Installation Guide
PS-POE-AF PoE Injector
Overview
The PS-POE-AF (FG423-80) is a Power-over-Ethernet (PoE) power supply with
integral DC Injector (FIG. 1). It provides DC power for one PoE-equipped device
by "Injecting" DC power through the CAT5 ethernet cable.
The PS-POE-AF supports the IEEE standard PoE pinout:
Pins 4&5 Power (+) / Pins 7&8 Power (-).
Key features include:
• Power over Ethernet (PoE)
• 10/100/1000 (MbPS) Data Rates
• Self-contained Injector
• 100-240VAC Universal Input
• Desktop Style / Non-vented Case
• IEEE802.3af Compliant Detection, Disconnect, Overload and Over Voltage
Control Function
• Load Diagnostic LED
• UNH IOL Test Report
• Over Load Shutdown and Short Circuit Protection
• Regulated Output With Low Ripple
• Meets Safety Agency Requirements
• Complies with EMI/RFI Regulations
Product Specifications
Pin Connections
FIG. 2 describes the PoE Gigabit pin-out connections for the IN and OUT Ports
on the rear panel of the PS-POE-AF:
FIG. 1 PS-POE-AF Power-Over-Ethernet Power Supply
PS-POE-AF Specifications
Output Specifications
Combined Line and Load
Voltage Regulation
Excluding Cord ±1%
Ripple 1% Vp-p max.
Transient Response • 0.5ms for 50%
• Load Change Typical
Protection • Foldback Overcurrent Protection
• Short Circuit Protection
Input Specifications
AC Input Voltage Range 100-240VAC -10%, +6%
Line Frequency 47-63Hz
AC Input Current • 90VAC Input
•0.6Amax.
Protection • Internal Primary Current Fuse
• Inrush Limiting
General Specifications
Topology • Switching-Fixed
• Frequency Flyback
Dielectric Withstand • Primary-Secondary 3000VAC, 4250VDC
• Secondary-Ground 500VDC
Spacing 5mm Primary-Secondary
Leakage Current Less than 250 uA
Efficiency • 65% Typical @ Max. Load
• and 120VAC/60 Hz
PS-POE-AF Specifications (Cont.)
Weight (excluding cord) 7 Ounces (200 Grams)
Dimension • 5.24L x 2.13W x 1.42H (in)
• 133.0L x 54.0W x 36.0H (mm)
Case Material Black 94V0 Polycarbonate
Cord and Connectors Dual RJ45 jacks built into the enclosure
EMC Information
FCC • Part 15 Class B
• EN55022 Class B
Immunity ESD: EN61000-4-2
RS EN61000-4-3
EFT EN61000-4-4
Surge EN61000-4-5
CS EN61000-4-6
Voltage Dip EN61000-4-11
Harmonic EN61000-3-2
CE CE Compliant
Hold-up Time • @120VAC 10ms min. typ.
• @240VAC 40ms min. typ.
Storage Temp -30° C to +85° C
Approvals and
Standards - Safety
• cULus: UL/CSA60950
• TUV: EN60950
• CE: LVD, EMCD
MTBF 100,000 Calculated Hours
Environmental Specifications
Thermal Performance • Operating Temperature 0° C to 40° C
• No Derating
• Convectional Cooling
• Non Vented Case
Relative Humidity Non-Condensing 5% to 95%
Altitude 0-10,000 feet
FIG. 2 PoE Gigabit pin-out connections
J2 J1
(Data IN)(Power and Data OUT)
(rear of unit)
POWER (+)
DATA Pins 4/5 (DATA + PWR)
DATA Pins 1/2 (DATA only)
DATA Pins 3/6 (DATA only)
POWER (-)
DATA Pins 7/8 (DATA + PWR)
Note: = Transformer
