AMT Crono S-PID 30 Operating instructions

Crono S-PID 30
Short Programming Guide - Flow Mode (mL/hr)
Pump activation and mode selection
The default delivery setting for the S-PID 30 is timed mode. This allows
programming of the duration of infusion. To change the mode of operation
remove and then replace the battery.
The pump will perform a short self test procedure during which a full screen
display of all elements should appear.
When the symbol [-t-] is displayed, press and hold the [P] button until the
display flashes. Press the [-] button until the display changes to [-F-]. Press
[P] to confirm and the pump will switch to [OFF] mode.
.Locking/unlocking the keypad
By default keyboard lock is not activated on this device.
With the pump displaying [OFF] press the (-) key for approximately 7
seconds. A number representing the number of completed infusions will
appear on the screen.
While still holding the [-] key depress the [+] key.The screen will display
flashing [L.0] and the keyboard is unlocked.
Use the (+) or (-) button to select required value. (L1 is on, L0 is off)
Caution: Users must familiarise themselves with the full user instructions.
These notes provide only a reminder of main functions.
This symbol will display when the keyboard is locked.

SG008/19BM
Start the infusion by pressing the [+/ON] button.
You are given the option to prime the infusion set [Pr]. Press and hold
the [P] button to deliver the required prime up to a maximum of 1.5mL.
Press the [+] button again to start the infusion at any time.
To change the infusion rate press the [+] button to display the current
flow rate . Press the [-] key until the screen symbols flash, and then
press the [+] button to increase, or the [-] button to reduce, the infusion
rate.
After 5 seconds this will be locked into the pump memory.
At the end of an infusion the plunger will automatically return to its
programmed start position
To return the plunger earlier, switch the pump into [StoP] mode by
pressing the [+] and [-] keys together. Then press the [P]and [-]
buttons together until [END] appears on the screen.
The syringe rubber plunger will not be withdrawn with this procedure.
With the keyboard unlocked, and the pump displaying [OFF] pressing
the [P] button will allow you to step through a menu to set the following
parameters in turn.
End of infusion alarm On/Off
Syringe Partial Volume 1ml steps
Press the [P] button to select alarm setting.
Use the (+) to set alarm on or (-) button to set alarm off
Press the [P] button to confirm value and select the partial volume
setting.
Press [-] button to reduce the volume or [+] button to increase.
Press the [P] button to confirm value and the pump will take a short
time to position the plunger at the programmed position.
Starting infusion and setting infusion time
Resetting plunger position
Programming the pump
Setting procedure
