
must be worn. Refer to the health and safety guidelines for the machinery/equipment before installing
this product. If in doubt, contact Land Instruments International.
Electrical Power Supply
Before working on the electrical connections, all of the electrical power lines to the equipment must
be isolated. All the electrical cables and signal cables must be connected exactly as indicated in these
operating instructions. If in doubt, contact Land Instruments International.
Storage
The instrument should be stored in its packaging, in a dry sheltered area.
Unpacking
Check all packages for external signs of damage. Check the contents against the packing note.
Lifting Instructions
Where items are too heavy to be lifted manually, use suitably rated lifting equipment. Refer to the
Technical Specication for weights. All lifting should be done as stated in local regulations.
IMPORTANT INFORMATION - PLEASE READ
Contact Us
UK - Droneld
Land Instruments International
Tel: [phone]
Email: [email protected]
Web: www.landinst.com
USA - Pittsburgh
AMETEK Land, Inc.
Tel: [phone]
Email: [email protected]
Web: www.ametek-land.com
China
AMETEK Land China Service
Tel: [phone] ext 122
Email: [email protected]
Web: www.landinst.com
India
AMETEK Land India Service
Tel: +91 - 80 67823240
Email: [email protected]
Web: www.landinst.com
For further details on all AMETEK Land oces, distributors and representatives, please visit
our websites.
Return of Damaged Goods
IMPORTANT If any item has been damaged in transit, this should be reported to the carrier and to the
supplier immediately. Damage caused in transit is the responsibility of the carrier not the supplier.
DO NOT RETURN a damaged instrument to the sender as the carrier will not then consider a claim. Save
the packing with the damaged article for inspection by the carrier.
Return of Goods for Repair
If you need to return goods for repair please contact our Customer Service Department. They will be able
to advise you on the correct returns procedure.
Any item returned to Land Instruments International should be adequately packaged to prevent damage
during transit.
You must include a written report of the problem together with your own name and contact information,
address, telephone number, email address etc.
Design and Manufacturing Standards
The Quality Management System of Land Instruments International is approved to BS EN ISO 9001 for
the design, manufacture and on-site servicing of combustion, environmental monitoring and non-contact
temperature measuring instrumentation.
Approvals apply in the USA
Operation of radio transmitters, telephones or other electrical/electronic devices in close proximity
to the equipment while the enclosure doors of the instrument or its peripherals are open, may cause
interference and possible failure where the radiated emissions exceed the EMC directive.
The protection provided by this product may be invalidated if alterations or additions are made to the
structural, electrical, mechanical or pneumatic parts of this system. Such changes may also invalidate the
standard terms of warranty.
Copyright
This manual is provided as an aid to owners of Land Instruments International’s products and contains
information proprietary to Land Instruments International. This manual may not, in whole or part, be
copied, or reproduced without the expressed written consent of Land Instruments International Ltd.
Copyright © 2016 Land Instruments International.
MARCOM0311, Issue 7, 01 November 2016
Approvals apply in India

Infrared Linescanning System
Installation Overview
Landscan LSP-HD
Blank

Landscan LSP-HDInfrared Linescanning System
Installation Overview
Contents
1 Introduction 1-1
1.1 About this Guide 1-1
1.2 System Installation Sequence 1-1
2 TypicalSystemCongurations 2-1
2.1 BasicSingleLandscanCongurationwithProcessorConguration
SoftwareforTCP/IPcommunication 2-1
2.2 BasicSingleLandscanCongurationwithProcessorConguration
SoftwareandLSP-HDIOProcessor 2-2
2.3 BasicSingleLandscanCongurationwithWCASoftware 2-3
2.4 BasicSingleLandscanCongurationwithWCASoftwareand
LSP-HDIOProcessor 2-4
2.5 TwoScannerLandscanCongurationwithWCASoftwareand
oneLSP-HDIOProcessor 2-6
2.6 TwoScannerLandscanCongurationwithWCASoftwareand
twoLSP-HDIOProcessors 2-8
2.7 MultipleScannerLandscanCongurationwithWCASoftware
andoneLSP-HDIOProcessor 2-10
2.8 MultipleScannerLandscanCongurationwithWCAServerand
ClientSoftwareandoneLSP-HDIOProcessor 2-12
2.9 MultipleScannerLandscanCongurationwithWCAServerand
ClientSoftwareandmultipleLSP-HDIOProcessors 2-14
3 MountingAccessories 3-1
3.1 BasicMountingPlate-PartNº031.520 3-2
3.2 WaterCooled,AirPurgedBasePlate-PartNº031.496 3-3
3.3 RightAngleMountingPlate-PartNº031.438 3-4
3.4 EnhancedWaterCooledMountingSystem-PartNº800095 3-5
3.5 LightIndustrialHousing-PartNº802664 3-6
3.6 HeavyIndustrialHousing-PartNº802665 3-7
4 Blowers 4-1
5 PowerSupplies 4-1
5.1 LSP-HDDesktopPowerSupply-PartNº805024 5-1
5.2 LSP-HDIndustrialPowerSupplyonaDINRail-PartNº807105 5-2
5.3 LSP-HDIndustrialPowerSupplyinaTerminalBox-PartNº805037 5-3
6 Cables 6-1
7 SoftwareSetup 7-1
7.1 SoftwareRegistration 7-1
7.2 BasicSoftwareSetup 7-2
7.3 DataProcessing 7-12
7.4 Display 7-16
7.5 StorageManagement 7-19
7.6 Diagnostics 7-22
7.7 SaveConguration 7-24
7.8 ChangeConguration 7-24
7.9 SaveLPU/LSCConguration 7-25
7.10 ChangeLPU/LSCConguration 7-25
8 Maintenance&Service 8-1

INTRODUCTION
1

1 - 1
Landscan LSP-HDInfrared Linescanning System
Installation Overview
1Introduction
1.1 About this Guide
ThisdocumentprovidesanoverviewofthecomponentsavailableinaLandscanLSP-HD
InfraredLinescanningSystemandisintendedasaguidetotheinstallationandcommissioning
procedure.
Notethat,duetothevarietyofsystemcongurationsavailable,thereisnodenitive
‘standard’installationandcommissioningprocess.However,thisdocumentprovidesan
overviewofthetypicalstepsrequiredtocompleteinstallationandcommissioning.A
descriptionofthemostcommoncongurationsavailable,frombasicsinglescannersystemsto
multipleScannersystemswithI/Oprocessors,isgiveninSection2.
Readthisdocumentthoroughlypriortoinstallingyoursystem,referringalsototheuser
documentationprovidedwiththecomponentsofyourLSP-HDsystem.
1.2 System Installation Sequence
Atypicalinstallationandcommissioningsequenceisoutlinedbelow:
1) Install the MountingandverifythattheScannerisalignedcorrectlyonthetargeti.e.
thereisnothingintheeldofviewwhichobscuresthesighting:
• Makesurethatthereisnoframeworkorsimilarintheeldofview;
• Inordertoavoidreections,installthemountingsuchthatthescannerdoesnot
lookontorollers;
• Ifheatshieldsareinstalledthecutoutmustgivesucientspaceforthescan
angle(Maximum scan angle is 80°);
• Verifythatthemountingheightallowsthemaximumproductwidthtobecovered
bythemaximumscanangleof80°.
2) MakesurethatyouhavethecorrectCooling Water and Purge Air(withassociated
Blower)suppliessetupandoperational.Connectthesetothescannermountings
beforeinstallingit.
3) Choose an installation location for the Power Supply Unit such that it is shielded from
theprocessheatatthegivendistancetothescannerlocation(Thestandardlengthof
connectioncableis15m/48ft).Applythenecessarypowerconnections.
4) Connect the scanner Cabletothemounting.
5) ConnectthePoweroverEthernetSwitch(PoE Switch) to the PC or Network Switch.
• A Patch Cablecanbeusedforupto100m/330ftdistance:ifalongerdistance
isrequired,thenaFibrenetworkmustbeused.
6) IfaBeckho IOunitispartofthesystem,itmustalsobeconnectedtothenetwork
switch.
• Allcomponents,scannerandBeckhomustbeconnectedphysicallytothe
Networkbeforethesystemispoweredup.
7) InstalltheDataServerInstall(WCA Software) on the Server PC.
8) ApplyPower to all the system components.
9) Verify that all scanners and
Beckhoprocessorsarevisible
inthenetwork.Toverifythe
connectionusethe‘ping’command
from the command prompt as
shown.Therecommendednetwork
IPAddressofthePCrunningWCA
Softwareis10.1.10.25,subnet
255.255.0.0.
 Ifyouwishtocommunicateto
thescannerPCfromyourplant
network,werecommendttinga
secondNetworkInterfaceCardandaddressingittocomplywithyourplantnetwork.
 Inthisway,thescannerlivedatatracdoesnotaectyournetwork.

Infrared Linescanning System
Installation Overview
Landscan LSP-HD
1 - 2
10) SetupthecommunicationtotheScannerandBeckhoIO:
• All ScannersdeliveredfromAMETEKLandareshippedwiththesamedefault
IP Address: 10.1.10.100;
• All Beckho IOunitshaveadefaultIP Address: 10.1.10.110;
• Therefore,ifyouaresettingupamultiplescannersystem,thescannersmustbe
connectedtothenetworkinsequence.YouwillneedtochangetheIPaddress*
oftherstscannerconnectedtoavoidanyaddressconictinthenetwork.Itis
recommendedtochangetheIPfortherstscannerto10.1.10.101,andthe
second scanner to 10.1.10.102,andsoon.Thisalsoavoidsanyaddressconict
problemsifaspareorrepairedscannerwithadefaultIPaddresshastobe
integratedintoanexistingsystem.
• IfyouhavemultipleBeckhoIOunits,youwillalsoneedtochangetheirIP
addressesinasimilarmanner.i.e.settherstIPaddressto10.1.10.111 etc.
* InstructionsonhowtosettheIPaddressofeachcomponentinyourLSP-HDsystemare
giveninSection7.2.4ofthisGuide.

TYPICAL SYSTEM
CONFIGURATIONS
2

Infrared Linescanning System
Installation Overview
Landscan LSP-HD
Blank

2 - 1
Landscan LSP-HDInfrared Linescanning System
Installation Overview
2Typical System Configurations
Thissectiongivesanoverviewofthecomponentsandoptionsavailableintypical
congurationsofaLandscanLSP-HDsystem.Furtherinformationoneachcomponentisgiven
insubsequentsectionsofthisguide.
Identifywhichcongurationmatchesyoursystemandrefertotherelevantsectionsofthis
guideforinstallationandcommissioninginformation.
2.1 Basic Single Landscan Configuration with Processor Configuration
Software for TCP/IP communication
Item Component Option (IllustratedoptionsshowninBold text) Land Part Nº
1Scanner LSP-HD xx 80xxxx
2Mounting Basic Mounting Plate 031.520
•OptionalRightAngleBracket(Item2a) 031.438
WaterCooled,AirPurgedBasePlate 031.496
•OptionalRightAngleBracket(Item2a) 031.438
EnhancedWaterCooledMountingSystem 800095
LightIndustrialHousing(withAirPurging/WaterCooling) 802664
LightIndustrialHousing(withnon-reectiveheatshield) 806578
HeavyIndustrialHousing(withAirPurging/WaterCooling) 802665
WaterCooledPlate(SealedtoProcess) 805154
3 Cable LSP-HD Cable (Low Temperature) 15 m 805038
LSP-HDCable(LowTemperature)30m 807087
LSP-HDCable(HighTemperature)15m 804977
3a Adapter Cable M12 to RJ45 Cable 0.5 m* 805023
4PSU LSP-HD Desktop Power Supply 805024
LSP-HDIndustrialPowerSupplyonaDINRail 807105
LSP-HDIndustrialPowerSupplyinaTerminalBox*
*Adapter cable 805023 not required for use with 805037 805037
2
13
3a
4
Customer’sPC
ProcessorCongurationSoftware
suppliedwithLSP-HD
Customer’s RJ45
Ethernet cable

Infrared Linescanning System
Installation Overview
Landscan LSP-HD
2 - 2
2.2 Basic Single Landscan Configuration with Processor Configuration
Software and LSP-HD IO Processor
Item Component Option (IllustratedoptionsshowninBold text) Land Part Nº
1Scanner LSP-HD xx 80xxxx
2Mounting BasicMountingPlate 031.520
•OptionalRightAngleBracket 031.438
WaterCooled,AirPurgedBasePlate 031.496
•OptionalRightAngleBracket 031.438
Enhanced Water Cooled Mounting System 800095
LightIndustrialHousing(withAirPurging/WaterCooling) 802664
LightIndustrialHousing(withnon-reectiveheatshield) 806578
HeavyIndustrialHousing(withAirPurging/WaterCooling) 802665
WaterCooledPlate(SealedtoProcess) 805154
3 Cable LSP-HD Cable (Low Temperature) 15 m 805038
LSP-HDCable(LowTemperature)30m 807087
LSP-HDCable(HighTemperature)15m 804977
3a Adapter Cable M12toRJ45Cable0.5m 805023
4PSU LSP-HDIndustrialPowerSupplyonaDINRail 807105
LSP-HD Industrial Power Supply in a Terminal Box 805037
5 IO Processor LSP-HD I/O Processor 2/4/4/4 805773
LSP-HDI/OProcessor4/12/8/12 805774
5a IO PSU PSU for LSP-HD I/O Processor 805953
2
1
3
5a
4
OptionalPCforConguration/
DataDisplay
Customer’s RJ45
Ethernet cables
5

2 - 3
Landscan LSP-HDInfrared Linescanning System
Installation Overview
2.3 Basic Single Landscan Configuration with WCA Software
Item Component Option (IllustratedoptionsshowninBold text) Land Part Nº
1Scanner LSP-HD xx 80xxxx
2Mounting Basic Mounting Plate 031.520
• Optional Right Angle Bracket (Item 2a) 031.438
WaterCooled,AirPurgedBasePlate 031.496
•OptionalRightAngleBracket(Item2a) 031.438
EnhancedWaterCooledMountingSystem 800095
LightIndustrialHousing(withAirPurging/WaterCooling) 802664
LightIndustrialHousing(withnon-reectiveheatshield) 806578
HeavyIndustrialHousing(withAirPurging/WaterCooling) 802665
WaterCooledPlate(SealedtoProcess) 805154
3 Cable LSP-HD Cable (Low Temperature) 15 m 805038
LSP-HDCable(LowTemperature)30m 807087
LSP-HDCable(HighTemperature)15m 804977
3a Adapter Cable M12 to RJ45 Cable 0.5 m* 805023
4PSU LSP-HD Desktop Power Supply 805024
LSP-HDIndustrialPowerSupplyonaDINRail 807105
LSP-HDIndustrialPowerSupplyinaTerminalBox*
*Adapter cable 805023 not required for use with 805037 805037
5WCA Software Single Head License 804109
6 Workstation DELL Precision for 1 Scanner 806152
2a
2
1
3
3a
4
6
5

Infrared Linescanning System
Installation Overview
Landscan LSP-HD
2 - 4
2.4 Basic Single Landscan Configuration with WCA Software and LSP-HD
IO Processor
2
1
3
3a
4
8
5
5a
6
7
Customer’s RJ45
Ethernet cables

2 - 5
Landscan LSP-HDInfrared Linescanning System
Installation Overview
Item Component Option Land Part Nº
1Scanner LSP-HD xx 80xxxx
2Mounting BasicMountingPlate 031.520
•OptionalRightAngleBracket 031.438
WaterCooled,AirPurgedBasePlate 031.496
•OptionalRightAngleBracket 031.438
EnhancedWaterCooledMountingSystem 800095
LightIndustrialHousing(withAirPurging/WaterCooling) 802664
LightIndustrialHousing(withnon-reectiveheatshield) 806578
Heavy Industrial Housing (with Air Purging/Water
Cooling) 802665
WaterCooledPlate(SealedtoProcess) 805154
3 Cable LSP-HDCable(LowTemperature)15m 805038
LSP-HDCable(LowTemperature)30m 807087
LSP-HD Cable (High Temperature) 15 m 804977
3a Adapter Cable M12 to RJ45 Cable 0.5 m* 805023
4PSU LSP-HD Desktop Power Supply 805024
LSP-HDIndustrialPowerSupplyonaDINRail 807105
LSP-HDIndustrialPowerSupplyinaTerminalBox*
*Adapter cable 805023 not required for use with 805037 805037
5 IO Processor LSP-HDI/OProcessor2/4/4/4 805773
LSP-HD I/O Processor 4/12/8/12 805774
5a IO PSU PSU for LSP-HD I/O Processor 805953
6 WCA Single Head License 804109
7Workstation DELL Precision for 1 Scanner 806152
8 Switch Ethernet Switch 800983

Infrared Linescanning System
Installation Overview
Landscan LSP-HD
2 - 6
2.5 Two Scanner Landscan Configuration with WCA Software and one
LSP-HD IO Processor
2a
1
3a
4
8
5
5a
6
7
1
2b
3b
4
Customer’s RJ45 Ethernet cables

2 - 7
Landscan LSP-HDInfrared Linescanning System
Installation Overview
Item Component Option Land Part Nº
1Scanner LSP-HD xx 80xxxx
BasicMountingPlate 031.520
•OptionalRightAngleBracket 031.438
WaterCooled,AirPurgedBasePlate 031.496
•OptionalRightAngleBracket 031.438
2a Mounting Enhanced Water Cooled Mounting System 800095
LightIndustrialHousing(withAirPurging/WaterCooling) 802664
LightIndustrialHousing(withnon-reectiveheatshield) 806578
2b Mounting Heavy Industrial Housing (with Air Purging/Water
Cooling) 802665
WaterCooledPlate(SealedtoProcess) 805154
3a Cable LSP-HD Cable (Low Temperature) 15 m 805038
3b Cable LSP-HD Cable (Low Temperature) 30 m 807087
LSP-HDCable(HighTemperature)15m 804977
4PSU LSP-HDDesktopPowerSupply 805024
LSP-HDIndustrialPowerSupplyonaDINRail 807105
LSP-HD Industrial Power Supply in a Terminal Box 805037
5 IO Processor LSP-HDI/OProcessor2/4/4/4 805773
LSP-HD I/O Processor 4/12/8/12 805774
5a IO PSU PSU for LSP-HD I/O Processor 805953
6 WCA Server Installation 802427
7Workstation DELL Precision for 1 Scanner 806152
8 Switch Ethernet Switch 800983

Infrared Linescanning System
Installation Overview
Landscan LSP-HD
2 - 8
2.6 Two Scanner Landscan Configuration with WCA Software and two
LSP-HD IO Processors
2b
1
3a
4
8
5
5a
6
7
1
2a
3b
4
Customer’s RJ45 Ethernet cables
5
5a

2 - 9
Landscan LSP-HDInfrared Linescanning System
Installation Overview
Item Component Option Land Part Nº
1Scanner LSP-HDxx 80xxxx
2a Mounting Basic Mounting Plate 031.520
•OptionalRightAngleBracket 031.438
2b Mounting Water Cooled, Air Purged Base Plate 031.496
•OptionalRightAngleBracket 031.438
EnhancedWaterCooledMountingSystem 800095
LightIndustrialHousing(withAirPurging/WaterCooling) 802664
LightIndustrialHousing(withnon-reectiveheatshield) 806578
HeavyIndustrialHousing(withAirPurging/WaterCooling) 802665
WaterCooledPlate(SealedtoProcess) 805154
3a Cable LSP-HD Cable (Low Temperature) 15 m 805038
3b Cable LSP-HD Cable (Low Temperature) 30 m 807087
LSP-HDCable(HighTemperature)15m 804977
4PSU LSP-HDDesktopPowerSupply 805024
LSP-HDIndustrialPowerSupplyonaDINRail 807105
LSP-HD Industrial Power Supply in a Terminal Box 805037
5 IO Processor LSP-HDI/OProcessor2/4/4/4 805773
LSP-HD I/O Processor 4/12/8/12 805774
5a IO PSU PSU for LSP-HD I/O Processor 805953
•Either805773or805774tobeallocatedtoeachindividualscanner
6 WCA Server Installation 802427
7Workstation DELL Precision for 2-4 Scanners 806151
8 Switch Ethernet Switch 800983

Infrared Linescanning System
Installation Overview
Landscan LSP-HD
2 - 10
2.7 Multiple Scanner Landscan Configuration with WCA Software and
one LSP-HD IO Processor
2b
3a
4
8
6
7
1
2a
3b
4
Customer’s RJ45 Ethernet cables
5
5a
3b
1
1
2c
4
