INVT Goodrive800 Pro Series User manual

Goodrive800ProSeriesBasicRectifierUnitHardwareManual Changehistory
No.
Change description
Version
Release date
1
Firstrelease.
V1.0
Feb2022

Goodrive800ProSeriesBasicRectifierUnitHardwareManual Preface
202202 (V1.0) i
Preface
ThankyouforchoosingINVTGoodrive800Proseriesengineeringvariable-frequencydrive(VFD).
Foreaseofuse,readthemanualcarefullybeforeusingGoodrive800Proseriesproduct.
As an upgrade product of Goodrive800 series engineering VFD, Goodrive800 Pro series engineering VFD
inherits the high reliability feature of Goodrive800 platform but optimizes the upgrade, structure, and
components,achievingunitmodularization,flexiblecabinetconfiguration,morecompactstructure,easier
installationandmaintenance,andoptimumprotection.
Excellentspeedandtorquecontrolperformance
Modulardesign,asflexibleasbuildingblocks,whichmakestheprojectintegrationsimpleandefficient
Long-lifecomponentselectionandfastfaultrecoverydesigntoensureefficientprocesscontrol
Ergonomicdesigntomakeinstallationandmaintenanceeasier
Enrichedexpansioncapabilitytosupportvariousprotectionoptions
Goodrive800ProseriesengineeringVFDcanbewidelyusedin:
Metallurgy:Suchashigh-speedwirerodandhotstriprollingequipment,wideandthickplateequipment,
cold rolling equipment, pickling lines, annealing lines, galvanizing line, color coating lines, non-ferrous
metalalloymanufacturingequipment,andnon-ferrousmetalrollingequipment.
Petroleum: All-electric oil drilling rigs, large well repair machines, large oil machinery and equipment
electric-drivepowertransformation,oilfieldwaterinjectionequipmentandotherheavyoilequipment.
Papermaking:Papermakingjointequipment,includingflowbox,netsection,presssection,dryingsection,
sizing,hardcalendering,coating,supercalender,rewinderandothercontinuousproductionlines.
Port and other large lifting equipment: Such as shore-side container overhead cranes, tire-type (orbital)
container gantry cranes, grab unloaders, grab gantry cranes, large shipbuilding gantry cranes, and large
metallurgicalcastingcranes.
Others: Suchasunit testbenches,militaryequipment, oiland gas transmission,andminingtransmission
equipment.
Goodrive800-71 series is the basic rectifier unit of Goodrive800 Pro series. If not otherwise specified, the
basic rectifier unit in this manual refers to the basic rectifier unit of Goodrive800 Pro series, that is,
Goodrive800-71 series product. The rated power of a single unit is 356kW–929kW, and the max. parallel
powercanbe5183kW.Thebasicrectifierunitconsistsofinputreactor,semi-controlledrectifierbridgeand
DCfuse.Itiscompactinstructureandeasytointegrateandmaintain,reducingcabinetfootprint.
ThismanualisGoodrive800Proseriesbasicrectifierunithardwaremanual,presentingsafetyprecautions,
productinformation,mechanicalandelectricalinstallation,andprecautionsrelatedtodailymaintenance.
Read through this manual carefully before installation to ensure the VFD is installed and operated in a
proper manner to give full play to its excellent performance and powerful functions. If you have any
questionaboutthefunctionandperformanceoftheproduct,pleaseconsultourtechnicalsupport.
Iftheproductisultimatelyusedformilitaryaffairsorweaponmanufacture,complywiththeexportcontrol
regulationsintheForeignTradeLawofthePeople'sRepublicofChinaandcompleterelatedformalities.
To continuously improve the performance of the product to meet higher application requirements, we
reservetherighttocontinuouslyimprovetheproductandaccordinglytheproductmanual,whichmaybe
madewithoutpriornotice.Wehavethefinalinterpretationofthemanualcontent.

Goodrive800ProSeriesBasicRectifierUnitHardwareManual Contents
202202 (V1.0) ii
Contents
Preface ......................................................................................................................................................... i
Contents...................................................................................................................................................... ii
1 Safety precautions .....................................................................................................................................1
1.1Safetydeclaration.................................................................................................................................................1
1.2Safetydefinition....................................................................................................................................................1
1.3Warningsymbols...................................................................................................................................................1
1.4Safetyguidelines...................................................................................................................................................2
1.4.1Deliveryandinstallation.............................................................................................................................2
1.4.2Commissioningandrunning......................................................................................................................3
1.4.3Maintenanceandcomponentreplacement..............................................................................................3
1.4.4Disposal.......................................................................................................................................................3
2 Product overview .......................................................................................................................................4
2.1Productspecifications..........................................................................................................................................4
2.2Productnameplateandmodel............................................................................................................................5
2.3Productratings.....................................................................................................................................................6
2.4Overloadcapability...............................................................................................................................................7
2.5Hardwareprinciples.............................................................................................................................................7
2.5.1Basicprinciples...........................................................................................................................................7
2.5.2Six-pulserectification.................................................................................................................................9
2.5.3Twelve-pulserectification........................................................................................................................10
2.6Productstructure................................................................................................................................................10
2.7Systemconfiguration.........................................................................................................................................12
2.8Electricalmodelselection..................................................................................................................................12
2.8.1Breaker......................................................................................................................................................12
2.8.2ACfuse.......................................................................................................................................................13
2.8.3Built-inDCfuse.........................................................................................................................................13
3 Mechanical installation ............................................................................................................................14
3.1Safetynotes.........................................................................................................................................................14
3.2Installationenvironment....................................................................................................................................14
3.3Installationprocedure........................................................................................................................................15
3.3.1Unpackinginspection...............................................................................................................................15
3.3.2Transportation..........................................................................................................................................16
3.3.3Unpacking.................................................................................................................................................16
3.3.4Lifting........................................................................................................................................................17
3.3.5Installation................................................................................................................................................20
3.3.6Fasteningtorque.......................................................................................................................................29
3.3.7Checklist....................................................................................................................................................29
4 Electrical installation ...............................................................................................................................31
4.1Safetynotes.........................................................................................................................................................31
4.2Insulationinspection..........................................................................................................................................31
4.3EMCregulations..................................................................................................................................................32
4.3.1Powercable...............................................................................................................................................33
4.3.2Controlcable.............................................................................................................................................33
4.3.3Wiringsuggestions....................................................................................................................................34
4.3.4Shieldedcableconnection.......................................................................................................................36
4.4Electricalwiring..................................................................................................................................................37
4.4.1Wiringprocedure......................................................................................................................................37
4.4.2Isolatedgrid(ITgrid)application.............................................................................................................37
4.4.3Maincircuitwiring....................................................................................................................................38
4.4.4Controlcircuitwiring................................................................................................................................39
4.4.5Electricalinstallationchecklist................................................................................................................40
5 Maintenance and inspection .....................................................................................................................41
5.1Periodicalinspection..........................................................................................................................................41
5.1.1Overview...................................................................................................................................................41

Goodrive800ProSeriesBasicRectifierUnitHardwareManual Contents
202202 (V1.0) iii
5.1.2Requiredtools...........................................................................................................................................41
5.1.3Maintenancecycle....................................................................................................................................41
5.2Replacementofwearingparts...........................................................................................................................43
5.2.1Coolingfan................................................................................................................................................43
5.2.2DCfuse.......................................................................................................................................................44
5.2.3Basicrectifierunit.....................................................................................................................................45
Appendix A Technical data ..........................................................................................................................47
A.1Deratedapplication............................................................................................................................................47
A.1.1Capacity....................................................................................................................................................47
A.1.2Derating....................................................................................................................................................47
A.2Gridspecifications..............................................................................................................................................48
A.3Applicationstandards........................................................................................................................................48
A.3.1CEmarking................................................................................................................................................48
A.3.2EMCcompliancedeclaration...................................................................................................................48
A.4EMCregulations..................................................................................................................................................48
A.4.1VFDcategoryofC2....................................................................................................................................49
A.4.2VFDcategoryofC3....................................................................................................................................49
Appendix B Dimension drawings .................................................................................................................50
B.1Installationdimensions......................................................................................................................................50

Goodrive800ProSeriesBasicRectifierUnitHardwareManual Safetyprecautions
202202 (V1.0) 1
1Safety precautions
1.1 Safety declaration
Read this manual carefully and follow all safety precautions before moving, installing, operating and
servicingtheproduct.Otherwise,equipmentdamageorphysicalinjuryordeathmaybecaused.
Weshallnotbeliableorresponsibleforanyequipmentdamageorphysicalinjuryordeathcauseddueto
youroryourcustomers'failuretofollowthesafetyprecautions.
1.2 Safety definition
Danger:Severepersonalinjuryorevendeathcanresultifrelatedrequirementsarenotfollowed.
Warning: Personalinjuryorequipmentdamagecanresultifrelatedrequirementsarenotfollowed.
Note:Actionstakentoensureproperrunning.
Trained and qualified professionals: People operating the equipment must have received professional
electrical and safety training and obtained the certificates, and must be familiar with all steps and
requirementsofequipmentinstalling,commissioning,runningandmaintainingandcapabletopreventany
emergencies.
1.3 Warning symbols
Warningscautionyouaboutconditionsthatcanresultinsevereinjuryordeathand/orequipmentdamage
andadviceonhowtopreventdangers.Thefollowingtableliststhewarningsymbolsinthismanual.
Symbol
Name
Description
Danger
Severepersonalinjuryorevendeathcanresultifrelatedrequirements
arenotfollowed.
Warning
Personalinjuryorequipmentdamagecanresultifrelatedrequirements
arenotfollowed.
Electrostatic
sensitive
ThePCBAmaybedamagedifrelatedrequirementsarenotfollowed.
Hotsides
Donottouch.Therectifierunitbasemaybecomehot.
15 min
Electric
shock
As high voltage stillpresents in the bus capacitorafter power off, wait
for at least 15 minutes (depending on the warning symbols on the
machine)afterpowerofftopreventelectricshock.
Note
Note
Actionstakentoensureproperrunning.

Goodrive800ProSeriesBasicRectifierUnitHardwareManual Safetyprecautions
202202 (V1.0) 2
1.4 Safety guidelines
Onlytrainedandqualifiedprofessionalsareallowedtocarryoutrelatedoperations.
Donotperformwiring,inspectionorcomponentreplacementwhenpowersupplyis
applied.Ensurealltheinputpowersupplieshavebeendisconnectedbeforewiring
or inspection, and wait for at least the time designated on the Goodrive800 Pro
series product or until the DC bus voltage is less than 36V. The minimum waiting
timeislistedinthefollowing.
Rectifier unit model
Minimum waiting time
380V
>356kW
15minutes
690V
>487kW
15minutes
DonotrefittheGoodrive800Proseriesproductunlessauthorized;otherwisefire,
electricshockorotherinjurymayresult.
ThebasemaybecomehotwhentheGoodrive800Proseriesproductisrunning.Do
nottouch.Otherwise,youmaygetburnt.
TheelectricalpartsandcomponentsinsidetheGoodrive800Proseriesproductare
electrostaticsensitive.Takemeasurementstopreventelectrostaticdischargewhen
performingrelatedoperations.
1.4.1 Delivery and installation
Donotinstalltherectifierunitoninflammables.Inaddition,preventtherectifier
unitfromcontactingoradheringtoinflammables.
Donotruntherectifierunitifitisdamagedorincomplete.
Donotcontacttherectifierunitwithdampobjectsorbodyparts.Otherwise,electric
shockmayresult.
Note
Selectappropriatetoolsforrectifierunitdeliveryandinstallationtoensurethesafe
andproperrunningandavoidphysicalinjuryordeath.Toensurepersonalsafety,
takemechanicalprotectivemeasureslikewearingsafetyshoesandworking
uniforms.
Protecttherectifierunitagainstphysicalshockorvibrationduringthedeliveryand
installation.
Donotcarrytherectifierunitonlybyitsfrontcoverasthecovermayfalloff.
Theinstallationsitemustbeawayfromchildrenandotherpublicplaces.
Preventthescrews,cablesandotherconductivepartsfromfallingintotherectifier
unit.
Asrectifierunitleakagecurrentcausedduringrunningmayexceed3.5mA,ground
properly and ensure the grounding resistance is less than 10Ω. The conductivity of
PEgroundingconductormustmeetthefollowingrequirements:
Power cable conductor
cross-sectional area S (mm2)
Grounding conductor
cross-sectional area (mm2)
S≤16
S
16<S≤35
16
35<S
S/2
R,S,andTarethepowerinputterminals,whileU,V,andWaretheDCbusoutput
terminals.Connecttheinputpowercablesandoutputbusbarsproperly;otherwise,
therectifierunitmaybedamaged.

Goodrive800ProSeriesBasicRectifierUnitHardwareManual Safetyprecautions
202202 (V1.0) 3
1.4.2 Commissioning and running
Cutoffallpowersuppliesconnectedtotherectifierunitbeforeterminalwiring,and
wait for at least the time designated on the rectifier unit after disconnecting the
powersupplies.
Highvoltagepresentsinsidetherectifierunitduringrunning.Donotcarryoutany
operationontherectifierunitduringrunningexceptforkeypadsetup.Forproducts
at voltage class of 4 or 6, the control terminals form extra-low voltage circuits.
Therefore,youneedtopreventthecontrolterminalsfromconnectingtoaccessible
terminalsofotherdevices.
Beforeturningonthepowersupply,checkthecableconnectionstatus.
Preventanyonefromdirectlytouchingtheenergizedpartofthecabinetdoor.Pay
specialattentiontosafetywhenhandlingshieldsthataremadeofmetalsheets.
Donotdoanywithstandvoltagetestingduringunitconnection.Disconnectthe
motorcablebeforeperforminganyinsulationandvoltagewithstandtestsforthe
motorormotorcable.
DonotopenthecabinetdoorsincehighvoltagepresentsinsidetheGoodrive800
Proseriesproductduringrunning.
Note
Do not switch on or switch off the input power supplies of the rectifier unit
frequently.
If the rectifierunit has been stored for along time without use, perform checking
andcarryoutpilotrunfortherectifierunitbeforeusingitagain.
Close the rectifier unit front cover before running; otherwise, electric shock may
occur.
1.4.3 Maintenance and component replacement
Only trained and qualified professionals are allowed to perform maintenance,
inspection,andcomponentreplacementfortherectifierunit.
Cutoffallpowersuppliesconnectedtotherectifierunit beforeterminalwiring,
andwaitforatleastthetimedesignatedontherectifierunitafterdisconnecting
thepowersupplies.
During maintenance and component replacement, take measures to prevent
screws,cablesandotherconductivemattersfromfallingintotheinternalofthe
rectifierunit.
Note
Usepropertorquetotightenscrews.
Duringmaintenanceandcomponentreplacement,keeptherectifierunitandits
partsandcomponentsawayfromcombustiblematerialsandensuretheyhaveno
combustiblematerialsadhered.
Do not carry out insulation voltage-endurance test on the rectifier unit, or
measurethecontrolcircuitsoftherectifierunitwithamegohmmeter.
During maintenance and component replacement, take proper anti-static
measuresontherectifierunitanditsinternalparts.
1.4.4 Disposal
The rectifier unit contains heavy metals. Dispose of a scrap rectifier unit as
industrialwaste.
Dispose of a scrap product separately at an appropriate collection point but not
placeitinthenormalwastestream.

Goodrive800ProSeriesBasicRectifierUnitHardwareManual Productoverview
202202 (V1.0) 4
2Product overview
2.1 Product specifications
Table2-1Productspecifications
Description
Specifications
Powerinput
Inputvoltage
(V)
380–480VAC 3PH ±10%, -15%<1min;Ratedvoltage:380V
520–690VAC 3PH ±10%, -15%<1min;Ratedvoltage:690V
Inputcurrent
(A)
See2.3Productratings.
Input
frequency
(Hz)
50Hzor60Hz;Allowedrange:47–63Hz
Poweroutput
Output
voltage(V)
Inputvoltage*1.35
Output
current(A)
See2.3Productratings.
Outputpower
(kW)
See2.3Productratings.
Environment
condition
Working
temperature
-10°C – +50°C; Derating is required when the ambient
temperature exceeds 40°C.
Relative
humidity
5%–95%,nocondensation
Installation
altitude
Below1000m(Deratingisrequiredwhenthealtitudeexceeds
1000m.Derateby1%foreveryincreaseof100m.)
Mechanical
data
Anti-vibration
performance
Compliantwith3M4vibrationlevelinGB/T4798.3
IPrating
Forthemodule:IP00
Forthecabinet:IP20(Optional:IP23andIP42)
Safety
performance
CompliantwithEN61800-5-1
Cooling
method
Forcedaircooling
Protection
functions
Protection
functions
Includingfunctionsofprotectionagainstshortcircuit,
overcurrent,overload,overvoltage,undervoltage,
overtemperature,andphaseloss

Goodrive800ProSeriesBasicRectifierUnitHardwareManual Productoverview
202202 (V1.0) 5
2.2 Product nameplate and model
Figure2-1Productnameplate
Note: The preceding nameplate is a standard product nameplate example. The marking varies slightly
depending on the model.
The modeldesignationcodecontains basicproductinformationsuch asrated currentandratedvoltage.
Youcanfindthemodeldesignationcodeontheproductnameplate.
Figure2-2Productmodel
GD800 71 0815 6 01- - - - Version
01：Proseries
Productseries
GD800:Goodrive800seriesengineeringVFD
Rating
0815:815A
Producttype
71:Basicrectifierunit
Voltageclass
4:AC3PH380V(-15%)–480V(+10%)
6:AC3PH520V(-15%)–690V(+10%)
Note: The preceding model is only an example of GD800-71 models.

Goodrive800ProSeriesBasicRectifierUnitHardwareManual Productoverview
202202 (V1.0) 6
2.3 Product ratings
Table2-2AC3PH380V(-15%)–480V(+10%)
Model
GD800-71…
Rating
Light overload
application
Heavy overload
application
Structure
Heat
dissipa
tion
Air
volume
IN
IN
Imax
SN
PN
ILd
PLd
Ihd
PHd
A (AC)
A (DC)
A (DC)
kVA
kW(DC)
A (DC)
kW(DC)
A (DC)
kW(DC)
kW
m³/h
6-pulse
0718-4-01
718
879
1142
497
475
844
456
659
356
D8T
2.8
1500
0980-4-01
980
1200
1560
680
648
1154
623
901
487
D8T
3
1500
1336-4-01
1336
1635
2126
926
883
1570
848
1226
662
2*D8T
5.6
3000
1822-4-01
1822
2232
2902
1263
1205
2143
1157
1670
902
2*D8T
6
3000
2734-4-01
2734
3348
4353
1895
1808
3214
1736
2504
1352
3*D8T
9
4500
3645-4-01
3645
4464
5804
2525
2411
4285
2314
3339
1803
4*D8T
12
6000
4556-4-01
4556
5580
7254
3156
3013
5357
2893
4174
2254
5*D8T
15
7500
5467-4-01
5467
6696
8705
3788
3616
6428
3471
5009
2705
6*D8T
18
9000
12-pulse
1336-4-01
1336
1635
2126
926
883
1570
848
1226
662
2*D8T
5.6
3000
1822-4-01
1822
2232
2902
1263
1205
2143
1157
1670
902
2*D8T
6
3000
2674-4-01
2674
3273
4255
1852
1767
3142
1697
2455
1325
4*D8T
11.2
6000
3645-4-01
3645
4464
5804
2525
2408
4285
2314
3339
1803
4*D8T
12
6000
4008-4-01
4008
4906
6377
2777
2649
4709
2543
3679
1987
6*D8T
16.8
9000
5467-4-01
5467
6696
8705
3788
3616
6428
3471
5009
2705
6*D8T
18
9000
Table2-3AC3PH520V(-15%)–690V(+10%)
Model
GD800-71…
Rating
Light overload
application
Heavy overload
application
Structure
Heat
dissipa
tion
Air
volume
IN
IN
Imax
SN
PN
ILd
PLd
Ihd
PHd
A (AC)
A (DC)
A (DC)
kVA
kW (DC)
A (DC)
kW(DC)
A (DC)
kW (DC)
kW
m³/h
6-pulse
0570-6-01
570
698
907
682
650
670
624
523
487
D8T
2.5
1500
0815-6-01
815
998
1297
974
929
958
892
748
697
D8T
2.8
1500
1061-6-01
1061
1299
1688
1268
1210
1247
1161
974
907
2*D8T
5
3000
1515-6-01
1515
1854
2411
1810
1727
1780
1658
1391
1295
2*D8T
5.6
3000
2273-6-01
2273
2782
3617
2716
2591
2671
2488
2087
1944
3*D8T
8.4
4500
3031-6-01
3031
3710
4823
3622
3456
3561
3317
2782
2592
4*D8T
11.2
6000

Goodrive800ProSeriesBasicRectifierUnitHardwareManual Productoverview
202202 (V1.0) 7
Model
GD800-71…
Rating
Light overload
application
Heavy overload
application
Structure
Heat
dissipa
tion
Air
volume
IN
IN
Imax
SN
PN
ILd
PLd
Ihd
PHd
A (AC)
A (DC)
A (DC)
kVA
kW (DC)
A (DC)
kW(DC)
A (DC)
kW (DC)
kW
m³/h
3788-6-01
3788
4636
6027
4527
4319
4451
4146
3477
3239
5*D8T
14
7500
4546-6-01
4546
5564
7233
5433
5183
5341
4976
4173
3887
6*D8T
16.8
9000
12-pulse
1061-6-01
1061
1299
1688
1268
1210
1247
1161
974
907
2*D8T
5
3000
1515-6-01
1515
1854
2411
1810
1727
1780
1658
1391
1295
2*D8T
5.6
3000
2122-6-01
2122
2597
3376
2536
2419
2493
2323
1948
1814
4*D8T
10
6000
3031-6-01
3031
3710
4823
3622
3456
3561
3317
2782
2592
4*D8T
11.2
6000
4546-6-01
4546
5564
7233
5433
5183
5341
4976
4173
3887
6*D8T
16.8
9000
Note:
INindicates the rated current for continuous running when no overload occurs at 40℃, while Imax
indicatesthemax.outputcurrent.
Lightoverloadapplication:ILd indicatesthecontinuousrunningcurrentatlightoverload.Every5
minutes,theoverloadwiththecurrentof110%*ILd can last for 1 minutes at 40℃.
Heavyoverloadapplication:ILd indicatesthecontinuousrunningcurrentatheavyoverload.Every5
minutes,theoverloadwiththecurrentof150%*IHd can last for 1 minutes at 40℃.
2.4 Overload capability
Basedonthelightoverloadcontinuousruncurrent(ILd),thebasicrectifierunitcankeeprunningfor60sat110%
oftheratedcurrent.SeeFigure2-3.
Figure2-3Lightoverloadapplication
60s
Short-timeoverloadcurrent
110%ILD
Lightoverloadrating ILD Ratedcurrent IN(Continuous)
Figure2-4Heavyoverloadapplication
60s 60s
300s
Short-timeoverloadcurrent
Heavyoverloadrating
RatedcurrentIN(Continuous)
150%IHD
IHD
2.5 Hardware principles
2.5.1 Basic principles
The basic rectifier unit converts 3PH AC voltage into intermediate DC voltage, and the intermediate DC
voltagecansupplythesubsequentinvertermodules.Itcanconnecttooneormultipleinvertermodules.
The basic rectifier unit is equipped with AC reactors to suppress AC voltage and current harmonics. The

Goodrive800ProSeriesBasicRectifierUnitHardwareManual Productoverview
202202 (V1.0) 8
thyristorrectifierbridgehasthecontrollabilitycharacteristic,whichcangraduallyboostthebusvoltageby
controlling the thyristor switch-on through the conduction angle. In this way, there is no need to add
additionalprechargecircuit.
The basic rectifier unit mainly consists of input reactor, semi-controlled rectifier bridge, energy storage
capacitorandDCfuse.Figure2-5showsthesimplifiedmaincircuit.
Figure2-5Simplifiedmaincircuit
Input
reactor
R
S
T
DC+
DC-
12
3
4
5
No.
Name
Description
1
ACfuse
To protect against overload and short-circuit on the basic
rectifierunitside.
2
ACinputreactor
TosuppressACvoltageandcurrentharmonics.
3
Basicrectifiermodule
ToconvertACcurrenttoDCcurrent.
4
Buscapacitor
TofilterouttheACpartfromthebusvoltage.
5
DCfuse
To prevent backend device short circuit from causing
machineburndown.
Note: The AC fuse is not a component of the basic rectifier unit. You can choose to configure AC fuses
according to the actual application requirements.
When the system is switched on and started, and the three-phase AC power is connected to the basic
rectifierunit,andthenthecontrolboarddetectsthethree-phaseinputlinevoltageandcontrolsthetrigger
signalofthethree-phaserectificationtomakethesystementertherectificationstate.Therectificationof
threephasesistriggeredinturn.Therectificationistriggeredfromthenegativezero-crossingpointofthe
linevoltageofeachphase,andthengraduallyshiftedtotheleftaccordingtothemovingrule(thewidthof
the triggered pulse train does not exceed 120°). Thus the effect of gradually boosting the bus voltage is
achievedbyswitchingtoahigherlinevoltagebymeansofphaseshifting.Subsequently,DCbusvoltageis
providedtodownstreaminverterside.Figure2-6showsthebasicrectifierunitworkingprinciples.
Figure2-6Basicrectificationprinciples
URUsUT
UDC

Goodrive800ProSeriesBasicRectifierUnitHardwareManual Productoverview
202202 (V1.0) 9
2.5.2 Six-pulse rectification
Six-pulse basic rectification can meet most common rectification applications, in which there is no
demandingrequirementsonharmonics.Figure2-7showshowasinglebasicrectifierunitworks.
Figure2-7Simplifiedmaincircuitofasinglesix-pulserectifierunit
（ + ）
（ - ）
A
B
C
DC+
DC-
-T
-S
-R
No.
Name
1
Gridtransformer
2
Breaker
3
ACfuse
4
Basicrectifierunit
Thebasicrectifierunitsupportsparalleluse. Multiple basicrectifierunitscanbeconnectedinparallel,as
showninFigure2-8.
Figure2-8Simplifiedmaincircuitofparallelsix-pulserectifierunits
-R
-S
-T
（ + ）
（ - ）
A
B
C
-R
-S
-T
（ + ）
（ - ）
DC+
DC-
No.
Name
1
Gridtransformer
2
Breaker
3
ACfuse
4
Basicrectifierunit

Goodrive800ProSeriesBasicRectifierUnitHardwareManual Productoverview
202202 (V1.0) 10
2.5.3 Twelve-pulse rectification
The basicrectifierunitisahigh-powerdevice,whichisrequired tominimize theharmonicimpactonthe
power supply system from the view of engineering design. The requirements can be met by using
twelve-pulserectificationatarelativelylowcost,whilethetransformerselectstwowindingswithaphase
difference of 30°. See Figure2-9.
Figure2-9Simplifiedmaincircuitoftwelve-pulserectifierunits
A
B
C
-R
-S
-T
（ + ）
（ - ）
-R
-S
-T
（ + ）
（ - ）
DC+
DC-
No.
Name
1
Phaseshiftingtransformer
2
Framebreaker
3
Fuse
4
Basicrectifierunit
2.6 Product structure
Figure2-10showsthebasicrectifierunitstructure(takingGD800-71-0815-6-01forexample).

Goodrive800ProSeriesBasicRectifierUnitHardwareManual Productoverview
202202 (V1.0) 11
Figure2-10Basicrectifierunitstructure
No.
Description
1
Moduletopfixinghole
2
Femaleconnector,mountedandfixedtothecabinet
3
(+)and(-)busoutputcopperbar
4
Modulebottomfixinghole
5
Warningmarking
6
Handle
7
Userterminalsontheandcontrolboards
8
Fancoverplate
9
Anti-tippingstand
10
Pulley
11
RSTACinputterminals
12
Liftinghole
13
Modulegroundingpoint

Goodrive800ProSeriesBasicRectifierUnitHardwareManual Productoverview
202202 (V1.0) 12
2.7 System configuration
Figure2-11showsthetypicaltopologyinwhichthebasicrectifierunitworkswiththreeinverterunits.
Figure2-11Systemconfiguration
Power incoming cable
No.
Description
1
Gridtransformer,secondary-side short circuit impedance ≥ 5%
2
Breaker
3
ACfuse
4
Basicrectifierunit
5
DCfuse
6
Inverterunit
7
Motor
2.8 Electrical model selection
2.8.1 Breaker
A breaker can effectively prevent the overload of the variable-frequency equipment and break the fault
currentgeneratedbythephase-to-phaseorto-groundshortcircuit,andatthesametimeithasthefunction
ofisolationsoastoavoidelectricshockaccidentsduringmaintenance.
Table2-4Breakermodelselection
Power supply module
Structure
Recommended
specification
Recommended breaker
(ABB)
Qty
GD880-71-0718-4-01
D8T
1000V800A
T6S800
1
GD880-71-0980-4-01
D8T
1000V1250A
T7S1250M
1
GD880-71-1336-4-01
2*D8T
1000V1600A
T7S1600M
1
GD880-71-1822-4-01
2*D8T
1000V2000A
E3S2000R2000
1
GD880-71-2734-4-01
3*D8T
1000V3200A
E3S3200R3200
1

Goodrive800ProSeriesBasicRectifierUnitHardwareManual Productoverview
202202 (V1.0) 13
Power supply module
Structure
Recommended
specification
Recommended breaker
(ABB)
Qty
GD880-71-3645-4-01
4*D8T
1000V4000A
E4S4000R4000
1
GD880-71-4556-4-01
5*D8T
1000V5000A
E6H6300R5000
1
GD880-71-5467-4-01
6*D8T
1000V6300A
E6H6300R6300
1
GD880-71-0570-6-01
D8T
1000V800A
T6S800
1
GD880-71-0815-6-01
D8T
1000V1000A
T7S1000M
1
GD880-71-1061-6-01
2*D8T
1000V1250A
T7S1250M
1
GD880-71-1515-6-01
2*D8T
1000V2000A
E3S3200R2000
1
GD880-71-2273-6-01
3*D8T
1000V2500A
E3S3200R2500
1
GD880-71-3031-6-01
4*D8T
1000V3200A
E3S3200R3200
1
GD880-71-3788-6-01
5*D8T
1000V4000A
E4S4000R4000
1
GD880-71-4546-6-01
6*D8T
1000V5000A
E6H6300R5000
1
2.8.2 AC fuse
An AC fuse protects the rectifier unit and input power cable in case of short circuit, avoiding thermal
overload.SeethefollowingtabletoselectACfuses.
Table2-5ACfusemodelselection
Power supply
module
Structure
Voltage (V)
Current (A)
Qty
GD800-71-0718-4-01
D8T
690V
1000A
3
GD800-71-0980-4-01
D8T
690V
1250A
3
GD800-71-0570-6-01
D8T
690V
1000A
3
GD800-71-0815-6-01
D8T
690V
1250A
3
2.8.3 Built-in DC fuse
ADCfuseprotectstherectifierunitandDCbusincaseofshortcircuit,avoidingthermaloverload.Thesame
brandreplacementprincipleshouldbefollowed.Seethefollowingtableforselection.
Table2-6DCfusemodelselection
Power supply module
Structure
Voltage (V)
Current (A)
Qty
GD800-71-0653-4-01
D8T
1250V
900A
4
GD800-71-0980-4-01
D8T
1250V
900A
4
GD800-71-0570-6-01
D8T
1250V
900A
2
GD800-71-0815-6-01
D8T
1250V
900A
4

Goodrive800ProSeriesBasicRectifierUnitHardwareManual Mechanicalinstallation
202202 (V1.0) 14
3Mechanical installation
3.1 Safety notes
Equipmentcantipoveriftransportedincorrectlyorwithdisallowedmeansof
transport.Seriousinjury,propertydamage,orevendeathmayresult.
Onlytrainedandqualifiedprofessionalsareallowedtocarryouttheoperations
mentioned in this chapter. Please carry out operations according to
instructionspresentedin1.4.1 Delivery andinstallation.Ignoringthese safety
precautionsmayleadtophysicalinjuryordeath,ordevicedamage.
Ensuretherectifierunitpowerhasbeendisconnectedbeforeinstallation.Ifthe
rectifierunithasbeenpoweredon,disconnecttherectifierunitpowerandwait
for at least the time specified on the rectifier unit, and ensure the POWER
indicatorisoff.Youarerecommendedtouseamultimetertocheckandensure
therectifierunitDCbusvoltageisbelow36V.
The equipment installation must be designed and done according to
applicable local laws and regulations. We do not assume any liability
whatsoever for any equipment installation which breaches local laws or
regulations.Ifrecommendationsgivenbyusarenotfollowed,therectifierunit
mayexperienceproblemsthatthewarrantydoesnotcover.
Only trained and qualified professionals are allowed to carry out related
operations.
Do not perform wiring, inspection or component replacement when power
supplyisapplied.Ensurealltheinputpowersupplieshavebeendisconnected
before wiring or inspection, and wait for at least the time designated on the
Goodrive800ProseriesproductoruntiltheDCbusvoltageislessthan36V.
3.2 Installation environment
Environment
Condition
Ambient
temperature
-10–+50℃.
When the ambient temperature exceeds 40°C, derate 1% for every
increase of 1°C.
Donotusetherectifierunitwhentheambienttemperatureexceeds
50℃.
To improve reliability, do not use the rectifier unit in the places
wherethetemperaturechangesrapidly.
When the rectifier unit is used in a closed space, such as control
cabinet,useacoolingfanorairconditionerforcooling,preventing
theinternaltemperaturefromexceedingthetemperaturerequired.
Whenthetemperatureistoolow,ifyouwanttousetherectifierunit
thathasbeenidledforalongtime,installanexternalheatingdevice
before the use to eliminate the freeze inside the rectifier unit.
Otherwise,therectifierunitmaybedamaged.
Relative
humidity(RH)
RH:lessthan90%
Condensationis
notallowed.
Themax.RHcannotexceed60%inthe
environmentwithcorrosivegases.
