amiad ADI-X User manual

Amiad Water Systems - ADI-X QSG 910101-001182 / 06.2021
Introduction
About the Quick Guide
This Quick Guide provides basic installation and operation instructions for your ADI-X
controller, with focus on the ADI-X mobile applications.
For a complete guide for using your ADI-X controller please refer to the ADI-X Manual
or scan the QR code.
About the ADI-X Controller
ADI-X by Amiad, is our most advanced smart controller for a wide range of filtration solutions.
By using the ADI-X, you will be able to receive real time data regarding your filter performance, relevant alerts,
technical and marketing updates. ADI-X allows you to modify various parameters for your filtration system remotely.
Supporting both Cloud and Bluetooth® wireless technology, ADI-X allows you to connect to your filter from any
mobile device or desktop, regardless of your location (while on the Cloud).
The ADI-X Controller Components
Take a few moments to familiarize yourself with the ADI-X Controller components:
1. Protection cover
2. LCD display
3. Left control button
4. Right control button
5. Water connection for internal DP sensors (inlet/piston/outlet)
6. Power cable gland
7. RJ-45 connection (optional)
8. External antenna SMA connection
NOTE: This document contains Amiad confidential information. Copying and distributing this document are strictly prohibited.

Amiad Water Systems - ADI-X QSG 910101-001182 / 06.2021
ADI-X Controller Buttons
There are two main buttons on the ADI-X controller control panel.
Following is the functionality description of the buttons:
Left button
Right button
Short push
Turn on display backlight
Start manual flush
Long push
Enter communication mode
Force full cloud synchronization
Batteries Installation/Replacement
The ADI-X controller is supplied with 4 x 1.5V Type D batteries supplied loose.
The estimated batteries’ lifetime is one year or about 80K flushes (whichever comes first).
To install/replace the batteries:
1. Remove the top cover by loosening the four screws.
2. Remove the two screws that secure the battery cover. This will allow access to the battery assembly.
3. Remove the battery assembly from the device and replace 4 x 1.5V Type D batteries.
4. Reinstall the battery assembly.
5. Close battery cover and tighten the screws.
6. Reassemble the top cover and tighten the screws.

Amiad Water Systems - ADI-X QSG 910101-001182 / 06.2021
ADI-X Desktop, ADI-X Mobile, and ADI-BLE Mobile Applications
The ADI-X controller can be controlled by three applications as follows:
1. ADI-X Desktop application connects to the controller via the cloud. It allows you to operate your controller by
remote access.
To access the ADI-X Desktop application go to the adix.amiad.com website.
2. ADI-X Mobile application connects to the controller via the cloud. It allows you to operate your controller by
remote access.
3. ADI-BLE Mobile application connects to the controller via Bluetooth® wireless technology.
The mobile device should be within a range of 10-15 meters from the controller. This application does not
require or support cloud services.
The free ADI-X and ADI-BLE mobile applications by Amiad Water Systems are available for download on Google Play
(Android version 5 and up) or the App Store (iOS version 9 and up).
Applications Preparation
ADI-X Desktop Application Sign Up
To create a new ADI-X user account:
1. Click "SIGN UP".
2. Enter your Email address and click "SEND".
3. A verification code will be sent to your email. Log into your email account, open the mail and copy your
verification code. Paste the verification code and click "Verify code".
4. Create your new password in the "New Password" field and reenter the new password in the "Confirm New
Password" field. Remember your password! Click "Create".
5. Enter your Full Name, Country, Company and Job Description. Click "Next".
6. Select your application language and units (METRIC or IMPERIAL). Click "SUBMIT".
7. Your ADI-X user account was created!

Amiad Water Systems - ADI-X QSG 910101-001182 / 06.2021
ADI-X Mobile Application Log In
Download and install the ADI-X Mobile application on your mobile device.
Log in using Email and password created earlier (see 4.1.1).
1. Enter your Email (used for signing up in ADI-X Desktop application). Click "CONTINUE".
2. Enter your password (created during sign up in ADI-X Desktop application). Click "SUBMIT".
ADI-BLE Mobile Application Registration
Download and install the ADI-BLE Mobile application on your mobile device. To register your account in the ADI-BLE
application:
1. Activate your mobile device’s Bluetooth® discovery mode and start the ADI-BLE application.
2. Click "OK" to start setting up your account.
3. Select your preferred system units (Metric or Imperial and click "OK".
4. Enter your Full Name, Email, Country, Company, and Job Description. Click "SUBMIT".
To skip this step, click "SKIP" in the upper right corner (completing these steps is recommended for better
support).
5. At this stage, your account was successfully created and is ready use.

Amiad Water Systems - ADI-X QSG 910101-001182 / 06.2021
Adding ADI-X Controller to a User Account
Adding an ADI-X controller to your user account can be done using the ADI-X Desktop application or the ADI-X
Mobile application. When the controller is added to your account it will be reflected on both applications.
The ADI-X controller can be added only to a single account – the owner account.
The owner can share the ADI-X controller with other users (see 5.2 ADI-X Controller Sharing).
To add your ADI-X controller to your account, you need to set the ADI-X controller in communication mode and get
the specific PIN code displayed, by following these instructions:
1. Open the ADI-X controller display protection cover.
2. If needed, Press the Left Button to enable LED backlight.
3. Press and hold the Left Button on the ADI-X controller until the 8-digit PIN code appears on the screen.
Adding ADI-X Controller using the ADI-X Mobile Application
To add ADI-X controller to a user account using ADI-X Mobile Application:
1. Open the ADI-X Mobile Application. Sign in with your email and password.
2. Click the "" in the “List of Sites” window.
3. Make sure the controller is turned on and in communication mode. Enter the 8-digit PIN code obtained from
the controller. Click "NEXT".
4. In “Site ID” screen enter your site name in the "Name Your Site" field, select filter model from the list, enter
filter serial number in "Filter Serial Number" field, add site picture by clicking the Site image icon. Click
"NEXT".
5. In “Site Information” screen select water source from the list, enter flow rate in "Flow Rate (m3/h)" field,
enter working pressure in "Working Pressure (BAR)" field, select filtration degree from the list. Click "NEXT".
6. In “Site Location” screen set the location of the site on the map. Click "NEXT".
7. In “Payment” window you should confirm the payment notice. At this stage, your controller is connected to
your account and ready for use! Click “Next”.
8. At this stage your controller was connected to your user account and ready for use! Click "SUBMIT".
Left button

Amiad Water Systems - ADI-X QSG 910101-001182 / 06.2021
Pairing ADI-X Controller using the ADI-BLE Mobile Application
Notice: Pairing the ADI-X controller with the Bluetooth® application will utilize part of the full list of features
available in the cloud applications. Amiad recommends pairing the ADI-X controller with the dedicated ADI-X
applications (Mobile and Desktop).
To pair the controller with the ADI-BLE Mobile Application:
1. Verify your mobile device’s Bluetooth® discovery mode is activated. To start pairing with the ADI-X
controller, click " " in the window. The application scans for controllers within the Bluetooth® range (10-
15 meters).
2. Select your controller from the controllers list in range. The application will start pairing.
3. Verify that the blue/green LED on your controller is blinking. Click "YES" to confirm.
4. At the end of the pairing process, complete the Site ID form: name your site, enter filter model and
controller serial number if needed. You may add a site photo by clicking on "Add Photo". Click " ".
5. Enter the Site Information details (optional), Click "SUBMIT" to add your new filter to the Sites List.
6. To view data from your controller, select the active controller from the “Sites List”, marked by the active
Bluetooth® icon.
1.
