KEEN+ microcontroller onboard
WELCOME AND QUICK START GUIDE
Dear Valued Customer,
Thank you for choosing CryptoRF®for your security needs. CryptoRF provides
powerful security for wireless authentication and data storage in convenient and
affordable passive RFID tags. The Keen+ kit is an all Atmel complete solution with
13.56 MHz RFID Reader, Tag, and Software Technologies. This complete development
kit based on AVR®for CryptoRF, World’s Largest Family of Secure RFID, features
demonstration and evaluation possibilities. Designed with developers in mind, Keen+
offers ample development resources in the onboard large-memory AT90USB AVR
microcontroller, rich debug capabilities with JTAG-ICE and ISP programming ports,
and simple connectivity option through USB port. With PC availability, accompanying
Embedded Crypto Evaluation (ECE) Studio provides a rich experience in product
configuration, evaluation, and demonstration through an intuitive menu driven GUI
application. Keen+ is truly a one stop shop for complete immersion into CryptoRF
products.
We wish you a fulfilling experience working with Keen+
Your Embedded Crypto Solutions Team

www.atmel.com
Getting Started
1. Connect Keen+ to your PC using the provided USB cable
2. Launch ECE Studio
3. Select the CryptoRF application option
4. Follow instructions at the bottom of each screen
5. Click forward arrow to advance screens
KEEN+ WELCOME AND QUICK START GUIDE
Package Contents
1. 1 Keen+ board
2. 1 Embedded Crypto Solutions CD
3. Atmel CryptoRF Tag Assortment
4. 1 USB cable Type-A, Mini-B cable
Systems Requirements
n Windows XP
n 200 MB available disk space
n Available USB Port
Software Installation
1. Insert Embedded Crypto Solutions CD into a PC.
2. Select the “Detailed Information” option.
3. Click “Install Now” to install Embedded Crypto Evaluation Studio and
other resources. This will place program icons on the desktop as well
as the START menu.
