Access Code Logins
Unified Visitor Management
amigopod Technical Note
Revision 1.0
30 September 2010
United States of America
[phone]
Europe, Middle East & Asia
[phone]
Australia & Pacific
[phone]
http://www.amigopod.com

Access Code Logins Version 1.0
CONFIDENTIAL 2
Table of Contents
Introduction ..............................................................................................................................3!
Audience ..............................................................................................................................3!
Document Overview .............................................................................................................3!
Disclaimer.............................................................................................................................3!
Confirming Compatibility ..........................................................................................................4!
Check Plugin Versions .........................................................................................................4!
Customizing Guest Manager ...................................................................................................5!
Customize Random Username and Passwords...................................................................5!
Create a Print Template...........................................................................................................6!
Create the Print Template ....................................................................................................6!
Edit the Print Template.........................................................................................................6!
Customize Create Multi............................................................................................................8!
Add username_auth the the Field List .................................................................................8!
Create Multiple Accounts.........................................................................................................9!
Create Multi..........................................................................................................................9!
Create Multi Results.............................................................................................................9!
Print Cards .........................................................................................................................10!
Creating a Web Login Page...................................................................................................12!
Create a Web Login ...........................................................................................................12!
Testing Authentication ...........................................................................................................16!
WLAN Controller and Access Point setup..........................................................................16!
Authenticating.....................................................................................................................16!
Troubleshooting..................................................................................................................17!
Invalid username or password........................................................................................17!
Logging in timeout ..........................................................................................................17!
WLAN Authentication Failure .........................................................................................17!

Access Code Logins Version 1.0
CONFIDENTIAL 3
Introduction
This technical note explains the creation of bulk accounts and a login page
that require a single access code for access to the network.
This method of authentication can be convenient for short-term access where
security does not play as important of a role as security.
The accounts will be valid for 1 year, or 4 hours after the account first logs on.
NOTE The default username and password based authentication remains the
preferred and recommend deployment for guest access.
Audience
This document is intended for network administrators and system integrators
deploying an amigopod-based visitor management solution.
Basic familiarity with the amigopod Visitor Management Appliance is
assumed. For in-depth information about the features and functions of the
amigopod appliance, refer to the amigopod Deployment Guide.
Document Overview
The first section of the document explains configuring guest manager to
create multiple accounts with the ability to login in with only the username.
We will refer to this as an Access Code.
The next section will explain creating a web login that only requires the
access code for entry onto the system
Finally, we will show you how to test the authentication.
Disclaimer
The topics of network design, security architectures and visitor access are
complex subjects, and no single document can hope to cover all of the
possible combinations of network equipment, network design, deployment
requirements, and device configurations, nor can all the possible security
implications for a particular recommendation be covered.
Therefore, while you read this document, it is best to consider it as a guide to
developing your own understanding of the network design topics covered,
and as a basis for further investigation.

Access Code Logins Version 1.0
CONFIDENTIAL 4
Confirming Compatibility
Check Plugin Versions
Access Code logins requires the following plugin versions:
amigopod RADIUS Services 3.0.4 or later
GuestManager Plugin 3.0.3
To verify you have the correct plugin versions installed, navigate to
Administrator > Plugin Manager > Manage Plugins and check the version
number in the list.
Use the Update Plugins link to download and install updated plugins.

Access Code Logins Version 1.0
CONFIDENTIAL 5
Customizing Guest Manager
Customize Random Username and Passwords
In this example we will set the random usernames and passwords to be a mix
of letters and digits. Navigate to Guest Manager > Customization >
Customize Guest Manager.
We have chosen an 8character Random letters and digits username, and a
Password Complexity of digits for the password. Note that the generator
matching the complexity will also include a mix of upper and lower case
letters.
Our accounts will be created with an expiration of 1 year and a lifetime of 4
hours. By default the expiration list does not have a value for 1 year. We
have added 8736 (24 * 365) as an additional value.

Access Code Logins Version 1.0
CONFIDENTIAL 6
Create a Print Template
By default, the print templates include username, password, expiration, as
well as other options. For the purpose of access codes, we only want the
username presented.
Create the Print Template
We will base our print template off one of the existing scratch card templates.
Navigate to Guest Manager > Customization > Print Templates and select
Two-column scratch cards and click Duplicate.
Edit the Print Template
We need to replace Username for Access Code, as well as remove the
extraneous data.
The exact text is provided below.
<table {$table_class_content}>
<thead>
<tr>
<th class="nwaTop" colspan="3">Access Details</th>

Access Code Logins Version 1.0
CONFIDENTIAL 7
</tr>
</thead>
<tbody>
<tr>
<td class="nwaBody" rowspan="99" valign="top"><img
src="images/icon-user48.png" width="48" height="48" border="0"
alt=""></td>
<th class="nwaLeft">Access Code</th>
<td class="nwaBody"
style="width:12em">{$u.username|htmlspecialchars}</td>
</tr>
{if $u.create_result.error}
<tr>
<th class="nwaLeft">Error</th>
<td class="nwaBody"><span
class="nwaError">{$u.create_result.message}</span></td>
</tr>
{/if}
</tbody>
</table>

Access Code Logins Version 1.0
CONFIDENTIAL 8
Customize Create Multi
Create Multi is the screen used to generate accounts with random usernames
and passwords. We need to modify it to add a flag to accounts to allow the
access-code based authentication.
Add username_auth the the Field List
Navigate to Guest Manager > Customization > Customize Forms & Views
and select create_multi and then click Edit Fields. Look for a field named
username_auth.
If the field exists, but is not bolded and enabled, click Enable Field.
If the field does not exist, select a field that does (num_accounts) and select
Insert After. Select username_auth from the Field Name dropdown and
allow the page to refresh. The defaults should be acceptable, but feel free to
customize the label or description.
Once the field is enabled or inserted, you should see it bolded in the list of
fields.

Access Code Logins Version 1.0
CONFIDENTIAL 9
Create Multiple Accounts
With the account generation customized, we can now create our accounts.
Create Multi
Navigate to Guest Manager > Create Multi (or select Use this form from the
previous fields list). We will create 10 accounts that will expire in 1 year, or 4
hours after they first log in, whichever comes first.
NOTE Note that the Username Authentication field we added must be selected.
Otherwise if the username is entered on the login screen, the authentication
will be denied.
Create Multi Results
After clicking Create Accounts, the results page will be displayed with a list of
accounts. If a large number of accounts are created at one time they may not
all be displayed at the same time. This will not effect the printing action

Access Code Logins Version 1.0
CONFIDENTIAL 10
Confirm that the accounts settings are as you expected with respect to letters
and digits in the username and password, expiration, and role.
Print Cards
Select the new print template from the dropdown at the bottom of the table. A
new window or tab will open with the cards.

Access Code Logins Version 1.0
CONFIDENTIAL 11
NOTE Your method of printing and delivery to the customer should define the print
template used in production. If you have a label printer, or cards, they should
be tested prior to the creation of the actual accounts.

Access Code Logins Version 1.0
CONFIDENTIAL 12
Creating a Web Login Page
The web login will need to be customized to hide the password, and check for
accounts with the username_auth flag set.
Create a Web Login
Navigate to RADIUS Services > Web Logins and click Create a new web
login page at the bottom of the table.
In our example we will create a page called access_codes that has been
customized to our liking.
In order to provide access-code based authentication, we must also enable
the Pre-Auth Check.

Access Code Logins Version 1.0
CONFIDENTIAL 13
We also update the helper text to remove mention of username or password.

Access Code Logins Version 1.0
CONFIDENTIAL 14
Click Save Changes to create the web login.
Select Test to open the login page in a new window or tab.

Access Code Logins Version 1.0
CONFIDENTIAL 15

Access Code Logins Version 1.0
CONFIDENTIAL 16
Testing Authentication
WLAN Controller and Access Point setup
Please refer to your WLAN reference documentation where to configure the
external redirection URL. Enter the URL as it appeared when clicking Test.
As a proof of concept, some of the below steps can be used without being
connected to the WLAN. However the test will not do complete a RADIUS
authentication to verify the complete setup.
Authenticating
Connect to the WLAN and open your browser to a web page. You should be
redirect to the web login configured above. Enter one of the access codes
generated previously.
Select Log In and you should briefly see a logging in message, followed by a
successful authentication with the WLAN.

Access Code Logins Version 1.0
CONFIDENTIAL 17
Troubleshooting
Invalid username or password
If you receive the error Invalid username or password, it could be due to an
username that does not exist, which you can check in the List Accounts list. It
could also be due to not selecting Allow visitor access using their
username only while creating the accounts. To verify the flag, you can add
username_auth to the List Accounts column view (guest_users), or the
guest_edit form, and then edit the user.
Logging in timeout
If you sit on the logging in page until it times out, confirm that you have
entered the WLAN settings correctly on the web login page.
WLAN Authentication Failure
If you get an error regarding authentication from the WLAN, ensure your
RADIUS settings, especially the shared secret are configured correctly.
RADIUS Services > Server Control > Debug RADIUS Server can be very
useful in determining errors.
