AmRad CAPACITANCE TURBO DSC TESTER User manual

INSTRUCTION MANUAL FOR
NOTICE:
The information contained in this document is subject to change without notice.
AMRAD MANUFACTURING MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS MATERIAL,
INCLUDING, BUT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE. AMRAD MANUFACTURING Shall not be liable for errors contained herein or for
incidental consequential damages in connection with the nishings, performance, or use of this material.
This document contains proprietary information which is protected by copyright. All rights reserved.
© Copyright 2018 by AmRad Manufacturing, all right reserved.
THIS DOCUMENT CONTAINS IMPORTANT INFORMATION
This manual must be read and understood before use of the meter.
CAPACITANCE TURBO®METER
Part # DSC TESTER
Please refer to the AmRad website (www.amradmanufacturing.com)
for information relating to AmRad Instruction Manual, Products, etc.
PATENT NUMBER: 7,619,420
AmRad Manufacturing
32 Hargrove Grade
Palm Coast, FL 32137
1-800-445-6033
1
1
Rev: 10/21.00

Switch in A
Position
Blue
25mfd
Yellow
20mfd
Red
10mfd
Green
2.5mfd
White
5mfd
White
5mfd
STEP 1
Turn meter on by depressing the ‘red power’
button. Attach common lead wire from capacitor meter
to common(center terminal) of capacitor.
Switch in A
Position
Blue
25mfd
Yellow
20mfd
Red
10mfd
Green
2.5mfd
White
5mfd
White
5mfd
STEP 2
Attach yellow lead of the capacitor meter to
the 5mfd (white terminal). The reading on the meter will
show approximately 5.0mfd (left hand side).
Switch in A
Position
Blue
25mfd
Yellow
20mfd
Red
10mfd
Green
2.5mfd
White
5mfd
White
5mfd
STEP 3
Attach a “jumper” wire from the 5mfd to the
2.5mfd (green terminal). The reading will now show
approximately 7.5mfd. You have now created the
necessary “fan” capacitor.
Jumper #1
STEP 4
Attach the red lead of the capacitor meter to
the 10mfd terminal (red). It will show approximately
10mfd on the screen (right hand side).
Green
2.5mfd
Switch in A
Position
Blue
25mfd
Yellow
20mfd
Red
10mfd
White
5mfd
White
5mfd
Jumper #1
STEP 5
Attach a “jumper” wire from the 10mfd
terminal to the 20mfd terminal (yellow). You will now
see approximately 30mfd on the capacitance meter.
Green
2.5mfd
Switch in A
Position
Blue
25mfd Yellow
20mfd
Red
10mfd
White
5mfd
White
5mfd
Jumper #1
Jumper #2
STEP6
Attach a “jumper” wire from the 20mfd
terminal to the 25mfd terminal (blue). You will now see
approximately 55mfd on the capacitance meter.
Green
2.5mfd
Switch in A
Position
Blue
25mfd Yellow
Jumper #3
20mfd
Red
10mfd
White
5mfd
White
5mfd
Jumper #1
Jumper #2
00 5.8 00 00
7.5 7.500 10
7.5 7.530 55
How to measure a Dual 55/7.5 microfared (mfd) capacitor
wired using a TURBO200®UNIVERSAL REPLACEMENT CAPACITOR
NOTES: Do not test the capacitor when it is connected to a live circuit. In addition, be sure to discharge the capacitor before testing it with the meter.

How to measure the capacitance of the TES5 –
AMRAD’S UNIVERSAL TURBO®EASY-START
P.R.
Switch in B
Position
a) Switch meter to position B
b) Attach the Black wire (com) from the meter to
the center black terminal of the TES5
c) Attach the Red wire from the meter to the WHITE
terminal of the TES5*
d) A capacitance reading of 108mfd to 130mfd will
appear in the RIGHT SCREEN of the meter
12 0
a) Switch meter to position B
b) Attach the Black wire (com) from the meter to
the center black terminal of the TES5
c) Attach the Red wire from the meter to the WHITE
terminal of the TES5*
d) Using colored jumper wire supplied–connect the
PURPLE, YELLOW and RED terminals together
e) A capacitance reading of 233mfd to 280mfd will
appear in the RIGHT SCREEN of the meter
P.R.
Switch in B
Position
260
a) Switch meter to position B
b) Attach the Black wire (com) from the meter to
the center black terminal of the TES5
c) Attach the Red wire from the meter to the WHITE
terminal of the TES5*
d) Using colored jumper wire supplied–connect the
PURPLE, YELLOW, RED and BROWN terminals
together
e) A capacitance reading of 270mfd to 324mfd will
appear in the RIGHT SCREEN of the meter
P.R.
Switch in B
Position
300
a) Switch meter to position B
b) Attach the Black wire (com) from the meter to the
center black terminal of the TES5
c) Attach the Red wire from the meter to the White
terminal of the TES5*
d) Using the colored jumper wire supplied-connect the
PURPLE and YELLOW terminals together
e) A capacitance reading of 189mfd to 227mfd will
appear in the RIGHT SCREEN of the meter
P.R.
Switch in B
Position
20512 0
* Up to 1 ton
108-130mfd
* 2.5-3 tons
233-280mfd
* 1-2 tons
189-227mfd
* 3.5-5 tons
270-324mfd
NOTES: Do not test the TES5 when it is connected to a live circuit. In addition, be sure to discharge the TES5 before testing it with the meter.

US PATENT NUMBERS:
RE29,126; 4,028,595; 4,263,638; 4,312,027; 4,352,145; 4,558,394; 4,633,365; 5,001,597; 5,313,360; 6,014,308; 6,313,978; 7,203,053; 7,423,861; 7,474,519;
7,619,420; 7,765,712; 7,835,133; 7,911,762; 7,952,854; 8,037,616; 8,270,143; 8,296,965; 8,456,795; 8,531,815; 8,537,522; 8,885,318; 8,891,224; 9,316,474;
9,318,261; 9,324,501; 9,335,026; 9,343,238; 9,378,893; 9,412,521; 9,424,995; 9,496,086; 9,536,670; 9,859,060; 9,944,364; D818,437; D818,959; 10,054,417;
10,056,194; 10,056,195; D829,173; 10,134,528; 10,147,549; 10,147,550; 10,163,571; 10,249,439; 10,366,840; 10,464,641; 10,475,588, 10,497,518;
10,497,520; 10,586,655; ULTRAMET®; EASY-START®; TURBOLYTIC®; TURBO 200®; AMRAD®; AMERICAN RADIONIC COMPANY, INC.®;
AMRAD ENGINEERING®; CPT®; COMPRESSOR PROTECTOR TERMINAL®; PULSECAP®.
AmRad Manufacturing, LLC, is the sole owner of these patents and trademarks.
TURBO200®Mini-Oval – Replaces single value (“fan size”) motor-run capacitors up to 15mfd at 370VAC - 440VAC
TURBO200®– Replaces over 200 single and dual capacitors up to 67.5mfd at 370VAC - 440VAC
TURBO200®Mini – Offers 7 popular single values (“fan size”) up to 15.0mfd
TURBO200X®– Replaces over 350 single and dual capacitors up to 97.5mfd at 370VAC - 440VAC
TURBOLYTIC JUNIOR – 12 of the most popular “motor-start” values in one compact, hermetically - sealed aluminum can
TURBOLYTIC 50 – Universal replacement motor - Start Capacitor - 50 popular values up to 302mfd at 330VAC
TES5 – Universal replacement hard start - replaces hard start kits up to 5 tons with encapsulated potential relay
TES5EXT – Universal replacement hard start - replaces hard start kits up to 5 tons with external potential relay
TURBOMETER – Dual Screen Capacitance Meter
5
5
3
3
www.amradmanufacturing.com
AMRAD FAMILY OF PRODUCTS FOR THE HVACR SERVICE INDUSTRY
Turbo® Capacitors, Turbolytics and TES5 have a FIVE-YEAR warranty
from the date of installation. TES5EXT has a THREE-YEAR warranty and
the Turbo Meter has a ONE-YEAR warranty.
For an authorized wholesaler nearest you, please contact
Global at 800-531-5967 or
AmRad at 800-445-6033
32 Hargrove Grade
Palm Coast, FL 32137
For Technical Questions/Support
800-445-6033
GLOBAL
Exclusive Distributor
