DEMO MANUAL DC2652A-A
Rev. 0
DESCRIPTION
LTC3888
8-Phase, Dual-Output Synchronous Buck
Converter with Power System Management
Demonstration circuit 2652A-A is an 8-phase dual-output,
high efficiency, high density, synchronous buck converter
with 7V to 14V input range. Each output can supply up to
120A maximum load current with 1V output. The demo
board showcases the LT C
®
3888, which is a PMBus-
compliant dual loop 8-phase step-down DC/DC controller
with digital power system management. The LTC3888 is
designed to work with DrMOS devices that provide an out-
put current sense and temperature monitor. Please refer
to LTC3888’s data sheet for more detailed information.
DC2652A-A powers up to default settings and produces
power based on configuration resistors (or with the set-
ting in its non-volatile memory) without the need for any
serial bus communication. This allows easy evaluation of
All registered trademarks and trademarks are the property of their respective owners.
BOARD PHOTO
the DC/DC converter. To fully explore the extensive power
system management features of the part, download the
GUI software LTpowerPlay™onto your PC and use ADI’s
I2C/SMBus/PMBus dongle DC1613A to connect to the
board. LTpowerPlay allows the user to reconfigure the part
on the fly and store the configuration in EEPROM, view
telemetry of voltage, current, temperature and fault status.
GUI Download
The software can be downloaded from:
here
For more details and instructions of LTpowerPlay,
please refer to LTpowerPlay Quick Start Procedure.
Design files for this circuit board are available.
Figure1. Dual-Output LTC3888/DC2652A-A Demo Circuit

2
DEMO MANUAL DC2652A-A
Rev. 0
QUICK START PROCEDURE
DC2652A-A is easy to set up to evaluate the performance
of LTC3888. Refer to Figure2 for the proper measurement
equipment setup and follow the procedure below.
1. With power off, connect the input power supply
(7V-14V) to VIN (J1) and GND (J2).
2. Connect the 1.0V output load (Initial load: no load)
between VOUT0 (J3) and GND (J4).
3. Connect the 1.0V output load (Initial load: no load)
between VOUT1 (J5) and GND (J6).
4. ConnecttheDMMstotheinputandoutputs.Setdefault
jumper position:
• JP1: ON
• JP2: EXT
• JP3: SLAVE
• JP4: SLAVE
• SW1: ON
• SW2: ON
5. Turn on the input power supply and check for the
proper output voltages. VOUT0 should be 1.0V±0.5%
and VOUT1 should be 1.0V ±0.5%.
6. Oncetheproperoutputvoltagesareestablished,adjustthe
loads within the operating range and observe the output
voltage regulation, ripple voltage and other parameters.
7. Connect the dongle and control the output voltages
from the GUI. See LTpowerPlay Quick Start Procedure
for details.
Note:
1. When measuring the efficiency, it is recommended
to monitor the VIN, VOUT0 and VOUT1 at the locations
close to the power stage. Here are examples:
(1) Monitor VIN across CIN9 and VOUT0 across COUT11
for VOUT0 efficiency measurement
(2) MonitorVIN acrossCIN29 and VOUT1across COUT31
for VOUT1 efficiency measurement
2. When measuring the output or input voltage ripple,
do not use the long ground lead on the oscilloscope
probe. Figure3 for the proper scope probe technique.
Short, stiff leads need to be soldered to the (+) and (–)
terminals of an output capacitor. The probe’s ground
ring needs to touch the (–) lead and the probe tip needs
to touch the (+) lead.
3. Whendoing theloadtransienttest, itisrecommendedto
use a function generator to generate a pulse (~3% duty
cycle with 10Hz~100Hz frequency). Then applying this
pulse to the EXT PULSE (E9) and GND (E10) turrets, the
dynamic load circuit will work well to achieve desired
load transient test by adjusting the amplitude, rising
edge and falling edge of the pulse. Here are examples:
(1) Set the amplitude of the pulse to 3.4V for a 0A to 30A
load transient test with 10mΩ IOUT sensing resistor
(2) Set the amplitude of the pulse to 3.6V for a 0A to 40A
load transient test with 10mΩ IOUT sensing resistor
PERFORMANCE SUMMARY
Specifications are at TA= 25°C
PARAMETER CONDITIONS VALUE
Input Voltage Range 7V to 14V
Output Voltage, VOUT0 VIN = 7 to 14V, IOUT0 = 0A to 120A 0.3 to 1.8V, Default: 1.0V
Maximum Output Current, IOUT0 VIN = 7 to 14V, VOUT0 = 0.3V to 1.8V 120A
Output Voltage, VOUT1 VIN = 7 to 14V, IOUT1 = 0A to 120A 0.3 to 1.8V, Default: 1.0V
Maximum Output Current, IOUT1 VIN = 7 to 14V, VOUT1 = 0.3V to 1.8V 120A
Typical Efficiency of VOUT0 VIN = 12V, VOUT0 = 1.0V, IOUT0 = 120A 91.7%
Typical Efficiency of VOUT1 VIN = 12V, VOUT1 = 1.0V, IOUT1 = 120A 91.7%
Default Switching Frequency 500kHz

3
DEMO MANUAL DC2652A-A
Rev. 0
QUICK START PROCEDURE
Figure2. Proper Measurement Equipment Setup
Figure3. Measuring Output Voltage Ripple
+
–
+
–
VOUT0
IOUT0
IOUT1
VOUT1
+–
+–
+–
+–
V
IN
IIN
POWER
SUPPLY
+–
+
–
LOAD0
–
+
LOAD1
DC2652A-A F02
+ –
V
OUT
GND
COUT

4
DEMO MANUAL DC2652A-A
Rev. 0
QUICK START PROCEDURE
Connecting a PC to DC2652A-A
You can use a PC to reconfigure the power management
features of LTC3888 such as:nominal VOUT, margin set
points, OV/UV limits, temperature fault limits, sequenc-
ing parameters, the fault log, fault responses, GPIOs
and other functionalities. The DC1613A dongle may be
plugged when VIN is present.
USB CABLE VIN
VOUT0
LOAD0
LOAD1
V
OUT1
12-PIN (J12)
CONNECTOR
USB TO I2C/PMBUS
DONGLE DC1613A
INPUT POWER
SUPPLY
LTC3888 DEMO BOARD
DC2652A-A
VOUT0 = 1.8V
VOUT0 = 1V
70
75
80
85
90
95
100
0
20
40
60
80
100
120
EFFICIENCY (%)
LOAD CURRENT (A)
DC2652A-A F05
VOUT1 = 1.8V
VOUT1 = 1V
70
75
80
85
90
95
100
0
20
40
60
80
100
120
EFFICIENCY (%)
LOAD CURRENT (A)
DC2652A-A F06
Figure4. Demo Setup with PC
Figure5. Efficiency vs. Load Current on VOUT0 Figure6. Efficiency vs. Load Current on VOUT1

5
DEMO MANUAL DC2652A-A
Rev. 0
QUICK START PROCEDURE
VOUT0
(20MHz BW)
[50mV/DIV]
I
OUT0 0A-30A
LOAD STEP
[20A/DIV]
DC2652A-A F07
100µs/DIV
VOUT1
(20MHz BW)
[50mV/DIV]
I
OUT1 0A-30A
LOAD STEP
[20A/DIV]
DC2652A-A F08
100µs/DIV
VOUT0
(20MHz BW)
[10mV/DIV]
DC2652A-A F09
1µs/DIV
VOUT1
(20MHz BW)
[10mV/DIV]
DC2652A-A F10
1µs/DIV
Figure7. VOUT0 Load Transient Response at
VIN = 12V, VOUT0 = 1.0V
Figure9. VOUT0 Voltage Ripple at VIN = 12V,
VOUT0 = 1.0V, IOUT0 = 120A
Figure8. VOUT1 Load Transient Response at
VIN = 12V, VOUT1 = 1.0V
Figure10. VOUT1 Voltage Ripple at VIN = 12V,
VOUT1 = 1.0V, IOUT1 = 120A

6
DEMO MANUAL DC2652A-A
Rev. 0
Figure11. Thermal at VIN = 12V, VOUT0 = 1.0V, IOUT0 = 120A, VOUT1 = 1.0V, IOUT1 = 120A, TA= 23°C, No Airflow
QUICK START PROCEDURE

7
DEMO MANUAL DC2652A-A
Rev. 0
LTpowerPlay is a powerful Windows based development
environment that supports Analog Devices power sys-
tem management ICs and μModules, including LTM4675,
LTM4676, LTM4677, LTM4678, LTM4680, LTM4700,
LTC3880, LTC3882, LTC3883, LTC3884 and LTC3888.
The software supports a variety of different tasks. You
can use LTpowerPlay to evaluate Analog Devices ICs by
connecting to a demo board system. LTpowerPlay can
also be used in an offline mode (with no hardware pres-
ent) in order to build a multichip configuration file that
can be saved and reloaded at a later time. LTpowerPlay
provides unprecedented diagnostic and debug features.
It becomes a valuable diagnostic tool during board bring-
up to program or tweak the power management scheme
in a system, or to diagnose power issues when bringing
LTPOWERPLAY SOFTWARE GUI
up rails. LTpowerPlay utilizes the DC1613A USB-to-I2C/
SMBus/PMBus controller to communicate with one of
many potential targets, including LTM4675, LTM4676,
LTM4677, LTM4678, LTM4680, LTM4700, LTC3880,
LTC3882, LTC3883, LTC3884 and LTC3888’s demo sys-
tem, or a customer board. The software also provides an
automatic update feature to keep the software current with
the latest set of device drivers and documentation. The
LTpowerPlay software can be downloaded from:
here
To access technical support documents for ADI’s
Digital Power System Management Products, visit the
LTpowerPlay Help menu.
Figure12. LTpowerPlay Main Interface

8
DEMO MANUAL DC2652A-A
Rev. 0
LTPOWERPLAY QUICK START PROCEDURE
The following procedure describes how to use LTpowerPlay
to monitor and change the settings of LTC3888.
1 Download and install the LTpowerPlay GUI:
here
2. Launch the LTpowerPlay GUI.
a. The GUI should automatically identify the DC2652A-A.
The system tree on the left hand side should look like
this:
b. A green message box shows for a few seconds in the
lower left-hand corner, confirming that LTC3888 is
communicating:
c. In the Toolbar, click the “R” (RAM to PC) icon to read
theRAM fromtheLTC3888.This readstheconfiguration
from the RAM of LTC3888 and loads it into the GUI.
d. If you want to change the output voltage to a different
value, like 1.8V. In the Config tab, type in 1.8 in the
VOUT_COMMAND box, like this:
Then, click the “W” (PC to RAM) icon to write these
registervaluestotheLTC3888. After finishing this step,
you will see the output voltage will change to 1.8V.
If the write is successful, you will see the following
message:
e. You can save the changes into the NVM. In the tool
bar, click “RAM to NVM” button, as following
f. Save the demo board configuration to a (*.proj) file.
Click the Save icon and save the file. Name it whatever
you want.

9
DEMO MANUAL DC2652A-A
Rev. 0
PARTS LIST
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
Required Circuit Components
1 6 C1, C2, C3, C4, C5, C6 CAP., 270µF, ALUM, 16V, 20%, SMD 8 × 11.9mm,
E12
PANASONIC/16SVPC270M
2 18 COUT1, COUT2, COUT6, COUT7,
COUT10, COUT11, COUT14,
COUT15, COUT18, COUT19,
COUT22, COUT23, COUT26,
COUT27, COUT30, COUT31,
COUT64, COUT65
CAP., 100µF, X5R, 6.3V, 20%, 1210 AVX/12106D107MAT2A
3 32 CIN1, CIN2, CIN3, CIN4, CIN5, CIN6,
CIN7, CIN8, CIN9, CIN10, CIN11,
CIN12, CIN13, CIN14, CIN15, CIN16,
CIN17, CIN18, CIN19, CIN20, CIN21,
CIN22,CIN23, CIN24, CIN25, CIN26,
CIN27, CIN28, CIN29, CIN30, CIN31,
CIN32
CAP., 22µF, X7R, 25V, 10%, 1210 AVX/12103C226KAT2A
4 16 COUT3, COUT4, COUT8, COUT9,
COUT12, COUT13, COUT16,
COUT17, COUT20, COUT21,
COUT24, COUT25, COUT28,
COUT29, COUT32, COUT33
CAP., 470µF, TANT, POSCAP, 2.5V, 20%, 7343,
TPF Series
PANASONIC/ETPF470M5H
5 16 C7, C16, C20, C27, C29, C34, C36,
C41, C43, C48, C50, C55, C57, C62,
C64, C69
CAP., 0.47µF, X5R, 10V, 10%, 0402 AVX/0402ZD474KAT2A
6 1 C8 CAP., 4.7µF, X5R, 16V, 20%, 0603 MURATA/GRM188R61C475MAAJD
7 1 C9 CAP., 1µF, X7R, 16V, 20%, 0603 AVX/0603YC105MAT2A
8 1 C10 CAP., 2.2µF, X5R, 16V, 10%, 0603 KEMET/C0603C225K4PAC7867
9 2 C11, C108 CAP., 2.2µF, X5R, 16V, 10%, 0805 AVX/0805YD225KAT2A
10 16 C12, C14, C23, C25, C30, C32, C37,
C39, C44, C46, C51, C53, C58, C59,
C65, C67
CAP., 4.7µF, JB, 10V, 20%, 0402 TDK/C1005JB1A475M050BC
11 8 C17, C28, C35, C42, C49, C56, C63,
C70
CAP., 330pF, X7R, 50V, 10%, 0402 AVX/04025C331KAT2A
12 2 C18, C19 CAP., 3300pF, X7R, 50V, 10%, 0603 AVX/06035C332KAT2A
13 2 C21, C22 CAP., 330pF, X7R, 50V, 10%, 0603 KEMET/C0603S331K5RAC7867
14 3 CIN33, CIN34, COUT67 CAP., 10µF, X7R, 16V, 10%, 1210 AVX/1210YC106KAT2A
15 1 COUT66 CAP., 4.7µF, X5R, 16V, 20%, 1210 AVX/1210YD475MAT2A
16 2 C110, C113 CAP., 1µF, X7R, 50V, 10%, 0805 MURATA/GRM21BR71H105KA12L
17 1 C111 CAP., 4.7µF, X5R, 16V, 10%, 0603 AVX/0603YD475KAT2A
18 1 C112 CAP., 0.1µF, X7R, 16V, 10%, 0603 AVX/0603YC104KAT2A
19 1 C114 CAP., 5.6pF, C0G/NP0, 50V, ±0.25pF, 0603 AVX/06035A5R6CAT2
20 1 C116 CAP., 100pF, C0G/NP0, 25V, 5%, 0603 AVX/06033A101JAT2
21 1 D1 DIODE, SCHOTTKY, 200V, 1A, PowerDI-123,
AEC-Q101
DIODES INC./DFLS1200-7
22 8 L1, L2, L3, L4, L5, L6, L7, L8 IND., 215nH, PWR, FERRITE, 10%, 61A, 0.29mΩ,
10.4 × 8.0mm SMD
EATON/FP1007R3-R22-R
23 1 L9 IND., 4.7µH, PWR, 20%, 5.9A, 40mΩ,
5.48 × 5.28mm SMD, XAL5030, AEC-Q200
COILCRAFT/XAL5030-472ME

10
DEMO MANUAL DC2652A-A
Rev. 0
PARTS LIST
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
24 1 R3 RES., 1Ω, 5%, 1/10W, 0603, AEC-Q200 VISHAY/CRCW06031R00JNEA
25 3 R9, R10, R18 RES., 1kΩ, 1%, 1/10W, 0603, AEC-Q200 NIC/NRC06F1001TRF
26 7 R15, R17, R48, R49, R51, R54, R244 RES.,10kΩ, 1%, 1/10W, 0603, AEC-Q200 KOA SPEER/RK73H1JTTD1002F
27 1 R16 RES., 4.99kΩ, 1%, 1/10W, 0603, AEC-Q200 NIC/NRC06F4991TRF
28 8 R23, R46, R68, R82, R97, R112,
R126, R139
RES., 10kΩ, 1%, 1/16W, 0402, AEC-Q200 NIC/NRC04F1002TRF
29 1 R41 RES., 18.7kΩ, 1%, 1/10W, 0603, AEC-Q200 NIC/NRC06F1872TRF
30 1 R53 RES., 2kΩ, 1%, 1/10W, 0603, AEC-Q200 KOA SPEER/RK73H1JTTD2001F
31 4 R89, R98, R234, R235 RES., 10Ω, 1%, 1/10W, 0603 NIC/NRC06F10R0TRF
32 1 R250 RES., 2Ω, 1%, 1/10W, 0603, AEC-Q200 VISHAY/CRCW06032R00FKEA
33 1 R251 RES., 100kΩ, 1%, 1/10W, 0603, AEC-Q200 PANASONIC/ERJ3EKF1003V
34 1 R252 RES., 60.4kΩ, 1%, 1/10W, 0603, AEC-Q200 PANASONIC/ERJ3EKF6042V
35 1 R253 RES., 619kΩ, 1%, 1/10W, 0603, AEC-Q200 NIC/NRC06F6193TRF
36 1 R255 RES., 200kΩ, 1%, 1/10W, 0603 NIC/NRC06F2003TRF
37 1 R256 RES., 84.5kΩ, 1%, 1/10W, 0603, AEC-Q200 NIC/NRC06F8452TRF
38 1 U1 IC, 8-Phase,Dual Output Synch. Buck Cvrtr,
QFN-52 (UHG)
LINEAR TECH/LTC3888IUHG#PBF
39 8 U2, U3, U4, U5, U6, U7, U8, U9 IC, Powerstage Gate Driver, DrMOS, PQFN 5mm ×
6mm, 70A
INFINEON/TDA21470AUMA1
40 1 U22 IC, 1A SYNC. STEP-DOWN CONVERTER, DFN-14 LINEAR TECH/LTC3646EDE-1#PBF
Additional Demo Board Circuit Components
1 0 C13, C24, C31, C38, C45, C52, C60,
C66
CAP., OPTION, 0402
2 0 C15, C26, C33, C40, C47, C54, C61,
C68,C115, C119, C121, C122
CAP., OPTION, 0603
3 0 COUT38, COUT45, COUT46,
COUT50, COUT51, COUT52,
COUT53, COUT54, COUT57,
COUT58, COUT59, COUT62
CAP., OPTION, 7343
4 4 COUT39, COUT60, COUT61,
COUT63
CAP., 470µF, TANT, POSCAP, 2.5V, 20%, 7343,
TPF Series
PANASONIC/ETPF470M5H
5 10 COUT40, COUT41, COUT42,
COUT44, COUT47, COUT48,
COUT55, COUT56, C84, C85
CAP., 100µF, X5R, 6.3V, 20%, 1210 AVX/12106D107MAT2A
6 2 COUT43, COUT49 CAP., 1µF, X7R, 16V, 20%, 0603 AVX/0603YC105MAT2A
7 4 C102, C103, C105, C106 CAP., 10µF, X5R, 10V, 10%, 0603 AVX/0603ZD106KAT2A
8 2 C104, C107 CAP., 0.01µF, C0G, 25V, 5%, 0603 AVX/06033A103JAT2
9 1 C86 CAP., 0.1µF, X7R, 50V, 10%, 0603 AVX/06035C104KAT2A
10 2 C87, C89 CAP., 1µF, X7R, 16V, 20%, 0603 AVX/0603YC105MAT2
11 1 C88 CAP., 150pF, C0G, 25V, 10%, 0603 AVX/06033A151KAT2
12 1 C90 CAP., 0.1µF, X7R, 50V, 10%, 0603 AVX/06035C104KAT2A
13 2 C91, C92 CAP., 0.01µF, C0G, 25V, 5%, 0603 AVX/06033A103JAT2A
14 6 C99, C100, C101, C117, C118, C120 CAP., 0.1µF, X7R, 50V, 10%, 0603 AVX/06035C104KAT2A
15 0 D2, D3 DIODE, OPTION, SOD-323

11
DEMO MANUAL DC2652A-A
Rev. 0
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
16 2 D4, D5 LED, GREEN, WATER CLEAR, 0603 Wurth/150060GS75000
17 3 D6, D7, D8 LED, SUPER RED, WATERCLEAR, 0603 Wurth/150060SS75000
18 1 D9 LED, SUPER RED, WATERCLEAR, 0603 Wurth/150060SS75000
19 6 D10, D11, D12, D13, D14, D15 DIODE, SCHOTTKY, 20V, 0.5A, SOD-882,
LEADLESS
NEXPERIA/PMEG2005AEL,315
20 2 Q1, Q2 XSTR., MOSFET, N-CH, 40V, 14A, DPAK (TO-252) VISHAY/SUD50N04-8M8P-4GE3
21 4 Q3, Q4, Q5, Q6 XSTR., MOSFET, P-CH, 30V, 3.5A, SOT23-3,
AEC-Q101
DIODES INC./DMP3130L-7
22 2 Q7, Q8 XSTR., MOSFET, N-CH, 60V, 210mA, SOT-23 DIODES INC./2N7002-13-F
23 1 Q9 XSTR., MOSFET, P-CH, 30V, 3.5A, SOT23-3,
AEC-Q101
DIODES INC./DMP3130L-7
24 64 R1, R2, R5, R6, R8, R12, R21, R22,
R25, R27, R29, R32, R34, R36, R43,
R50, R55, R57, R58, R59, R61, R64,
R66, R67, R69, R71, R72, R74, R75,
R78, R80, R81, R83, R85, R86, R88,
R90, R93, R95, R96, R99, R101,
R102, R104, R105, R107, R110,
R111, R113, R115, R116, R117,
R119, R122, R124, R125, R127,
R129, R130, R131, R133, R135,
R138, R140
RES., 0Ω, 1/16W, 0402 NIC/NRC04ZOTRF
25 0 R4, R7, R11, R26, R33, R35, R56,
R60, R62, R70, R73, R77, R84,
R87, R92, R100, R103, R106, R114,
R118, R120, R128, R132, R134
RES., OPTION, 0402
26 14 R28, R30, R166, R198, R200, R202,
R203, R257, R276, R279, R281,
R283, R286, R288
RES., 0Ω, 1/10W, 0603, AEC-Q200 NIC/NRC06ZOTRF
27 0 R37, R38, R39, R40, R42, R44,
R47, R52, R179, R180, R181, R182,
R187, R188, R191, R196, R197,
R199, R201, R204, R210, R211,
R212, R213, R268, R269, R274,
R275, R277, R278, R280, R282,
R284, R285, R287, R289, R290,
R291, R292
RES., OPTION, 0603
28 0 R162, R163, R183, R184, R189,
R190, R192, R193, R194, R195
RES., OPTION, 2010
29 1 R164 RES., 2Ω, 1%, 1/10W, 0603, AEC-Q200 VISHAY/CRCW06032R00FKEA
30 1 R165 RES., 3.3Ω, 1%, 1/10W, 0603, AEC-Q200 VISHAY/CRCW06033R30FKEA
31 1 R167 RES., 154kΩ, 1%, 1/10W, 0603,AEC-Q200 NIC/NRC06F1543TR
32 1 R168 RES., 1MΩ, 1%, 1/10W, 0603, AEC-Q200 NIC/NRC06F1004TRF
33 2 R169, R170 RES., 20kΩ, 1%, 1/10W, 0603 NIC/NRC06F2002TRF
34 1 R171 RES., 681kΩ, 1%, 1/10W, 0603, AEC-Q200 NIC/NRC06F6813TRF
35 2 R172, R218 RES., 10kΩ, 1%, 1/10W, 0603, AEC-Q200 KOA SPEER/RK73H1JTTD1002F
36 1 R173 RES., 301Ω, 1%, 1/10W, 0603, AEC-Q200 NIC/NRC06F3010TRF
PARTS LIST

12
DEMO MANUAL DC2652A-A
Rev. 0
PARTS LIST
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
37 1 R174 RES., 82.5Ω, 1%, 1/10W, 0603, AEC-Q200 NIC/NRC06F82R5TRF
38 1 R175 RES., 5kΩ, 10%, 1/2W, THT 3/8" SQ, 1-TURN,
TOP ADJ., TRIMPOT
BOURNS/3386P-1-502LF
39 0 R176 RES., OPTION, 2512
40 1 R177 RES., 0.01Ω, 1%, 1W, 2512, PWR, METAL,
SENSE, AEC-Q200
VISHAY/WSL2512R0100FEA
41 1 R178 RES., 1.21kΩ, 1%, 1/10W, 0603 PANASONIC/ERJ3EKF1211V
42 2 R185, R186 RES., 27.4Ω, 1%, 1W, 2512, AEC-Q200 PANASONIC/ERJ1TNF27R4U
43 2 R205, R206 RES., 10Ω, 1%, 1/10W, 0603 NIC/NRC06F10R0TRF
44 2 R207, R208 RES., 4.99kΩ, 1%, 1/10W, 0603, AEC-Q200 NIC/NRC06F4991TRF
45 0 R209 RES., OPTION, 1206
46 5 R214, R215, R216, R217, R219 RES., 2kΩ, 1%, 1/10W, 0603, AEC-Q200 KOA SPEER/RK73H1JTTD2001F
47 1 R220 RES.,15.8kΩ, 1%, 1/10W, 0603, AEC-Q200 NIC/NRC06F1582TRF
48 1 R233 RES., 2kΩ, 1%, 1/10W, 0603, AEC-Q200 KOA SPEER/RK73H1JTTD2001F
49 1 R258 RES., 0Ω, 1/8W, 0805 VISHAY/CRCW08050000Z0EA
50 2 R242, R246 RES., 332kΩ, 1%, 1/10W, 0603, AEC-Q200 NIC/NRC06F3323TRF
51 2 R243, R245 RES., 3.32kΩ, 1%, 1/10W, 0603, AEC-Q200 PANASONIC/ERJ3EKF3321V
52 2 R262, R263 RES., 1Ω, 1%, 1/8W, 0805, AEC-Q200 VISHAY/CRCW08051R00FKEA
53 7 R259, R260, R261, R264, R267,
R272, R273
RES., 1Ω, 5%, 1/10W, 0603, AEC-Q200 VISHAY/CRCW06031R00JNEA
54 3 R265, R266, R270 RES., 10kΩ, 1%, 1/10W, 0603, AEC-Q200 KOA SPEER/RK73H1JTTD1002F
55 1 U13 OSC., 3.81Hz to 1MHz, 5pF, 90ppm, TSOT23-6 ANALOG DEVICES/LTC6992IS6-1#PBF
56 1 U14 IC, Single R to R In/Out Op Amp, TSOT23-5,
100V/µs, 85MHz
ANALOG DEVICES/LT1803IS5#PBF
57 1 U15 IC,EEPROM, I2C, TSSOP-8, 2Kb (256 × 8), 400kHz MICROCHIP/24LC024-I/ST
58 1 U18 IC, TRANSLATING TRANSCEIVER, XQFN-12 NXP/NTB0104GU12,115
59 1 U19 IC, SWITCH QUAD SPST, TSSOP-16 ANALOG DEVICES/ADG711BRUZ
60 2 U20, U21 IC, 1.1A ADJ. SINGLE RESISTOR LDO, MSOP-8 LINEAR TECH/LT3080EMS8E-1#PBF
61 1 U23 IC, 4-BIT DUAL-SUPPLY BUS XCVR, TSSOP-16 TEXAS INSTRUMENTS/SN74AVC4T774PW
62 1 U24 IC, DUAL BUFFER GATE, SOT23-6 TEXAS INSTRUMENTS/SN74LVC2G34DBV
63 1 U25 IC, I2C BUS TO SPI BRIDGE, TSSOP-16 NXP/SC18IS602BIPW, 112

13
DEMO MANUAL DC2652A-A
Rev. 0
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
Hardware: For Demo Board Only
1 4 XJP1, XJP2, XJP3, XJP4 CONN., SHUNT, FEMALE, 2 POS, 2mm Wurth/60800213421
2 8 MP1, MP2, MP3, MP4, MP5, MP6,
MP7, MP8
STANDOFF, NYLON, SNAP-ON, 0.50" Wurth/702935000
3 25 E1, E2, E3, E4, E5, E6, E7, E8, E9,
E10, E11, E12, E13, E14, E15, E16,
E17, E18, E19, E20, E21, E22, E23,
E24, E25
TEST POINT, TURRET, 0.094" MTG. HOLE,
PCB 0.062" THK
MILL-MAX/2501-2-00-80-00-00-07-0
4 6 J1, J2, J3, J4, J5, J6 STUD, FASTENER, #10-32 PennEngineering/KFH-032-10ET
5 12 J1, J2, J3, J4, J5, J6 NUT, HEX, #10-32, STEEL, ZINC PLATE KEYSTONE/4705
6 6 J1, J2, J3, J4, J5, J6 RING, LUG, #10, CRIMP, 16/14 AWG, NON-
INSULATED, SOLDERLESS TERMINALS
KEYSTONE/8205
7 6 J1, J2, J3, J4, J5, J6 WASHER, FLAT, STEEL, ZINC PLATE, OD: 0.436
[11.1]
KEYSTONE/4703
8 4 JP1, JP2, JP3, JP4 CONN., HDR, MALE, 1 × 3, 2mm, VERT, ST, THT Wurth/62000311121
9 3 J8, J9, J10 CONN., RF, BNC, RCPT, JACK, 5-PIN, ST, THT, 50Ω AMPHENOL RF/112404
10 1 J12 CONN., HDR, SHROUDED, MALE, 2 × 6, 2mm,
VERT, ST, THT
AMPHENOL/98414-G06-12ULF
11 1 J13 CONN., HDR, FEMALE, 2 × 7, 2mm, R/A THT SOLUTIONS/NPPN072FJFN-RC
12 1 J14 CONN., HDR, MALE, 2 × 7, 2mm, R/A THT MOLEX/0877601416
13 1 J22 CONN., HDR, SHROUDED, MALE, 2 × 7, 2mm,
VERT, ST, THT
MOLEX/87831-1420
14 2 SW1, SW2 SWITCH, SLIDE, DPDT, 0. 3A, 6VDC, PTH C&K/JS202011CQN
PARTS LIST

14
DEMO MANUAL DC2652A-A
Rev. 0
SCHEMATIC DIAGRAM
5
5
4
4
3
3
2
2
1
1
D D C C B B A A
7V - 14V
1V/120A
FP1007R3-R22-R
FP1007R3-R22-R
CONVERTER WITH POWER SYSTEM MANAGEMENT
LTC3888IUHG-1
- A
VERSION
- B
LTC3888IUHG
31.6K
R274,R275,R280,R282,R287,R289R276,R279,R281,R283,R286,R288
OPT
OPT
U1
21K
*
0
0
R277,R284
OPT
R278,R285
OPT
VDR_MON
VDR
VOUT0
INTVCC VDD25 VDD33
VIN
VIN
VDD33
VDR
VDD33
VDD33
VDD33
VIN
VDD33
VDD33
VOUT0
VOUT0
VDR
IREF
ITH1
SCL SDA
PWM1 ISENSE1 PWM5 ISENSE5 PWM6 ISENSE6 PWM7 ISENSE7 PWM2 ISENSE2 PWM3 ISENSE3 PWM4 ISENSE4 VSENSE0+
PGOOD0/CLKOUT
VOUT0
SW0
RUN1 ITH0 ITHR0 ITHR1
VSENSE1+ VSENSE1-
VSENSE0-
PGOOD1
SHARE_CLK
SYNC
ALERTb
FAULT1b
RUN0
FAULT0b
TSNS1
SDI SCK
SERRb
SCSb
SW2
PGOOD0/CLKOUT
TSNS0
REVISION HISTORY
DESCRIPTION DATE APPROVEDECO REV
YL
PRODUCTION3 02-22-21
REVISION HISTORY
DESCRIPTION DATE APPROVEDECO REV
YL
PRODUCTION3 02-22-21
REVISION HISTORY
DESCRIPTION DATE APPROVEDECO REV
YL
PRODUCTION3 02-22-21
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
2555 AUGUSTINE DRIVE
www.analog.com
ANALOG
DEVICES
AHEAD OF WHAT'S POSSIBLE TM
SANTA CLARA, CA 95054
18
LT YL
LTC3888UHG
8-PHASE, DUAL OUTPUT SYNCHRONOUS BUCK
DC2652A 710-DC2652A(A,B)_REV03
N/A
Monday, April 11, 2022
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
2555 AUGUSTINE DRIVE
www.analog.com
ANALOG
DEVICES
AHEAD OF WHAT'S POSSIBLE TM
SANTA CLARA, CA 95054
18
LT YL
LTC3888UHG
8-PHASE, DUAL OUTPUT SYNCHRONOUS BUCK
DC2652A 710-DC2652A(A,B)_REV03
N/A
Monday, April 11, 2022
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
2555 AUGUSTINE DRIVE
www.analog.com
ANALOG
DEVICES
AHEAD OF WHAT'S POSSIBLE TM
SANTA CLARA, CA 95054
18
LT YL
LTC3888UHG
8-PHASE, DUAL OUTPUT SYNCHRONOUS BUCK
DC2652A 710-DC2652A(A,B)_REV03
N/A
Monday, April 11, 2022
R15 10K
R1 0
+
COUT9 470uF 2.5V 7343
C21 330pF
P1
R51 10K
P2
C9
1.0uF
L1 0.215uH
CIN3 22uF 1210
R8 0
C28 330pF
C7 0.47uF
C19 3300pF
COUT2 100uF 1210 6.3V
C20 0.47uF
R291 OPT
R40 OPT
R29 0
+
C4
270uF
16V
R7 OPT
CIN7 22uF 1210
+
COUT8 470uF 2.5V 7343
R18
1k
C13 OPT
C23 4.7uF
R276 0
J2
GND
R42 OPT
CIN8 22uF 1210
R41 18.7K
E24
SERRb
R2
0
R279 0
R235 10
CIN2 22uF 1210
CIN6 22uF 1210
C26 OPT
R50 0
R292 OPT
L2 0.215uH
C16 0.47uF
R16 4.99K
R49 10K
R47 OPT
R6 0
R3
1
1%
COUT64 100uF 1210 6.3V
R244 10K
R285 OPT
E1
VIN+
+
C3
270uF
16V
C12
4.7uF
R17 10K
R44 OPT
+
C6
270uF
16V
E4
VOUT0-
E23
SCK
R11 OPT
R269 OPT
R4 OPT
R275 OPT
R37 OPT
R36 0
C10
2.2uF
+
C1
270uF
16V CIN1
22uF 1210
R32
0
R278 OPT
C17 330pF
R21
0
R48 10K
J3
VOUT0
R52 OPT
E25
SDI
R34 0
R12 0
COUT7 100uF 1210 6.3V
C18 3300pF
U3
TDA21470
VCC
3
LGND
2
VOS
1
PGND 5
GL
6
VDRV
4
SW 19
VIN 28
VIN 29
SW 10 SW 12 SW 13 SW 14 SW 15 SW 16 SW 11
PGND 24
VIN 25
VIN 26
VIN 27
VIN 30
NC
31 PHASE 32
SW 17 SW 18
BOOST 33
PWM
34
EN
35
TOUT/FLT
36
OCSET
37
IOUT
38
REFIN
39
PGND 40
GL
41
PGND 23 PGND 22 PGND 21 PGND 20
PGND
9
PGND
8
PGND
7
R10 1k
R27
0
R33
OPT
COUT1 100uF 1210 6.3V
R290 OPT
E2
VIN-
R35 OPT
R274 OPT
C24 OPT
R26 OPT
R280 OPT
R268
OPT
+
C5
270uF
16V CIN4
22uF 1210
U2
TDA21470
VCC
3
LGND
2
VOS
1
PGND 5
GL
6
VDRV
4
SW 19
VIN 28
VIN 29
SW 10 SW 12 SW 13 SW 14 SW 15 SW 16 SW 11
PGND 24
VIN 25
VIN 26
VIN 27
VIN 30
NC
31 PHASE 32
SW 17 SW 18
BOOST 33
PWM
34
EN
35
TOUT/FLT
36
OCSET
37
IOUT
38
REFIN
39
PGND 40
GL
41
PGND 23 PGND 22 PGND 21 PGND 20
PGND
9
PGND
8
PGND
7
+
C2
270uF
16V
R9 1k
R28 0
R283 0
R288 0
R30 0
R277 OPT
C27 0.47uF
C14 4.7uF
R281 0
+
COUT3 470uF 2.5V 7343
E7
SCSb
C22 330pF
C11
2.2uF 0805
J1
VIN
R38 OPT
R22 0
CIN5 22uF 1210
C25 4.7uF
R287 OPT
R53 2K
R43 0
U1 *
PWM1 42 PWM4 50
ISENSE4 51
IREF 33
ISENSE0 4
ITH_R0
10
SYNC
14
SCL
15
SDA
16
ALERTb
17
SHARE_CLK
29
RUN0
20
RUN1
21
ITH_R1
37
ITH1
38
TSNS0/VDR_MON
8
TSNS1
39
ASEL0
23
ASEL1
24
VDD33 30
ITH0
9
VDD25 28
FAULT0b 18 FAULT1b 19
PWM5 49
ISENSE1 43
VOUT1_CFG
26
VSENSE1- 41
VSENSE1+ 40
ISENSE5 48
VSENSE0+ 7
PWM3 1
ISENSE2 3
PWM2 2
VOUT0_CFG
25
VSENSE0- 6
53
GND
RSET
22
PWM_CFG
27
PGOOD1
36
PGOOD0/CLKOUT
11
PWM0 5
INTVCC 31
VIN 32
SDI
12
SCK
13
SERRb
34
SCSb
35
ISENSE3 52
PWM6 46
ISENSE6 47
PWM7 45
ISENSE7 44
R39 OPT
E3
VOUT0+
C8
4.7uF
R289
OPT
+
COUT4 470uF 2.5V 7343
R284 OPT
E22
INTVCC
C121 OPT
R25 0
R54 10K
R282 OPT
R5
0
R286
0
R46 10k
C122 OPT
J4
GND
R23 10k
R234 10
C15 OPT
COUT6 100uF 1210 6.3V
SW2
ASEL0 ASEL1
PWM2
VOUT0_CFG VOUT1_CFG
SCL SDA ALERTb
SHARE_CLK
ISENSE2
SYNC
IREF
RUN0
VSENSE0+
VSENSE0-
RUN0
TSNS0
TSNS0
SW0
IREF
TSNS0/VDR_MON
TSNS0/VDR_MON

15
DEMO MANUAL DC2652A-A
Rev. 0
5
5
4
4
3
3
2
2
1
1
D D C C B B A A
FP1007R3-R22-R
FP1007R3-R22-R
CONVERTER WITH POWER SYSTEM MANAGEMENT
VIN
VIN
VDR
VDR
VOUT0
VOUT0
RUN0
VOUT0
SW3
PWM3
IREF
ISENSE3
PWM4
ISENSE4
IREF
SW4
RUN0
TSNS0
TSNS0
SW4
SW3
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
2555 AUGUSTINE DRIVE
www.analog.com
ANALOG
DEVICES
AHEAD OF WHAT'S POSSIBLE TM
SANTA CLARA, CA 95054
28
LT YL
LTC3888UHG
8-PHASE, DUAL OUTPUT SYNCHRONOUS BUCK
DC2652A 710-DC2652A(A,B)_REV03
N/A
Monday, April 11, 2022
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
2555 AUGUSTINE DRIVE
www.analog.com
ANALOG
DEVICES
AHEAD OF WHAT'S POSSIBLE TM
SANTA CLARA, CA 95054
28
LT YL
LTC3888UHG
8-PHASE, DUAL OUTPUT SYNCHRONOUS BUCK
DC2652A 710-DC2652A(A,B)_REV03
N/A
Monday, April 11, 2022
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
2555 AUGUSTINE DRIVE
www.analog.com
ANALOG
DEVICES
AHEAD OF WHAT'S POSSIBLE TM
SANTA CLARA, CA 95054
28
LT YL
LTC3888UHG
8-PHASE, DUAL OUTPUT SYNCHRONOUS BUCK
DC2652A 710-DC2652A(A,B)_REV03
N/A
Monday, April 11, 2022
R72 0
CIN9 22uF 1210
R56 OPT
C31 OPT
R78 0
CIN16 22uF 1210
R60 OPT
R62 OPT
R66 0
C32 4.7uF
C29 0.47uF
R61 0
+
COUT17
470uF 2.5V 7343
C30 4.7uF
+
COUT16
470uF 2.5V 7343
U5
TDA21470
VCC
3
LGND
2
VOS
1
PGND 5
GL
6
VDRV
4
SW 19
VIN 28
VIN 29
SW 10 SW 12 SW 13 SW 14 SW 15 SW 16 SW 11
PGND 24
VIN 25
VIN 26
VIN 27
VIN 30
NC
31 PHASE 32
SW 17 SW 18
BOOST 33
PWM
34
EN
35
TOUT/FLT
36
OCSET
37
IOUT
38
REFIN
39
PGND 40
GL
41
PGND 23 PGND 22 PGND 21 PGND 20
PGND
9
PGND
8
PGND
7
C34 0.47uF
CIN13 22uF 1210
COUT14 100uF 1210 6.3V
R68 10k
+
COUT12
470uF 2.5V 7343
R80
0
L4 0.215uH
R70 OPT
COUT15 100uF 1210 6.3V
R59
0
CIN10 22uF 1210
L3 0.215uH
C36 0.47uF
R55 0
U4
TDA21470
VCC
3
LGND
2
VOS
1
PGND 5
GL
6
VDRV
4
SW 19
VIN 28
VIN 29
SW 10 SW 12 SW 13 SW 14 SW 15 SW 16 SW 11
PGND 24
VIN 25
VIN 26
VIN 27
VIN 30
NC
31 PHASE 32
SW 17 SW 18
BOOST 33
PWM
34
EN
35
TOUT/FLT
36
OCSET
37
IOUT
38
REFIN
39
PGND 40
GL
41
PGND 23 PGND 22 PGND 21 PGND 20
PGND
9
PGND
8
PGND
7
R82 10k
CIN11 22uF 1210
P3
C35 330pF
R73
OPT
CIN15 22uF 1210
R57
0
C39 4.7uF
C38 OPT
R77 OPT
R64 0
CIN12 22uF 1210
C40 OPT
R58 0 R75 0
CIN14 22uF 1210
R81 0
R67
0
+
COUT13
470uF 2.5V 7343
C37 4.7uF
C33 OPT
COUT10 100uF 1210 6.3V
P4
R69 0
R74
0
COUT11 100uF 1210 6.3V
C42 330pF
R71
0
C41 0.47uF
SCHEMATIC DIAGRAM

16
DEMO MANUAL DC2652A-A
Rev. 0
5
5
4
4
3
3
2
2
1
1
D D C C B B A A
FP1007R3-R22-R
FP1007R3-R22-R
1V/120A
CONVERTER WITH POWER SYSTEM MANAGEMENT
VIN
VIN
VDR
VDR
VL6
VOUT1
VOUT1
RUN1
VOUT1
SW1
PWM1
IREF
ISENSE1
PWM5
ISENSE5
IREF
SW5
RUN1
VSENSE1-
VSENSE1+
TSNS1
TSNS1
SW1
SW5
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
2555 AUGUSTINE DRIVE
www.analog.com
ANALOG
DEVICES
AHEAD OF WHAT'S POSSIBLE TM
SANTA CLARA, CA 95054
38
LT YL
LTC3888UHG
8-PHASE, DUAL OUTPUT SYNCHRONOUS BUCK
DC2652A 710-DC2652A(A,B)_REV03
N/A
Monday, April 11, 2022
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
2555 AUGUSTINE DRIVE
www.analog.com
ANALOG
DEVICES
AHEAD OF WHAT'S POSSIBLE TM
SANTA CLARA, CA 95054
38
LT YL
LTC3888UHG
8-PHASE, DUAL OUTPUT SYNCHRONOUS BUCK
DC2652A 710-DC2652A(A,B)_REV03
N/A
Monday, April 11, 2022
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
2555 AUGUSTINE DRIVE
www.analog.com
ANALOG
DEVICES
AHEAD OF WHAT'S POSSIBLE TM
SANTA CLARA, CA 95054
38
LT YL
LTC3888UHG
8-PHASE, DUAL OUTPUT SYNCHRONOUS BUCK
DC2652A 710-DC2652A(A,B)_REV03
N/A
Monday, April 11, 2022
COUT19 100uF 1210 6.3V
R106 OPT
R104
0
CIN19 22uF 1210
R105 0
J5
VOUT1
R92 OPT
C55
0.47uF
U6
TDA21470
VCC
3
LGND
2
VOS
1
PGND 5
GL
6
VDRV
4
SW 19
VIN 28
VIN 29
SW 10 SW 12 SW 13 SW 14 SW 15 SW 16 SW 11
PGND 24
VIN 25
VIN 26
VIN 27
VIN 30
NC
31 PHASE 32
SW 17 SW 18
BOOST 33
PWM
34
EN
35
TOUT/FLT
36
OCSET
37
IOUT
38
REFIN
39
PGND 40
GL
41
PGND 23 PGND 22 PGND 21 PGND 20
PGND
9
PGND
8
PGND
7
C54 OPT
R112 10k
R86 0
CIN24 22uF 1210
E5
VOUT1+
+
COUT25
470uF 2.5V 7343
C50 0.47uF
C47 OPT
R110 0
+
COUT24
470uF 2.5V 7343
R84 OPT
CIN17 22uF 1210
R93 0
COUT22 100uF 1210 6.3V
R89 10
P5
COUT23 100uF 1210 6.3V
R85
0
L6 0.215uH
C51 4.7uF
R107 0
R96 0
U7
TDA21470
VCC
3
LGND
2
VOS
1
PGND 5
GL
6
VDRV
4
SW 19
VIN 28
VIN 29
SW 10 SW 12 SW 13 SW 14 SW 15 SW 16 SW 11
PGND 24
VIN 25
VIN 26
VIN 27
VIN 30
NC
31 PHASE 32
SW 17 SW 18
BOOST 33
PWM
34
EN
35
TOUT/FLT
36
OCSET
37
IOUT
38
REFIN
39
PGND 40
GL
41
PGND 23 PGND 22 PGND 21 PGND 20
PGND
9
PGND
8
PGND
7
R99 0
CIN21 22uF 1210
J6
GND
C44 4.7uF
L5 0.215uH
CIN18 22uF 1210
COUT65 100uF 1210 6.3V
R83 0
CIN20 22uF 1210
C56 330pF
R111
0
COUT18 100uF 1210 6.3V
C45 OPT
R97 10k
R100 OPT
C49
330pF
R98 10
R102 0
CIN23 22uF 1210
R90 0
P6
+
COUT20
470uF 2.5V 7343
R101
0
C53 4.7uF
E6
VOUT1-
R88
0
CIN22 22uF 1210
C46 4.7uF
C48
0.47uF
R103
OPT
R87 OPT
R95
0
C52 OPT
C43 0.47uF
+
COUT21
470uF 2.5V 7343
SCHEMATIC DIAGRAM

17
DEMO MANUAL DC2652A-A
Rev. 0
5
5
4
4
3
3
2
2
1
1
D D C C B B A A
FP1007R3-R22-R
FP1007R3-R22-R
CONVERTER WITH POWER SYSTEM MANAGEMENT
VIN VIN
VDR
VDR
VOUT1
VOUT1
RUN1
VOUT1
SW6
PWM6
IREF
ISENSE6
PWM7
ISENSE7
IREF
SW7
RUN1
TSNS1
TSNS1
SW6
SW7
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
2555 AUGUSTINE DRIVE
www.analog.com
ANALOG
DEVICES
AHEAD OF WHAT'S POSSIBLE TM
SANTA CLARA, CA 95054
48
LT YL
LTC3888UHG
8-PHASE, DUAL OUTPUT SYNCHRONOUS BUCK
DC2652A 710-DC2652A(A,B)_REV03
N/A
Monday, April 11, 2022
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
2555 AUGUSTINE DRIVE
www.analog.com
ANALOG
DEVICES
AHEAD OF WHAT'S POSSIBLE TM
SANTA CLARA, CA 95054
48
LT YL
LTC3888UHG
8-PHASE, DUAL OUTPUT SYNCHRONOUS BUCK
DC2652A 710-DC2652A(A,B)_REV03
N/A
Monday, April 11, 2022
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
2555 AUGUSTINE DRIVE
www.analog.com
ANALOG
DEVICES
AHEAD OF WHAT'S POSSIBLE TM
SANTA CLARA, CA 95054
48
LT YL
LTC3888UHG
8-PHASE, DUAL OUTPUT SYNCHRONOUS BUCK
DC2652A 710-DC2652A(A,B)_REV03
N/A
Monday, April 11, 2022
COUT27 100uF 1210 6.3V
R134 OPT
R131 0
R133 0
CIN27 22uF 1210
C69
0.47uF
R120 OPT
R139 10k
R116 0
CIN32 22uF 1210
C68 OPT
R129
0
U9
TDA21470
VCC
3
LGND
2
VOS
1
PGND 5
GL
6
VDRV
4
SW 19
VIN 28
VIN 29
SW 10 SW 12 SW 13 SW 14 SW 15 SW 16 SW 11
PGND 24
VIN 25
VIN 26
VIN 27
VIN 30
NC
31 PHASE 32
SW 17 SW 18
BOOST 33
PWM
34
EN
35
TOUT/FLT
36
OCSET
37
IOUT
38
REFIN
39
PGND 40
GL
41
PGND 23 PGND 22 PGND 21 PGND 20
PGND
9
PGND
8
PGND
7
+
COUT33
470uF 2.5V 7343
C61 OPT
P7
R114 OPT
CIN25 22uF 1210
R122 0
COUT30 100uF 1210 6.3V
R138 0
+
COUT32
470uF 2.5V 7343
COUT31 100uF 1210 6.3V
P8
L8 0.215uH
C65 4.7uF
R135 0
R124 0
R127 0
CIN29 22uF 1210
R115
0
U8
TDA21470
VCC
3
LGND
2
VOS
1
PGND 5
GL
6
VDRV
4
SW 19
VIN 28
VIN 29
SW 10 SW 12 SW 13 SW 14 SW 15 SW 16 SW 11
PGND 24
VIN 25
VIN 26
VIN 27
VIN 30
NC
31 PHASE 32
SW 17 SW 18
BOOST 33
PWM
34
EN
35
TOUT/FLT
36
OCSET
37
IOUT
38
REFIN
39
PGND 40
GL
41
PGND 23 PGND 22 PGND 21 PGND 20
PGND
9
PGND
8
PGND
7
C58 4.7uF
L7 0.215uH
CIN26 22uF 1210
CIN28 22uF 1210
C70 330pF
C64 0.47uF
R113 0
R128 OPT
R140
0
COUT26 100uF 1210 6.3V
C60 OPT
R126 10k
R130 0
CIN31 22uF 1210
C63 330pF
C67 4.7uF
R119 0
+
COUT28
470uF 2.5V 7343
CIN30 22uF 1210
C59 4.7uF
C62
0.47uF
R132
OPT
R117
0
R118 OPT
R125
0
C66 OPT
C57 0.47uF
+
COUT29
470uF 2.5V 7343
SCHEMATIC DIAGRAM

18
DEMO MANUAL DC2652A-A
Rev. 0
5
5
4
4
3
3
2
2
1
1
D D C C B B A A
VOUT0
VOUT1
PULSE
DYNAMIC LOAD TEST CIRCUIT, FOR DEMO BOARD ONLY
70Hz, 3% Duty Cycle
INT
1%
EXT
1%
IOUT STEP
BLEEDER LOADS
SHT 1 SHT 1,2
OPTION FOR EIGHT-PHASE CONFIGURATION CONNECTION
XAL5030-472MEB
COILCRAFT
5V BIAS
CONVERTER WITH POWER SYSTEM MANAGEMENT
VDR
VOUT1
VOUT0
VOUT0
VOUT1
VOUT0 VOUT1 VOUT0 VOUT1
INTVCC1
INTVCC1
VDR
VIN
VOUT0 VOUT1
ITHR0 ITHR1
FAULT0b FAULT1b
VSENSE0- VSENSE1-
ITH0 ITH1
RUN0 RUN1
VSENSE0+ VSENSE1+
PGOOD0/CLKOUT PGOOD1
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
2555 AUGUSTINE DRIVE
www.analog.com
ANALOG
DEVICES
AHEAD OF WHAT'S POSSIBLE TM
SANTA CLARA, CA 95054
58
LT YL
LTC3888UHG
8-PHASE, DUAL OUTPUT SYNCHRONOUS BUCK
DC2652A 710-DC2652A(A,B)_REV03
N/A
Monday, April 11, 2022
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
2555 AUGUSTINE DRIVE
www.analog.com
ANALOG
DEVICES
AHEAD OF WHAT'S POSSIBLE TM
SANTA CLARA, CA 95054
58
LT YL
LTC3888UHG
8-PHASE, DUAL OUTPUT SYNCHRONOUS BUCK
DC2652A 710-DC2652A(A,B)_REV03
N/A
Monday, April 11, 2022
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
2555 AUGUSTINE DRIVE
www.analog.com
ANALOG
DEVICES
AHEAD OF WHAT'S POSSIBLE TM
SANTA CLARA, CA 95054
58
LT YL
LTC3888UHG
8-PHASE, DUAL OUTPUT SYNCHRONOUS BUCK
DC2652A 710-DC2652A(A,B)_REV03
N/A
Monday, April 11, 2022
D1
DFLS1200
R188 OPT
R184 OPT 2010
R252 60.4k 1%
R162 OPT
2010
C110 1uF 0805
+
COUT38 OPT
7343
2.5V
R174
82.5 1%
+
COUT61 470uF 7343 2.5V
C87 1.0uF
R171 681K
1%
COUT42 100uF 1210 6.3V
L9 4.7uH
C116
100pF
C115 OPT
R170 20K
R163 OPT
2010
+
COUT39 470uF 7343 2.5V
COUT55 100uF 1210 6.3V
4.7uF COUT66 1210
16V
COUT48 100uF 1210 6.3V
R187 OPT R181 OPT
R169 20K
COUT47 100uF 1210 6.3V
+
COUT46 OPT 7343 2.5V
R258
0
0805
R173
301
COUT40 100uF 1210 6.3V
R193 OPT 2010
R179 OPT
R190 OPT 2010
+
COUT57
OPT 2.5V 7343
+
COUT52
OPT
2.5V 7343
C113 1uF 0805
+
COUT62 OPT
2.5V 7343
C85 100uF 1210 6.3V
R183 OPT 2010
R164 2
R257
0
R251 100k
JP2
1
2
3
J10
1
2
J8
1
2
CIN34 10uF 16V 1210
R166 0
C86 0.1uF
+
COUT63 470uF 7343 2.5V
R192 OPT 2010
R256 84.5k
1%
R189 OPT 2010
R176 OPT 2512
+
COUT59
OPT 2.5V 7343
COUT56 100uF 1210 6.3V
C114
5.6pF
C111
4.7uF
C108
2.2uF 16V
0805
+
COUT45
OPT 7343
2.5V
C89
1.0uF
C88 150pF
R175
5K
+
COUT50
OPT 2.5V 7343
COUT41 100uF 1210 6.3V
R168 1M
+
COUT54
OPT
2.5V 7343
U14
LT1803IS5
VOUT 1
V-
2
+IN
3-IN 4
V+
5
R177 0.01
2512
R195 OPT 2010
+
COUT60 470uF 7343 2.5V
COUT49 1.0uF
Q2
SUD50N04-8M8P
R167 154k
10uF COUT67 1210 16V
R186 27.4 2512
R250
2
C112
0.1uF
R178
1.21k
R172
10K
R180 OPT
R185 27.4 2512
U13
LTC6992IS6-1
MOD
1
GND
2
SET
3DIV 4
V+ 5
OUT 6
R182 OPT
JP1
ON OFF
RUN
1 3 2
R165 3.3
1%
U22
LTC3646EDE-1
BOOST 10
VFB 2
VON 5
PGOOD
6
PGND
15
SW 9
SVIN 14
EXTVCC 12
ITH
3
PVIN 8
RT
4
INTVCC 11
MODE/SYNC
7
RUN
13
SGND
1
E10
GND
CIN33 10uF 16V 1210
+
COUT58
OPT 2.5V 7343
Q1
SUD50N04-8M8P
R253 619k
1%
+
COUT51
OPT
2.5V 7343
R194 OPT 2010
C84 100uF 1210 6.3V
J9
1
2
R191 OPT
COUT44 100uF 1210 6.3V
COUT43
1.0uF
E9
EXT PULSE
+
COUT53
OPT
2.5V 7343
R255
200k
1%
SW VDR
SCHEMATIC DIAGRAM

19
DEMO MANUAL DC2652A-A
Rev. 0
5
5
4
4
3
3
2
2
1
1
D D C C B B A A
PGOOD0 PGOOD1
ON OFF
ON
OFF
RUN0
RUN1TO DC1613A
ALL PARTS ON THIS PAGE ARE FOR DEMO BOARD ONLY, NOT NEEDED IN CUSTOMER DESIGN
1206
ALERTb
FAULT0 FAULT1
MASTER
SLAVE
MASTER
SLAVE
CONVERTER WITH POWER SYSTEM MANAGEMENT
3V33V3
VDD33
VIN
3V3
3V3_1
VIN
3V3
3V3
5V_1
3V3 3V3
PGOOD1
PGOOD0/CLKOUT
ALERTb SDA SCL
RUN0 RUN1
FAULT1b
FAULT0b
PGOOD0/CLKOUT
SHARE_CLK
ALERTb
FAULT0b FAULT1b
SYNC
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
2555 AUGUSTINE DRIVE
www.analog.com
ANALOG
DEVICES
AHEAD OF WHAT'S POSSIBLE TM
SANTA CLARA, CA 95054
68
LT YL
LTC3888UHG
8-PHASE, DUAL OUTPUT SYNCHRONOUS BUCK
DC2652A 710-DC2652A(A,B)_REV03
N/A
Monday, April 11, 2022
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
2555 AUGUSTINE DRIVE
www.analog.com
ANALOG
DEVICES
AHEAD OF WHAT'S POSSIBLE TM
SANTA CLARA, CA 95054
68
LT YL
LTC3888UHG
8-PHASE, DUAL OUTPUT SYNCHRONOUS BUCK
DC2652A 710-DC2652A(A,B)_REV03
N/A
Monday, April 11, 2022
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
2555 AUGUSTINE DRIVE
www.analog.com
ANALOG
DEVICES
AHEAD OF WHAT'S POSSIBLE TM
SANTA CLARA, CA 95054
68
LT YL
LTC3888UHG
8-PHASE, DUAL OUTPUT SYNCHRONOUS BUCK
DC2652A 710-DC2652A(A,B)_REV03
N/A
Monday, April 11, 2022
E20
RUN1
E17
FAULT0b
R208 4.99K
R200 0
D3 OPT
Q3
DMP3130L-7
23
1
E13
SDA R196 OPT
D7
RED
R209 OPT
E11
FAULT1b
J13DEMO HEADER (F)
FAULTB 1
CTRL 2
ALERTB 3
SDA 4
SHARE_CLK 5
SCL 6
RESETB 7
AUXP 8
UNUSED 9 UNUSED 10
GND 11 GND 12
12V 13 12V 14
R216 2K
E19
RUN0
D8
RED
R212 OPT
Q7
2N7002A
2 3
1
J14DEMO HEADER (M)
FAULTB
1
CTRL
2
ALERTB
3
SDA
4
SHARE_CLK
5
SCL
6
RESETB
7
AUXP
8
UNUSED
9
UNUSED
10
GND
11
GND
12
12V
13
12V
14
D4 GRN
R197 OPT
Q6
DMP3130L-7
23
1
R198 0
U15
24LC024-I/ST
A0
1
A1
2
A2
3
VSS
4SDA 5
SCL 6
WP 7
VCC 8
R213 OPT
E16
CLKOUT/SYNC
R219 2K
R207 4.99K
R217 2K
D6
RED
Q5
DMP3130L-7
23
1
R204 OPT
R202
0
R211 OPT
R220 15.8k
R199 OPT
Q4
DMP3130L-7
23
1
C90
0.1uF
E15
SHARE_CLK
C92 10nF
SW1
1
2
3
4
5
6
J12
AUXP 1
SDA 2
GND 3
SCL 4
LGKPWR 5
ALERTB 6
GPIO_1 7
OUTEN_0 8 OUTEN_1 9
GND 10
AUXSCL 11
AUXSDA 12
R206 10
Q8
2N7002A
2 3
1
D2 OPT
E14
SCL
JP3
1
2
3
JP4
1
2
3
E21
GND
R215 2K
R201 OPT
SW2
1
2
3
4
5
6
D5 GRN
R203 0
R205 10
E12
ALERTb
R218 10K
R214 2K
C91 10nF
R210 OPT
EEWP
EESDA
AUXVCC
EESCL
SCHEMATIC DIAGRAM

20
DEMO MANUAL DC2652A-A
Rev. 0
5
5
4
4
3
3
2
2
1
1
D D C C B B A A
SPI INTERFACE
SERRb
CONVERTER WITH POWER SYSTEM MANAGEMENT
5V_1 3V3_1 5V_2
VDR
5V 3V3
3V3_2
3V3_3
5V_2
VCCA
5V
5V 3V3
3V3
3V3
3V3
3V3
3V3
SCL
SDA
ALERTb
SDI
SCK
SERRb
SCSb
OE
SERRb
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
2555 AUGUSTINE DRIVE
www.analog.com
ANALOG
DEVICES
AHEAD OF WHAT'S POSSIBLE TM
SANTA CLARA, CA 95054
78
LT YL
LTC3888UHG
8-PHASE, DUAL OUTPUT SYNCHRONOUS BUCK
DC2652A 710-DC2652A(A,B)_REV03
N/A
Monday, April 11, 2022
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
2555 AUGUSTINE DRIVE
www.analog.com
ANALOG
DEVICES
AHEAD OF WHAT'S POSSIBLE TM
SANTA CLARA, CA 95054
78
LT YL
LTC3888UHG
8-PHASE, DUAL OUTPUT SYNCHRONOUS BUCK
DC2652A 710-DC2652A(A,B)_REV03
N/A
Monday, April 11, 2022
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY TO ANALOG DEVICES AND SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
2555 AUGUSTINE DRIVE
www.analog.com
ANALOG
DEVICES
AHEAD OF WHAT'S POSSIBLE TM
SANTA CLARA, CA 95054
78
LT YL
LTC3888UHG
8-PHASE, DUAL OUTPUT SYNCHRONOUS BUCK
DC2652A 710-DC2652A(A,B)_REV03
N/A
Monday, April 11, 2022
R266
10K
R233 2K
D12
0.5A
2 1
R259
1
U25
SC18IS602B
INT 9
SS2 10
SPICLK 11
SS3 13
VDD 12
A2
16
SS0 1 SS1 2
RESET
3
VSS
4
A1
15
MISO 5
A0
14
MOSI 6
SDA
7
SCL
8
U19
ADG711BRUZ
IN1 1
D1
2
S1
3
NC 4
GND 5
S4
6
D4
7
IN4 8 IN3 9
D3
10
S3
11
NC 12
VDD 13
S2
14
D2
15
IN2 16
C118 0.1uF
D11
0.5A
2 1
R261
1R264
1
R267
1
C117 0.1uF
D9 RED
D13
0.5A
2 1
C100 0.1uF
Q9
DMP3130L-7
23
1
C101
0.1uF
R260
1
C99
0.1uF
R270
10K
U23
SN74AVC4T774
OE 9
GND 10
B4 11 B2 13 B3 12
VCCA 16
DIR1
1
DIR2
2
A1
3
A2
4
VCCB 15
A3
5
B1 14
A4
6
DIR3
7
DIR4
8
E18
3.3V
D10
0.5A
2 1
R265
10K
C120 0.1uF
R273
1
C119 OPT
R272
1
U18
NTB0104GU12
B2
9A2 3
VCC(A) 1
A1 2
OE
12
A3 4 A4 5
VCC(B) 11
B1
10
GND
6
B4
7
B3
8
D14
0.5A
2 1
U24
SN74LVC2G34
2Y 4
VCC 5
1A
1
GND
2
2A
3
1Y 6
J22
MOLEX 87831-1420
V+ (ISOPWR) 1
VCCA(5/3.3V) 2
GND 3
SCK/SCL 4
MISO 5
nCS 6
MOSI/SDA 7
GND 8
EESDA 9
+5V(EEVCC) 10
EESCL 11
GND 12 GND 13
GPIO_1 14
E8
5V
D15
0.5A
2 1
SDA
SCL
SCHEMATIC DIAGRAM
