Amica 601GE1.33ZYFG User manual

IOAK-1023 / 8034979
(02.2008./1)
601GE1.33ZYFG(W)
601GE2.33ZpYFG(Xx)
INSTRUCTION MANUAL
GAS COOKER

2
DEAR CUSTOMER,
The cooker is exceptionally easy to use and extremely efcient. After reading the instruction
manual, operating the cooker will be easy.
Before being packaged and leaving the manufacturer, the cooker was thoroughly checked
with regard to safety and functionality.
Before using the appliance, please read the instruction manual carefully.
By following these instructions carefully you will be able to avoid any problems in using the
appliance.
It is important to keep the instruction manual and store it in a safe place so that it can be
consulted at any time.
It is necessary to follow the instructions in the manual carefully in order to avoid possible
accidents.
Caution!
Do not use the cooker until you have read this instruction manual.
The cooker is intended for household use only.
The manufacturer reserves the right to introduce changes which do not affect the
operation of the appliance.

3
Safety instructions ............................................................................................................. 4
Description of the appliance ............................................................................................. 9
Installation......................................................................................................................... 12
Operation........................................................................................................................... 17
Baking in the oven – practical hints ............................................................................... 23
Cleaning and maintenance.............................................................................................. 29
Technical data................................................................................................................... 33
TABLE OF CONTENTS

4
SAFETY INSTRUCTIONS
The appliance becomes hot during operation. Take care not to touch the hot parts inside
the oven.
Please pay attention to children whilst the cooker is in operation, as children do not know
the rules of cooker use. In particular, hot surface burners, the oven chamber, grates,
the door pane, and pans containing hot liquids standing on the hob may cause burns to
children.
Mind that electrical connection leads from other home appliances (e.g. of a food mixer)
do not touch hot parts of the cooker.
 Donotplaceammablematerialintothedrawerwhilstusingtheoven,asitmaycatcha
re.
 Do not leave the cooker unattended when frying. Oils and fats may catch re due to
overheating.
At the point of boiling, mind to avoid spills on the burner.
 Ifthecookerisdamaged,itmaybeusedagainonlyafterthefaulthasbeenxedbya
specialist.
Do not open the tap on the gas connection or cylinder valve before checking that all burner
knobs are closed.
Do not allow the burners to be soiled or liquids to spill on the burners. If soiled, clean and
dry burners immediately after they have cooled down.
Do not put pans directly onto burners.
Do not place pans with a weight greater than 10 kg onto the grate over one burner, or
pans with a total weight of over 40 kg on the whole grate.
Do not hit the knobs and burners.
Do not put objects with a weight greater than 15 kg onto the open oven door.
 Alterationsandrepairscarriedoutbyanunqualiedpersonarenotallowed.
Do not open the cooker knobs before already having a lighted match or a gas lighter in
your hand.
 Donotputoutaburneramebyblowing.
Before opening the cover, cleaning it of any dirt is recommended. The cooker hob surface
should be cooled down before closing the cover.
A glass cover may crack when heated. Switch off all the burners before lowering the cover.
(Cookers with a glass cover).

5
SAFETY INSTRUCTIONS
Do not make your own alterations to the cooker in order to adapt it to a different type
of gas, move the cooker to another place or make changes to the power supply. These
operationsmayonlybecarriedoutbyanauthorisedelectricianortter.
Do not use harsh cleaning agents or sharp metal objects to clean the door as they can
scratch the surface, which could then result in the glass cracking.
Keep young children and people not acquainted with the instruction manual away from
the cooker.
IN CASE OF ANY SUSPICION OF GAS LEAKAGE YOU MUST NOT:
light matches, smoke cigarettes, switch electrical receivers (door bell or light switch) on
and off, or use other electric and mechanical devices that create electrical or percussive
sparks. In such a case, immediately close the cylinder valve or tap cutting off gas supply,
air the room, and then call a person authorised to repair the source of the leakage.
In the event of any incident caused by a technical fault, disconnect the power (applying
the above rule) and report the fault to the service centre to be repaired.
Do not attach any antenna cords (e.g. radio) to the gas supply.
 Inacaseofgasescapingfromleakypipingandcatchingre,closegassupplyimmediately
using a cutting-off valve.
 Inacaseofgasescapingfromaleakycylinderandcatchingre:throwawetblanketover
the cylinder to cool it down and turn off the cylinder valve. After it has cooled down, take
the cylinder out to an open space. Do not use the damaged cylinder.
When the cooker is not to be used for several days, close the main valve on the gas pip-
ing; when using a gas cylinder, close it after each use.
The cooker should not be cleaned using steam cleaning equipment.

6
SAFETY INSTRUCTIONS
VENTILATION
The use of a gas cooking appliance results
in the production of heat and moisture in the
room in which it is installed. Ensure that the
kitchen is well ventilated: keep natural ventila-
tion holes open or install a mechanical ven-
tilation device (mechanical extractor hood).
Prolonged intensive use of the appliance
may cali for additional ventilation, for exam-
ple, opening of a window, or more effectiye
ventilation, for example increasing the level of
mechanical ventilation where present.
GAS & ELECTRICAL CONNECTION
Please refer to installation instructions for the
Gas & Electrical Safety Regulations and the
Ventilation Requirements.
In your own interest, and that of safety, it is
thelawthatallgaśappliancesbeinstalledby
competent persons, who will ensure that the
installation is in accordance with „The Gas
Safety (Installation & Use) Regulations 1994”,
& the „The Gas Safety (Installation & Use)
(Amendment) Regulations 1996”. Failure to
comply with these Regulations is a criminal
offence. CORGI registered installers under-
take to work to satisfactory standards.
Disconnection of gas and electric appliances
should always be carried out by competent
persons.
Warmng: This appliance must be earthed.
MOVING THE COOKER
Do not attempt to move the cooker by pulling
on the doors or handles. Open the door and
grasp the frame of the cooker, taking care that
thedoordoesnotshutonyourngers.
Take care to avoid damage to soft or uneven
oorcoveringswhenmovingtheappliance.
Somecushionedvinyloorcoveringsmaynot
be designed to withstand sliding appliances
without marking or damage.

7
HOW TO SAVE ENERGY
Using energy in a respon-
sible way not only saves
money but also helps the
environment. So let’s save
energy! And this is how you
can do it:
Use proper pans for cooking.
A saucepan should never be smaller than a
burner crown.
Always remember to cover and pans.
Ensure burners, the grate the hob are
clean.
Soils can prevent heat transfer – and repeat-
edly burnt-on spillages can often only be
removed by products which cause damage
to the environment.
Inparticular,ensurethatameopeningsin
the rings under caps, and openings of burner
nozzles are clean.
Do not uncover the pan too often (a
watched pot never boils!).
Do not open the oven door unnecessarily
often.
Only use the oven when cooking larger
dishes.
Meat of up to 1 kg can be prepared more
economically in a pan on the cooker burner.
Make use of residual heat from the
oven.
If the cooking time is greater than 40 minutes
it is recommended to switch off the oven 10
minutes before the end time.
Make sure the oven door is properly
closed.
Heat can leak through spillages on the door
seals. Clean up any spillages immediately.
Do not install the cooker in the direct
vicinity of refrigerators/freezers.
Otherwise energy consumption increases
unnecessarily.

8
During transportation, protec-
tive packaging was used to
protect the appliance against
any damage. After unpack-
ing, please dispose of all
elements of packaging in a
way that will not cause dam-
age to the environment.
All materials used for packaging the appli-
ance are environmentally friendly; they are
100% recyclable and are marked with the
appropriate symbol.
Caution! During unpacking, the packag-
ing materials (polythene bags, polystyrene
pieces, etc.) should be kept out of reach of
children.
UNPACKING DISPOSAL OF THE APPLIANCE
Old appliances should not sim-
ply be disposed of with normal
household waste, but should
be delivered to a collection and
recycling centre for electric and
electronic equipment. A symbol
shown on the product, the in-
struction manual or the packag-
ing shows that it is suitable for recycling.
Materials used inside the appliance are
recyclable and are labelled with information
concerning this. By recycling materials or
other parts from used devices you are making
asignicantcontributiontotheprotectionof
our environment.
Information on appropriate disposal centres
for used devices can be provided by your
local authority.

9
DESCRIPTION OF THE APPLIANCE
Spark ignitor
Burner safety valve
1
3, 4 5, 6
14
9
10
11
1Temperature/function oven control knob
2 Push-button ignition
3, 4, 5, 6 Gas burner control knobs
7Temperatureregulatorsignal light red
8Cooker operation signal light yellow
9 Oven door handle
10 Drawer
11 Large burner
12 Medium burner
13 Medium burner
14 Small burner
2
12 13
78
601GE1.33ZYFG(W)

10
DESCRIPTION OF THE APPLIANCE
Spark ignitor
Burner safety valve
1
3, 4 5, 6
14
2
10
11
1Temperature control knob
2Oven function selection knob
3, 4, 5, 6 Gas burner control knobs
7Temperatureregulatorsignal light red
8Cooker operation signal light yellow
9 Oven door handle
10 Drawer
11 Large burner
12 Medium burner
13 Medium burner
14 Small burner
12 13
78
9
601GE2.33ZpYFG(Xx)

11
SPECIFICATIONS OF THE APPLIANCE
Oventtings:
Baking tray* Grill grate
(drying rack)
Roasting tray
*optional

12
INSTALLATION
Before you start: Please read the instructions.
Planning your installation will save you time
and effort.
Prior to installation, ensure that the local
distribution conditions (nature of the gas
and gas pressure) and the adjustment of the
appliance are compatible. The adjustment
conditions are stated on the data badge.
This appliance is not connected to a combus-
tion evacuation device. It shall be installed
and connected in accordance with current
installation regulation. Particular attention
shall be given to the relevant requirements
regarding ventilation.
In your own interest and that of safety, it is
thelawthatallgaśappliancesbeinstalled
and serviced by competent persons. CORGI
registered installers undertake to work to
satisfactory standards.
Where regulations or standards have been
revised since this handbook was printed,
always use the latest edition.
In the UK the regulations and standards
are as follows:
1. Gas Safety Regulations 1996 (Instal-
lation and Use).
2. Building Regulations - Issued by the De-
partment of the Environment.
3. Building Standards (Scotland) (Consoli-
dated) - Issued by the Scottish Development
Department.
4. The current l.E.E. Wiring Regulations.
5. Electricity at Work Regulations 1989.
6. BS 6172 Installation of Domestic Gas
cooking Appliances.
7. Installation & Servicing Instructions for this
appliance.
For installation in countries other than the
UK, the appliance must be connected in
accordance with all local gas and electrical
regulations.
Ventilation Requirements
The room containing the appliance should
have an air suppły in accordance with
BS5440: Part2: 1989:
Ali rooms require an openable window, or
equivalent, and some rooms will require a
permanent vent as well.
For room volumes up to 5m3an air vent of
lOOcm2is required.
Iftheroomhasadoorthatopensdirectły
to the outside, or the room exceeds 10m3,
NO AIR VENT is required.
For room volumes between 5m3and 10m3
an air vent of 50cm2is required.
Iftherearęotherfuelburningappliances
in the same room, BS 5440: Parł 2: 1989
should be consulted to determine the air vent
requirements.
This appliance must not be installed in
a bed sitting room of less than 20m3or in
a bathroom or shower room. Windows and
permanent vents should therefore not be
blockedorremoyedwithoutrstconsulting
a CORGI gas installer.
Failure to install appliances correctly
is dangerous and could lead to prosecu-
tion.
Important:
Whilst every care is taken to eliminate burrs
and raw edges from this product, please take
care when handling - we recommend the use
of protective gloves during installation.
Please note that the weight of this appliance
is approximately 40kg (unpacked).
Take care if the appliance needs to be lifted
during installation - always use an appropriate
method of lifting.

13
INSTALLATION
Clearances
No shelf or oyerhang or cooker hood should
be closer than a minimum of 650mm, but
check with cooker hood manufacturer’s rec-
ommendations.
The cooker must have a side clearance
above hob level of 90mm up to a height of
400mm.
Checkthattherearęnoprojectionsintherear
waliwhichwillpreyentthelid(wheretted)
being raised to the vertical position.
Thiscookermaybettedushtobaseunits.
However, for models with side opening doors,
we recommend a side clearance of 6Omm
between the cooker and any side wall.
This is a type X appliance regarding installa-
tion requirements.
Important:
Ensure that you route all mains cables well
clear of any adjacent heat source.
Thecookershouldstandonahard,evenoor
(do not put it on a base).
Levelling
Before you start using the cooker it should be
leveled, which is particularly important for fat
distribution in a frying pan. To this purpose,
adjustable feet are accessible after removal
of the drawer. The adjustment range is +/- 5
mm.
HOOD
400
mm
400
mm
650
mm
Connect to the electricity supply
Warmng: This appliance must be earthed.
The cooker is manufactured to work with
a one-phase alternating current (220-
240V~50 Hz) and is equipped with a 3
x 1,5 mm2connection lead of 1.5 mm
length with a plug including a protection
contact.
A connection socket for electricity supply
should be equipped with a protection
pin and may not be located above the
cooker. After the cooker is positioned, it is
necessary to make the connection socket
accessible to the user.
Before connecting the cooker to the
socket, check if:
- the fuse and electricity supply are able to
withstand the cooker load,
- the electricity supply is equipped with an
efcaciousgroundsystemwhichmeets
the requirements of current standards
and provisions,
- the plug is within easy reach.
Important:
Ifthexedpowersupplycableisdamaged,
it should be replaced at the manufacturer
or at an authorized servicing outlet, or by a
qualiedpersontoavoiddanger.

14
INSTALLATION
Connect to the gas suppły
The iniet to the cooker is 1/2” BSP internal
situated at the rear corner.
Fit the bayonet connection. This should be
locatedsoastoensurethattheexiblecon-
nector hose does not kink.
Use a 900-1125mm length of exible con-
nector.
Ensurethatallpipęworkisofthecorrectrat-
ing for both size and temperature.
Flexible connections should comply with BS
669. Parts of the appliance likely to come
intocontactwithaexibleconnectorhavea
temperaturęriseoflessthan70°C.
After installałion, make sure all connec-
tions are gas sound.

15
INSTALLATION
Burner ame Re-arming from liquid
gas
to natural gas
Re-arming from natural
gas
to liquid gas
Full
1. Exchange a burner noz-
zle for the appropriate type
according to the nozzle
table.
Economical
1. Exchange a burner
nozzle for the appropriate
type according to the noz-
zle table.
2. Unscrew an adjusting
bolt slightly and adjust the
amesize.
2. Screw in an adjusting
bolt slightly to the end and
checktheamesize.
In order to perform adjusting operations, take off the knobs. Adjusting elements of the
ovenburnerareaccessibleafterdrawingouttheovenchamberoor.
Type of gas
burner
injector size
large
medium
small
Natural G20 /20 mbar 1,24
0,84
1,09
0,67
0,75
0,52
LPG G30 /28 mbar
Adapting the cooker to another type of
gas.
This operation may only be carried out by an
appropriatelyauthorisedtter.
If the gas the cooker is to be supplied with
differs from the gas provided for the cooker
by the manufacturer, that is G20 20 mbar,
burner nozzles must be exchanged and the
ameneedstobeadjusted.
In order to adapt the cooker to burn a different
type of gas, you should:
exchange nozzles (see tables below),
 adjustthe“economical”ame.
Warning:
The cookers provided by the manufacturer
have burners which are factory-adapted to
usethegasspeciedontheirdataplates.

16
Surface burners applied do not require adjust-
mentofprimaryair.Acorrectamehasdis-
tinct internal cones of blue and green colour.
Ashort,hummingameorlong,yellowand
smoking one, without clearly outlined cones,
shows improper quality of gas in the house-
hold piping or a damaged or soiled burner.
Inordertocheckaame,heataburnerfor
around10minuteswithafullame,andnext
turnthevalveknobtotheeconomicalame
position.Theameshouldnotgooutorjump
onto the nozzles.
INSTALLATION
Caution!
Adapting the appliance to a different
type of gas than that indicated by the
manufacturer of the cooker on the
data plate, or purchasing a cooker for
a different type of gas than supplied to
the house, is exclusively the responsi-
bilityoftheuserandthetter.
Gas supply to surface burners is opened and
setbyknobs,g.A.Knobsshouldbeadjusted
with the burner switched on and set to the
economicalameposition,usinganadjust-
ment screwdriver of the 2.5 mm size.
Exchange of a burner noz-
zle – unscrew the nozzle
with special socket span-
ner No 7 and replace with
a new one according to a
type of gas (see tables).
Caution!
After adjustment is completed, place
a label indicating the type of gas to
which the cooker is now adapted.

17
Before rst use
remove packaging elements,
gently (slowly) remove labels from the
oven door, trying not to break the glue
tape.
empty the drawer, clean off factory pre-
servatives from the oven chamber,
 takeoutandwashtheoventtingswith
warm water and a little washing-up liq-
uid,
switch on the ventilation in the room or
open a window,
 heattheoven(toatemperatureof250°C,
for approximately 30 min.), remove any
stains and wash carefully.
The oven chamber should only be washed
with warm water and a small amount of
washing-up liquid.
when handling the cooker, follow the
safety instructions carefully.
OPERATION

18
Push-button
ignition*
press the spark ignition push-button
marked with ....,
press in the knob to the end and turn it
lefttothe“largeame”position
hold down until gas has lit,
settherequiredamesize(e.g.“economi-
cal” ),
switchofftheburnerafternishingcook-
ing, turning the knob right (to the off
position).
OPERATION
How to use surface burners
Choice of cookware
Mind that the diameter of a pan base is always
largerthantheburneramecrown,andthat
the pan itself is covered. The recommended
pan diameter is around 2.5 to 3 times larger
than the burner diameter, that is, for:
an auxiliary burner – a pan with a diameter
of 90 to 150 mm,
a medium burner – a pan with a diameter
of 160 to 220 mm,
a large burner – a pan with a diameter of
200 to 240 mm, and the pan height should
not be greater than its diameter.
Ignition without an ignitor
light a match,
press in the knob to the end and turn it
lefttothe“largeame”position
ignite gas with a match,
setrequiredamesize(e.g.“economical”
),
switch off the burner after finishing
cooking, turning the knob right (to the off
position).
Gas burner control knobs
Position
burner “switched off”
Position
“large ame”
Position
“economical ame”
Knob ignition*
press in the knob to the end and turn it left
tothe“largeame”position,
hold until gas is lit,
aftertheameislightedreleasethepres-
sureontheknobandsetarequiredame
size.
WRONG
RIGHT
*optional

19
OPERATION
Selection of the appropriate ame
A correctly adjusted burner has a light blue
amewithaclearlyvisibleinternalcone.Se-
lectionofamesizedependsontheposition
of the burner knob which has been set:
largeame
smallame(“economicalame”)
 burner switched off (gas supply is cut off)
Dependingonrequirements,amesizecan
be set in a continuous manner.
Caution!
In cooker models equipped with a
surface burner safety valve, hold the
knob pressed down to the end when
igniting for 10 seconds at the “large
ame”positiontoactivatethesafety
device.
Caution!
Donotadjusttheamebetweenthe
off position  and the large ame
position
Operation of the burner protection valve
Some models are equipped with an automatic
system that cuts off gas supply to a burner
whentheamehasdisappeared.
This system protects the cooker against gas
leakagewhentheameonaburnergoesout
e.g. in case of spillage.
The user’s intervention is needed to re-ignite
the burner.
RIGHT
WRONG

20
Separate oven lighting
By setting the knob to this posi-
tion, the lighting inside the oven is
switched on. Use, for example, when
washing the oven chamber.
Bottom and top heaters on
The thermostat enables the user
to set the temperature within a
range from 50°C to 250°C. Use
for baking.
Grill heater on
Setting the knob to this position
allows dishes to be grilled on the
grate or rotisserie.
Bottom heater on
When the knob is set to this po-
sition, the oven is heated using
only the bottom heater. Use for,
e.g.nalbakingfromthebottom.
OPERATION
Oven functions and operation.
The oven can be heated up using the bottom
and top heaters, and the grill (if any). The
oven is controlled by one knob handling,
serving as a work type switch integrated with
a temperature regulator.
Natural convection oven
(conventional)
Caution!
In cooker models which do not have
a grill, the position is not present
on the knob.
Possible knob positions
Oven on and off
In order to switch on the oven you need to:
set required working conditions of the
oven, its temperature and a mode of
heating,
set the knob to the required position, turn-
ing it right.
Switching on the oven is indicated by two
signal lights, yellow and red, turning on. The
yellow light turned on means the oven is work-
ing. If the red light goes out, it means the oven
has reached the set temperature. If a recipe
recommends placing dishes in a warmed-up
oven, this should be not done before the red
lightgoesoutforthersttime.Whenbaking,
the red light will temporarily come on and go
out (to maintain the temperature inside the
oven). The yellow signal light may also turn
on at the knob position of “oven chamber
lighting”.
Switching off the oven – in order to switch off
the oven, set the knob to the “0” knob position,
turning it left. The signal light should go out.
Top heater on
When the knob is set to this po-
sition, the oven is heated using
only the top heater, e.g. use for,
nalbakingfromabove.
50
100
150
200
250
