Amtech Axpert-Eazy Series User manual

NOTICE
1. Read this manual thoroughly before using the Axpert-Eazy, and store in a safe place for reference.
2. Make sure that this manual is delivered to the final user.
200 V System, 11 kW (15 Hp) ~ 90 kW (125 Hp)
400 V System, 22 kW (30 Hp) ~ 1550 kW (2075 Hp)
500 V System, 30 kW (40 Hp) ~ 1550 kW (2075 Hp)
600 V System, 30 kW (40 Hp) ~ 1800 kW (2415 Hp)
Instruction Manual
Axpert-Eazy Series
AMTECH
IMAE-01, Rev. 1.20
JUL 2017
AMTECH

Amtech
ii

Axpert-Eazy AC Variable Frequency Drive
iii
TABLE OF CONTENTS
PREFACE
Precautions For Safety
CHAPTER
-
1
DELIVERY, INSPECTION AND STORAGE
1-1
Delivery, inspection and storage
1-2
Details of rating nameplate
CHAPTER
-
2
INSTALLATION AND WIRING
2-1
Installation environment
2-2
Precautions for power supply and motor wiring
2-3
Power terminal layout
2-4
Precautions for control signals wiring
CHAPTER
-
3
DIGITAL OPERATION PANEL
(LCD KEYPAD MODULE)
3-1
Drive status
3-2
Modes & parameters
3-3
Parameter display & setting
CHAPTER
-
4
T
EST OPERATION AND ADJUSTMENT
4-1 Preparation before turning power ON
4-2 Initialization of motor constants in Mode-B
4-3 Automatic tuning & adjustment
CHAPTER
-
5
CONTROL INPUT / OUTPUT TERMINALS
5-1
Input/output terminal functions of PCA-2014A/PCA-2004A
5-2
Programmable sequence input (PSI) wiring
5-3
Programmable analog input (PAI) wiring
5-4
Programmable analog output (PAO) wiring
5-5
Programmable sequence output (PSO) wiring
5-6
Programmable sequence output (Relay) wiring
5-7
Default function assignment to terminals
CHAPTER
-
6
PARAMETER SETTINGS & FUNCTIONS
Mode-M monitor mode parameters
Mode-A parameters
Mode-B parameters
Mode-C parameters
Mode-D parameters
Mode-E parameters
Mode-G parameters
Mode-H parameters
Mode-P parameters

Amtech
iv
Function explanations
In-built PLC function explanations
CHAPTER
-
7
ELECTRONICS CIRCUIT BOARDS
7-1 Main control board
7-2 Display board
7-3 Power supply unit
7-4 IGBT gate driver boards
7-5 MOV, RC snubber, SC & bleeder board
7-6 Bleeder board
7-7 RC snubber board
7-8 MOV board
CHAPTER
-
8
MAINTENANCE, INSPECTION & PART REPLACEMENT
8-1
Inspection items
8-2
Measuring devices
CHAPTER
-
9
OPTIONS
CHAPTER
-
10
ENCODER SPECIFICATIONS
10-1 Applicable encoder specifications
10-2 Wiring example
CHAPTER
-
11
SERIAL COMMUNICATION SET UP
11-1 Connection method
11-2 Connecting the host computer and Axpert-Eazy (1-to-1)
11-3 Connecting the host computer and Axpert-Eazy (1-to- many)
11-4 Communication specifications
CHAPTER
-
12
UL INSTRUCTIONS
CHAPTER
-
13
CE Marking
13-1 Installation environments
13-2 Input filters and their connections
13-3 Wiring & Earthing
13-4 Considerations to measuring devices
13-5 Installation into a metal cabinet
13-6 Insulation test
Appendix
-
A
Standard Specifications
and
Outline Dimension
Appendix
-
B
Fault Codes
Appendix
-
C
Trouble Shooting Guidelines
Appendix
-
D
Revision History

Axpert-Eazy AC Variable Frequency Drive
v
PREFACE
THANK YOU for purchasing the “Amtech Axpert-Eazy Series AC Variable Frequency Drive”.
Axpert-Eazy Series AC Variable Frequency Drive is a modern Digital Signal Processor based highly
functional AC DRIVE that is easy to use. It employs latest generation IGBT as a switching device and
pwm control technique to apply commanded output to the motor to control the motor speed.
PLEASE READ THIS MANUAL THOROUGHLY before use, and keep the manual at hand for later
reference. Also make sure that this manual is delivered to the final users.
The purpose of this Instruction Manual is to provide basic information on Installation, Start-up,
Operational and Troubleshooting for the Axpert-Eazy Series AC Variable Frequency Drive.
WARNING
ALWAYS READ THIS MANUAL THOROUGHLY BEFORE USING THE AC DRIVE.
THIS AC DRIVE CONTAINS HIGH VOLTAGE CIRCUITS THAT MAY BE FATAL TO HUMANS. USE
EXTREME CAUTION DURING INSTALLATION. MAINTENANCE MUST BE PERFORMED BY
QUALIFIED TECHNICIANS, AND ALL POWER SOURCES MUST BE DISCONNECTED BEFORE
ANY MAINTENANCE. SUFFICIENT NOTICE MUST BE GIVEN TO THE GENERAL OPERATORS
AND WORKERS BEFORE STARTING.
• ELECTRIC SHOCK MAY OCCUR IF THE FOLLOWING POINTS ARE NOT OBSERVED.
(1) DO NOT OPEN THE FRONT COVER WHILE THE POWER IS ON.
(2) A CHARGE STILL REMAINS IN THE AC DRIVE WHILE THE INDICATOR IS LIT EVEN IF THE
POWER HAS BEEN TURNED OFF. DO NOT OPEN THE FRONT COVER IN THIS CASE. WAIT AT
LEAST 20 MINUTES AFTER THE INDICATOR GOES OUT.
(3) DO NOT CONTACT THE ELECTRICAL CIRCUIT WHILE THE "CHARGE" LED ON THE UNIT IS
LIT. PERFORM SERVICING, ETC., AFTER WAITING AT LEAST 20 MINUTES AFTER THE LAMP
GOES OUT.
(4) ALWAYS GROUND THE AC DRIVE CASE. THE GROUNDING METHOD MUST COMPLY WITH
THE LAWS OF THE COUNTRY WHERE THE AC DRIVE IS BEING INSTALLED.
• THE AC DRIVE MAY BE DESTROYED BEYOND REPAIR IF THE FOLLOWING POINTS ARE
NOT OBSERVED.
(1) OPERATION WITHIN THE AC DRIVE SPECIFICATIONS.
(2) PROPER CABLE CONNECTIONS TO INPUT/OUTPUT TERMINALS.
(3) CLEANING AND ENOUGH VENTILATION TO THE AC DRIVE INTAKE/OUTTAKE PORTS.
(4) OBSERVATION OF CAUTIONS LISTED IN THIS INSTRUCTION MANUAL.
• THERE MAY BE SOURCES OF NOISE AROUND THIS AC DRIVE AND MOTOR DRIVEN BY THIS
AC DRIVE. CONSIDER THE POWER SUPPLY SYSTEM, INSTALLATION PLACE AND WIRING
METHOD BEFORE INSTALLATION.
INSTALL THIS AC DRIVE AWAY FROM DEVICES THAT HANDLE MINUTE SIGNALS, SUCH AS
MEDICAL EQUIPMENT IN PARTICULAR. ALSO SEPARATE THE DEVICES ELECTRICALLY, AND
TAKE SUFFICIENT NOISE MEASURES.
• TAKE SUFFICIENT SAFETY MEASURES WHEN USING THIS AC DRIVE FOR PASSENGER
TRANSPORTATION, SUCH AS IN ELEVATORS (LIFTS).

Amtech
vi
Precautions For Safety
Items to be observed to prevent physical damage or property damage and to ensure safe use of this
product are noted on the product and in this instruction manual.
 Please read this instruction manual and enclosed documents before starting operation to ensure
correct usage. Thoroughly understand the device, safety information and precautions before
starting operation. After reading, always store this manual where it can be accessed easily.
 The safety precautions are ranked as "DANGER" and "CAUTION" in this instruction manual.
: When a dangerous situation may occur if handling is mistaken, leading to
fatal or major injuries.
: When a dangerous situation may occur if handling is mistaken, leading to
medium or minor injuries, or physical damage.
Note that some items described as
CAUTION
may lead to major problems depending on
the situation. In any case, important information that must be observed is described.
This instruction manual is written on the presumption that the user has an understanding of the AC
Drive. A qualified person must do installation, operation, maintenance and inspection of this product.
Even qualified persons must undergo periodic training.
Qualified refers to satisfying the following conditions.
The person has thoroughly read and understood this instruction manual.
The person is well versed in the installation, operation, maintenance and inspection of this
product, and understands the possible dangers.
The person is informed on matters related to starting, stopping, installation, locks and tag
displays, and has been trained in the operation and remedies.
The person has been trained on the maintenance, inspection and repairs of this product.
The person has been trained on protective tools used to ensure safety.
KEEP SAFETY FIRST IN YOUR SYSTEM
AMTECH puts the maximum effort into making products better and more reliable, but there is always
the possibility that trouble may occur with them. Trouble with AC Drive may lead to personal injury,
fire or property damage. Remember to give due consideration to safety when making your system,
with appropriate measures such as isolating devices, mechanical brakes, prevention against any
malfunction or mishap.
DANGER
CAUTION

Axpert-Eazy AC Variable Frequency Drive
1.1
1
CHAPTER-1: DELIVERY, INSPECTION AND STORAGE
CAUTION
Always transport the product with an appropriate method according to the products weight.
Failure to observe this could lead to injuries.
Do not place the product near inflammable items.
Failure to observe this could lead to fires.
Do not hold the product with front cover while transporting the product.
Failure to observe this could lead to injuries from dropping.
Do not let conductive materials such as screws or metal pieces and inflammable materials such
as oil enter the product.
Failure to observe this could lead to fires.
Install the product in a place that can withstand the weight of the product, and follow the
instruction manual.
Failure to do so could lead to injuries from dropping.
Do not install and operate an AC Drive that is damaged or that has missing parts.
Failure to observe this could lead to injuries.
Always observe the conditions described in the instruction manual for the installation
environment.
Failure to observe this could lead to faults.
1-1 Delivery, inspection and storage
Axpert-Eazy Series AC Variable Frequency Drive has gone through rigorous quality control tests at
the factory before shipment. After receiving the AC drive, check for the following.
(1) Check to make sure that the package includes an AC Variable Frequency Drive and User Manual
(2) Remove the unit from packaging, and check the details on the rating nameplate to confirm that the
AC DRIVE is as ordered.
(3) Confirm that the product has not been damaged during shipment.
The Axpert-Eazy Series AC Variable Frequency Drive should be kept in the shipping carton before
installation. In order to retain the warranty coverage, the AC Drive should be stored properly when it is
not to be used for an extended period of time. Some storage suggestions are:
(1) Store in a clean, dry location.
(2) Store within an ambient temperature range of -20°C (-4°F) to +60°C (140°F).
(3) If possible, store in an air-conditioned environment where the relative humidity is less than 95%,
non-condensing.
(4) Do not store the AC Variable Frequency Drive in places where it could be exposed to corrosive
gases.
(5) Do not store the AC Variable Frequency Drive on a shelf or on an unstable surface.
(6) If the AC Variable Frequency Drive is not to be used for a while (more than 2 months) after
purchasing, store it in a place with no humidity or vibration in the packaged state.
(7) Always inspect the AC Variable Frequency Drive before using after storing for a long period.

Amtech
1.2
1
1-2 Details of rating nameplate and type display method
The following details are listed on the rating nameplate.
Using the above type as an example, the type is displayed as follows:
AXPERT- EAZY AMT - 055 - 4
Series name
Capacity 55kW
4: 380 ~ 480VAC, 3-phase, 50/60Hz
5: 500 ~ 575VAC, 3-phase, 50/60Hz
6: 600 ~ 690VAC, 3-phase, 50/60Hz
2: 200 ~ 240VAC, 3-phase, 50/60Hz

Axpert-Eazy AC Variable Frequency Drive
2.1
2
CHAPTER-2: INSTALLATION AND WIRING
This chapter provides the information needed to properly install and wire the AC Drive. Make sure
that the AC Drive is wired according to the instructions contained in this chapter. The instructions
should be read and understood before the actual installation begins.
CAUTION
Install the AC Drive, dynamic braking unit and resistor, and other peripheral devices on
noncombustible material such as metal.
Failure to observe this could lead to fires.
Do not mount unit in horizontal position. Always mount unit in Vertical position only.
Failure to observe this could lead to damage the unit.
Do not place the product near inflammable items.
Failure to observe this could lead to fires.
Do not let conductive materials such as screws or metal pieces and inflammable materials such
as oil enter the product.
Failure to observe this could lead to fires.
Install the product in a place that can withstand the weight of the product.
Failure to do so could lead to injuries from dropping.
Do not install and operate AC Drive that is damaged or that is missing parts.
Failure to observe this could lead to injuries.
Always observe the conditions described in the instruction manual for the installation
environment.
Failure to observe this could lead to faults.
Install an overheating protection device on the dynamic braking resistor, and shut off the power
with this fault signal.
Failure to do so could lead to fires in the event of abnormal overheating.
2-1 Installation environment
Observe the following points when installing the AC Drive.
(1) Install the AC Drive vertically to provide proper ventilation.
(2) Make sure that the ambient temperature is 0°C (32°F) to
50°C (122°F) for 400 Volt series Drive and 0°C (32°F) to 40°C
(104°F) for 500 Volt and 600 Volt series Drive.
(3) Avoid installation in the following environment.
•Places subject to direct sunlight.
•Places with oil mist, dust or cotton lint, or subject to salty
winds.
•Places with corrosive gas, explosive gas or high humidity
levels.
•Places near vibration sources such as dollies or press
machines.
•Places made of in-flammable materials such as wood, or
places that are not heat resistant.
(4) Ensure ventilation space around the AC DRIVE as shown in
the below figure.
AXPERT
EAZY
200mm (7.87")
200mm (7.87")
50mm (1.97") 50mm (1.97")

Amtech
2.2
2
2-2 Precautions for power supply and motor wiring
DANGER
Always turn the device's input power OFF before starting wiring.
Failure to do so could lead to electric shocks or fires.
Carry out grounding that complies with the standards of the country where the AC DRIVE is being
installed.
Failure to do so could lead to electric shocks or fires.
Wiring must always be done by a qualified electrician
Failure to observe this could lead to electric shocks or fires.
Always install the device before starting wiring.
Failure to do so could lead to electric shocks or injuries.
Use circuit breaker or fuses that match with the capacity of AC DRIVE power supply.
Failure to do so could lead to fires.
CAUTION
Do not connect an AC power supply to the output terminals (U, V, W) and DC terminals (L+1,
L+2, and L–).
Failure to observe this could lead to injuries or fires.
Confirm that the product's rated input voltage and frequency match the power supply voltage and
frequency.
Failure to do so could lead to injuries or fires.
Install an overheating protection device on the dynamic braking resistor, and shut off the power
with this fault signal.
Failure to do so could lead to fires in the event of abnormal overheating.
Do not directly connect a resistor to the DC terminals (L+1, L+2, and L–).
Failure to observe this could lead to fires.
Tighten the terminal screws with the designated tightening torque.
Failure to do so could lead to fires.
Correctly connect the output (U, V, W) to motor terminals to ensure proper phase sequence.
Failure to do so could cause the motor to rotate in reverse and the machine to be damaged.
When using the encoder, ensure its proper connections. The signal polarity specifications differ
according to the encoder. If the specifications differ from the specified AC DRIVE standard
specifications, correct the signal polarity as specified. Refer Chapter-10 for more information on
encoder specifications.
Failure to observe this could lead to reverse rotation or abnormal acceleration of the motor, and to
injuries or machine damage.
Refer to below figure and wire the main circuits for the power supply and motor, etc.
Always observe the following precautions for wiring.
CAUTION
There is a risk of electric shocks.
The AC DRIVE has a built-in electrolytic capacitor, so a charge will remain even when the AC DRIVE
power is turned off. Always observe the following items before carrying out the wiring work.
Wait at least 20 minutes after turning the power off before starting work. Make sure that the
displays on the Digital Operation Panel have gone out before removing the cover.

Axpert-Eazy AC Variable Frequency Drive
2.3
2
After removing the cover, confirm that the “DC BUS CHARGE LED“ in the unit on bleeder board
has gone out. Also check that the voltage between terminals L+1 or L+2 and L- is 15V or less
before starting the inspections.
M
Power Supply
(Note 4)
(Note 3) (Note 4)
(Note 2)
MCCB ACL
(Note 7)
Noise
Filter
E E
(Note 5)
L1
L2
L3
U
V
W
AXPERT
EAZY
(Note 1)
L+1 L+2 L-
DCL
(Note 2)
DB UNIT
(Note 6)
(Note 8)
(Note 7)
(Note 9)
(Note 10)
EXAMPLE OF MAIN CIRCUIT WIRING
(Note 12)
(Note 1) AC DRIVE input / output terminals
The AC DRIVE input terminals are L1, L2 & L3. The output terminals to the motor are U, V & W.
Connect the power supply to input terminals L1, L2 & L3 only. Never connect the power supply to
the U, V, and W terminals. Incorrect wiring will lead to AC DRIVE damage or fires.
(Note 2) Wire size
Use wires having the size (or larger) shown in the below table for the main circuit wiring shown in
the above figure. The applicable wire size range, applicable ring terminal and tightening torque for
the main circuit terminals are shown in the Table-1 for 400V Series, Table-2 for 500V Series and
Table-3 for 600V Series.
Listed ZMVV, Lugs shall be used & copper wire with 75°C (167°F) used for external connection.

Amtech
2.4
2
Table-1: 400V Series Axpert-Eazy drive (Terminal and applicable wire for Input and Output)
AMT-XXX-
4
Rated
Current
(A)
Wire
size Lug size
max
+
Lug ID
mm
(inch)
Lug
width
mm
(inch)
Terminal
width
mm (inch)
Hole
diameter
mm
(inch)
Terminal
screw
size
Tightening
torque
N*m
(lb-inch)
mm
2
AWG I/P O/P
011
23 5.5 10 - - - - - - - 1.58 (14)
015
31 8 8 - - - - - - - 1.92 (17)
018
37 14 6 - - - - - - - 1.92 (17)
022
44 14 6 - - - - - - - 1.92 (17)
030
60 35 2 - - - - - - - 2.26 (20)
037
72 35 2 - - - - - - - 2.26 (20)
045
87 50 1 - - - - - - - 4.3 (38)
055
110 50 1 - - - - - - - 4.3 (38)
075
147 85 3/0 85 x M10 11.0
(0.43)
25.5
(1.00)
19 (0.75) 11.0 (0.43) M10 22.5 (199)
090
175 120 4/0 120 x
M10
11.0
(0.43)
28.3
(1.11)
19 (0.75) 11.0 (0.43) M10 22.5 (199)
110
215 50 x
2p
1/0 x
2p
50 x M10
x 2p
11.0
(0.43)
18.5
(0.73)
30 (1.18) 11.0 (0.43) M10 22.5 (199)
132
245 70 x
2p
2/0 x
2p
70 x M10
x 2p
11.0
(0.43)
21.4
(0.84)
30 (1.18) 11.0 (0.43) M10 22.5 (199)
160
320 85 x
2p
3/0 x
2p
85 x M10
x 2p
13.0
(0.51)
25.5
(1.00)
30 (1.18) 11.0 (0.43) M10 22.5 (199)
200
360 120 x
2p
4/0 x
2p
120 x
M12 x 2p
13.0
(0.51)
28.3
(1.11)
40
(1.58)
38
(1.50)
13.0 (0.51) M12 31.2 (276)
250
470 185 x
2p
400 x
2p
185 x
M12 x 2p
13.0
(0.51)
34.2
(1.35)
40
(1.58)
38
(1.50)
13.0 (0.51) M12 31.2 (276)
315
530 300 x
2p
500 x
2p
300 x
M12 x 2p
17.0
(0.67)
44.0
(1.73)
40
(1.58)
38
(1.50)
17.0 (0.67) M16 85.0 (752)
355
600 400 x
2p
600 x
2p
400 x
M12 x 2p
17.0
(0.67)
51.0
(2.01)
40
(1.58)
38
(1.50)
17.0 (0.67) M16 85.0 (752)
+
2p = Two parallel

Axpert-Eazy AC Variable Frequency Drive
2.5
2
Table-2: 500V Series Axpert-Eazy drive (Terminal and applicable wire for Input and Output)
AMT-XXX-
5
Rated
Current
(A)
Wire
size Lug size
max
+
Lug ID
mm
(inch)
Lug
width
mm
(inch)
Terminal
width
mm (inch)
Hole
diameter
mm
(inch)
Terminal
screw
size
Tightening
torque
N*m
(lb-inch)
mm
2
AWG I/P O/P
011
20 6 10 - - - - - - - 1.92 (17)
015
23 6 10 - - - - - - - 1.92 (17)
018
30 10 8 - - - - - - - 1.92 (17)
022
37 10 8 - - - - - - - 1.92 (17)
030
46 16 6 - - - - - - - 1.92 (17)
037
54 25 4 - - - - - - - 4.3 (38)
045
73 25 4 - - - - - - - 4.3 (38)
055
87 35 2 - - - - - - - 4.3 (38)
075
110 50 1/0 50 x
M10
11.0
(0.43)
18.5
(0.73)
19 (0.75) 10.5 (0.41) M10 22.5 (199)
090
135 70 2/0 70 x
M10
11.0
(0.43)
21.4
(0.84)
19 (0.75) 10.5 (0.41) M10 22.5 (199)
110
150 90 3/0 90 x
M10
11.0
(0.43)
25.5
(1.0)
19 (0.75) 10.5 (0.41) M10 22.5 (199)
132
175 50 x
2p
1/0 x
2p
50 x
M10 x
2p
11.0
(0.43)
18.5
(0.73)
30 (1.18) 11.0 (0.43) M10 22.5 (199)
160
215 70 x
2p
2/0 x
2p
70 x
M10 x
2p
11.0
(0.43)
21.4
(0.84)
30 (1.18) 11.0 (0.43) M10 22.5 (199)
200
290 90 x
2p
3/0 x
2p
90 x
M12 x
2p
13.0
(0.51)
25.5
(1.0)
40
(1.58)
38
(1.50)
13.0 (0.51) M12 31.2 (276)
250
345 150 x
2p
250
kcmil x
2p
150 x
M12 x
2p
13.0
(0.51)
31.0
(1.22)
40
(1.58)
38
(1.50)
13.0 (0.51) M12 31.2 (276)
315
390 185 x
2p
300
kcmil x
2p
185 x
M12 x
2p
13.0
(0.51)
34.2
(1.35)
40
(1.58)
38
(1.50)
13.0 (0.51) M12 31.2 (276)
+
2p = Two parallel

Amtech
2.6
2
Table-3: 600V Series Axpert-Eazy drive (Terminal and applicable wire for Input and Output)
AMT-XXX-
6
Rated
Current
(A)
Wire
size Lug size
max
+
Lug
ID
mm
(inch)
Lug
width
mm
(inch)
Terminal
width
mm
(inch)
Hole
diameter
mm
(inch)
Terminal
screw
size
Tightening
torque
N*m
(lb - inch)
mm
2
AWG I/P O/P
011
15 4 12 - - - - - - - 1.92 (17)
015
20 6 10 - - - - - - - 1.92 (17)
018
22 6 10 - - - - - - - 1.92 (17)
022
30 10 8 - - - - - - - 1.92 (17)
030
37 10 8 - - - - - - - 1.92 (17)
037
46 16 6 - - - - - - - 1.92 (17)
045
54 25 4 - - - - - - - 4.3 (38)
055
72 25 4 - - - - - - - 4.3 (38)
075
87 35 2 - - - - - - - 4.3 (38)
090
110 50 1/0 50 x M10 11.0
(0.43)
18.5
(0.73)
19 (0.75) 10.5
(0.41)
M10 22.5 (199)
110
135 70 2/0 70 x M10 11.0
(0.43)
21.4
(0.84)
19 (0.75) 10.5
(0.41)
M10 22.5 (199)
132
150 90 3/0 90 x M10 11.0
(0.43)
25.5
(1.0)
19 (0.75) 10.5
(0.41)
M10 22.5 (199)
160
175 50 x
2p
1/0 x
2p
50 x M10
x 2p
11.0
(0.43)
18.5
(0.73)
30 (1.18) 11.0
(0.43)
M10 22.5 (199)
200
215 70 x
2p
2/0 x
2p
70 x M10
x 2p
11.0
(0.43)
21.4
(0.84)
30 (1.18) 11.0
(0.43)
M10 22.5 (199)
250
290 90 x
2p
3/0 x
2p
90 x M12
x 2p
13.0
(0.51)
25.5
(1.0)
40
(1.58)
38
(1.50)
13.0
(0.51)
M12 31.2 (276)
315
345 150 x
2p
250
kcmil
x 2p
150 x
M12 x 2p
13.0
(0.51)
31.0
(1.22)
40
(1.58)
38
(1.50)
13.0
(0.51)
M12 31.2 (276)
355
387 185 x
2p
300
kcmil
x 2p
185 x
M12 x 2p
13.0
(0.51)
34.2
(1.35)
40
(1.58)
38
(1.50)
13.0
(0.51)
M12 31.2 (276)
+
2p = Two parallel
(Note 3) Breaker for wiring
Install circuit breaker or fuse on the power supply side of the AC DRIVE. Refer to table and select
the Circuit Breaker or Fuses.
(Note 4) Power supply capacity
Make sure that the capacity of the transformer used as the AC DRIVE’s power supply is 10 times
(or less) AC DRIVE capacity (for 4% impedance transformer). If the above value is exceeded,
install an ACL on the AC DRIVE’s input side.
(Note 5) Noise filter
The AC DRIVE will generate high harmonic electromagnetic noise, so using the following noise
measures is recommended.
Insert a noise filter on the input side of the AC DRIVE. Contact Amtech to select the proper noise
filter.
Keep the wiring length between the noise filter and AC DRIVE to 500mm (19.7”) or less.

Axpert-Eazy AC Variable Frequency Drive
2.7
2
Use a shield cable for the AC DRIVE and motor wiring and connect the screen to the AC DRIVE’s
terminal.
When using the control circuit wiring and power circuit wiring in parallel, separate the wiring by
300mm (11.8”) or more or pass each of the wiring through separate metal conduits. If the control
circuit wiring and main circuit wiring intersect, make sure that they intersect at a right angle.
(Note 6) AC DRIVE output
Do not insert a power factor improvement capacitor on the output side of the AC DRIVE. When
inserting a magnetic contactor on the output side of the AC DRIVE, prepare a sequence control
circuit so that the magnetic contactor will not open and close when the AC DRIVE is running.
Directly connect only motor to the AC DRIVE load and do not connect through a transformer
etc...without consulting Amtech.
(Note 7) Grounding
Always ground the AC DRIVE unit according to the regulations of the country where the AC
DRIVE is being used to ensure personnel safety in all circumstances, and to reduce
electromagnetic emission and pickup.
Make sure that grounding conductors are adequately sized as required by safety regulations.
In a multiple-drive installation, connect each drive separately to protective earth.
In European CE compliant installations and in other installations where EMC emissions must be
minimized, make a 360° high frequency grounding of cable entries in order to suppress
electromagnetic disturbances.
In addition, connect the cable shields to protective earth (PE) in order to meet safety regulations.
As the normal leakage current of the drive is higher than 3.5 mA AC or 10 mA
DC (stated by EN 50178, 5.2.11.1), a fixed protective earth connection is required.
(Note 8) AC DRIVE output surge voltage
As the AC DRIVE output cable is lengthened, the surge voltage applied on the motor also
increases. If the wiring between the AC DRIVE and motor exceeds 20meters (65.6’), connect a
surge absorber dedicated for the AC DRIVE output.
(Note 9) DCL
Always short across L+1 and L+2 when not using the DCL (factory setting state). When
connecting the optional DCL, connect it to L+1 and L+2. Twist the wiring to the DCL, and keep the
wiring length to 5meters (16.4’) or less.
(Note 10) DB Unit
When connecting an optional DB unit, make the connections as shown in the main circuit wiring.
The DB unit and AC DRIVE unit will damage if the connections are incorrect. Twist the wiring to
the DB unit, and keep length to 3meters (9.8’) or less.
When using the external DB unit, use the overload detection relay or thermal relay to protect the
DB resistor and AC DRIVE.
(Note 11) Surge absorber
Install a surge absorber on the magnetic contactor and relay coils installed near the AC DRIVE.
(Note 12) Voltage Selection for the auxiliary equipment Power Supply
Ensure appropriate tapping for the control transformer, which provides the power supply to the
auxiliary equipments like fan/blower, soft charge contactor etc.

Amtech
2.8
2
•400V Series
0V
TR1
Fuse
To L1
To L3
440V
415V
0V
0V
115V
115V
380V
460V
480V BLUE
YELLOW
BROWN
VIOLET
ORANGE
BLACK
BLUE
GREEN
RED
WHITE
RED
RED
BLACK
•500V / 600V Series
0V
TR1
Fuse
To L1
To L3
575V
550V
0V
0V
115V
115V
525V
600V
660V YELLOW
WHITE
BLACK
BLUE
GREEN
RED
WHITE
RED
RED
BLACK
690V BLUE
BROWN
VIOLET
ORANGE

Axpert-Eazy AC Variable Frequency Drive
2.9
2
2-3 Power terminal layout
400V Series 400V Series
AMT-011-4, AMT-015-4, AMT-018-4 AMT-030-4, AMT-037-4, AMT-045-4, AMT-055-4
AMT-022-4 500V Series
500V Series AMT-037-5, AMT-045-5, AMT-055-5
AMT-011-5, AMT-015-5, AMT-018-5, 600V Series
AMT-022-5, AMT-030-5 AMT-045-6, AMT-055-6, AMT-075-6
600V Series
AMT-011-6, AMT-015-6, AMT-018-6,
AMT-022-6, AMT-030-6, AMT-037-6
400V Series
AMT-075-4, AMT-090-4
500V Series
AMT-132-5, AMT-090-5, AMT-110-5
600V Series
AMT-090-6, AMT-110-6, AMT-132-6

Amtech
2.10
2
400V Series
AMT-110-4, AMT-132-4, AMT-160-4
500V Series
AMT-132-5, AMT-160-5
600V Series
AMT-160-6, AMT-200-6

Axpert-Eazy AC Variable Frequency Drive
2.11
2
400V Series
AMT-200-4, AMT-250-4

Amtech
2.12
2
400V Series
AMT-315-4, AMT-355-4
500V Series
AMT-200-5, AMT-250-5, AMT-315-5
600V Series
AMT-250-6, AMT-315-6, AMT-355-6
