AmLed Technologies TFS Series User manual

1035 N Hilltop Dr Itasca, Illinois 60143 1-844-787-5858 Fax: [phone] www.amledtechnologies.com 1
®®
INSTALLATION INSTRUCTIONS
PLEASE READ ENTIRE DOCUMENT BEFORE INSTALLATION
TFS series luminaires
SAFTEY INSTRUCTIONS AND WARININGS
WARNING:
Risk of re or electric shock, LED Troer luminaire installation requires
knowledge of luminaires electrical systems. if not qualied, do not
attempt installation.
Be certain electrical power is OFF before and during installation and
maintenance. LED Troer luminaire must be connect to wiring system
with an equipment-grounding conductor. Make sure the supply
voltage is same as the rated luminaire voltage
Only those open holes indicated in the photograph and/or drawing
may be made or altered as a result of this kit installation. Do not
leave any other open holes in an enclosure of wiring or electrical
components.
To prevent wiring damage or abrasion, do not expose wiring to edge
of sheet metal or sharp objects.
No user serviceable parts inside of LED Troer Luminaire

TFS Series Installation Instruction
®
2
1035 N Hilltop Dr Itasca, Illinois 601431-844-787-5858Fax: [phone] www.amledtechnologies.com
LED+(RED)
LED-(BLACK) LED ARRAY
LED DRIVER
YELLOW & GREEN
WHITE
BLACK
PURPLE
GRAY

Powered by solar cell or optical energy.
USB charging is available.
Flame Retardant Rating
Bluetooth
3V(5V for
USB charging)
Communication way
UL 94 V-0
Working Condition Humidity ≤90%RH
Work Condition Temperature -10~45℃
Supply Voltage
70g
No external connection, Easy installation.
N.W/Product
Bluetooth communication.
86±1
L (mm)
LT-S-06-115
Item H(mm)
12.5±186±1
W(mm)
Remark:
Do not use it in the metal region and
the strong electromagnetic wave area.
*Pressing button 1 and 3 together over
2 seconds achieves reset function and
enters pairing mode for 30 seconds. Then,
switch can be added by APP searching
within 30 seconds.
*Light or light group can be associated.
Dim Raise
Dim Lower
ON/OFF
Scene Switching:
three scenes at most
Auto-brightness
according to the
APP default
®
3
1035 N Hilltop Dr Itasca, Illinois 601431-844-787-5858Fax: [phone] www.amledtechnologies.com
Dual Power Wireless Wall Switch
FEATURES
REMARK
SPECIFICATION
BUTTON FUNCTION
