1. 2.
USER’S MANUAL
Adaptor cable
* Camera and original monitor are not included. All the AMS cameras are compatible with this adaptor cable (except wireless camera)
FENDT ADAPTOR CABLE (HARVESTER)
• CONNECTION TO THE SCREEN
Adaptor cable
FT COMBINE
AMS
Camera *
· CONNECT AMS CAMERAS TO YOUR VARIOTRONIC MONITOR
Monitor
VARIOTRONIC
1 video input
Item code : VICAM-AMS-FT-COMBINE
Remove the cover from the back of the
monitor (remove the 7 screws)
Remove the cap from the video input 2 to
locate the 5-way female connector
Adaptor cable
FT COMBINE
(5 way male connector)
This adaptor cable enables the use of the VARIOTRONIC monitor for Fendt harvester with an AMS camera.

SAFETY & COMFORT
4. 5.
6.
3.
Extension
cable
• VISUAL DISPLAY ON THE TOUCH-SCREEN
USER’S MANUAL
Adaptor cable
FENDT ADAPTOR CABLE (HARVESTER)
Monitor
VARIOTRONIC Feed the cable in the bracket
holding the monitor towards
the armrest
AMS
Camera
Press the Settings button To enable the video function:
press
Refer to your manufacturer’s
handbook to change your video
settings.

SAFETY & COMFORT
AMS Diffusion
Tél. [phone]
Fax. [phone]
cont[email protected]
Adaptor cable
USER’S MANUAL
FENDT ADAPTOR CABLE (HARVESTER)
AMS Diffusion - Rue des Galeries - ZA du Chevalement - 59286 Roost Warendin - FRANCE
RCS DOUAI A 451 360 382 - CODE APE 4531Z - SIRET 451 360 382 00035 - TVA FR 55 451 360 382 - V01-122017
• RECOMMENDATIONS
• WARRANTY
• AFTER SALES SERVICE
If your monitor VARIOTRONIC does not have a video input management system, contact AGCO for an
update of the system.
The product is guaranteed for two years as from the date of sale to the end user, remembering that the
sale must take place within 24 months after delivery to the concession.
Reserved for professionals
Download the service form from our site
When returning, please include the following documents for managing repairs and the warranty:
The return-authorisation form duly completed
A copy of the invoice with the date of sale to the end user
The reason for the claim, or a description of the malfunction.
For more information, contact our technical department
Tel : [phone] or @ : cont[email protected]
If you are the end user
Please go to your dealer.
