Analog Devices ADZS-BF707-BLIP2 User manual

a
ADZS-BF707-BLIP2 Board
Evaluation System Manual
Revision 1.0, April 2015
Part Number
82-100126-01
Analog Devices, Inc.
One Technology Way
Norwood, Mass. 02062-9106

Copyright Information
©2015 Analog Devices, Inc., ALL RIGHTS RESERVED. This document
may not be reproduced in any form without prior, express written consent
from Analog Devices, Inc.
Printed in the USA.
Disclaimer
Analog Devices, Inc. reserves the right to change this product without
prior notice. Information furnished by Analog Devices is believed to be
accurate and reliable. However, no responsibility is assumed by Analog
Devices for its use; nor for any infringement of patents or other rights of
third parties which may result from its use. No license is granted by impli-
cation or otherwise under the patent rights of Analog Devices, Inc.
Trademark and Service Mark Notice
The Analog Devices logo, Blackfin, CrossCore, and EngineerZone are reg-
istered trademarks of Analog Devices, Inc.
Blackfin+ is a trademark of Analog Devices, Inc.
All other brand and product names are trademarks or service marks of
their respective owners.

Regulatory Compliance
The ADZS-BF707-BLIP2 board is designed to be used solely in a labora-
tory environment. The board is not intended for use as a consumer end
product or as a portion of a consumer end product. The board is an open
system design which does not include a shielded enclosure and therefore
may cause interference to other electrical devices in close proximity. This
board should not be used in or near any medical equipment or RF devices.
The ADZS-BF707-BLIP2 board is in the process of being certified to
comply with the essential requirements of the European EMC directive
2004/108/EC and therefore carries the “CE” mark.
The BLIP2 board evaluation system contains ESD (electrostatic discharge)
sensitive devices. Electrostatic charges readily accumulate on the human
body and equipment and can discharge without detection. Permanent dam-
age may occur on devices subjected to high-energy discharges. Proper ESD
precautions are recommended to avoid performance degradation or loss of
functionality. Store unused BLIP2 boards in the protective shipping pack-
age.

ADZS-BF707-BLIP2 Board Evaluation System Manual v
CONTENTS
PREFACE
Product Overview ............................................................................ x
Purpose of This Manual ................................................................. xii
Intended Audience ......................................................................... xii
Manual Contents .......................................................................... xiii
What’s New in This Manual .......................................................... xiii
Technical Support .......................................................................... xiv
Supported Processors ...................................................................... xiv
Supported Tools .............................................................................. xv
Product Information ....................................................................... xv
Analog Devices Web Site ........................................................... xv
EngineerZone ........................................................................... xvi
Notation Conventions .................................................................... xvi

Contents
vi ADZS-BF707-BLIP2 Board Evaluation System Manual
USING ADZS-BF707-BLIP2 BOARD
Package Contents ......................................................................... 1-2
Default Configuration .................................................................. 1-2
BLIP2 Board Installation .............................................................. 1-3
BLIP2 Board Session Startup ........................................................ 1-4
Evaluation License ........................................................................ 1-6
Mobile DDR Memory .................................................................. 1-7
SPI Flash ...................................................................................... 1-8
UART1 Interface .......................................................................... 1-8
USB Interface ............................................................................... 1-8
SD Interface ................................................................................. 1-9
Debug Interface ............................................................................ 1-9
Power-On-Self Test ....................................................................... 1-9
RF Wireless Interface .................................................................... 1-9
Power Architecture ..................................................................... 1-10
Example Programs ...................................................................... 1-10
Reference Design Information ..................................................... 1-11

ADZS-BF707-BLIP2 Board Evaluation System Manual vii
Contents
ADZS-BF707-BLIP2 BOARD HARDWARE REFERENCE
System Architecture ...................................................................... 2-2
Push Buttons ................................................................................ 2-4
GPIO Push Buttons (SW1 and SW2) ....................................... 2-5
Reset Push Button (SW3) ........................................................ 2-5
WAKE IO Push Button (SW4) ................................................ 2-5
LEDs ............................................................................................ 2-6
GPIO Status LED (LED1) ...................................................... 2-7
SYS_FAULT LED (LED4) ....................................................... 2-7
Connectors ................................................................................... 2-8
JTAG/SWD/SWO Connector (P3) ........................................ 2-10
USB Connector (P4) ............................................................. 2-10
USB to UART Connector (P8) .............................................. 2-10
Power Connector (P5) ........................................................... 2-11
RF Wireless Connector (J2) ................................................... 2-11
SD Connector (J3) ................................................................ 2-11
ADZS-BF707-BLIP2 BOARD BILL OF MATERIALS
ADZS-BF707-BLIP2 BOARD SCHEMATIC
INDEX

Contents
viii ADZS-BF707-BLIP2 Board Evaluation System Manual

ADZS-BF707-BLIP2 Board Evaluation System Manual ix
PREFACE
Thank you for purchasing the ADZS-BF707-BLIP2 board, Analog
Devices, Inc. low-cost evaluation system for the ADSP-BF70x family of
Blackfin®processors.
The ADSP-BF707 processor is a member of the Blackfin family of prod-
ucts. Blackfin processors combine a dual-MAC state-of-the-art signal
processing engine, the advantages of a clean, orthogonal RISC-like micro-
processor instruction set, and single-instruction, multiple-data (SIMD)
multimedia capabilities into a single instruction-set architecture. New
enhancements to the Blackfin+™ core add 32-bit MAC and 16-bit com-
plex MAC support, cache enhancements, branch prediction and other
instruction set improvements, all while maintaining instruction set com-
patibility to previous Blackfin products.
The ADZS-BF707-BLIP2 board is shipped with all of the necessary hard-
ware—you can start the evaluation immediately. The package contains the
standalone evaluation board, CE-approved power supply, and USB cable.
The BLIP2 board ships with an ICE-1000 emulator.
A RF Wireless connector is provided for connecting the BLIP2 board to
an Analog Devices Wireless Sensor Network (WSN) cluster board
(EV-ADRN-WSN-2Z).
The on-board mechanical switches are push buttons.

Product Overview
x ADZS-BF707-BLIP2 Board Evaluation System Manual
The evaluation board is designed to be used in conjunction with the
CrossCore®Embedded Studio (CCES) development tools to test capabil-
ities of the ADSP-BF70x processors. The development environment aids
advanced application code development and debug, such as:
• Create, compile, assemble, and link application programs written
in C++, C, and assembly
• Load, run, step, halt, and set breakpoints in application programs
• Read and write data and program memory
• Read and write core and peripheral registers
Product Overview
The board features:
• Analog Devices ADSP-BF707 processor
• 184-ball BGA package
• 24 MHz crystal oscillator for processor
• 24 MHz crystal oscillator for USB
• Mobile DDR memory (DMC0) chip
• 32M bit x 16 x 4 banks (2G bit)
• MT46H128M16LFDD-48WT
• Quad SPI Flash (SPI2)
• 32M bit serial flash memory
• Windbond W25Q32
