AMX AXR-NWS User manual

netwave wireless server
NETWAVE WIRELESS SERVER
Use the NetWave Server (AXR-NWS) to link 2-way NetWave compatible
wireless touch panels, such as the ViewPoint NetWave Color Passive Touch
Panel (VPN-CP), to an Axcess or NetLinx®system network. Each NetWave
Server manages up to 16 different wireless devices at the same time and
up to 16 NetWave Servers can be used in the same AMX Control System.
The NetWave 2.4 GHz RF digital spread-spectrum signal assures trouble-
free wireless operation.
The AXR-NWS can be installed on any flat surface or rack unit using an
optional Rack Mount Kit (AC-RK). This transceiver is capable of distributing
16 Device Addresses, in any combination, to communicating ViewPoint
Touch Panels, with each AXR-NWS allowing control of up to 1020 channels
per ViewPoint.

ARGENTINA • AUSTRALIA • BELGIUM • BRAZIL • CANADA • CHINA • ENGLAND • FRANCE • GERMANY • GREECE • HONG KONG • INDIA • INDONESIA • ITALY • JAPAN
LEBANON • MALAYSIA • MEXICO • NETHERLANDS • NEW ZEALAND • PHILIPPINES • PORTUGAL • RUSSIA • SINGAPORE • SPAIN • SWITZERLAND • THAILAND • TURKEY • USA
ATLANTA • BOSTON • CHICAGO • CLEVELAND • DALLAS • DENVER • INDIANAPOLIS • LOS ANGELES • MINNEAPOLIS • PHILADELPHIA • PHOENIX • PORTLAND • SPOKANE • TAMPA
3000 RESEARCH DRIVE, RICHARDSON, TX 75082 • 800.222.0193 • 469.624.8000 • +1.469.624.7400 • 469.624.7153 fax • www.amx.com
01.2006 ©2006 AMX. All rights reserved. AMX and the AMX logo are all trademarks of AMX. AMX reserves the right to alter specifications without notice at any time.
5.550" [141mm]
AXR-NWS
NetWave Server
AXP
AXM
GND
PWR
AXLink
AXR-NWS (FG5930, FG5930-02)
•Mounts on any flat surface or rack mount (with optional
Rack kit)
•Employs a 2.4 GHz RF digital spread-spectrum signal for
trouble-free operation
•Employs frequency hopping spread spectrum
technology
•Provides the user with a high-gain antenna for
optimum range
•Communicates with up to 16 Device Addresses
•Controls a maximum of 1020 channels per
ViewPoint panel
•Compatible with Axcess and NetLinx®Control Systems
•Includes a magnetic faceplate that covers the front
panel components
COMPATIBILITY
•NetLinx, Axcess and Landmark Systems
POWER
•175 mA @ 12 VDC
DIMENSIONS
•AXR-NWS (without antenna): 1.65" x 5.55" x 6.40"
(4.19 cm x 14.10 cm x 16.20 cm)
•AXR-NWS (with antenna): 7.41" x 5.55" x 6.40"
(18.82 cm x 14.10 cm x 16.20 cm)
•Faceplate: 1.50" x 5.55" x 0.53"
(3.80 cm x 14.10 cm x 1.30 cm)
ENCLOSURES
•Metal with black matte finish
OPERATING FREQUENCY
•2.4 GHz RF digital spread-spectrum transmission and
reception with up to 16 ViewPoints
CONTROL COMPATIBILITY
•Axcess Central Controller
•NetLinx Central Controller
•Landmark Controller
FRONT PANEL FEATURES
•AXLink LED: Green LED shows power and AXLink
communication activity
•STATUS LED: Red LED indicates when an RF link is
established with one or more devices
•RX LED: Yellow LED indicates when the AXR-NWS
receives RF control data
•GROUP ADDRESS: 8-position DIP switch that sets the
Group Address (range is 0-255)
•GROUP ID: 4-position DIP switch that sets the control
Group Identification (range is 0-15); enables
communication between the wireless devices and
the AXR-NWS
REAR PANEL FEATURES
•High-gain Antenna: Omni-directional, swivel RF antenna
•Connector: 4-pin (male) AXLink, 3.5 mm, bus connector;
connects to the Central Controller for receiving and
transmitting AXLink control data and 12 VDC power
OPTIONAL ACCESSORIES
•AC-RK Rack Kit
•PSN2.8 Power Supply
WEIGHT
•10.56 oz (299.37 grams)
6.915" [175mm]
6.390" [162mm]
1.500" [38mm]
1.650" [42mm]
6.54 {166.1mm]
0.87 [22.1mm]
7.41 [188.2mm]
AXR-NWS (Rear View with High Gain Antenna) AXR-NWS (Rear Side with High Gain Antenna)
netwave wireless server
6.54 (166.1MM)
7.41 (188.2MM)
6.390" (162MM)
1.500" (38MM)
1.650" (42MM)
6.915" (175MM)
