AMT GhostBusters ECTO-1 User manual

Model professionally assembled and finished by Mike Wherry
International Hobbycraft (UK) Ltd.
21 St. Thomas St.
Bristol BS1 6JS England
Contents include: All plastic pieces to complete
model, metal axles and pictorial instructions
describing assembly. Paint and glue not included.
SKILL
NIVEAU
NIVEL
1
round2models.com collectormodel.com
Round 2, LLC
4073 Meghan Beeler Ct.
South Bend, IN 46628
Ghostbusters and Christine TM & ©2013 Columbia Pictures Industries, Inc. All rights reserved. GENERAL MOTORS Trademarks
used under license to Round 2, LLC.Back to the Future ™ & © Universal Studios and U-Drive Joint Venture. POLAR LIGHTS, MPC,
AMT and design, and ROUND 2 and design are trademarks of Round 2, LLC. ©2013 Round 2, LLC, South Bend, IN 46628 USA.
Product and packaging designed in the USA. Made in China. All rights reserved.
ASSEMBLY MANUAL
POL914/12
1/25 scale model kit
Assembly: Carefully study and understand the
entire instruction sheet. Compare the parts in the box
to the instruction sheet to be sure you have received
all the parts required. Carefully remove parts from
trees. If subassemblies and components are painted
do so before any parts are attached. Use only cement
and paint made for styrene plastic.
Painting: Painting is optional and is not required
to complete kit.
Wash parts thoroughly with mild soap
and water. Parting lines, glue joints, and sharp edges
should be sanded or filled with filler putty designed for
plastic. Apply a "primer" coat and allow to dry. Check
parts for imperfections and repeat the procedure if
necessary. Remove any lint or dust. Apply paint
evenly, in several thin coats rather than one heavy
coat. Allow each coat to thoroughly dry before the next
is applied. Each coat should be carefully “wet
sanded” using slightly damp No. 1200 sandpaper. Be
careful not to remove any detail while sanding.
Lightest colors should be painted first. Use frosted
tape to mask off areas not to be painted. Remove tape
after paint is dry to the touch. Use a very fine brush to
touch up edges.
STICKERS: See back of instruction sheet for
proper application.
ECTO-1 INFORMATION
WHAT COULD BE MORE APPROPRIATE FOR CHASING
GHOSTS THAN A BLOCK-LONG ‘59 CADILLAC
AMBULANCE, SPECTACULARLY OUTFITTED WITH
ECTOPLASMIC SURVEILLANCE, DETECTION AND STORAGE
EQUIPMENT FOR THE ETHERIAL BOGIES? PLUS, ENOUGH
FLASHING LIGHTS TO LIGHT UP A SMALL TOWN?
WHY, NOTHING ELSE EVEN COMES CLOSE - IT IS THE
PERFECT VEHICLE FOR THIS SPOOKY JOB. WHETHER IT’S
SLIME IN YOUR REFRIGERATOR OR DANCING FURNITURE
OR REAL GHOSTS IN YOUR TV, THE ECTO-1 IS ALWAYS ON
CALL. AND WHO ARE YOU GONNA CALL?
GHOSTBUSTERS, THAT’S WHO! THEY BELIEVE YOU.
P914-200
STICKER
STICKER
NEW YORK
STICKER
X2
STICKER
X4
STICKER
NEW YORK
Last Touches.
Add the Ghostbusters™ stickers to the front doors and the
rear of the vehicle along with the Hubcap emblem stickers.
Place ECTO-1 license plates on the front and the rear.
STEP 4STEP 4 Look for these and other great kits from
AMT750
Ghostbuers™
ECTO-1A
POL91
Back to he Futre™
Time Machine
AMT801
Christne
1958 Plymouth Fry
For more information, visit: round2models.com
visit our blog at: collectormodel.com

STEP 1STEP 1 STEP 2STEP 2 STEP 3STEP 3
SCREWS
SCREWS
39
REAR BUMPER
& TAILLIGHTS
12
ASSEMBLED ROOF RACK
11
BODY
9
FRONT
WINDOWS
40
FRONT BUMPER,
GRILLE &
HEADLIGHTS
10
REAR
WINDOWS
38
ELECTRICAL
CONDUIT
37
LADDER
4
FRONT TIRE
3
WHITE SIDE
WALL INSERT
2
FRONT
WHEEL
METAL AXLE
2
FRONT WHEEL
4
FRONT TIRE
3
WHITE SIDE
WALL INSERT
2
REAR WHEEL
##
REAR TIRE
3
WHITE SIDE
WALL INSERT
1
CHASSIS
METAL AXLE
2
REAR WHEEL
3
WHITE SIDE
WALL INSERT
4
REAR TIRE
8
INTERIOR
7
STEERING
WHEEL
6
SHIFT SELECTOR
& TURN SIGNAL
5
DASHBOARD
25,26
SIREN
HALVES
36
WHIP
ANTENNA
22
FRONT
BULKHEAD
18
PARABOLIC
ANTENNA COVER
16
WEATHER
RADAR DOME
15
RADAR &
ANTENNA MAST
29
CLEAR COVER
14
AIR TANK
RIGHT
TAIL FIN
13
AIR TANK
12
ROOF RACK
35
DRIVER’S SPOTLIGHT
& MIRROR
11
BODY
30
LIGHT
30
LIGHT
30
LIGHT
30
LIGHT
31
LEFT TAIL FIN
34
DUCT
33
DUCT
28
LIGHT BAR
23,24
EQUIPMENT STORAGE
TUBE HALVES
27
SPOT
LIGHT
20
ELECTRON
CANNON
17
ANTENNA
BASE
19
CANNON
MOUNT
21
ELECTRON
CANNON
PYLON
STICKER
X2
or Red
STICKER
X2
or Red
28
LIGHT BAR
29
CLEAR COVER
Assemble the body of the ECTO 1.
Snap the Air tanks #13 & #14 to the left side of the Roof rack #12 – Snap the Front bulkhead #22 in place in the Roof rack #12. Install the Weather radar dome #16
on the Radar and antenna mast #15 and snap the assembled Mast to the left rear corner of the Roof rack #12. Install the clear Parabolic antenna cover #18 to the Antenna
base #17 – Snap the assembled Parabolic antenna to the rear of the Roof rack #12. Snap the Electron cannon mount #19 into the Cannon #20 – Snap the assembled
Cannon into the Electron cannon pylon #21 – Snap the pylon in place on the floor of the Roof rack #12. Snap the Equipment storage tube halves #23 & #24 together –
Then snap the assembled Tube to the right side of the Roof rack #12. Assemble the Siren parts #25 & #26 – Then snap the Siren and Spotlight #27 in place at the Front
of the Roof rack #12.
Install the Left tail fin #31 & Right tail fin #32 onto the Body #11. If you wish to add the Red Body-Side Stickers to your Model kit – DO SO NOW. Install the Ducts #33
& #34 to the left side and roof of the Body #11. Snap the assembled Roof rack #12 in place on the roof of the car Body #11. Snap the Clear covers #29 onto the Light
bars #28 – Snap the two assembled Light bars in place on the roof of the Body #11. Install four Lights #30 – Two to the front, and two to the rear of the roof. Install the
driver’s Spotlight & mirror #35 to the driver’s side door – Then attach the Whip antenna #36 to the top of the right front fender.
Assemble the chassis & the interior of the ECTO 1.
Assemble the White side wall inserts #3 onto the Wheels #2 – Snap these assemblies into the Tires #4. Press the assembled Wheels and Tires onto the Metal axles after
inserting the Axles into the holes in the Chassis #1.
Push the Steering wheel #7 through the Shift selector & Turn signal #6 – Then install the Steering column assembly in the Dashboard #5 – Snap the assembled
Dashboard into the Interior #8.
Final Assembly of the ECTO 1.
Snap the Front windows #9 and the Rear windows #10 into the Body #11. Install the Front bumper, grille & headlights #40 to the front of the Body #11. Install the Rear
bumper, grille & headlights #39 to the rear of the Body #11. Place the Interior assembly #8 into the Body #11 and fasten the Chassis assembly #1 into the Body #11
using the four Screws provided. Snap the Ladder #37 and the Electrical conduit #38 to the right side of the Body #11 and the Roof rack #12.
