AMX PT10-PRV 2 X 1 User manual

instruction manual
Camera Control Systems
PT10-PRV 2 X 1
Preview Switcher System

AMX Limited Warranty and Disclaimer
AMX Corporation warrants its products to be free of defects in material and workmanship under normal use for
three (3) years from the date of purchase from AMX Corporation, with the following exceptions:
• Electroluminescent and LCD Control Panels are warranted for three (3) years, except for the display and touch
overlay components that are warranted for a period of one (1) year.
• Disk drive mechanisms, pan/tilt heads, power supplies, MX Series products, and KC Series products are
warranted for a period of one (1) year.
• Unless otherwise specified, OEM and custom products are warranted for a period of one (1) year.
• Software is warranted for a period of ninety (90) days.
• Batteries and incandescent lamps are not covered under the warranty.
This warranty extends only to products purchased directly from AMX Corporation or an Authorized AMX Dealer.
AMX Corporation is not liable for any damages caused by its products or for the failure of its products to perform.
This includes any lost profits, lost savings, incidental damages, or consequential damages. AMX Corporation is not
liable for any claim made by a third party or by an AMX Dealer for a third party.
This limitation of liability applies whether damages are sought, or a claim is made, under this warranty or as a tort
claim (including negligence and strict product liability), a contract claim, or any other claim. This limitation of
liability cannot be waived or amended by any person. This limitation of liability will be effective even if AMX
Corporation or an authorized representative of AMX Corporation has been advised of the possibility of any such
damages. This limitation of liability, however, will not apply to claims for personal injury.
Some states do not allow a limitation of how long an implied warranty last. Some states do not allow the limitation or
exclusion of incidental or consequential damages for consumer products. In such states, the limitation or exclusion of
the Limited Warranty may not apply. This Limited Warranty gives the owner specific legal rights. The owner may
also have other rights that vary from state to state. The owner is advised to consult applicable state laws for full
determination of rights.
EXCEPT AS EXPRESSLY SET FORTH IN THIS WARRANTY, AMX CORPORATION MAKES NO
OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. AMX CORPORATION
EXPRESSLY DISCLAIMS ALL WARRANTIES NOT STATED IN THIS LIMITED WARRANTY. ANY
IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW ARE LIMITED TO THE TERMS OF THIS
LIMITED WARRANTY.

Table of Contents
i
P
T10-PRV 2 x 1 Preview Switcher System
Table of Contents
PT10-PRV 2 x 1 Preview Switcher System Package .............................................1
PT10-PRV System Components....................................................................................... 1
2 x 1 Video Preview Switcher Configuration ..................................................................... 2
Installation and Wiring .............................................................................................3
Wiring Information for the AV2SM..................................................................................... 3
Using the CC-REL connection cable........................................................................................ 3
Operation........................................................................................................................... 4
Recommended Lenses for Sony PosiTrack Systems ....................................................... 4
Troubleshooting .......................................................................................................5
General.............................................................................................................................. 5
Lens................................................................................................................................... 5
Setup ................................................................................................................................. 5
Setting the RS-232 DIP Switch (S2).................................................................................. 6
Troubleshooting Tips......................................................................................................... 7
Sony Technical Support ..........................................................................................9
On the Web ....................................................................................................................... 9
Telephone Support............................................................................................................ 9
Written Requests for Assistance ....................................................................................... 9

ii PT10-PRV 2 x 1 Preview Switcher System
Table of Contents

PT10-PRV 2 x 1 Preview Switcher System Package
1
P
T10-PRV 2 x 1 Preview Switcher System
PT10-PRV 2 x 1 Preview Switcher System
Package
The AMX Preview Switcher System uses the AXP-PLV PosiTrack Pilot Video Panel Camera
Controller in conjunction with the AXB-REL8 Relay Controller and the AV2SM 2 x 1
A/V Switcher.
PT10-PRV System Components
AXB-REL8 Relay Controller
The AXB-REL8 is a Relay Controller that provides remote control
for up to eight relay functions via the four-wire AXlink data bus.
AV2SM A/V Switcher
The AV2SM is a 2 x 1 A/V Switcher.
CC-AXL AXlink Connection Cable (4-pin captive-wire to 4-pin
captive-wire)
The AXlink cable is used in all configurations, and connects the
AXB-REL8 to the ABS AXlink Bus Strip.
CC-REL Relay Connection Cable (6-pin captive-wire to 6-pin
captive-wire)
CC-REL Relay Connection Cable connects the AV2SM to the
AXB-REL8.
4-pin captive-wire 4-pin captive-wire
10’ (3.05 m)
10’ (3.05 m)
6-pin captive-wire 6-pin captive-wire
(AXB-REL8) (ABS Bus Strip)
(AV2SM) (AXB-REL8)

PT10-PRV 2 x 1 Preview Switcher System Package
2PT10-PRV 2 x 1 Preview Switcher System
2 x 1 Video Preview Switcher Configuration
The following example (FIG. 1) adds a 2 x 1 video preview switcher to any of the other AMX
Camera Control Systems.
AMX components in this additional-camera control system:
FIG. 1 Sample two-camera control application using a CMA-D3 connection up to 100 m.
• AV2SM 2 x 1 A/V Switcher
• AXB-REL8 Relay Controller
• CC-AXL AXlink cable 10' (3.05 m) AXlink connection cable (4-pin captive-wire to 4-pin captive-
wire)
• CC-REL cable 10' (3.05 m) connection cable (6-pin captive-wire to 6-pin captive-wire)
AMX AXP-PLV
AXlink
AMX PS2.8
Power Supply
AMX
AXB-EM232
(rear view)
2-pin
captive-wire
AMX AV2SM
(front view)
AMX AXB-REL8
(rear view)
captive-wire
2-pin
CC-REL
(to INPUT A:
Select/GND
on rear panel)
CC-REL (to Relay 2)
AXlink
Video Feed 1 (to VIDEO-INPUT A on rear)
Video Feed 2 (to VIDEO-INPUT B on rear panel)
AXlink
AMX ABS (AXlink Bus Strip)

Installation and Wiring
3
P
T10-PRV 2 x 1 Preview Switcher System
Installation and Wiring
This section covers the steps necessary to connect and operate a PT10-PRV 2 x 1 Video Preview
System. Before continuing, verify that you have received the correct components for your package.
Refer to the PT10-PRV System Components section on page 1 for more information.
Wiring Information for the AV2SM
Using the CC-REL connection cable
Use the CC-REL relay control cable (6-pin captive-wire to 8-pin captive-wire) to connect the
AV2SM to the AXB-REL8, as shown in FIG. 3.
FIG. 2 Front and rear views of the AV2SM
FIG. 3 CC-REL relay control cable connections
AUDIOVIDEO
T
D
INPUT A
HT
VIDEO AUDIO
INPUT B
AUDIO
VIDEO
OUTPUT
12 VDC
D D D
T
D
HT
D
T
D
HT
12 VDC power
Front panel
Rear panel
(BNC connector)
INPUT A connector
VIDEO OUTPUT
(BNC connector)
VIDEO INPUT A
(BNC connector)
supply connection
VIDEO INPUT B
(6-pin captive-wire)
GND -
SELECT
AXB-AV2SM
INPUT A connector
AXB-REL8
relay contacts 1-4
2A
2B

Installation and Wiring
4PT10-PRV 2 x 1 Preview Switcher System
Operation
Setting camera stations 1 and 2 on the AXP-PLV controller will switch the appropriate video to the
touchpanel preview screen.
Recommended Lenses for Sony PosiTrack Systems
For optimal performance AMX recommends the use of direct analog voltage controllable lenses.
These lenses allow the PT10 or PT30 full control of lens functions. If direct analog voltage control
lenses are not available the PT10 and PT30 can support lenses controlled via the camera’s RS232
port such as the double hot shoe type. The user should keep in mind that lenses of this type are
limited by the camera’s RS232 protocol. For example, variable speed lens movements are not
possible, nor are fully coordinated preset recalls.
The Sony/AMX PosiTrack Pilot System supports the following lenses (recommended lenses are
highlighted):
Recommended Lenses for Sony PosiTrack Systems
Camera Lens Description
DXC-390 camera Fujinon T14x5.5DA-D58 Direct analog voltage controlled
Canon T10x6.5SSB/SC Direct analog voltage controlled
Fujinon VCL610WEA Camera controlled RS232
Fujinon VCL614WEA Camera controlled RS232
Canon TZ1065SSB/S Camera controlled RS232
DXC-990 camera Fujinon S14x73BWMDD18
(Sony S14x73BWMDD8)
Direct analog voltage controlled (Single hot shoe connection)
Canon YH14x73KTSA Direct analog voltage controlled (Single hot shoe connection)
Canon YH18x67KTSA Direct analog voltage controlled (Single hot shoe connection)
Fujinon S14x73BWMDD38
(Sony VCL714BXEA)
Camera controlled RS232 (Double hot shoe connection)
Canon YH18x67KTSB Camera controlled RS232 (Double hot shoe connection)
Canon CVL714B Camera controlled RS232 (Double hot shoe connection)
Canon HZ1707SSB/S
(Sony VCL717BXEA)
Camera controlled RS232 (Double hot shoe connection)

Troubleshooting
5
PT10-PRV 2 X 1 Preview Switcher System
Troubleshooting
General
! Balancing of camera/lens assembly is critical! Improper balancing can cause tilt
errors and lockup problems.
! On error detection, pan/tilt movement stops (for safety) and will not move until power is
cycled. Upon power cycle unit will attempt movement again until another error is
detected.
Lens
! The four slide switches next to the under the circular cover set the lens voltage control
mode. All Sony approved lenses are Positional Servo style lenses so all four slide
switches must all be set to the left.
! The LENS POWER switch toggles +12VDC on pin 1 of the 15 pin D sub connector. All
Sony approved lenses get power from the camera so set the LENS POWER switch to the
CAM position. If the lens gets power from the camera and you try to supply power from
the PT10, damage may occur.
! Many lenses are not connected to the 15 pin lens port at all and are actually controlled by
the camera, which we control via RS232. In these cases the lens control problem is
usually an RS232 communication issue between the PT10 and the camera. Check the
RS232 cable and restart the Master (AXB-EM232 or Axcent3).
Setup
With multiple camera systems the PT10 AXlink DIP switches must be set to unique values. All
AXB-PT10's are factory set to device 90 which corresponds to camera 1 on the controller.
Additional PT10's should be set sequentially.
Use the DIPSwitch.exe program to reference the correct switch settings. Power must be cycled for
changes to take effect.
AXlink Device Camera Number
90 1
91 2
92 3
93 4
94 5
95 6

Troubleshooting
6PT10-PRV 2 X 1 Preview Switcher System
Setting the RS-232 DIP Switch (S2)
If you are experiencing communication problems with the AXB-EM232, check the
communications settings for the device. The RS-232 communication parameters for this device are
set via the eight-position RS-232 DIP switch. On the AXB-EM232, the RS-232 DIP switch is
located on the front panel. Verify that this DIP switch is set to the default positions indicated in
below.
The following describes the RS-232 DIP switch default positions:
The following table lists the RS-232 DIP switch settings:
• 9,600 baud
• No parity
• 8 bits
• 1 stop bit
RS-232 DIP Switch (S2) Settings
Position1 2 3456 7 8
Function Stop Bits Data Bits Parity Baud Rate
Off Off Off Off Off Off Off Off
2 bits 7 bits Unused 300
On On On Off Off On Off Off
1 bit 8 bits Unused 600
Off On Off Off On Off
Unused 1,200
On On Off On On Off
Unused 2,400
Off Off On Off Off On
Unused 4,800
On Off On On Off On
Even 9,600
Off On On Off On On
Odd 19,200
On On On On On On
None 38,400

Troubleshooting
7
PT10-PRV 2 X 1 Preview Switcher System
Troubleshooting Tips
Problem Possible Cause
No zoom/focus/iris (lens control) If using analog voltage lens control:
• Ensure LENS POWER switch is set to CAM
• Ensure lens power switches are all set to the LEFT (Sony
only ships Servo Positional style lenses with these systems)
If using RS232 camera lens control:
• PT10 must be talking to camera for lens control to work.
• Verify camera communication by pressing 'BARS' button on
panel and looking for color bars from camera. Toggle on and
off.
• Cycle power on entire system to re-establish
communication.
• Upgrade to Master Axcess code version 1.56 or later with
enhanced Sony communication reliability.
• Verify AMX devices are set to 9600 baud.
1. On the PT10 switch S2 should have all switches up (on)
except switch 7 which should be down (off).
2. On the EM232 both interface switches (NOT the Pro-
gram switch) should have all switches down (on) except
switch 7 which should be up (off).
• Verify DXC camera is set to 9600 baud.
No Focus or Sporadic Focus
Movement
• The software version is incompatible with the version of Pilot
controller in the system.
• Serial numbers beginning with 563070 or 563080 must have
a "P" version of software.
• Serial numbers beginning with 563050 or 563060 must NOT
have a "P" version
No Pan/Tilt • Verify AXlink device address (90 - 95)
• Verify AXlink LED flashes on PT10
Multiple Heads Pan and Tilt at the
Same Time
Check for duplicate AXlink device ID's on the PT10's.
PT10 "Drifts" or Moves by Itself Joystick is not calibrated. Reboot the entire system and do not
touch the joystick or control knobs during initialization ("Please
Wait" screen).

Troubleshooting
8PT10-PRV 2 X 1 Preview Switcher System

Sony Technical Support
9
PT10-PRV 2 X 1 Preview Switcher System
Sony Technical Support
On the Web
You can contact the Technical Assistance Network (TAN) on the Internet:
! http://bpgprod.sel.sony.com/infosupport.bpg
Telephone Support
For dedicated phone support (available from 8:30 a.m. to 8:00 p.m. Eastern time, Monday through
Friday):
! [phone]
Written Requests for Assistance
Sony's Business Information Center (BIC) serves as a "virtual reception desk" for the Broadcast
and Professional Group. Staffed with full-time agents, the center is the focal point of contact for
any Broadcast and Professional Group inquiry. The BIC is designed to provide general information,
including product specifications, literature and list prices to inquiring callers.
! Tel: [phone]-SONY
! Email: http://bpgprod.sel.sony.com/cic.htm

Sony Technical Support
10 PT10-PRV 2 X 1 Preview Switcher System

Sony Technical Support
13
PT10-PRV 2 X 1 Preview Switcher System

AMX reserves the right to alter specifications without notice at any time.
brussels • dallas • los angeles • mexico city • philadelphia • shanghai • singapore • tampa • toronto* • york
3000 research drive, richardson, TX 75082 USA • 469.624.8000 • 800.222.0193 • fax [phone] • technical support 800.932.6993
048-004-2384 3/02 ©2002 AMX Corporation. All rights reserved. AMX, the AMX logo, the building icon, the home icon, and the light bulb icon are all trademarks of AMX Corporation.
AMX reserves the right to alter specifications without notice at any time. *In Canada doing business as Panja Inc.
FG 93-0630-92
