Amica KHF 664 610 S User manual

IO-HOO-0695/2
(04.2019)
Kitchen extractor hood / kaminhaube /
kuchyňského odsavače / kuchynského odsávača
/ Hotte aspirante / Afzuigkap / Kuhinjska napa /
Kuhinjska napa
KHF 664 610 S / KHF 684 610 S /
KHF 604 610 S
OPERATING INSTRUCTIONS EN
GEBRAUCHSANWEISUNG DE
NÁVOD K OBSLUZE CS
NÁVOD NA OBSLUHU SK
NOTICE D’UTILISATION FR
GEBRUIKSAANWIJZING NL
UPUTE ZA UPORABU HR
NAVODILA ZA UPORABO SL

- 2 -
NOTES ON SAFETY 6
UNPACKING 9
DISPOSAL OF OLD APPLIANCE 9
OPERATION 10
KITCHEN HOOD CONTROLS 10
OFF-TIMER 10
OTHER IMPORTANT INFORMATION CONCERNING THE OPERATION OF THE HOOD 11
CLEANING AND MAINTENANCE 12
MAINTENANCE 12
GREASE FILTER 12
ACTIVATED CHARCOAL FILTER 12
LIGHT 12
WARRANTY AND AFTER SALES SERVICE 13
WARRANTY 13
SICHERHEITSHINWEISE 15
AUSPACKEN 19
ENTSORGUNG VON ALTGERÄTEN 19
BEDIENUNG 20
STEUERUNG DER DUNSTABZUGSHAUBE 20
TIMER (AUSSCHALTVERZÖGERUNG DER DUNSTABZUGSHAUBE) 20
ANDERE WICHTIGE INFORMATIONEN ZUR BEDIENUNG DER DUNSTABZUGSHAUBE 21
REINIGUNG UND WARTUNG 21
WARTUNG 21
FETTFILTER 22
AKTIVKOHLEFILTER 22
BELEUCHTUNG 22
GARANTIE, NACHVERKAUF-SERVICE 23
GARANTIE 23
EN- Table of contents
DE- Inhaltsverzeichnis
BEZPEČNOSTNÍ POKYNY 25
VYBALENÍ 28
LIKVIDACE OPOTŘEBOVANÝCH ZAŘÍZENÍ 28
OBSLUHA 29
OVLÁDÁNÍ ODSAVAČE 29
ČASOVAČ (OPOŽDĚNÉ VYPNUTÍ ODSAVAČE) 29
JINÉ DŮLEŽITÉ INFORMACE O OBSLUZE ODSAVAČE 30
ČIŠTĚNÍ A ÚDRŽBA 31
ÚDRŽBA 31
PROTITUKOVÝ FILTR 31
UHLÍKOVÝ FILTR 31
OSVĚTLENÍ 31
ZÁRUKA, POPRODEJNÍ SERVIS 32
ZÁRUKA 32
CS- Obsah

- 3 -
BEZPEČNOSTNÉ POKYNY POUŽÍVANIA 34
ROZBALENIE 38
LIKVIDÁCIA ZARIADENÍ 38
OBSLUHA 39
OVLÁDANIE ODSÁVAČA 39
ČASOVAČ (ONESKORENÉ VYPNUTIE ODSÁVANIA) 39
INÉ DÔLEŽITÉ INFORMÁCIE TÝKAJÚCE SA POUŽÍVANIA ODSÁVAČA 40
ČISTENIE A ÚDRŽBA 41
KONZERVÁCIA 41
PROTITUKOVÝ FILTER 41
UHLÍKOVÝ FILTER 41
OSVETLENIE 41
ZÁRUKA, POPREDAJNÝ SERVIS 42
ZÁRUKA 42
INDICATIONS CONCERNANT LA SÉCURITÉ D'UTILISATION 44
DÉBALLAGE 48
ÉLIMINATION DES APPAREILS USAGÉS 48
EXPLOITATION 49
COMMANDE DE LA HOTTE 49
MINUTERIE (ARRÊT DIFFÉRÉ DE LA HOTTE) 49
AUTRES INFORMATIONS IMPORTANTES RELATIVES À L’UTILISATION DE LA HOTTE 50
NETTOYAGE ET ENTRETIEN 51
ENTRETIEN 51
FILTRE À GRAISSE 51
FILTRE À CHARBON 51
ÉCLAIRAGE 51
GARANTIE, SERVICE APRÈS-VENTE 52
GARANTIE 52
AANWIJZINGEN VOOR VEILIG GEBRUIK 54
UITPAKKEN 58
VERWIJDERING VAN GEBRUIKTE APPARATUUR 58
BEDIENING 59
BEDIENING VAN DE AFZUIGKAP 59
TIMER (UITGESTELD UITSCHAKELEN VAN DE AFZUIGKAP) 59
ANDERE BELANGRIJK INFORMATIE OVER DE BEDIENING VAN DE AFZUIGKAP 60
REINIGING EN ONDERHOUD 61
ONDERHOUD 61
ANTIVETFILTER 61
ACTIEVE KOOLFILTER 61
VERLICHTING 61
GARANTIE, SERVICE 62
GARANTIE 62
SK- Obsah
FR- Table des matières
NL- Inhoudsopgave

- 4 -
HR- Kazalo
SL- Sadržaj
SIGURNOSNE NAPOMENE 64
UKLANJANJE PAKIRANJA 67
ZBRINJAVANJE POTROŠENIH UREĐAJA 67
UPORABA 68
UPRAVLJANJE NAPOM 68
TIMER (ODGODA ISKLJUČENJA NAPE) 68
OSTALE VAŽNE INFORMACIJE O UPORABI NAPE 69
ČIŠĆENJE I ODRŽAVANJE 70
ODRŽAVANJE 70
FILTER PROTIV MASNOĆE 70
UGLJENI FILTER 70
RASVJETA 70
JAMSTVO, POSLIJEPRODAJNE AKTIVNOSTI 71
JAMSTVO 71
NAVODILA ZA ZAGOTAVLJANJE VARNOSTI UPORABE 73
RAZPAKIRANJE 76
ODSTRANJEVANJE IZRABLJENIH NAPRAV 76
UPORABA 77
UPRAVLJANJE S KUHINJSKO NAPO 77
ŠTOPARICA (ZAKASNJENA IZKLJUČITEV NAPE) 77
DRUGE POMEMBNE INFORMACIJE GLEDE NAVODIL ZA UPORABO NAPE 78
ČIŠČENJE IN VZDRŽEVANJE 79
VZDRŽEVANJE 79
MAŠČOBNI FILTER 79
OGLENI FILTER 79
OSVETLITEV 79
GARANCIJA, POPRODAJNE STORITVE 80
GARANCIJA 80

- 5 -
Dear customer,
From now on, your daily housework will be easier
than ever before. Your appliance is excepon-
ally easy to use and extremely ecient. Aer reading
these Operang Instrucons, operang the appliance
will be easy.
Before being packaged and leaving the manufacturer,
the appliance was thoroughly checked with regard to
safety and funconality.
Before using the appliance, please carefully read
these Operang Instrucons. By following these
instrucons carefully you will be able to avoid any
problems in using the appliance. It is important to
keep these Operang Instrucons and store them in a
safe place so that they can be consulted at any me.
Follow these instrucons carefully in order to avoid
possible accidents.
Sincerely,

- 6 -
NOTES ON SAFETY
• Before using the appliance, please carefully read
this manual!
• The appliance is designed for household use only.
• The manufacturer reserves the right to introduce
changes, which do not aect operation of the ap-
pliance.
• The manufacturer shall not be liable for any dam-
age or re caused by the appliance resulting from
failure to follow instructions in this manual.
• Cooker hood is designed to remove cooking
odours. Do not use cooker hood for other pur-
poses.
• Connect the cooker hood operating in extraction
mode to a suitable ventilation duct (do NOT con-
nect the cooker to smoke or ue gas ducts, which
are in use). It requires installation of the air ex-
traction duct to the outside. The length of the
duct (usually a pipe of Ø 120 or 150 mm) should
not be longer than 4-5 m. An air extraction duct
is also required for telescopic and furniture hoods
in absorption mode.
• Cooker hood operating in air recirculation mode
requires the installation of an activated charcoal
lter. In this case, installing an extractor duct is
not required, however it is recommended to in-
stall an air guide vane (Mainly in chimney cooker
hoods).
• The cooker hood features independent lighting
and exhaust fan that can be operated at one of
several speeds.
• Depending on the type, the hood is designed to
be permanently attached to a vertical wall over
a gas or electric stove (chimney and universal
hoods); on the ceiling over a gas or electric stove
(island hoods); on the vertical built in furniture
over a gas or electric stove (telescopic and built-
in hoods). Before installing, make sure that the

- 7 -
wall/ceiling structure is strong enough to suspend
the hood. Some hoods are very heavy.
• For details of the installation distance above an
electric hob please refer to product technical
sheet If the installation instructions of the gas
cooker specify a greater distance, this must be
taken into account (Fig. 1).
• Do not leave an open ame under the hood.
When the pots are removed from the burner, set
the minimum ame. Always make sure that the
ame does not extend outside the pot, because it
causes unwanted loss of energy and a dangerous
concentration of heat.
• When cooking on fat, supervise the pans con-
stantly, because overheated fat can ignite.
• Unplug the appliance before any cleaning, replac-
ing the lter or repair work.
• Cooker hood grease lter should be cleaned at
least once a month, because the lter saturated
with fat is ammable.
• Ensure adequate ventilation (air ow) if other
equipment such as liquid fuel stoves or heaters
are operated in the room in addition the cooker
hood. When the cooker hood is simultaneously
operated with burning appliances requiring ade-
quate fresh air from the room to work properly,
their safe operation is possible if under pressure
around these appliances is a maximum of 0.004
mbar (this does not apply when the cooker hood
is used as an odour lter)
• Do not lean on the hood.
• The hood should be cleaned regularly both inside
and out (AT LEAST ONCE A MONTH, following the
indications concerning maintenance provided in
this manual)..Failure to adhere to the rules con-
cerning cleaning the hood and replacing lters
results in a re risk.
• If the power cord is damaged it should be re-
placed by a specialised service centre.
• Ensure that it is possible to disconnect the ap-

- 8 -
pliance from the mains by removing the plug or
switching o the bi-polar switch.
• This appliance is not intended for use by persons
(including children) with physical, mental or sen-
sory handicaps, or by persons inexperienced or
unfamiliar with the appliance, unless under su-
pervision or in accordance with the instructions
as communicated to them by persons responsible
for their safety.
• Particular attention should be paid not to allow
unaccompanied children to use the appliance.
• Make sure voltage indicated on the nameplate
corresponds to the local mains supply voltage.
• Before use, extend and straighten the power cord.
• Packaging materials (bags, polyethylene, poly-
styrene, etc.) should be kept away from children
during unpacking.
• Before connecting the hood to the mains power
supply always check that the power cord is prop-
erly installed and is not trapped by the appliance.
Do not connect the appliance to the mains until
assembly is complete.
• Do not operate your kitchen hood without the al-
uminium grease lters.
• It is strictly forbidden to cook dishes under on an
open ame (ambé) under your kitchen hood.
• Always strictly adhere to regulations issued by the
competent local authorities regarding the techni-
cal and safety requirements for fume extraction.
• Failing to tighten bolts and fasteners in accord-
ance with these instructions may endanger life
and health.
• Hanging kitchen hoods operate only in air circu-
lation / odour absorber mode
• WARNING! Failure to install the screws or xing
device in accordance with these instructions may
result in electrical hazards.

- 9 -
UNPACKING
During transportation, protective
packaging was used to protect the
appliance against any damage. Af-
ter unpacking, please dispose of all
elements of packaging in a way that
will not cause damage to the environ-
ment.
All materials used for packaging the
appliance are environmentally friendly; they are
100% recyclable and are marked with the appropri-
ate symbol.
Important! Packaging materials (bags, polyethyl-
ene, polystyrene, etc.) should be kept away from
children during unpacking.
DISPOSAL OF OLD APPLIANCE
In accordance with European Directive
2012/19/EU and local legislation re-
garding used electrical and electronic
goods, this appliance is marked with
the symbol of the crossed-out waste
container. This marking indicates that
the appliance must not be disposed of
together with other household waste
after it has been used.
The user is obliged to hand it over to waste collec-
tion centre collecting used electrical and electron-
ic goods. The collectors, including local collection
points, shops and local authority departments pro-
vide recycling schemes.
Proper handling of used electrical and electronic
goods helps avoid environmental and health haz-
ards resulting from the presence of dangerous com-
ponents and the inappropriate storage and process-
ing of such goods.

- 10 -
OPERATION
Kitchen hood controls
Control Panel is shown in Figure 4, for reference it is also shown below:
42
31 5
The control panel is equipped with touch controls:
To turn on the kitchen hood, touch one of the sensors to select the
desired speed:
1- Low speed. Use this speed when cooking a little food with hardly any
fumes.
2- Medium speed. Use this speed when cooking multiple dishes at the
same time with moderate amount of fumes.
3- High speed. Use this speed when frying or grilling, with large
amount of fumes.
4- Turn Standby mode on/o
5- Turn light on/o
Note:
• To use one of the three speeds, rst touch the to turn on the
Standby mode and then select the desired speed. To turn o the
active speed, touch the backlit sensor again.
• To turn on the light, rst activate the Standby mode.
• When you turn o the Standby mode, the appliance fan and light
will turn o.
• Touch twice to turn o the hood when fan is operating.
O-Timer
Use O-Timer to turn o the hood after a specied time. Use O-Timer
to lter the fumes out of the air after cooking. The delay time is about
15 minutes. Touch to activate the O-Timer at any time. Sensor
ashes. Flashing indicates that O-Timer has been enabled. Touch
again to cancel the O-Timer. The appliance will turn o. To turn on the
appliance, touch the sensor corresponding to the desired fan speed.
