1 Introduction
SmartTerminal has been designed for use with the LoopSense series of FACP’s.
4 line by 40 character LCD with backlight and navigation keys keys allow the
SmartTerminal to be used for FACP operation and interrogation. Note the backlight is only
energised when alarms are present, a key has been pressed or controls enable key switch is
enabled
Buzzer and system Reset.
System expansion capabilities / options:
A wide range of secure user functions. This includes the ability to disable / re-enable a large
number of system functions.
Flush or surface mountable enclosure.
Controls have tactile and audible feedback of operation.
All terminals cater for 2.5mm cables.
SmartTerminal connects to the LoopSense Fire Alarm Control Panel (FACP) via the RS485
multidrop communication port. Generally it is designed to be used anywhere where the status of the
FACP is required to be monitored by local personnel and limited control is required.
Front panel controls that allow the resetting of alarms and activation/silencing of alarm
devices. Enabling operational access to the controls is via a key-switch;
Reports events from devices that are accessible to the host FACP. For example if the host
FACP is configured with global access then the connected SmartTerminal reports events
from all devices. If the host FACP is configured as local then the connected SmartTerminal
reports events from devices that are directly connected to the host FACP.
SmartTerminal essentially consists of two PCBs;
1. SmartTerminal Termination Board. A Termination Board is mounted in each SmartTerminal
to protect and interface the RS485 communications and 27VDC supply to the LCD Board
2. BRD82ICC – Control, LCD Communications and LCD Driver Board
SmartTerminal can be supplied in two styles;
1. BX05: Slim line SmartTerminal
2. BX1: Standard SmartTerminal
Note:A maximum of 30 SmartTerminal’s may be connected to the communications bus over a
distance of approximately 1.2Kms

Europe SmartTerminal Installation Commissioning & Operation
Page 5
2 Mechanical
SmartTerminal is supplied in an ABS cabinet and consists of;
The Main Card, with all controls and indicators mounted directly onto it
1 X Termination Board
2 X ABS door keys
2 X 003 Enable / Disable keys
2 X Jumper links
The front door of the ABS version is locked by way of two clips on the right hand side of the cabinet.
A special locating key which has two raised pins that are inserted into the side of the cabinet unlocks
the door.
DOOR RELEASE PINS
DOOR RELEASE PINS
Figure 1: ABS Door Key
2.1 Mounting the Enclosure
The panel MUST be mounted in an area that is NOT subject to conditions likely to affect its
performance, e.g. damp, salt-air, water ingress, extremes of temperature, abuse etc. is at an easily
accessible height and such that the indicators are at eye level.
Typical locations for the panel are the first and most obvious point of contact for emergency services
or a security office that is likely to be permanently staffed.
2.1.1 Enclosure Details
The LCDA can be surface or semi-flush mounted, is supplied with a detachable front door,
mountable back box and a minimum of two separate PCBs.
2.1.2 Fixing the Chassis to the Wall
Taking into account the weight of the panel securely mount it by using the three keyhole mounting
holes in the backpan, two in the top and one in the bottom. Use suitably sized screws and plugs for
the type of mounting surface.
Caution: Any dust or swarf created during the fixing process must be kept out of the cabinet and
great care should be taken not to damage any wiring or components.

Europe SmartTerminal Installation Commissioning & Operation
Page 6
2.1.3 Board Removal / Replacement
If a PCB has to be removed the following precautions should be observed;
Removing the door will provide better access to the boards and will ensure the hinges are
not accidentally stressed.
Personal anti- static procedures must be followed.
When disconnecting the RJ45 style connecting cable from the PCB, make sure that the
cable remains connected to at least one board to prevent it being misplaced.
Push Tab Inwards
and Gently Pull
the Connector
From the Socket
Connector
Note: Care should be taken when detaching this connector as it is necessary to depress the
small locking tab to unlock the connector from its base. To reconnect the cable the connector must
first be correctly aligned then pushed into the socket so it locks into position.
Carefully remove the retaining screws at each corner of the board taking care not to damage
any of the components.
Place each board into anti- static storage once removed.

Europe SmartTerminal Installation Commissioning & Operation
Page 7
2.1.4 Removing the Knockouts
The knock-outs should be removed with a sharp tap in the rim of the knock-out using a flat broad-
bladed screwdriver. Note: Use of excessive force could damage the enclosure around the knock-out.
Note: BX05 shown the BX1 is set out in a similar manner.
Note: Any unused knock-outs must be securely blanked off.
TO REMOVE THE FRONT DOOR
SLIDE THE TOP AND BOTTOM
HINGE PINS OUT OF THE HINGES
TAP AROUND
RIM TO
REMOVE
KNOCKOUTS
FRONT DOOR
KEY SUPPLIED
TAPED TO TOP
OF ENCLOSURE
ENABLE / DISABLE KEY
SUPPLIED TAPED TO INSIDE
OF ENCLOSURE
CONTROL
PANEL CLIPS
INTO FRONT DOOR
INSERT KEY
TABS HERE
TO UNLOCK
ENCLOSURE
CONNECT BRD82LTB
CN1 TO BRD82ICC
CN5
BRD82ICC
BRD82LTB
HINGE PIN 1
HINGE PIN 2
Figure 2: Exploded View
BRD82LTB
KNOCKOUTS
CN1
R 6mm.
12 mm
KEY HOLE
MOUNTING
HOLE
0V
POWER OUT
POWER IN
+24V
RS485 IN RS485 OUT
03/05/2006 BRD82LTB2-
TB2 TB1 TB4
TB3
LK1
COM
-+
COM
-+
0V
+24V
195mm
39 mm
324mm
213mm
127mm
304mm
175mm
Figure 3: Typical Layout (Externally Powered) and Location of Keyholes

Europe SmartTerminal Installation Commissioning & Operation
Page 8
3 Installation & Cabling
The SmartTerminal is then connected to the FACP as shown below.
TERMINATION BOARD No.1 ( BRD82LTB2 )
SmartTerminal 1
SmartTerminal 2
(IF FITTED)
SHIELDED COMMS CABLE
TO NEXT LCDA
MAXIMUM OF 30
LK1 MUST BE FITTED TO
THE LAST BOARD ON
THE COMMS BUS
+24VDC
TERMINATION BOARD No.2 ( BRD82LTB2 )
TO
LCD
TO
LCD
CN1
0V
POWER OUT
POWER IN
+24V
RS485
IN
RS485
OUT
03/05/2006 BRD82LTB2-
TB2 TB1 TB4
TB3
LK1 NOT FITTED
COM
-
+COM
-
+
0V
+24V
CN1
0V
POWER OUT
POWER IN
+24V
RS485 IN RS485 OUT
03/05/20 06 BRD82LTB2-
TB2 TB1 TB4
TB3
COM
-+
COM
-
+
0V
+24V
+24V
0V
VDC
IN
VDC
OUT
0V
USB
0V
AUX OUT1
3
2
1
OUT2
OUT1
+VE
COMMS
SGD
+VE +VEA+
0V+27V
INPUTS MONITOR ED O/PSLOOP 1 LOOP 2
B- RS485+ RS485- SHD 2+ 3+ 4+COM 1+ 2+
AUX OUT2
2- 3- 4-3+1+ 4+1-
ETH
+27V 0V
DIAGNOSTICS RS232
RS485
TERM
LOAD
RESET
HLI
PORT
PWR IN
N/O CN/C N/O CN/C N/O CN/C
REL AY 1 RELAY 2 RELAY3 COMMS
A- B+ B+A- B-A+
JTAG
JTAG
SEL
1
2
3
DIAGNOSTICS
CN11
TB1 U2U1 U4U3 TB6
R47
R1
CN1
D4
D1 D2
CN10
CN2
CN8
TB4
TB2 TB5TB3
SW1
D3
K3
R38
R4 R5 R6 R7
10K
10K
10K
10K 10K 10K 10K 10K
CONTROLS
SHIELD
MAIN CONTROL BOARD
Figure 4: Connecting SmartTerminal to the FACP
3.1 SmartTerminal Termination Board Interconnection
Terminal Block
TB1 (RS485 OUT) TB2 (RS485 IN) Purpose
1 (Pin Number) RS485 +ve
2 RS485 -ve
3 SCREEN
Terminal Block
TB4 (27VDC OUT) TB3 (27VDC IN)
1 (Pin Number) 0V
2 +24VDC
3.2 FACP Comms
Terminal Block
TB1 (RS 485 OUT) Purpose
1 (Pin Number) RS485 +ve
2 RS485 -ve
3 SCREEN
Terminal Block
TB4 (27VDC OUT)Number Purpose
1 0V
2 +24VDC

Europe SmartTerminal Installation Commissioning & Operation
Page 9
4 Setting the Address
