Amico GoLift Portable450 User manual

Installation and Operation Instructions
Portable450 Portable450

2Amico Mobility Solutions Corporation
Contents
Introduction 3-4
Application 3
Description 3
Symbols Used in this Manual 4
Markings 4
Safety Instructions 5
Technical Specifications for Amico GoLift Portable450 6
Anatomy of the GoLift Portable450 7
Basics in Transferring a Patient 8-9
Installing the GoLift Portable450 in the Amico PLP Track 9-10
Installing the Endstop on the Amico Track 10
Labeling the Tracks 11
Using the Reacher Bar 12
Magnetic Connection of the Hand Control to the GoLift Portable450 12
Operating the GoLift Portable450 13
Charging the GoLift Portable450 13
LED and Buzzer Functions 14
Emergency Stop 15
Emergency Lowering 15
Manual Emergency Lowering 15
Overspeed Cam 15
Cleaning and Disinfection 16
Troubleshooting 16
Inspection and Maintenance 17
GoLift Portable450 Accessories 18
GoTrack Systems and Support Structure 19-20
Environmental Conditions 21
Electro-Magnetic Compliance Data for GoLift Portable450 22-25
Warranty 26

www.amico.com 3
Introduction
APPLICATION
The primary purpose of the GoLift Portable450 system is to safely lift and transfer a patient within an institutional
setting or at home. The GoLift Portable450 allows these transfers with as little effort as possible for the caregiver, while
providing dignity to the patient. A ceiling lift is simple and safe for the caregiver as well as the patient. The lift can be
easily moved by a caregiver along the track from one location to another.
DESCRIPTION
The Amico GoLift Portable450 is an ideal ceiling lift system designed for routine transfers of patients. The most
compact portable lift in its class, the Amico GoLift Portable450 is designed to be aesthetically pleasing to both the
caregiver and the patients. In an effort to address infection control requirements, we gave careful consideration to
the smooth edges and rounded corners of our ceiling lift, carry bar and hand control. When you look under the cover
of this compact lift, you will find an impressive set of all metal gears and state-of-the-art battery technology that will
allow the caregiver to safely, and effortlessly transfer a patient weighing up to 450 lbs on a single lift.
The GoLift Portable450 weight capacity is 450 lbs. This weight limit must not be exceeded.
The Amico GoLift Portable450 is a fixed lift and can be installed in a variety of track profiles (the trolley can be
customized to fit these track profiles) and it also works seamlessly with the Amico GoLift Portable450 Pendant (PLP)
System.
Contents of Packaging:
1. Amico GoLift Portable450
2. Hand Control
3. Charger
4. Owner’s Manual
5. Portable Trolley
Upon receipt of the packages, verify it against the packing slip to
ensure the shipment is complete and inspect the equipment for
possible damage. If there is any damage, DO NOT USE the equipment
and notify the carrier immediately to file a claim. Provide complete
information concerning damage claims or shipping errors to Amico
Mobility Solutions Corporation. Include all equipment identification
numbers along with a description of the damaged parts.

4Amico Mobility Solutions Corporation
SYMBOLS USED IN THIS MANUAL
Symbol Reference Title
!
ISO 7000-0434A Caution risk of danger
TUV Certified by TUV
IEC 60417-5840 Type BF Applied Part
CE Certification of Conformity
ISO 7010-M002 Refer to instruction manual/booklet
Amico Mobility Emergency Lowering
Amico Mobility Emergency Stop
Introduction
AJW Technology Consulting GmbH
Königsallee 106
40215 Dusseldorf
Germany
REV. DESCRIPTION BY DATE
5
4
3
1
122B East Beaver Creek Rd.
Richmond Hill, ON, L4B 4V1, CANADA
Tel: [phone]
Fax: [phone]
DESCRIPTION:
PART NO:
SHEET:
OF
DRAWING NO:
11
PROJECTION
PRIVATE AND CONFIDENTIAL
THIS PRINT IS PROPERTY OF AMICO CLINICAL AND IS LOANED IN CONFIDENCE SUBJECT TO RETURN UPON
REQUEST AND WITH THE UNDERSTANDING THAT NO COPIES ARE TO BE MADE WITHOUT THE CONSENT OF
AMICO CLINICAL.
ALL RIGHTS TO DESIGN OR INVENTION ARE RESERVED
2021-03-18
DATE:
2021-03-18
DATE:
VC
CHECKED BY:
AC
DRAWN BY:
NTS
SCALE:
2
A
B
C
D
SEE NOTE 2
FINISH:
MATERIAL:
SEE NOTE 1
YYMMDD-XXX
UNLESS SPECIFIED:
ALL DIMENSIONS IN INCHES
SURFACE FINISH 63 uin
BREAK ALL EDGES 0.005 - 0.010
REMOVE SHARP EDGES AND BURRS
ANGLE TOLERANCES 0.25
CONCENTRICITY OF 0.005"
STRAIGHTNESS & FLATNESS
PARALLELISM OF 0.005"
DECIMAL TOLERANCES: X.XX .05
X.XXX .005
X.XXXX .0005
Assem1^GO-LIFT-PORT-450-WR
Amico Mobility Solutions Corporation
Email: [email protected]
1. 87 7. 4 6 2 . 6 4 2 6
M
A
D
E
I
N
N
O
R
T
H
A
M
E
R
I
C
A
!
Charger : Wall Industries 36V 1.11 A 40W
Duty Cycle: 1 M in ON / 9 Min OFF
Serial #:
Mfg. Date:
GLP450-9999
450 lbs (205 kg)
IP23
7.315
A A
B B
4
4
3
3
2
2
1
1
Back
Front
0.8341”
1.6256”
!
WARNING: This symbol is intended to alert the user of hazard or unsafe practices, which could result in
serious bodily harm.
MARKINGS
The GoLift Portable450 is designed to comply with the following Standards:
Standard(s): CAN/CSA-C22.2 No. 60601-1:08 Medical Electrical Equipment – Part 1: General requirements for
basic safety and essential performance. ISO10535:2006 Hoists for the transfer of disables persons –
Requirements and Test Methods. CAN/CSA-C22.2 60601-1-11:2-15 home use environments.
Product: Amico GoLift Portable
Brand Name: GoLift
Models: 450 lbs

www.amico.com 5
Safety Instructions
!
READ THESE INSTRUCTIONS CAREFULLY OR SERIOUS INJURY MAY OCCUR
• The Amico GoLift Portable450 must be installed only by personnel authorized by Amico Mobility Solutions
Corporation.
• Do not use this equipment prior to understanding the contents of this manual.
• Contents of this manual are subject to change without prior notice to users. Keep for future reference.
• Never place the Amico GoLift Portable450, track/PLP and sling(s) in control of a person who has not been
properly trained in the use and care of this equipment.
• The Amico GoLift Portable450 and associated Track/PLP and sling(s) are for transferring patients only. Never use
the GoLift Portable450 for any other purpose.
• Amico Mobility’s Warranty is void if unauthorized personnel perform service on the Amico GoLift Portable450
system.
• In facilities where more than one caregiver is responsible for using the Amico GoLift Portable450 and associated
track and slings, it is important that all caregivers be trained in the proper use of this equipment. A training
program should be established by the facility to familiarize new caregivers with this equipment.
• Do not expose the Amico GoLift Portable450 directly to water. Warranty does not cover any misuse or abuse of
the Amico GoLift Portable450.
• The Amico GoLift Portable450 should be inspected and maintained on a regular basis to keep it operating safely
and correctly. Refer to page 16 of this manual.
• Any accessories used with the Amico GoLift Portable450 including the track/PLP and sling(s) should be checked
to ensure that they are in good working order. Check for signs of tear or fraying prior to use. Report any unusual
wear or damage immediately.
• Amico Mobility will not be responsible for any damage caused by misuse, neglect or purposeful destruction of
the lift and its associated components. Do not attempt to modify/alter the Amico GoLift Portable450.
• Do not in any circumstance exceed the maximum allowable load of this lift. Refer to the “Technical
Specifications” section of this manual and/or the labels on the lift.
• The installation of the lift, track and sling are certified to a maximum load. Do not exceed the maximum rated
load of any of the components.
• There is a risk of explosion if the lift is used in the presence of flammable anesthetics.
• The Amico GoLift Portable450 should be decommissioned/disposed of after the recommended service lift in
accordance with local law regulations.
• If the battery case cracks and the contents of the battery contact your skin or clothing rinse immediately with
warm water.
• If the contents of the battery contact your eyes, rinse immediately with plenty of water and seek medical
attention.
• If the contents of the battery can cause respiratory irritation, provide fresh air and seek medical attention.
!
There are no known contraindications associated with the use of the Amico GoLift Portable450 and its
accessories, provided they are used per our recommendations and guidelines.
However, for any independent users of the Amico GoLift Portable450, it is extremely important that the patient is able
to receive assistance during the transfer in the event of an equipment failure. This assistance can be provided in the
form of; a nearby qualified caregiver, a phone, or other communication device.

6Amico Mobility Solutions Corporation
Maximum Lifting Speed:
No load: 1.7 inches/second
150 lbs/68 kg: 1.3 inches/second
450 lbs/204 kg: 1.0 inch/second
Unit Weight:
6 lbs
Safe Working Load (SWL):
450 lbs
Dimensions (see diagram):
Length: 19.4" (49.27 cm)
Height: 5.2" (13.20 cm)
Depth of Lift: 3.7" (9.398 cm)
Strap Length: 74" (187.96 cm)
Number of Lifts per Charge (Duty: 10/90):
78 with 150 lbs (25% of strap at midrange)
46 with 450 lbs (25% of strap at midrange)
Charging time: 2-4 Hours
Lift Case:
Flame retardant ABS
IP23 Lift - protected from fingers and water spray less 60
degrees from vertical
Batteries:
High Capacity, Long Lasting NiMH
1 x 24V (1.6Ah)
Battery Charger:
Input: 100-240VAC
Output: 36VDC, 40 Watt, 1.0A
Hand Control:
IPX4 Hand Control – protects from splashing water, no
matter the direction
Safety:
Emergency Stop
Emergency Lowering Device: Independent Circuit
Manual Lowering
Upper Limit Detection
Lower Limit Detection
Slack Tape Sensor
Free Fall Brake (Over Speed Governor)
Low Battery and Dead Battery Alarms
Soft Start and Stop
Overload Protection
Technical Specifications for Amico GoLift Portable450
M
A
D
E
I
N
N
O
R
T
H
A
M
E
R
I
C
A
Approvals:
CAN/CSA-C22.2 No 60601-1:08
CAN/CSA-Z10535.1:15
Expected Service Life:
22,500 cycles or 10 years.
It is recommended that the lift be replaced after this time.
The expected life of slings, batteries fuses, straps and cord is
dependent upon proper maintenance.
18.2"
19.4"
81"
5.2"

www.amico.com 7
Anatomy of the GoLift Portable450
Emergency lowering
Durable all metal gears
Unit controls
Quick magnetic hand
control connection
Wired hand control
Lifts up to
450 lbs!
GoLift Portable450 weighs
just 6 lbs
Back of the GoLift Portable450
Emergency lowering
Emergency stop

8Amico Mobility Solutions Corporation
Basics in Transferring a Patient
Lifting sling:
A lifting sling with four to six straps designed for mounting on hooks
should be used with the Amico Portable450 lift.
Amico Mobility shall not be liable for faults or accidents due to
incorrect use of the lifting sling, or for reasons of inadequate attention
on the part of the caregiver or patient.
Working with the Amico GoLift Portable450:
The Amico GoLift Portable450 moves freely in the track system
and does not have any special requirements for space or power in
connection with moving. Attention can be fully focused on the user’s
functional level and the caregivers technique.
To use the GoLift Portable450 correctly, the patient should only be lifted to the extent that she/he is clear of the
surface and should be moved at this height.
Attaching the lifting sling:
Place the straps from the lifting sling on the hooks of the GoLift Portable450 Start with the uppermost set of straps
(from the back) and then take the lowest set of straps (from the legs).
!
Be careful when attaching the lifting sling on the hooks. Check that the straps have been completely through
the opening and into place in the Portable lift hooks.
When pressing the up button to lift the patient, check
again that all straps remain correctly placed.
Lifting to and from a seated position:
• When lifting a patient from e.g. a wheelchair, move the
Amico GoLift Portable450 towards the patient to be
lifted.
• The lifting hooks should be at the same height as the
patient’s chest.
• Place the lifting hooks parallel to the patient’s shoulders.
• Place the lifting sling behind the patient’s back between
the back of the chair and the patient’s back.
• The center band of the lifting sling should follow the
patient’s spine. Lead the leg straps along the outer sides
of the patient’s shins and beneath the thighs between
the hollow of the knees and the hip joints. Cross the leg
straps in front of the patient.
• All four lifting straps are now ready to be attached. The
lifting sling can now be mounted onto the carry bar
hooks.

www.amico.com 9
Lifting to and from lying position in bed:
• Bring the GoLift Portable450 over the center of the patient to be lifted.
• Place the hooks parallel to the patient’s shoulders.
• Turn the patient onto their side. The sling should be placed so that the top of the sling is at the same height as
the top of the patient’s head. Now position the sling over the patient so that the center band follows the patient’s
spine. Turn the patient onto their back and pull out the remaining part of the lifting sling. Place the leg straps
beneath the patient’s thighs and cross them. All four lifting straps are now ready to be attached and the lifting
sling can now be mounted on the hooks. It would be advantageous to elevate the head of the bed so that the
patient is sitting up.
• Only persons who have received competent instruction regarding the use of the lifting equipment and fitting of
slings should use the Amico GoLift Portable450.
!
Important: Plan the move and avoid leaving the patient in the sling unattended. Before lifting, check that the
patient is completely free of their surroundings. The patient’s head, arms, hands and feet must not be in
danger or becoming trapped. Be careful with any tubes and wires that are attached to the user. Check that the
Portable450 hand control and hand control cable is not tangled to the patient and other objects before the
lift is activated.
Never leave the lift unattended in an area such as a Psychiatric Ward with the patient.
Installing the GoLift Portable450 in the Amico PLP Track
1. Remove both endcaps on the PLP Arm.
2. Make sure the portable trolley is inserted correctly in the PLP track.
Basics in Transferring a Patient

10 Amico Mobility Solutions Corporation
Installing the GoLift Portable450 in the Amico PLP Track
3. By using an adjustable wrench, remove the endstop on
the PLP track by loosening the bolts.
4. Fasten the endstops back on to the PLP track. Ensure there is enough clearance room to place the endcap on the
PLP arm and place the endcap back on the arm.
5. Fasten all endstops tightly using an adjustable wrench.
!
NOTE: If you are installing the Amico GoLift Portable450 in an existing track system you must ensure that the
max load of the track system is equal or higher than the max load of the Amico GoLift Portable450.
6. To disconnect the lift from the trolley, open up the hook in the carabiner to release.
Installing the Endstop on the Amico Track
Amico Track Endstop
Use a 3/16 Allen key to
secure the endstop to
the track.

www.amico.com 11
All of the lifts come with two track maximum capacity labels inside the box.
Before installing the lift in the track system, verify the maximum capacity of the room and the certifying load test. Walk
around the room and find a spot on either side of the track where the label would be visible. Wipe down the surface
of the track where the label is to be attached using one of the recommended cleaning agents (see Cleaning and
Disinfection section). Allow the track to dry before peeling the label from the backing and attaching to either side of
the track. With a permanent writing material, fill in the date that the track was certified using a permanent marker.
Example Track Label
Labeling the Tracks
1.877.4 62. 6426
[email protected]
Amico Mobility Solutions Corporation
122-B East Beaver Creek Road
Richmond Hill, ON L4B 1G6, Canada
Certified Date:
Track Maximum Capacity:
XXXX lbs
2”
3.5”

12 Amico Mobility Solutions Corporation
1. With the lift resting on a bed, cart, table or
other stationary object, use the down button
on the lift or hand control to release enough
of the strap to the point that will allow you to
connect the carabiner to the trolley without
having to pick up the lift from its position.
2. Open the carabiner latch by pressing the
colored latch towards the back of the
carabiner. This "opens" the carabiner so
that it can be attached to the latch of the
Reacher Arm. Once the carabiner is hooked
onto the Reacher latch, release the latch of
the carabiner so that it will be closed, and
therefore locked in place.
3. Raise the Reacher Bar up to the trolley. Make
sure there is enough slack on the lift strap to
accomplish this step otherwise it will not be
possible to hook on.
4. Slide the top hook of the Reacher Bar through
the trolley. Make sure there is enough slack on
the lift strap to accomplish this step otherwise
it will not be possible to hook on.
5. The lift has now been securely hooked
onto the trolley. The Reacher Bar remains in
position until the lift is removed.
Using the Reacher Bar
Open carabiner to attach
in slot of the Reacher Bar.
Raise the Reacher Bar to
the trolley.
Slide the top hook
through the trolley.
Lift is securely hooked
onto the trolley. The
Reacher Bar remains
in position.
Closed carabiner attached to latch of the
Reacher Bar.
Magnetic Connection of the Hand Control to the
GoLift Portable450
Magnetic hand control for quick attachment to the GoLift Portable450.
!
Do not place the hand control within 6" of a pacemaker.
Patients with pacemakers must follow the instructions provided by
their physician and pacemaker manufacturer.

www.amico.com 13
The Amico GoLift Portable450 is switched on automatically when a
button on the hand control is pressed. The Amico GoLift Portable450
switches off automatically after approximately three minutes without
activation.
Charging the GoLift Portable450
The charger plugs in into the port on the GoLift Portable450.
The batteries should be charged on a regular basis. It is recommended that the lift be left on charge when not in
operation, and at the end of each day. This will maximize the life cycle of the batteries.
The GoLift Portable450 may remain connected to the charger indefinitely since the charger has a built-in regulator,
eliminating the danger of overcharging.
As a general rule, it is recommended that the lift be raised to a height that will not interfere with anything or anyone
while the lift is not in use.
!
Do not drain the batteries excessively. This will dramatically reduce the lifespan of the batteries. If the battery
level is critically low (see LED and Buzzer Functions section), be sure to recharge the battery as soon as
possible.
!
Charge the batteries to full and turn the lift off before storing. Recharge the lift every three months while the
lift is in storage.
Operating the GoLift Portable450
DOWN button
UP button

14 Amico Mobility Solutions Corporation
LED and Buzzer Functions
Charging Battery Main Lift LED Main Lift Buzzer
Yes Full Green N/A
No Full Green N/A
Yes Not full Orange N/A
No Low Flashing Orange N/A
No Very low Solid Red 1 beep every 3 seconds
No Max current state Flashing Red Continuous beep until
max current state exited
Yes Charging Solid Orange N/A
Yes Top-up Solid Orange for 5 seconds when charger plugged in
then solid Green N/A
Yes Battery over temp/
Sensor error Flashing Red 1 beep every 5 seconds
Yes No temp sensor
detected Flashing Red 3 times per second then 1 second off 1 beep every 5 seconds
Function/Error Main Lift LED Main Lift Buzzer
Emergency down Solid Red 2 beeps per second
Maintenance Alarm
At 1001 lifts, the LED will flash Green, indicating the unit is due for a maintenance check.
To reset, press Up button, then Down button, then Up button, then Down button and then hold both buttons for 10 seconds.
If successful, the LED turns Red, Green and Orange. The buzzer beeps three times.
Please note, that a reset can be done any time maintenance is performed on the lift, not just after the 1000th lift.
Emergency Stop
The GoLift Portable450 has an Emergency Stop feature that allows the operator
to completely shut off the power to the lift in the event of an emergency. This
can be completed by pressing down on the “O” indicator on the red switch
located on the back of the unit. To re-activate the lift, simply press down on the
“I”indicator on the same red switch.

www.amico.com 15
Emergency Lowering
Overspeed Cam
The Overspeed Cam brake is made of a metal bar fixed to the drum. In case of gear or motor breakage, the centrifugal
force created will block the bar against the frame.
Manual Emergency Lowering
The manual emergency lowering and raising feature should only be used if all other controls fail. A proper safety
ladder or stool may be required. Use a 3/16" or 2.5 mm Allen key to rotate the motor in the up or down direction.
!
Do not attempt to use the lift while using manual lowering.
Continue to press down until the patient
is safely lowered to the desired position.
In the event that the DOWN button on the hand control does not function, or in power failure situations, the patient
may be lowered by pressing and holding down the RED emergency lowering button located on the top of the lift.
Continue to press down until the patient is safely lowered to the desired position. The lift will beep as you continue
to press down on the red button and will continue beeping until the button is released after the desired lowering has
been achieved.
NOTE: The emergency lowering button does not provide a raising function. The failure of any of the lowering devices
should be reported to Amico Mobility.
!
In an event of emergency when normal lowering system of the lift malfunctions and the “emergency
lowering” function is used, the lift must be reset by a qualified lift technician before re-use.
!
Do not press the red button forcefully. For assistance after an emergency, contact:
Amico Service: amo[email protected]om or 1.877.462.6426
Emergency Lowering button

16 Amico Mobility Solutions Corporation
Cleaning and Disinfection
The exterior of the GoLift Portable450 should only be cleaned, disinfected using the recommended cleaning agents
shown below. Damp a cloth with the cleaning agent and wipe down the entire exterior of the lift. Other chemicals
and/or liquids not listed should not be used to clean and disinfect this lift.
!
Take great care to ensure that no liquids get inside the Amico GoLift Portable450. The lift is not drip proof or
water tight. Failure to protect the lift from liquids may result in damage to the lift and may cause personal
injury.
Recommended cleaning agents:
• CaviWipes
• Clorox Healthcare Professional Disinfecting Bleach Wipes
• Dispatch Hospital Cleaner Disinfectant Towels With Bleach
• Oxivir Tb Disinfectant Wipes
• Sani-Cloth Super Germicidal Disposable Wipes
• tB Minuteman NEX GEN
• Virocidin-X
• Virox-5
• Virox Accel Tb
Clean the inside of the tracks every 4 months using a damp cloth to ensure a smooth rolling surface for the trolley.
Troubleshooting
Should problems arise with the use of the Amico GoLift Portable450, review the following chart. Find the fault and
complete the recommended solution. If the fault is not found and or/the solution does not correct the problem
contact Amico Mobility.
Fault Recommended Solution
The GoLift Portable450 beeps once every 3 seconds
while in use. The lift only goes down but not in the
upwards direction.
The batteries are low and the lift should be charged.
The GoLift Portable450 cannot lift. If the load is in excess of the safe working load the GoLift Portable450
will not work due to over-current protection.
The batteries are always dead after a few charges. Replace the batteries as they may be at the end of their service life.
The GoLift Portable450 does not operate when you
press the buttons on the hand control. Check that the emergency cord is not pulled.
The lift does not go up. There may be a twist in the lift strap.

www.amico.com 17
Inspection and Maintenance
Prior to using the Amico GoLift Portable450, the inspections should be conducted per the following schedule:
Item Before Use Every Month Annual
GoLift Portable •
Ensure that endstops are installed •
Inspect strap for wear or fraying •
Ensure Batteries are charged •
Inspect hooks for damage or sharp edges •
Inspect the wheels in the portable trolley. Replace if damaged. •
Sling
Check all straps for wear or fraying •
Inspect the sling for any damage in the fabric •
Ensure there are no loose threads in the stitching •
Maintenance by a certified technician
Check the strap and replace only if frayed or damaged •
Inspect the gearbox for any unusual noises •
Inspect the hook components for any signs of damage •
Inspect the gears for any broken or worn teeth •
** Verify the overspeed cam is operating freely •
Check emergency stop button •
** Check emergency lowering device •
*Annual load test with SWL (maximum safe working load) •
Ensure the endstops are installed •
*Reapply grease to the gears •
* In accordance to the ISO 10535 Standard“Hoists for the transfer of disabled persons – Requirements and test
methods”an inspection should be performed on the GoLift Portable450 at least once a year. This inspection should be
performed by a qualified technician and should include a working load test of one (1) lifting cycle with the maximum
load.
*Re-apply grease to the gears using the Amico certified grease. Can be bought from Amico.
** These two functions must be checked by a qualified technician to ensure the essential performance of the GoLift
Portable450.
!
Do not operate the GoLift Portable450 until any issues discovered during the inspection have been addressed
by a certified technician.

18 Amico Mobility Solutions Corporation
GoLift Portable450 Accessories
Slings Material S M L XL
GoBasic
With Head Support Polyester SLG-GO-BASIC-WV-HS-S SLG-GO-BASIC-WV-HS-M SLG-GO-BASIC-WV-HS-L SLG-GO-BASIC-WV-HS-XL
GoBasic
With Head Support Mesh SLG-GO-BASIC-MSH-HS-S SLG-GO-BASIC-MSH-HS-M SLG-GO-BASIC-MSH-HS-L SLG-GO-BASIC-MSH-HS-XL
GoBasic
No Head Support Polyester SLG-GO-BASIC-WV-S SLG-GO-BASIC-WV-M SLG-GO-BASIC-WV-L SLG-GO-BASIC-WV-XL
GoBasic
No Head Support Mesh SLG-GO-BASIC-MSH-S SLG-GO-BASIC-MSH-M SLG-GO-BASIC-MSH-L SLG-GO-BASIC-MSH-XL
GoLong Polyester SLG-GO-LONG-WV-42X78 SLG-GO-LONG-WV-56X78
GoLong Mesh SLG-GO-LONG-MSH-42X78 SLG-GO-LONG-MSH-56X78
GoHygiene Polyester SLG-GO-HYGIENE-WV-S SLG-GO-HYGIENE-WV-M SLG-GO-HYGIENE-WV-L SLG-GO-HYGIENE-WV-XL
GoComfort Polyester SLG-GO-COMFORT-WV-S SLG-GO-COMFORT-WV-M SLG-GO-COMFORT-WV-L SLG-GO-COMFORT-WV-XL
Guidelines For Choosing Your Sling Size
S M L XL
Height 31.4 - 34.5" / 798 - 876 mm 33.4 - 36.2" / 848 - 820 mm 35.4 - 38.2" / 899 - 970 mm 37.4 - 41.3" / 950 - 1049 mm
Width 14.2 - 15.8" / 361 - 401 mm 15.4 - 17" / 391 - 432 mm 16.5 - 17.7" / 419 - 450 mm 19 - 20.5" / 483 - 521 mm
Washing Instructions
176°F
80°C
Normal washing at indicated
temperature
Do not bleach Tumble dry low Do not iron Do not dry clean

www.amico.com 19
GoTrack Systems and Support Structure
GoTrack Configurations
We offer three different track profiles, as well as
modular and custom configurations that come in:
• Straight Track
• Curved Systems
• Full Room Coverage (X/Y or H Systems)
• Optional Infection Control Track
• Optional recessed, flush mount track
systems
All GoTrack Systems feature:
• Low weight and high capacity
• Fast and flexible installation
• Hidden Endstops for safety
• Anywhere charge
Approved by:
PROJECT MANAGER : ___________________
ENGINEERING : __________________________
PRODUCTION : __________________________
REV. DESCRIPTION BY DATE
5
4
3
1
55 East Wilmot St.
Richmond Hill, Ontario
L4B 1A4, CANADA
Tel: [phone]
Fax: [phone]
DESCRIPTION:
PART NO:
SHEET:
OF
DRAWING NO:
11
PROJECTION
PRIVATE AND CONFIDENTIAL
THIS PRINT IS PROPERTY OF AMICO CLINICAL AND IS LOANED IN CONFIDENCE SUBJECT TO RETURN UPON
REQUEST AND WITH THE UNDERSTANDING THAT NO COPIES ARE TO BE MADE WITHOUT THE CONSENT OF
AMICO CLINICAL.
ALL RIGHTS TO DESIGN OR INVENTION ARE RESERVED
DATE:
DATE:
CHECKED BY:
DRAWN BY:
NTS
SCALE:
2
A
B
C
D
FINISH:
MATERIAL:
YYMMDD-XXX
UNLESS SPECIFIED:
ALL DIMENSIONS IN INCHES
SURFACE FINISH 63 uin
BREAK ALL EDGES 0.005 - 0.010
REMOVE SHARP EDGES AND BURRS
ANGLE TOLERANCES 0.25
CONCENTRICITY OF 0.005"
STRAIGHTNESS & FLATNESS
PARALLELISM
DECIMAL TOLERANCES: X.XX .05
X.XXX .005
X.XXXX .0005
Regular
Approved by:
PROJECT MANAGER : ___________________
ENGINEERING : __________________________
PRODUCTION : __________________________
REV. DESCRIPTION BY DATE
5
4
3
1
55 East Wilmot St.
Richmond Hill, Ontario
L4B 1A4, CANADA
Tel: [phone]
Fax: [phone]
DESCRIPTION:
PART NO:
SHEET:
OF
DRAWING NO:
11
PROJECTION
PRIVATE AND CONFIDENTIAL
THIS PRINT IS PROPERTY OF AMICO CLINICAL AND IS LOANED IN CONFIDENCE SUBJECT TO RETURN UPON
REQUEST AND WITH THE UNDERSTANDING THAT NO COPIES ARE TO BE MADE WITHOUT THE CONSENT OF
AMICO CLINICAL.
ALL RIGHTS TO DESIGN OR INVENTION ARE RESERVED
DATE:
DATE:
CHECKED BY:
DRAWN BY:
NTS
SCALE:
2
A
B
C
D
FINISH:
MATERIAL:
YYMMDD-XXX
UNLESS SPECIFIED:
ALL DIMENSIONS IN INCHES
SURFACE FINISH 63 uin
BREAK ALL EDGES 0.005 - 0.010
REMOVE SHARP EDGES AND BURRS
ANGLE TOLERANCES 0.25
CONCENTRICITY OF 0.005"
STRAIGHTNESS & FLATNESS
PARALLELISM
DECIMAL TOLERANCES: X.XX .05
X.XXX .005
X.XXXX .0005
Double
Approved by:
PROJECT MANAGER : ___________________
ENGINEERING : __________________________
PRODUCTION : __________________________
REV. DESCRIPTION BY DATE
5
4
3
1
55 East Wilmot St.
Richmond Hill, Ontario
L4B 1A4, CANADA
Tel: [phone]
Fax: [phone]
DESCRIPTION:
PART NO:
SHEET:
OF
DRAWING NO:
11
PROJECTION
PRIVATE AND CONFIDENTIAL
THIS PRINT IS PROPERTY OF AMICO CLINICAL AND IS LOANED IN CONFIDENCE SUBJECT TO RETURN UPON
REQUEST AND WITH THE UNDERSTANDING THAT NO COPIES ARE TO BE MADE WITHOUT THE CONSENT OF
AMICO CLINICAL.
ALL RIGHTS TO DESIGN OR INVENTION ARE RESERVED
DATE:
DATE:
CHECKED BY:
DRAWN BY:
NTS
SCALE:
2
A
B
C
D
FINISH:
MATERIAL:
YYMMDD-XXX
UNLESS SPECIFIED:
ALL DIMENSIONS IN INCHES
SURFACE FINISH 63 uin
BREAK ALL EDGES 0.005 - 0.010
REMOVE SHARP EDGES AND BURRS
ANGLE TOLERANCES 0.25
CONCENTRICITY OF 0.005"
STRAIGHTNESS & FLATNESS
PARALLELISM
DECIMAL TOLERANCES: X.XX .05
X.XXX .005
X.XXXX .0005
Triple

20 Amico Mobility Solutions Corporation
GoTrack Systems and Support Structure
Description Part Number Length x Width x Height Product Weight Material
Regular
TRK-REG-100 100" x 2.63" x 2.36"
2540 mm x 67 mm x 60 mm
21 lbs
9.5 kg
White powder coated extruded aluminum
TRK-REG-120 120" x 2.63 "x 2.36"
3050 mm x 67 mm x 60 mm
25 lbs
11.3 kg
TRK-REG-150 150" x 2.63" x 2.36"
3810 mm x 67 mm x 60 mm
32 lbs
14.5 kg
TRK-REG-240 240" x 2.63" x 2.36"
6100 mm x 67 mm x 60 mm
51 lbs
23.1 kg
Double
TRK-DBL-95 95" x 2.63" x 3.55"
2413 mm x 67 mm x 90 mm
25 lbs
11.4 kg
TRK-DBL-120 120" x 2.63" x 3.55"
3050 mm x 67 mm x 90 mm
32 lbs
14.5 kg
TRK-DBL-150 150" x 2.63" x 3.55"
3810 mm x 67 mm x 90 mm
40 lbs
18.1 kg
TRK-DBL-180 180" x 2.63" x 3.55"
4570 mm x 67 mm x 90 mm
48 lbs
21.8 kg
Triple
TRK-TRP-120 120" x 2.63" x 5.75"
3050 mm x 67 mm x 146 mm
38 lbs
17. 2 kg
TRK-TRP-156 156" x 2.63" x 5.75"
3960 mm x 67 mm x 146 mm
49 lbs
22.2 kg
TRK-TRP-180 180" x 2.63" x 5.75"
4570 mm x 67 mm x 146 mm
57 lbs
25.9 kg
TRK-TRP-240 240" x 2.63" x 5.75"
6100 mm x 67 mm x 146 mm
76 lbs
34.5 kg
