AGH7100 &
AGVH7300
Gas hobs
Installation, use and maintenance

2
Contents:
3 Important safety warnings
4 Important safety warnings and appliance information
6 Using Your Hob
7 Hob layout(s)
9 Igniting the burners
10 Ecient use of your hob
11 Care And Maintenance- AGH7100
12 Care And Maintenance- AGVH7300
13 Troubleshooting
14 What to do if you smell gas
17 Preventing unsafe conditions
18 Mains Electricity Connection
19 Gas Supply Requirements
20 Ventilation
21 Natural Gas to LPG Conversion
22 LPG to Natural Gas Conversion
22 Fitting the hob
24 How to install the hob
25 Installation diagrams
26 Energy eciency information
IMPORTANT: THIS APPLIANCE MUST BE INSTALLED BY GAS
SAFE REGISTERED PERSONS, IN COMPLIANCE WITH THE
CURRENT REGULATIONS AND ONLY INSTALLED IN ROOMS
EQUIPPED WITH ADEQUATE VENTILATION. CONSULT THIS
ENTIRE MANUAL BEFORE PROCEEDING WITH INSTALLATION
OR USE OF THE APPLIANCE. DO NOT MODIFY THE HOB IN ANY
WAY. TO DO SO MAY BE DANGEROUS.

3
Important safety warnings
1. It is a legal requirement that all gas appliances are installed by
qualified personnel and only in accordance with current legislation. It
is your responsbility to ensure compliance with the law.
2. Repairs or servicing of this product must only be carried out by an
authorised service agent using approved parts.
3. No attempt must be made to modify this appliance under any
circumstances.
4. Cooking appliances can become very hot in use – please keep
children and pets away from them at all times.
5. Do not allow children to operate or play with any part of the
appliance.
6. Do not use unstable pans and ensure that the handle is positioned
away from the edge of the worktop.
7. In the interest of hygiene and safety, please ensure the hob is kept
clean.
8. This appliance is designed for domestic cooking only. Commercial
use will invalidate the warranty.
9. Do not cover the hob or place combustible materials on or near the
surface even when the hob is not in use.
10. Do not fill deep fat frying containers more than one thrid full of oil
and never leave unattended.
11. If the supply cable is damaged it must be replaced by a CDA
authorised service agent or qualified person only.
12. Do not immerse the appliance or the power cable into water or any
other liquid.
13. Any gas regulator used must comply with EN 16129 or EN 12864
and local and national regulations. Make sure of the outlet pressure
before connecting the regulator to the product.

4
Important safety warnings
The manufacturer cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product.
Please note that we reserve the right to invalidate the guarantee
supplied with this product following incorrect installation or misuse of
the appliance.
This appliance is not designed to be used by people (including
children) with reduced physical, sensorial or mental capacity, or
who lack experience or knowledge about it, unless they have had
supervision or instructions on how to use the appliance by someone
who is responsible for their safety.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number
EU Declarations of Conformity:
This appliance has been manufactured to the strictest standards and
complies with all applicable legislation, including Gas safety, Electrical

5
safety (LVD) and Electromagnetic interference compatibility (EMC).
Parts intended to come into contact with food conform to 1935/2004/
EC.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EU DIRECTIVE 2012/19/EU.
At the end of its working life, the product must be taken to a special
local authority waste collection centre or to a dealer providing
appliance recycling services.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health. It also
enables the constituent materials to be recovered, saving both energy
and resources. As a reminder of the need to dispose of household
appliances separately, the product is marked with a crossed-out
wheeled dustbin.
Please note:
•Gas hobs become hot and remain hot during and immediately after
use. Do not touch the pan stands, burners or hob spill tray until the
appliance has been allowed to cool.
•Keep children away from the appliance when in use.
•After use, please ensure that the gas taps are in the ‘O” position.
•Ensure that the appliance is correctly adjusted for the type of gas
available before installation.
•The use of a gas appliance produces heat and humidity in the room
in which it is installed. Ensure that the room is well ventilated, either
by the use of natural ventilation outlets (e.g. windows) or a ducted
extractor.

6
•This hob (Class 3) has been designed for use only as a cooking
appliance. Any other use (e.g. heating rooms) should be considered
incorrect and potentially dangerous.
•These instructions are valid only for the countries of destination, the
symbols of which appear the appliance.
Using your hob
Gas burners:
Gas flow to the burners is controlled by the control knobs (5, 6, 7, 8 and
9 on the diagrams on pages 6 & 7). There are 3 positions shown on the
control panel. Turning the control knob to the positions shown below
achieves the following:
Closed (OFF position)
Maximum position: Provides fast boiling function
Minimum position: Provides simmer function
The burners can be set to the desired position by turning the control
knobs through the adjustment range in an anti-clockwise direction.
Fig. 1

7
AGH7100
Fig. 2
AGVH7300
Fig. 3
3
3
2
4
5 6 7 8 9
1
5 6 7 8 9
3
3
2
4
1

8
Key to Fig 2
Gas burners:
1. Triple burner 3.8kW
2. Rapid burner 3.0kW
3. Semi-Rapid burner 1.75kW
4. Auxiliary burner 1.0kW
Control panel:
5. Front left burner control knob
6. Back left burner control knob
7. Centre burner control knob
8. Back right burner control knob
9. Front right burner control knob
Key to Fig 3
Gas burners:
1. Triple burner 3.8kW
2. Rapid burner 3.0kW
3. Semi-Rapid burner 1.75kW
4. Auxiliary burner 1.0kW
Control panel:
5. Front left burner control knob
6. Back left burner control knob
7. Centre burner control knob
8. Back right burner control knob
9. Front right burner control knob
These appliances are class 3

9
Igniting the burners
The hob is fitted with flame failure de-
vices on each burner. Flame failure de-
vices operate by shutting o the supply
of gas to the burner in the event that
the flame is extinguished accidentally.
To ignite the burners, follow these
instructions:
1. Lightly press the control knob down and turn the knob anti-
clockwise to the maximum position. Firmly press and hold down
the control knob to begin the ignition process (a clicking sound
will be heard). Hold down the control knob for a few seconds
(sometimes up to 10) after ignition to allow the safety device to
detect that the burner is lit.
2.Once the burner is lit, adjust the burner power to the required
position.
Please note:
• The ignition device should not be operated for more than 15
seconds.
• If a burner does not ignite, or turns o accidentally, turn the
control knob to the ‘o’ position, and wait for one minute before
attempting to reignite the burner.
• If the burner does not ignite, repeat the ignition process with the
burner at the minimum position.
• Switch all controls o after you have finished cooking.
Fig. 4

10
Fig. 5
Burner Size Minimum Pan Diameter (cm) Maximum Pan Diameter (cm)
Auxiliary 10 14
Semi-Rapid 16 18
Rapid 20 22
Triple 24 26
Wok - 36
Ecient use of your hob
The hob is equipped with burners of dierent sizes, designed to
accommodate most shapes and sizes of pan. For best results,
only use pans with flat bottoms and choose an appropriate burner
depending on the size of the pan. The most ecient use of the hob is
shown below, where the pan and burner are correctly chosen.
Ensure that the pans do not overlap the
edge of the pan stand, or cover the
control panel.
The table below shows the sizes of pan that should be used with each
burner:

11
Care and maintenance -AGH7100
As the hob has a stainless steel or enamel surface, you should use a
nonabrasive cleaner. Any abrasive cleaner (including Cif) will scratch
the surface and could erase the control panel markings. Stainless
steel can be eectively cleaned by simply using a dilute solution of
water and mild detergent and drying to a shine with a clean cloth.
Over time with use, the stainless steel surface may discolour; this is
normal and does not constitute a fault with this appliance. Proprietary
stainless steel cleaners are available.
IMPORTANT:
• Switch the appliance o at the mains before any cleaning or
maintenance.
• Steam cleaners must not be used when cleaning this appliance.
• Ensure that all parts are correctly replaced after cleaning, before
attempting to use the hob.
• After removing the pan stands, ensure the rubber pads are in place
on the base of the pan stands before repositioning the pan stands
straight and level on the hob.
• Do not flood the hob as water could seep into the inner workings.
Always allow your hob to dry properly before using it again.

12
Care and maintenance - AGVH7300
Important:
• Switch the appliance o at the mains before any cleaning or
maintenance.
•Steam cleaners must not be used when cleaning this appliance.
•You should use a non-abrasive cleaner to clean the hob top. Any
abrasive cleaner (including Cif) will scratch the surface and could
erase the control panel markings.
•Sugar and starch can cause permanent damage to the surface of the
hob. Wipe away any spillages immediately but be careful given that
the hob top will be hot during and after usage.Avoid letting pans boil
over where possible to ensure that the need for cleaning is minimal.
•Always use a soft sponge or cloth where possible. Utensils such as
scouring sponges and some brushes could cause scratches to the
hob top.
Type of residue Clean with Cleaning advice
Light Cleaning sponge
and soft cloth.
Wipe over the area to be cleaned with
a sponge and hot water, and then wipe
o with a soft dry cloth.
Accumulated baked-
on stains/dirt, sugar
spills or melted
plastics.
Cleaning sponge
or glass scraper
and soft cloth.
Wipe over the area to be cleaned
with a sponge and hot water, using a
ceramic scraper to remove any large
marks or stains and then wipe o with
a soft dry cloth.
Rings and hard water
residues.
White vinegar and
soft cloth.
Pour a small amount of warm white
vinegar onto the stain, leave it to stand,
and then wipe o with a soft dry cloth.
Shiny metallic streaks Cleaning agent for
vitroceramic glass.
Use specialist vitroceramic glass
cleaner (preferably one with silicone
for its protective properties).
9 fast frying steaks

13
Troubleshooting
IF YOUR HOB IS NOT WORKING:
1. Check that the mains supply has not been switched o.
2. Check that the fuse or circuit breaker has not blown/tripped.
3. Check that the burner crowns and caps are fitted correctly and
are not impeding the ignition candles or the flame failure devices
(circled in Fig. 6).
4. Check that the burner caps
(black metal plates that sit atop
the burners) are clean and free
from grease and debris on
both sides.
5. Check the burners are clean
and not blocked.
6. If you have just cleaned
your hob, or it has become
wet through spillages, allow it to dry and try again.
IMPORTANT: Ensure burners have been allowed to cool before
handling them.
If one or more burners continue to malfunction, please contact CDA
Customer Care. Contact details can be found below:
A: Amica CCD, The CDA Group Building, Harby Road, Langar,
Nottinghamshire, NG13 9HY
T: 01949 862 012 F: 01949 862 003
E: [email protected]
W: www.amica-international.co.uk
Fig.6

14
WHAT TO DO IF YOU SMELL GAS:
1. Turn o the gas.
For natural gas -
Turn o the gas supply at the meter situated at the emergency control
valve (ECV) unless the meter is located in a basement or cellar. If there
is a smell of gas in the basement or cellar, evacuate the building.
For Liquefied Petroleum Gas (LPG) -
• Bulk storage supply - shut o the ECV outside the building and the
gas isolation valve on top of the above-ground storage vessel(s), or
underground storage vessel(s).
• Metered installations - shut o the ECV at the meter installation
outside the building.
• Cylinder fed installations - shut all cylinder valves.
2. Extinguish all naked flames.
Do not smoke, ignite a lighter of any kind or strike matches.
3. Do not operate electrical switches
Turning a light on or o, or activating any kind of switch or socket
outlet, can ignite escaping gas.
4. Open windows and doors
This gets rid of gas by ventilating the property. For LPG, ventilate at
low level (LPG is heavier than air).
Please note: If gas is evident externally, consideration should be given
to preventing gas entering the property (close windows and doors
etc.).

15
5. Call the Gas Emergency Contact Centre
In the case of natural gas, contact the Gas Emergency Service
Provider (ESP) or, in the case of LPG, the Gas Supplier. Below is a list
of ESPs relevant to region:
England, Scotland and Wales:
Natural Gas - 0800 111 999 (Gas Emergency Contact Centre)
LPG - Bulk and Metered supplies - See telephone number on bulk
storage vessel or at the meter.
LPG - Cylinder supplies - See gas supplier emergency contact details
in the local telephone directory or as identified on the cylinder(s).
Please note that caravan park owners, hire boat owners, etc. may
have their own responsibilities in the event of a gas leak, so always
contact the relevant site owner/authority.
Northern Ireland:
Natural Gas - 0800 002 001 (Northern Ireland Gas Emergency
Service)
LPG - Bulk and Metered supplies - See telephone number on bulk
storage vessel or at the meter.
LPG - Cylinder supplies - See gas supplier emergency contact details
in the local telephone directory or as identified on the cylinder(s).
Please note that caravan park owners, hire boat owners, etc. may
have their own responsibilities in the event of a gas leak, so always
contact the relevant site owner/authority.
Channel Islands - Guernsey:
Mains Gas + LPG (mains gas in the Channel Islands is an LPG and air
mixture) - 01481 749000 (Guernsey Gas Ltd.).

16
Channel Islands - Jersey:
Mains Gas + LPG (mains gas in the Channel Islands is an LPG and air
mixture) - 01534 755555 (Jersey Gas Company Ltd.)
Isle of Man:
Natural gas and LPG - 0808 1624 444 (Manx Gas Ltd.)
Gas Emergency contact details for the four main suppliers of LPG in
the British Isles are shown below:
Calor - 08457 444 999
BP - 0845 607 6118
Flogas - 0845 7200 100
Shell - 0870 7539 999
Please note: The CDA Group Ltd. makes no warranty about
the content of this section and will not be held liable, under any
circumstances, for any direct or indirect damages resulting from the
use of this information. If you have any questions regarding gas and
safe practice, contact the Gas Safe Register® using the below details:
Consumers - 0800 408 5500
Engineers - 0800 408 5577

17
Preventing unsafe conditions
Knowing how to treat your appliances will help you to prevent unsafe
conditions.
•Keep electrical leads from trailing over or going near the hob.
•Do not hang towels, cloths or other combustibles on, over or near
your hob (nor any cooking appliance).
•Keep all cooking appliances clean. Build ups of fat, grease, food
particles etc. can start a fire.
•Avoid cooking whilst tired, inebriated or under the influence of
drugs and/or alcohol.
•Ensure regularly that all smoke alarms/fire detectors are functional.
•We recommend the use of carbon monoxide alarms in your kitchen
and house/property. Ensure that these are tested and maintained.
•Never leave cooking unattened, even for a moment.
•Never use an appliance that you know to be faulty.
•Ensure that anyone in need of supervision is supervised and kept
away from appliances that are cooking.

18
Mains electricity connection
THIS APPLIANCE MUST BE CONNECTED TO THE MAINS SUPPLY
BY A COMPETENT PERSON, USING FIXED WIRING VIA A DOUBLE
POLE SWITCHED FUSE SPUR OUTLET AND PROTECTED BY A 3A
FUSE.
The appliance should be connected by a
qualified electrician, who is a member of the
N.I.C.E.I.C. and who will comply with the I.E.T.
and local regulations.
The wires in the mains lead of this appliance
are coloured in accordance with the following
code:
Green & Yellow = Earth, Blue = Neutral, Brown = Live.
As the colours of the wires in the mains lead for the appliance may
not correspond with the coloured markings identifying the terminals
connecting to the fuse spur, proceed as follows:
•The wire which is coloured green and yellow must be connected to
the terminal marked E (Earth) or coloured green.
•The wire which is coloured blue must be connected to the terminal
marked N (Neutral) or coloured black.
•The wire which is coloured brown must be connected to the
terminal marked L (Live), or coloured red.
Note: Use a 3A Fuse
Assembly and electrical connection should be carried out by
specialised personnel. When installing this product we recommend
you seek the help of another individual.
DOUBLE POLE SWITCHED
FUSE SPUR OUTLET
USE A 3 AMP FUSE
Fig. 7

19
Gas supply requirements
IMPORTANT: THIS APPLIANCE MUST BE FITTED BY A GAS SAFE
REGISTERED FITTER OR OTHER SUITABLY QUALIFIED PERSON.
• This installation must comply with the Gas Safety (installation and
use) Regulations 1984.
• This appliance is category II2H3+ and is designed for use in the
UK and Ireland. The installation must comply with the Gas Safety
(installation and use) Regulations 1984.
•The CDA Group Ltd is not legally able to provide any assistance
in the installation of gas appliances except to Gas Safe registered
installers. Any Gas Safe registered fitter requiring help must provide
their name, address and registration number. Information supplied
will be validated before help is provided.
• In the event that this appliance is not installed in accordance with
the above requirements, the appliance may be disconnected
from the mains gas supply until any faults are rectified; this is a legal
requirement.
•This appliance should be installed using 15mm copper pipe
connected via an isolation valve in an adjacent unit. The isolation
valve needs to be accessible in an emergency or for service
purposes.
•This appliance must not be connected to a combustion gas recovery
scavenging system
•The connection to the gas supply must comply with all current
regulations in force.
•We are not legally able to oer advice on the installation of gas
appliances to non Gas Safe registered personnel.

20
Ventilation
All rooms require a window or equivalent (e.g. a door) which can be
opened. Some rooms require a permanent vent in addition to a win-
dow (see below).
This unit must not be used in a room which is less than 5m3. The fol-
lowing table details the requirements based on the kitchen volume
(L x W x H) in m3.
The above requirements also allow use of a gas oven and grill but if
there are any other fuel burning appliances in the same room, consult
the relevant British Standard (BS5440) or GAS SAFE document.
Sealing the gas connection
The gas inlet fitting for these models is a ½” male threaded conic gas
type, complying with ISO 7-1 standards. Please ensure that the con-
nection is made using rigid (15mm copper) pipe (see page 18). When
making the connection, it is important to place the fibre washer (A) in
betweem the inlet pipe (C) and the elbow (B) to ensure a tight seal.
Room Volume (m3)
5
6 to 10
6 to 11
11 or more
Air Vent Required (cm2)
100
50
No permanent vent required if a door opens to the outside
None required
BAC
