AMX Modero G5 User manual

Instruction Manual
Touch Panels
Modero G5
Configuration and Programming
X Series G5 Touch Panels
Last Revised: 9/03/2014

AMX Limited Warranty and Disclaimer
This Limited Warranty and Disclaimer extends only to products purchased directly from AMX or an AMX Authorized Partner which
include AMX Dealers, Distributors, VIP’s or other AMX authorized entity.
AMX warrants its products to be free of defects in material and workmanship under normal use for three (3) years from the date of
purchase, with the following exceptions:
• Electroluminescent and LCD Control Panels are warranted for three (3) years, except for the display and touch overlay compo-
nents are warranted for a period of one (1) year.
• Disk drive mechanisms, pan/tilt heads, power supplies, and MX Series products are warranted for a period of one (1) year.
• AMX lighting products are guaranteed to switch on and off any load that is properly connected to our lighting products, as long
as the AMX lighting products are under warranty. AMX also guarantees the control of dimmable loads that are properly con-
nected to our lighting products. The dimming performance or quality there of is not guaranteed, impart due to the random combi-
nations of dimmers, lamps and ballasts or transformers.
• AMX software is warranted for a period of ninety (90) days.
• Batteries and incandescent lamps are not covered under the warranty.
• AMX AutoPatch Epica, Modula, Modula Series4, Modula CatPro Series and 8Y-3000 product models will be free of defects in
materials and manufacture at the time of sale and will remain in good working order for a period of three (3) years following the
date of the original sales invoice from AMX. The three-year warranty period will be extended to the life of the product (Limited
Lifetime Warranty) if the warranty card is filled out by the dealer and/or end user and returned to AMX so that AMX receives it
within thirty (30) days of the installation of equipment but no later than six (6) months from original AMX sales invoice date. The
life of the product extends until five (5) years after AMX ceases manufacturing the product model. The Limited Lifetime Warranty
applies to products in their original installation only. If a product is moved to a different installation, the Limited Lifetime Warranty
will no longer apply, and the product warranty will instead be the three (3) year Limited Warranty.
All products returned to AMX require a Return Material Authorization (RMA) number. The RMA number is obtained from the AMX
RMA Department. The RMA number must be clearly marked on the outside of each box. The RMA is valid for a 30-day period. After
the 30-day period the RMA will be cancelled. Any shipments received not consistent with the RMA, or after the RMA is cancelled, will
be refused. AMX is not responsible for products returned without a valid RMA number.
AMX is not liable for any damages caused by its products or for the failure of its products to perform. This includes any lost profits, lost
savings, incidental damages, or consequential damages. AMX is not liable for any claim made by a third party or by an AMX Autho-
rized Partner for a third party.
This Limited Warranty does not apply to (a) any AMX product that has been modified, altered or repaired by an unauthorized agent or
improperly transported, stored, installed, used, or maintained; (b) damage caused by acts of nature, including flood, erosion, or earth-
quake; (c) damage caused by a sustained low or high voltage situation or by a low or high voltage disturbance, including brownouts,
sags, spikes, or power outages; or (d) damage caused by war, vandalism, theft, depletion, or obsolescence.
This limitation of liability applies whether damages are sought, or a claim is made, under this warranty or as a tort claim (including
negligence and strict product liability), a contract claim, or any other claim. This limitation of liability cannot be waived or amended by
any person. This limitation of liability will be effective even if AMX or an authorized representative of AMX has been advised of the
possibility of any such damages. This limitation of liability, however, will not apply to claims for personal injury.
Some states do not allow a limitation of how long an implied warranty last. Some states do not allow the limitation or exclusion of inci-
dental or consequential damages for consumer products. In such states, the limitation or exclusion of the Limited Warranty may not
apply. This Limited Warranty gives the owner specific legal rights. The owner may also have other rights that vary from state to state.
The owner is advised to consult applicable state laws for full determination of rights.
EXCEPT AS EXPRESSLY SET FORTH IN THIS WARRANTY, AMX MAKES NO OTHER WARRANTIES, EXPRESSED OR
IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. AMX
EXPRESSLY DISCLAIMS ALL WARRANTIES NOT STATED IN THIS LIMITED WARRANTY. ANY IMPLIED WARRANTIES THAT
MAY BE IMPOSED BY LAW ARE LIMITED TO THE TERMS OF THIS LIMITED WARRANTY. EXCEPT AS OTHERWISE LIMITED
BY APPLICABLE LAW, AMX RESERVES THE RIGHT TO MODIFY OR DISCONTINUE DESIGNS, SPECIFICATIONS, WARRAN-
TIES, PRICES, AND POLICIES WITHOUT NOTICE.

Table of Contents
i
Modero G5 Touch Panels - Configuration and Programming
Table of Contents
Modero X Series ® G5 Programming .................................................................1
Overview .................................................................................................................. 1
Transitioning from G4 to G5 ..................................................................................... 1
Using the "Pipe" ( | ) Character ....................................................................................... 2
Settings Menu ....................................................................................................3
Overview .................................................................................................................. 3
Accessing the Settings Menu .................................................................................... 3
Using AMX System Recovery .................................................................................... 3
Using the Settings Menu........................................................................................... 4
Settings..................................................................................................................... 5
Opening Settings pages.................................................................................................. 5
Closing the Settings menu .............................................................................................. 5
Device Info................................................................................................................ 6
Legal Information ............................................................................................................ 7
Maintenance ............................................................................................................. 7
Rebooting the Panel........................................................................................................ 7
Shutting Down the Panel................................................................................................. 8
Storage ..................................................................................................................... 8
Apps................................................................................................................................ 9
Pictures............................................................................................................................ 9
Audio............................................................................................................................. 10
Downloads .................................................................................................................... 11
Cached Data.................................................................................................................. 11
Miscellaneous ................................................................................................................ 11
USB Storage .................................................................................................................. 11
Unmounting a USB Storage Device .......................................................................................... 12
Sound...................................................................................................................... 12
Adjusting Volumes ........................................................................................................ 13
Selecting a Button Hit Sound ........................................................................................ 13
Selecting a Button Miss Sound...................................................................................... 13
Selecting an NFC Notification Sound ............................................................................ 13
Selecting a Default Notification Sound ......................................................................... 14
Display .................................................................................................................... 14
Adjusting the Panel Brightness ..................................................................................... 15
Adjusting the Display Timeout ...................................................................................... 15
Selecting the Font Size.................................................................................................. 15
Calibration Test ............................................................................................................. 16
G5 Settings ............................................................................................................. 16

ii Modero G5 Touch Panels - Configuration and Programming
Table of Contents
Camera ................................................................................................................... 17
Streaming Video............................................................................................................ 17
Entering a Streaming Video URL ................................................................................... 18
Sensors ................................................................................................................... 18
Calibrating the Light Sensor.......................................................................................... 19
VNC ........................................................................................................................ 20
SIP........................................................................................................................... 21
Custom Ringtones ......................................................................................................... 21
Ethernet.................................................................................................................. 22
Setting Static IP Information ......................................................................................... 22
Entering a New Hostname ............................................................................................ 23
NetLinx ................................................................................................................... 24
Scanning for Masters..................................................................................................... 25
Changing the Master Connection Mode........................................................................ 25
Changing the Master IP/URL ......................................................................................... 26
Changing the Master Port Number ............................................................................... 26
Changing the Master Username and Password ............................................................. 27
Changing the Current Master Username .................................................................................. 27
Changing the Master Password ................................................................................................ 27
Changing the Device Number and Device Name .......................................................... 27
Browser................................................................................................................... 28
Adding a URL to the URLs List ...................................................................................... 28
Switching Between Desktop and Mobile Content......................................................... 29
Deleting a URL from the URL’s List ............................................................................... 29
Multi Preview.......................................................................................................... 29
Configuring the Touch Panel To Accept Multi Preview Signals................................................. 30
NFC......................................................................................................................... 30
NFC Commands ............................................................................................................ 31
NFC Read tag custom event .................................................................................................. 31
Streaming video custom event............................................................................................... 31
Add an Account ...................................................................................................... 31
Adding an Account ................................................................................................................... 32
Date & Time............................................................................................................ 33
Retrieving the Date and Time From NTP .................................................................................. 33
Manually Setting the Date ........................................................................................................ 34
Manually Setting the Time ........................................................................................................ 34
Manually Setting the Time Zone ............................................................................................... 34
Specifying a Date Format ......................................................................................................... 35
Language & Input ................................................................................................... 35
Selecting The Touch Panel’s Language.......................................................................... 36
Personal Dictionary ....................................................................................................... 36
Changing Input Methods............................................................................................... 37
Changing the Pointer Speed ......................................................................................... 37

Table of Contents
iii
Modero G5 Touch Panels - Configuration and Programming
Security................................................................................................................... 38
Changing a Previously Established Password ........................................................................... 38
Viewing the Current Touch Panel Security Level....................................................................... 39
Reset and Update ................................................................................................... 39
Removing All Data From the Touch Panel ..................................................................... 40
Storing and Loading Settings Configuration Files ......................................................... 40
Saving the Current Settings ...................................................................................................... 40
Loading Settings ....................................................................................................................... 41
Valid Values .............................................................................................................................. 41
Resetting the Touch Panel Settings to Factory Defaults ............................................... 43
Resetting to Factory-Installed Firmware........................................................................ 43
Installing Previous Firmware.......................................................................................... 44
Installing New Firmware From An External USB Stick ................................................... 44
Installing Touch Panel Pages From an External Disk ..................................................... 45
Removing User Pages From a Touch Panel ................................................................... 46
Diagnostics ............................................................................................................. 46
Gestures ...........................................................................................................49
Overview ................................................................................................................ 49
Touch Gesture Recognition..................................................................................... 49
Gesture Velocity............................................................................................................ 49
Gesture Prioritization .................................................................................................... 50
Gesture VNC/Mouse Support........................................................................................ 50
Gesture Custom Event .................................................................................................. 50
Gesture numbers ...................................................................................................................... 50
Simplified gesture velocity values............................................................................................. 50
Precise gesture velocity ............................................................................................................ 51
Enabling or Disabling the Gesture Custom Event ......................................................... 51
MXA-MP and MXA-MPL Programming .............................................................53
Overview ................................................................................................................ 53
Configuring the Touch Panel................................................................................... 53
Stand-Alone Images and Video Feeds .................................................................... 53
Adding a Preview Image to a Touch Panel Page ........................................................... 53
Adding a Live Motion Stream To A Touch Panel Page via an MXA-MPL ....................... 54
Code-Driven Buttons and Video Feeds................................................................... 55
Programming - Send Commands ......................................................................57
Overview ................................................................................................................ 57
Panel Send Commands ........................................................................................... 57
^ABP ...................................................................................................................................... 57
^ADB ..................................................................................................................................... 57
^BRT ...................................................................................................................................... 57
?BRT....................................................................................................................................... 58
^CPR ...................................................................................................................................... 58

iv Modero G5 Touch Panels - Configuration and Programming
Table of Contents
^DMM.................................................................................................................................... 58
^GCE...................................................................................................................................... 59
?MAC ..................................................................................................................................... 59
^MUT ..................................................................................................................................... 59
?MUT...................................................................................................................................... 60
^RSS....................................................................................................................................... 60
^SLP....................................................................................................................................... 60
^SLT ....................................................................................................................................... 61
?SLT........................................................................................................................................ 62
^SOU ..................................................................................................................................... 62
^SSL ....................................................................................................................................... 62
^STP....................................................................................................................................... 62
^SWK ..................................................................................................................................... 63
^TPF....................................................................................................................................... 63
^TPN ...................................................................................................................................... 63
^VOL...................................................................................................................................... 63
?VOL ...................................................................................................................................... 64
^WKE ..................................................................................................................................... 65
SHUTDOWN........................................................................................................................... 65
WEBU..................................................................................................................................... 65
Page Commands ..................................................................................................... 66
^PGE...................................................................................................................................... 66
^PPA ...................................................................................................................................... 66
^PPF....................................................................................................................................... 66
^PPG...................................................................................................................................... 66
^PPK ...................................................................................................................................... 67
^PPN...................................................................................................................................... 67
^PPT....................................................................................................................................... 67
^PPX ...................................................................................................................................... 67
Collapsible Popup Send Commands ....................................................................... 68
^PCL....................................................................................................................................... 68
^PCT ...................................................................................................................................... 68
^PDO ..................................................................................................................................... 69
^POP...................................................................................................................................... 69
^PTC ...................................................................................................................................... 69
^PTO...................................................................................................................................... 70
Button Send Commands ........................................................................................ 71
^ANI....................................................................................................................................... 71
^AFP ...................................................................................................................................... 71
^APF ...................................................................................................................................... 72
^BSF....................................................................................................................................... 72
^BSM ..................................................................................................................................... 72
^CPF ...................................................................................................................................... 73
^GLH...................................................................................................................................... 73
^GLL....................................................................................................................................... 73
^ENA ..................................................................................................................................... 73
^SCE ...................................................................................................................................... 74
?SCE....................................................................................................................................... 75
^SDR ...................................................................................................................................... 75
^SHA...................................................................................................................................... 75
^SHD...................................................................................................................................... 76
^SHO ..................................................................................................................................... 76

Table of Contents
v
Modero G5 Touch Panels - Configuration and Programming
^SPD ...................................................................................................................................... 76
^SSH ...................................................................................................................................... 77
^STG ...................................................................................................................................... 77
Button State Commands ........................................................................................ 78
^BAT ...................................................................................................................................... 78
^BAU...................................................................................................................................... 78
^BBR ...................................................................................................................................... 79
^BCB ...................................................................................................................................... 79
?BCB ...................................................................................................................................... 80
^BCF ...................................................................................................................................... 80
?BCF....................................................................................................................................... 81
^BCT ...................................................................................................................................... 81
?BCT....................................................................................................................................... 82
?BOS ...................................................................................................................................... 82
^BMP ..................................................................................................................................... 83
?BMP...................................................................................................................................... 84
^BMX ..................................................................................................................................... 85
?BMX...................................................................................................................................... 85
^BOP...................................................................................................................................... 87
^BOS...................................................................................................................................... 87
?BOS ...................................................................................................................................... 88
^BSP ...................................................................................................................................... 88
^BWW.................................................................................................................................... 88
?BWW .................................................................................................................................... 89
^DPF ...................................................................................................................................... 89
^ENC...................................................................................................................................... 90
?JSB ....................................................................................................................................... 90
^SDM ..................................................................................................................................... 92
^TEC ...................................................................................................................................... 92
?TEC....................................................................................................................................... 93
^TXT ...................................................................................................................................... 93
?TXT ....................................................................................................................................... 94
^UNI....................................................................................................................................... 94
ISO-8859-1 Character Encoding/Decoding table ......................................................... 95
Query Bitmap Justification Command table.................................................................. 95
^UTF ...................................................................................................................................... 95
Keyboard/Keypad Send Commands ...................................................................... 96
^AKB...................................................................................................................................... 96
^AKP...................................................................................................................................... 96
^AKR...................................................................................................................................... 96
^PKB ...................................................................................................................................... 96
^PKP ...................................................................................................................................... 97
^EKP ...................................................................................................................................... 97
^DKP...................................................................................................................................... 97
^VKB...................................................................................................................................... 97
^VKP ...................................................................................................................................... 98
^BIT........................................................................................................................................ 98
^VKS ...................................................................................................................................... 98
^TKP ...................................................................................................................................... 98
Resource Send Commands ................................................................................... 101
^RAF .................................................................................................................................... 101
^RMF ................................................................................................................................... 101

vi Modero G5 Touch Panels - Configuration and Programming
Table of Contents
^RFR .................................................................................................................................... 102
^RFRP .................................................................................................................................. 103
^RSR .................................................................................................................................... 103
^RA ^RAF, ^RMF
Embedded Codes.............................................................................................................. 103
Escape Sequences ................................................................................................................ 103
^RAF and ^RMF Embedded Codes / Escape Sequences ......................................... 104
App Send Commands ........................................................................................... 105
^APC.................................................................................................................................... 105
?APC .................................................................................................................................... 105
^APP .................................................................................................................................... 106
?APP..................................................................................................................................... 107
SIP Send Commands ............................................................................................. 108
^PHN-AUTOANSWER .......................................................................................................... 108
^PHN-CALL .......................................................................................................................... 108
^PHN-DECLINE .................................................................................................................... 108
^PHN-INCOMING ................................................................................................................ 108
^PHN-LINESTATE................................................................................................................. 108
^PHN-MSGWAITING............................................................................................................ 109
^PHN-PRIVACY .................................................................................................................... 109
^PHN-REDIAL ...................................................................................................................... 109
^PHN-TRANSFERRED .......................................................................................................... 109
SIP Call Management Commands................................................................................ 110
^PHN-ANSWER.................................................................................................................... 110
^PHN-AUTOANSWER .......................................................................................................... 110
?PHN-AUTOANSWER........................................................................................................... 110
^PHN-CALL .......................................................................................................................... 110
^PHN-DTMF......................................................................................................................... 110
^PHN-HANGUP.................................................................................................................... 110
^PHN-HOLD......................................................................................................................... 110
SIP Setup Commands .................................................................................................. 111
^PHN-SETUP-ENABLE.......................................................................................................... 111
^PHN-SETUP-PASSWORD.................................................................................................... 111
?PHN-LINESTATE ................................................................................................................. 111
^PHN-PRIVACY .................................................................................................................... 111
?PHN-PRIVACY..................................................................................................................... 111
^PHN-REDIAL ...................................................................................................................... 111
^PHN-TRANSFER ................................................................................................................. 111
VNC Send Commands........................................................................................... 112
^BVL .................................................................................................................................... 112
^BVG.................................................................................................................................... 112
^PHN-SETUP-PORT.............................................................................................................. 112
^PHN-SETUP-PROXYADDR.................................................................................................. 112
^PHN-SETUP-USERNAME .................................................................................................... 112
^BVP .................................................................................................................................... 113
^BVT .................................................................................................................................... 113
^BVN.................................................................................................................................... 113
RGB Triplets and Names For Basic 88 Colors ............................................................. 114

Table of Contents
vii
Modero G5 Touch Panels - Configuration and Programming
SSH Commands ..............................................................................................115
Overview .............................................................................................................. 115
help ...................................................................................................................................... 115
? ........................................................................................................................................... 115
back...................................................................................................................................... 115
clear ..................................................................................................................................... 115
date...................................................................................................................................... 115
debug................................................................................................................................... 116
echo ..................................................................................................................................... 116
logout................................................................................................................................... 116
exit ....................................................................................................................................... 116
quit....................................................................................................................................... 116
g5:cache............................................................................................................................... 116
g5:config .............................................................................................................................. 116
g5:sensor.............................................................................................................................. 117
g5:settings ........................................................................................................................... 117
g5:setup ............................................................................................................................... 117
g5:touch............................................................................................................................... 117
g5:version ............................................................................................................................ 117
g5:ver................................................................................................................................... 117
g5:webu ............................................................................................................................... 118
g5:window-stats ................................................................................................................... 118
g5:ws.................................................................................................................................... 118
get........................................................................................................................................ 118
history .................................................................................................................................. 118
ip.......................................................................................................................................... 118
key ....................................................................................................................................... 119
man ...................................................................................................................................... 119
msg ...................................................................................................................................... 119
netlinx .................................................................................................................................. 120
ping...................................................................................................................................... 120
reboot .................................................................................................................................. 120
scope.................................................................................................................................... 121
set ........................................................................................................................................ 121
support................................................................................................................................. 121
temp..................................................................................................................................... 121
time...................................................................................................................................... 122
Appendix A: Text Formatting .........................................................................123
Text Formatting Codes for Bargraphs .................................................................. 123
Text Area Input Masking....................................................................................... 124
Input mask character types ......................................................................................... 124
Input Mask Ranges ...................................................................................................... 125
Input Mask Operations................................................................................................ 125
Input Mask Literals ...................................................................................................... 125
Input Mask Output Examples ...................................................................................... 126
URL Resources ...................................................................................................... 126
Special Escape Sequences ........................................................................................... 126

viii Modero G5 Touch Panels - Configuration and Programming
Table of Contents
Appendix B: Bargraph Functions ....................................................................127
Overview .............................................................................................................. 127
Setup Codes ......................................................................................................... 127
Appendix C: Video Streaming Troubleshooting .............................................129
Optimizing Motion JPEG Video Presentation and Speed ..................................... 129
Transcoding Guidelines......................................................................................... 129
NMX-ENC H.264 Encoder - Encoder Settings for G5 Panels ................................ 132

Modero X Series ® G5 Programming
1
Modero G5 Touch Panels - Configuration and Programming
Modero X Series ®G5 Programming
Overview
The Modero X Series® G5 line of touch panels is the next generation in touch panel design, control and functionality.
Each Modero X Series G5 touch panel shares basic programming functionality with the other G5 products, whether a
tabletop, portrait, or landscape panel. In order to assist programmers and developers with designing the perfect project,
each Modero X Series G5 touch panel shares the following features:
A common arrangement of Settings pages (page 3) that allow easy configuration of new panels into a new or
existing network.
Mutual NetLinx programming commands for the panel gestures supported by the Modero X Series G5
product line
Mutual NetLinx programming commands for other touch panel functions (page 57).
Ability to support applications (apps), such as a web browser or Skype, to enhance the functionality of the
control surface
For more information on designing touch panel pages intended to optimize the Modero X Series G5 experience, please
refer to the TPDesign5 Operation Reference Guide and the G5 Considerations Guide, both available at www.amx.com.
The Modero X-Series G5 touch panels covered in this document are listed below:
Transitioning from G4 to G5
The G5 platform is a new operating system for Modero X Series touch panels, and existing TPDesign4 files are not
compatible with G5 touch panels. A new software tool, TPDesign5, is required to design touch panel files for G5
systems, and is available for download at www.amx.com.
TPDesign5 is similar in look and feel to TPDesign4 and can be installed concurrently with TPDesign4 to enable the
developer to design for both G4 and G5 systems at the same time. TPDesign5 also contains a utility called G4Utility, that
converts existing TPD4 files to TPD5-formatted files.
While G4Utility converts the bulk of a TPD4 file to a format usable in TPD5, given the enormous variations of TPD4
files currently in the field, some tweaking of the converted TPD5 file may still be necessary afterwards.
Modero X-Series G5 Touch Panels
MXT-2001-PAN FG5968-35 20.3" Modero X Series G5 Panoramic Tabletop Touch Panel
MXD-2001-PAN FG5968-36 20.3" Modero X Series G5 Panoramic Wall Mount Touch Panel - Portrait
FG5968-37 20.3" Modero X Series G5 Panoramic Wall Mount Touch Panel - Landscape
MXT-1901-PAN FG5968-41 19.4" Modero X Series G5 Panoramic Tabletop Touch Panel
MXD-1901-PAN FG5968-42 19.4" Modero X Series G5 Wall Touch Panel - Portrait
FG5968-43 19.4" Modero X Series G5 Wall Touch Panel - Landscape
MXT-1001 FG5968-47 10.1" Modero X Series G5 Tabletop Touch Panel
MXD-1001 FG5968-48 10.1" Modero X Series G5 Wall Panel - Portrait
FG5968-49 10.1" Modero X Series G5 Wall Panel - Landscape
MXT-701 FG5968-53 7" Modero X Series G5 Tabletop Touch Panel
MXD-701 FG5968-54 7" Modero X Series G5 Wall Touch Panel - Portrait
FG5968-55 7" Modero X Series G5 Wall Touch Panel - Landscape
For information on Configuring and Programming X Series G4 touch panels, refer to
the Modero G4 Configuration and Programming Guide (available at www.amx.com)
For more information on transitioning from the G4 platform to G5, please refer to the
AMX G5 Considerations white paper, available at www.amx.com.

Modero X Series ® G5 Programming
2Modero G5 Touch Panels - Configuration and Programming
Using the "Pipe" ( | ) Character
Previously, in G4, the pipe character ( |) was used to create a new line.
G5 uses carriage return / line feed ($0d,$0a) instead.
The examples below illustrate indicating a new line (between the words "Hello" and "World") in G4 and in G5
programming:
G4 : "'^TXT-200,0,Hello|World'"
G5 : "'^TXT-200,0,Hello',$0d,$0a,'World'"

Settings Menu
3
Modero G5 Touch Panels - Configuration and Programming
Settings Menu
Overview
G5 Modero X Series touch panels present all configuration information via the on-board Settings menu. The Device,
Connections, Accounts, and System sections are password-protected.
Accessing the Settings Menu
To access the Settings menu, press and hold the Sleep/Settings button on the touch panel for 3 seconds.
Using AMX System Recovery
During a normal firmware upgrade, if a Modero X Series G5 touch panel is unable to boot all the way, AMX System
Recovery can be used to try to reset system data or re-install firmware.
To initiate system recovery:
1. Power up the device while holding the Sleep/Settings button (FIG. 1).
2. Release the button 3 seconds after seeing the AMX boot logo (FIG. 2).
3. Wait a few seconds for recovery mode to begin.
4. The text screen titled "AMX System Recovery" appears. The user is presented with 4 options:
Reboot Device
Factory Data Reset
Revert to Factory Firmware
Install Firmware from USB
5. Navigate the menu options by pressing the Sleep/Settings button. To select an item, press and hold the Sleep/
Settings button for 2 or more seconds. In addition, if the device has a USB keyboard plugged in at bootup, the user
can use the Up/Down arrows and Enter keys to navigate the menus.
Select Reboot Device to reboot.
FIG. 1 Location of the Sleep/Settings button on the MXD-2001-PAN
FIG. 2 Modero X Series boot logo
Sleep/Settings Button

Settings Menu
4Modero G5 Touch Panels - Configuration and Programming
Select Factory Data Reset and then select Yes on the confirmation window to erase all of the user data
(settings, application data, user pages) on the touch panel.
Select Revert to Factory Firmware and then select Yes on the confirmation window for the system to extract
the factory firmware (this can take a minute) and then automatically initiate a firmware upgrade as usual.
Select Install Firmware from USB for a new menu to come up, where the user can navigate the files on the
USB drive. Selecting the "../" entry will take the user back to the previous directory.
Entries with a trailing "/" on the name are directories, and selecting a directory will bring up a new menu with
the contents of that directory shown. All other entries will be ".kit" files. Selecting a KIT file and selecting
"Yes" on the confirmation screen will extract the firmware (this can take a minute) and then automatically
initiate a firmware upgrade as usual.
Using the Settings Menu
When opened, the Settings menu appears in the center of the panel display. Please note that many of the pages in the
menu may be longer than they initially appear. To reach additional functions on a given page, the page itself may be
scrolled up and down to reveal those functions.
Many of the entries in the Settings menu are read-only, or may be modified if information on the same or another page is
changed. The current information on a page appears in white under the main category title; press the text to open the
category’s page (FIG. 3).
If the text is grey, then the option associated with that category is currently disabled. This may be altered with changes in
connectivity (connecting a USB stick to the touch panel, for instance) or changes to other pages within the menu.
For more information on disabling Settings menu access through the Sleep/Settings
button, please refer to the Security section on page 38.
The Settings menu uses scrolling lists. Not all items on a Settings page are visible on
screen at one time, and scrolling up and down to see them may be necessary. In the
case of long Settings pages, a scroll bar appears momentarily when a new menu
appears, and allows you to gauge current position and length of the menu.
FIG. 3 Settings page - Menu Options

Settings Menu
5
Modero G5 Touch Panels - Configuration and Programming
Settings
The main Settings window (FIG. 4) controls access to all of the settings pages within G5 touch panels. The individual
menus are separated into five categories: Info, Device, Connections, Accounts, and System. In the main page, the
following menu functions are available:
All of the pages and menus in the Device, Connections, Accounts, and System categories are password-protected.
Opening Settings pages
1. Select the appropriate page from the Settings menu.
2. In the Password keypad, enter the password and select OK. The default password is 1988.
Closing the Settings menu
To close the Settings menu and return to the touch panel’s user pages, select the Close Settings App icon at the bottom
of the Settings window.
FIG. 4 Settings Menu
Settings Menu options
Configuration: If the lock icon is closed, you will need the correct password to make any changes to this
page.
Maximize/Minimize: Select this to maximize or minimize the size of the Settings menu window on the display.
Volume: Click this to open the Volume window and adjust the output volume on the device.
Return to Previous Menu: Click the arrow to return to the previous menu.
Close Settings App: Click the “X” button to shut the Settings menu and return to the main display.
Adjust Window Size: Hold and drag the corner to adjust the size of the Settings menu window.

Settings Menu
6Modero G5 Touch Panels - Configuration and Programming
Device Info
The Device Info page (FIG. 5) displays basic touch panel information, such as currently available memory and the screen
resolution dimensions.
FIG. 5 Device Info page
Device Info page options
Device
Device IP Displays the panel’s IP address.
Device Number Displays the panel’s device number.
Device Name Displays the panel’s device name.
Device Type Displays the panel model.
Serial Number Displays the specific serial number value assigned to the panel.
Version Displays the current version of the panel’s firmware.
MAC Address Displays the panel’s MAC address.
Resolution Displays the panel’s screen height and width in pixels.
NetLinx Master
Master IP Displays the IP address for the panel’s Master.
Master Port Displays the port used by the panel’s Master.
Master System Number Displays the Master’s system number.
Connection Displays the panel’s connection status.
Memory & File System
Memory Displays the amount of memory available on the panel.
File System Displays the amount of MicroSD card memory available on the panel.
File Information Displays information on the current main touch panel page.
Misc
Up Time Displays the time elapsed since the touch panel was last started.
Legal Information Select this entry to open the Legal Information window (see FIG. 6 on page 7).
Scroll down
to see all
Device Info
menu items

Settings Menu
7
Modero G5 Touch Panels - Configuration and Programming
Legal Information
The Legal Information window can be accessed from the Device Info page. It displays information on intellectual
property notices and information on copyright concerns (FIG. 6).
Maintenance
The Maintenance page (FIG. 7) controls basic functions of the touch panel, including rebooting or shutting down the
touch panel.
Rebooting the Panel
1. In the Maintenance page, select Reboot. This opens the Reboot window (FIG. 8).
FIG. 6 Legal Information window
FIG. 7 Maintenance page
Maintenance page options
Reboot: Select this entry to open the Reboot window.
Shutdown: Select this entry to open the Shutdown window.

Settings Menu
8Modero G5 Touch Panels - Configuration and Programming
2. Click OK to reboot.
Shutting Down the Panel
1. In the Maintenance page. select Shutdown. This opens the Shutdown window (FIG. 9):
2. Click OK to shut down the touch panel.
Storage
The Storage page (FIG. 10) displays and allows access to apps, pictures, audio files, and other files stored on the touch
panel. This page also displays files accessible via USB, such as from hard drives or thumb drives.
FIG. 8 Reboot window
FIG. 9 Shutdown window
The Device pages are all password-protected. The default password is 1988.
FIG. 10 Storage page
Storage page options
Internal Storage
Internal Storage graph This graph displays, in color, how much internal storage is being used compared to what is
available, and which file categories are using that storage.
Total Space The total amount of storage space on the touch panel.
Available The total amount of storage that may be used for apps and other files on the touch panel.
Apps The total amount of storage currently being used for apps and related files on the touch
panel.
Scroll down
to see all
Storage
menu items

Settings Menu
9
Modero G5 Touch Panels - Configuration and Programming
Apps
In the Storage page, the Apps entry displays the total volume of installed apps on the touch panel. Apps are installed via
TPDesign5, and cannot be added or removed via the touch panel.
Pictures
To view all picture and video files either stored on the touch panel or stored on USB storage media, select the Pictures,
Videos entry on the Storage page to open the Pictures/Video window (FIG. 11). The main window will display all folders
containing graphics or video files accessible by the touch panel, in alphabetical order.
Depending upon how the graphics files were tagged with metadata, you may use the Filter by Tag selector at the top of
the page to select between all albums on the touch panel (see FIG. 11). These may be categorized based on a tagged
location, time, individual or group, or by unique tags.
Storage page options (Cont.)
Pictures, Videos The total amount of storage currently being used for picture and video files on the touch
panel. Select this entry to open the Albums window (page 9).
Audio The total amount of storage currently being used for audio files (such as music, ring tones,
and podcasts) on the touch panel. Select this entry to open the Choose Music Track
window (page 10).
Downloads The total amount of storage currently being used for downloaded files (such as text files or
spreadsheets) on the touch panel. Select this entry to open the Downloads window
(page 11).
Cached Data The total amount of storage currently being used for cached data on the touch panel.
Select this entry to open the Clear Cached Data? window (page 11).
Misc. The total amount of storage currently being used for files not matching the previous
categories on the touch panel. Select this entry to open the Misc Files window (page 11).
USB Storage
Mount USB Storage This option only appears if no USB data storage is connected to the touch panel.
USB Storage Graph This graph displays the total used storage in a connected USB storage device versus the
total amount available. This graph only appears if a USB storage device is connected to
the touch panel.
Total Space The total amount of used storage on the connected USB storage device.
Available The total amount of available storage on the connected USB storage device.
Unmount Shared Storage Select this option to allow safe removal of any USB data storage connected to the touch
panel.
FIG. 11 Storage - Pictures/Video with the Tag selection menu open

Settings Menu
10 Modero G5 Touch Panels - Configuration and Programming
Once an album has been chosen, select it to open the album and display the images or videos in it (FIG. 12). Drag and
flick to move the displayed files to the left or right. When you reach the beginning or the end of an album, the displayed
items will "crinkle" to show that you have reached the ending. To view a particular file, select the thumbnail in the album
to open the file.
To close a picture or video file and return to the album, touch the touch panel display to display the Album icon in the
upper left corner. Select the icon to return to the main album. Alternately, select the Return to Previous Page icon at the
bottom of the page.
For more display options, select the downward-pointing arrow in the upper left corner of the window to open the view
selector menu (FIG. 13). Choose between showing each picture or video file in either Grid view or Filmstrip view
(FIG. 13).
To return to the Storage page, select the Return to Previous Page icon at the bottom of the window.
Audio
To access all audio files either stored on the touch panel, stored on USB storage media or stored in an individual
Dropbox account, select the Audio entry on the Storage page to open the Audio Access Options window (FIG. 14).
Choose the location of the file by selecting Choose Music Track if the file is accessible via internal storage or USB, or
Dropbox if the file is accessible via a Dropbox account.
After selecting the option, either select Always to access files in this way every time the Audio option is selected, or
select Just once to give both options every time.
FIG. 12 Album window - Grid view
FIG. 13 View selector menu
FIG. 14 Audio Access Options
