DEMO MANUAL DC2836A
Rev. 0
DESCRIPTION
LT7182S
Dual Channel 6A, 20V, PolyPhase
Step-Down Silent Switcher with Digital
Power System Management
Demonstration Circuit 2836A is a dual-output PolyPhase
®
DC/DC synchronous step-down regulator with 4V to 20V
input range featuring LT
®
7182S. Each output can sup-
ply 6A continuous/9A maximum transient load current.
LT7182S is a dual 6A monolithic step-down regulator.
The second-generation Silent Switcher
®
structure is
incorporated into LT7182S to minimize EMI and reduce
PCB layout sensitivity. It also integrates digital power sys-
tem management function allowing for programmability
and telemetry with a PMBus/I2C compliant serial inter-
face. Please see LT7182S data sheet for more detailed
information.
The demonstration circuit 2836A runs at 1MHz to mini-
mize solution size. The peak efficiency at 12V input is
83.2% for 1.2V rail and 91.1% for 3.3V rail. The IC tem-
perature rise is 70°C when both channels run at full load,
6A each, at 1MHz.
The demo board has EMI filters installed for both chan-
nels. The conducted and radiated EMI performances of
the board (with EMI filters) are shown in Figure2. The red
lines in Figure2 are CISPR25 CLASS 5 limit.
All registered trademarks and trademarks are the property of their respective owners.
PERFORMANCE SUMMARY
DC2836A powers up to default settings and produces
power based on configuration resistors without the need
for any serial bus communication. This allows easy evalu-
ation of the DC/DC converter. To fully explore the power
system management features of the part, download the
GUI software LTpowerPlay
®
onto your PC and use ADI’s
I2C/SMBus/PMBus dongle DC1613A to connect to the
board. LTpowerPlay allows the user to reconfigure the part
on the fly and store the configuration in EEPROM, view
telemetry of voltage, current, temperature and fault status.
GUI Download
The software can be downloaded from: LTpowerPlay
The LT7182S data sheet gives a complete description of
the part, operation and application information. The data
sheet must be read in conjunction with this demo manual
for DC2836A.
For more details and instructions of LTpowerPlay, please
refer to LTpowerPlay GUI for LT7182S Quick Start Guide.
Design files for this circuit board are available.
Specifications are at TA= 25°C
SYMBOL PARAMETER CONDITIONS MIN TYP MAX UNITS
VIN Input Voltage Range 4 20 V
VOUT0 Output0 Voltage 1.2 V
IOUT0 Maximum Output0 Current 9 A
VOUT1 Output1 Voltage 3.3 V
IOUT1 Maximum Output1 Current 9 A
fSW Switching Frequency 0.925 1 1.075 MHz
EFE Efficiency at DC VIN = 12V, IOUT0 = 3A, IOUT1 = 0A
VIN = 12V, IOUT1 = 3A, IOUT0 = 0A
83.2
91.1
%
%

2
DEMO MANUAL DC2836A
Rev. 0
QUICK START PROCEDURE
DC2836A is easy to set up to evaluate the performance of
the LT7182S. Refer to Figure3 for proper measurement
equipment setup and follow the procedure below:
NOTE:When measuring the input or output voltage ripple,
care must be taken to avoid a long ground lead on the
oscilloscope probe. See Figure5 for the proper scope
technique.
1. Set an input power supply that is capable of 20V/18A.
Then turn off the supply.
2. With power off, connect the supply to the input termi-
nals VEMI and GND. Set default jumper position:SW1:
ON; SW2: ON
3. Turn on the power at the input.
NOTE:Make sure that the input voltage never exceeds 20V.
4. Check for the proper output voltages of 1.2V ±0.5%
(1.194V ~ 1.206V) and 3.3V ±0.5% (3.283V ~ 3.317V).
Turn off the power at the input.
5. Once the proper output voltage is established, connect
variable loads capable of sinking 6A at 1.2V and 3.3V
to the output terminals VOUT0/VOUT1 and GND. Set
the current for 0A.
a. If efficiency measurements are desired, ammeters
can be put in series with the output loads to measure
the DC2836A’s output currents.
b. Voltmeters can be placed across the output termi-
nals to get accurate output voltage measurements.
6. Turn on the power at the input.
NOTE: If there is no output, temporarily disconnect the
load to make sure that the load is not set too high.
7. Once the proper output voltages are established again,
adjust the load and/or input within the operating range
and observe the output voltage regulation, ripple volt-
age, efficiency and other desired parameters.
8. Connect the dongle and control the output voltages
from the GUI. See LTpowerPlay GUI for the LT7182S
Quick Start Guide for details.
NOTE: When measuring the output or input voltage rip-
ple, do not use the long ground lead on the oscilloscope
probe. See Figure4 for the proper scope probe technique.
Short, stiff leads need to be soldered to the (+) and (–)
terminals of an output capacitor. The probe’s ground ring
needs to touch the (–) lead and the probe tip needs to
touch the (+) lead.
Figure1. Efficiency vs Load Current at 1MHz Switching Frequency
VOUT0 = 1.2 VOUT1 = 3.3
LOAD CURRENT (A)
0
1
2
3
4
5
6
0
10
20
30
40
50
60
70
80
90
100
0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1.8
2.0
EFFICIENCY (%)
LOSS (W)
dc2836a F01a
EFFICIENCY
LOSS
fSW = 1MHz
VIN = 8V
VIN = 12V
VIN = 18V
EFFICIENCY
LOSS
fSW = 1MHz
VIN = 8V
VIN = 12V
VIN = 18V
LOAD CURRENT (A)
0
1
2
3
4
5
6
0
10
20
30
40
50
60
70
80
90
100
0
0.3
0.6
0.9
1.2
1.5
1.8
2.1
2.4
2.7
3.0
EFFICIENCY (%)
LOSS (W)
dc2836a F01b

3
DEMO MANUAL DC2836A
Rev. 0
QUICK START PROCEDURE
Figure2. Demo Circuit 2836A EMI Performance in CISPR25 Conducted and Radiated Emission Test
(VIN = 14V, VOUT0 = 1.2V, IOUT0 = 6A, VOUT1 = 3.3V, IOUT1 = 6A, 1MHz Switching Frequency)
Conducted EMI Performance (CISPR25 Conducted
Emission Test with Class 5 Peak Limits)
Radiated EMI Performance (CISPR25 Radiated
Emission Test with Class 5 Peak Limits)
DC2836A DEMO BOARD
(WITH EMI FILTER INSTALLED)
14V INPUT TO 1.2V OUTPUT0 PLUS 3.3V OUTPUT1 AT 6A
f
SW
= 1MHz
CLASS 5 PEAK LIMIT
CONDUCTED PEAK MAX
FREQUENCY (kHz)
100
1k
10k
100k
–20
–10
0
10
20
30
40
50
60
70
80
AMPLITUDE (dBµV)
dc2836a F02a
DC2836A DEMO BOARD
(WITH EMI FILTER INSTALLED)
14V INPUT TO 1.2V OUTPUT0 PLUS 3.3V OUTPUT1 AT 6A
f
SW
= 1MHz
CLASS 5 PEAK LIMIT
RADIATED PEAK MAX
FREQUENCY (MHz)
0.1
1
10
100
1k
–20
–10
0
10
20
30
40
50
60
AMPLITUDE (dBµV/m)
dc2836a F02b

4
DEMO MANUAL DC2836A
Rev. 0
Figure3. Proper Measurement Equipment Setup
QUICK START PROCEDURE

5
DEMO MANUAL DC2836A
Rev. 0
QUICK START PROCEDURE
Figure4. Measuring Input or Output Ripple
Figure5. Demo Setup with PC
INPUT OR OUTPUT CAPACITOR
Connecting a PC to DC2836A
You can use a PC to reconfigure the power manage-
ment features of the LT7182S such as:nominal VOUT,
margin set points, OV/UV limits, temperature fault limits,
sequencing parameters, the fault log, fault responses,
GPIOs and other functionalities. The DC1613A dongle
may be plugged when VIN is present.
dc2836a F05
LT7182S
Demo Board
DC2836A
USB to
I2C/PMBus Dongle
DC1613A
Input
Power Supply
LOAD0
USB CABLE
12-PIN (J8)
CONNECTOR
VOUT0
LOAD1
VOUT1
VIN

6
DEMO MANUAL DC2836A
Rev. 0
LTpowerPlay SOFTWARE GUI
LTpowerPlay is a powerful Windows based development
environment that supports Linear Technology power sys-
tem management ICs and μModules. The software sup-
ports a variety of different tasks. You can use LTpowerPlay
to evaluate Linear Technology ICs by connecting to a
demo board system. LTpowerPlay can also be used in an
offline mode (with no hardware present) in order to build a
multichip configuration file that can be saved and reloaded
at a later time. LTpowerPlay provides unprecedented diag-
nostic and debug features. It becomes a valuable diagnos-
tic tool during board bring-up to program or tweak the
power management scheme in a system, or to diagnose
power issues when bringing up rails. LTpowerPlay utilizes
the DC1613A USB-to-SMBus controller to communicate
with one of many potential demo system, or a customer
board. The software also provides an automatic update
feature to keep the software current with the latest set
of device drivers and documentation. The LTpowerPlay
software can be downloaded from:
LTpowerPlay | Analog Devices
To access technical support documents for LTC Digital
Power Products visit the LTpowerPlay Help menu. Online
help also available through the LTpowerPlay.
Figure6. LTpowerPlay Main Interface

7
DEMO MANUAL DC2836A
Rev. 0
LTpowerPlay QUICK START PROCEDURE
The following procedure describes how to use LTpowerPlay
to monitor and change the settings of LT7182S.
1. Download and install the LTPowerPlay GUI:
LTpowerPlay | Analog Devices
2. Launch the LTpowerPlay GUI.
a. The GUI should automatically identify the DC2836A.
The system tree on the left hand side should look
like this:
b. A green message box shows for a few seconds in
the lower left hand corner, confirming that LT7182S
is communicating:
c. In the Toolbar, click the R (RAM to PC) icon to read
the RAM from the LT7182S. This reads the configu-
ration from the RAM of LT7182S and loads it into
the GUI.
d. If you want to change the output voltage to a differ-
ent value, like 1.5V. In the Config tab, type in 1.5 in
the VOUT_COMMAND box, like this:
Then, click the W (PC to RAM) icon to write these reg-
ister values to the LT7182S. After finishing this step,
you will see the output voltage will change to 1.5V.
If the write is successful, you will see the following
message:
e. You can save the changes into the NVM. In the tool
bar, click RAM to NVM button, as following
f. Save the demo board configuration to a (*.proj) file.
Click the Save icon and save the file. Name it what-
ever you want.

8
DEMO MANUAL DC2836A
Rev. 0
PARTS LIST
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
Required Circuit Components
1 3 C5, C6, C8 CAP., 10µF, X6S, 10V, 10%, 0603 MURATA, ZRB18AC81A106KE01L
2 1 C7 CAP., 1µF, X7R, 16V, 10%, 0603 MURATA, GRM188R71C105KA12D
3 2 C14, C22 CAP., 0.1µF, X7R, 25V, 10%, 0402 MURATA, GRM155R71E104KE14
4 4 C15, C23, C55, C56 CAP., 100µF, X5R, 6.3V, 10%, 1206 MURATA, GRM31CR60J107KE39L
5 2 C17, C25 CAP., 10µF, X5R, 10V, 10%, 0603 MURATA, GRM188R61A106KAALD
6 2 C36, C37 CAP., 1µF, X5R, 35V, 10%, 0402 MURATA, GRM155R6YA105KE11D
7 2 C53, C54 CAP., 4.7µF, X6S, 25V, 10%, 0603 MURATA, GRM188C81E475KE11D
8 1 L1 IND., 0.47µH, 21.2A, 3.4mΩ COILCRAFT, XGL4030-471MEC
9 1 L2 IND., 1.2µH, 12.2A, 9.4mΩ COILCRAFT, XGL4030-122MEC
10 6 R2, R3, R4, R7, R8, R9 RES., 10k, 1%, 1/10W, 0603 VISHAY, CRCW060310K0FKEA
11 1 R19 RES., 51.1k, 1%, 1/10W, 0603 VISHAY, CRCW060351K1FKEA
12 1 R20 RES., 107k, 1%, 1/10W, 0603 VISHAY, CRCW0603107KFKEA
13 1 R21 RES., 80.6k, 1%, 1/10W, 0603 VISHAY, CRCW060380K6FKEA
14 1 U1 IC, REGULATOR, LQFN-40 ANALOG DEVICES, LT7182SRV#PBF
Additional Demo Board Circuit Components
1 1 C1 CAP., 1µF, X5R, 50V, 10%, 0603 MURATA, GRM188R61H105KAALD
2 1 C2 CAP., 0.01µF, X7R, 25V, 10%, 0603 TDK, C1608X7R1E103K080AA
3 1 C3 CAP., 100µF, ALUM, 35V PANASONIC, EEHZK1V101XP
4 1 C4 CAP., 4.7µF, X7R, 10V, 10%, 0805 TDK, C2012X7R1A475K085AC
5 1 C57 CAP., 10µF, X6S, 10V, 10%, 0603 MURATA, ZRB18AC81A106KE01L
6 0 C16, C24 CAP., OPTION, 7343
7 0 C19, C20, C27, C28 CAP., OPTION, 0603
8 2 C29, C30 CAP., 0.01µF, X5R, 25V, 10%, 0603 AVX, 06033D103KAT2A
9 1 C31 CAP., 0.1µF, X7R, 10V, 20%, 0603 AVX, 0603ZC104MAT2A
10 2 C32, C33 CAP., 1µF, X5R, 10V, 10%, 0603 MURATA, GRM188R61A105KA61D
11 2 C34, C35 CAP., 0.01µF, X5R, 50V, 10%, 0603 AVX, 06035D103KAT2A
12 4 C38, C39, C40, C41 CAP., 0.1µF, X7R, 50V, 10%, 0402 MURATA, GCM155R71H104KE02D
13 2 C42, C44 CAP., 10µF, X5R, 50V, 10%, 1210 TDK, C3225X5R1H106K250AB
14 1 C43 CAP., 1µF, X5R, 50V, 10%, 0603 TAIYO YUDEN, UMK107ABJ105KAHT
15 3 C50, C51, C52 CAP., 4.7µF, X5R, 25V, 10%, 0603 MURATA, GRM188R61E475KE15D
16 0 D1, D2 DIODE, OPTION, SOD-323
17 2 D4, D5 LED, GREEN, DIFFUSED, 0603 BROADCOM INC., HSMG-C190
18 3 D6, D7, D8 LED, RED, DIFFUSED, 0603 BROADCOM INC., HSMH-C190
19 1 FB1 FERRITE BEAD, 100Ω, 1812 WURTH ELEKTRONIK, 74279226101
20 1 L3 IND., 0.47µH, 6.8A, 14mΩ WURTH ELEKTRONIK, 744373240047
21 2 Q2, Q3 MOSFET, N-CH, SOT-23-3 VISHAY, 2N7002K-T1-GE3
22 1 Q4 MOSFET, N-CH, DPAK VISHAY, SUD50N04-8M8P-4GE3

9
DEMO MANUAL DC2836A
Rev. 0
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
23 11 R1, R11, R12, R14, R16, R18, R23, R25,
R35, R38, R41
RES., 0Ω, 1/10W, 0603 VISHAY, CRCW06030000Z0EA
24 5 R5, R6, R37, R39, R56 RES., 10k, 1%, 1/10W, 0603 VISHAY, CRCW060310K0FKEA
25 0 R13, R15, R22, R24, R26, R27, R28,
R33, R34, R36, R40, R42, R43, R49,
R50, R62, R63, R67
RES., OPTION, 0603
26 0 R29, R30 RES., OPTION, 2512
27 2 R44, R45 RES., 10Ω, 5%, 1/10W, 0603 VISHAY, CRCW060310R0JNEA
28 2 R46, R61 RES., 4.99k, 1%, 1/10W, 0603 VISHAY, CRCW06034K99FKEA
29 0 R48 RES., OPTION, 1206
30 5 R51, R52, R64, R65, R66 RES., 866Ω, 1%, 1/10W, 0603 VISHAY, CRCW0603866RFKEA
31 1 R53 RES., 0Ω, 1W, 2010 VISHAY, CRCW20100000Z0EFHP
32 0 R54 RES., OPTION, 2010
33 1 R57 RES., 0.01Ω, 1%, 1W, 2512 VISHAY, WSL2512R0100FEA
34 1 U2 IC, EEPROM, 2Kb (256x8), TSSOP-8 MICROCHIP, 24LC025-I/ST
35 1 U3 IC, IDEAL DIO, 10DFN ANALOG DEVICES, LTC4413EDD#PBF
36 1 U4 IC, LDO, TSOT23-5 ANALOG DEVICES, LT1761ES5-3.3#PBF
Hardware: For Demo Board Only
1 6 E1, E2, J3-J6 BANANA JACK, FEMALE KEYSTONE, 575-4
2 13 E12-E21, E40, E47, E48 TEST POINT, TURRET, 0.094" MILL-MAX, 2501-2-00-80-00-00-07-0
3 6 E41-E46 TEST POINT, TURRET, 0.064" MILL-MAX, 2308-2-00-80-00-00-07-0
4 1 J8 CONN., HDR, MALE, 2x6, 2mm AMPHENOL, 98414-G06-12ULF
5 1 J9 CONN., HDR, MALE, 2x7, 2mm MOLEX, 0877601416
6 1 J10 CONN., HDR, FEMALE, 2x7, 2mm SULL. CONN. SOLU., NPPN072FJFN-RC
7 3 J11, J12, J13 CONN., BNC, 50Ω AMPHENOL RF, 112404
8 4 JP1, JP2, JP3, JP4 CONN., HDR, MALE, 1x3, 2mm WURTH ELEKTRONIK, 62000311121
9 4 MP1, MP2, MP3, MP4 STANDOFF, NYLON, SNAP-ON, 0.50" KEYSTONE, 8833
10 2 SW1, SW2 SWITCH, SLIDE, DPDT, 0.3A, 6VDC, PTH C&K, JS202011CQN
11 4 XJP1, XJP2, XJP3, XJP4 CONN., SHUNT, FEMALE, 2 POS, 2mm WURTH ELEKTRONIK, 60800213421
PARTS LIST

10
DEMO MANUAL DC2836A
Rev. 0
SCHEMATIC DIAGRAM
BOOST1
VSENSE0+
ITH1
ITH0
VSENSE0-
VSENSE1+
VSENSE1-
ITH0 ITH1
VSENSE0+ VSENSE1+
VSENSE0-
VIN0
BOOST0 X00001
X00002
VSENSE0+ VSENSE0-
VIN1
VSENSE1+ VSENSE1-
VIN1
VIN0
VSENSE1-
X00001 X00002
VOUT0
INTVCCVDD18DRVCC
INTVCC
INTVCC
VOUT1
VOUT1
VOUT0
VOUT1
3V3
/ALERT
SCL SDA
PGOOD1
SHARE_CLK
PGOOD0 /FAULT0 /FAULT1
RUN1 RUN0
SYNC
VPULLUP
EXTVCC
VIN0
VEMI
EXTVCC
VPULLUP
1. ALL RESISTORS AND CAPACITORS ARE 0603.
NOTE: UNLESS OTHERWISE SPECIFIED
2 FOR SINGLE OUTPUT CONFIGURATION.
Optional Resistors for Single Output Configuration
22 2
22
C39 0.1uF 0402 50V
J5 VOUT1
3.3V / 6A
R22 OPT
R2
10k
R15 OPT
E48
GND
R19 51.1k
R21 80.6k
R24 OPT
E43
VOUT0 SENSE
L3
0.47uH
744373240047
1 2
C55 1206
C38 0.1uF 0402 50V
C8
10uF
R12
0
R18 0
J4
GND
E44
GND
L2
1.2uH
XGL4030-122MEB
1 2
C22
0.1uF 0402
C36 1uF 0402
43
44
41 42
U1
LT7182SIV
SGND
3
ITH0 4 ITH1 5
INTVCC 6
VDD18 7
VOUT0_CFG
8
VOUT1_CFG
9
VSENSE1P 11
VSENSE1N 12 VSENSE0N 1
PGND 19 PVIN0 35
PGND
34
PGND
39
/FAULT1
27
SCL
30
SDA
31
SW1 16
BOOST1 13
DRVCC 20
EXTVCC 21
PGND 14
SHARE_CLK
25
SW0 37
BOOST0 40
PVIN0 38
SW0 36
PGOOD1
32
PVIN1 15
ASEL
10
SYNC/PWM_CFG
22
VSENSE0P 2
PVIN1 18
SW1 17
RUN1
23
RUN0
24
WP
26
/FAULT0
28
/ALERT
29
PGOOD0
33
SW0
41
SW1
42
GND
43
GND
44
PGND
45
PGND
46
PGND
47
PGND
48
R23
0
FB1
74279226101
1 2
C42 10uF
50V
1210
C5
10uF
R4
10k
R29 OPT 2512
R20 107k
E47
GND
E1
VEMI
4V-20V
R67
OPT C53
4.7uF
0603
25V
JP4
1
3
2
R16 0
+
C16 OPT
12
J6 GND
R3
10k
R13 OPT
C19 OPT
R11 0
R26 OPT
C57 10uF
R9
10k
E42
GND
L1 0.47uH
XGL4030-471MEB
1 2
R25 0
R5
10k
R28 OPT
C28 OPT
+
C24 OPT
12
E2
GND
E46
VOUT1 SENSE
C17 10uF
E41
VIN SENSE
C25 10uF
C14
0.1uF 0402
C20 OPT
C41 0.1uF 0402 50V
+
C3 100uF
35V
12
C27 OPT
R27 OPT
C54
4.7uF
0603
25V
E45
GND
J3 VOUT0
1.2V/6A
R7
10k
C6
10uF
R6
10k
C23 100uF
6.3V
C7
1uF
E40
EXTVCC
C15 100uF
6.3V
C43 1uF 50V
C44 10uF
50V
1210
R30 OPT 2512
R14 0
C40 0.1uF 0402 50V
C56 100uF
1206
R62 OPT
R8
10k
C37 1uF 0402

11
DEMO MANUAL DC2836A
Rev. 0
Information furnished by Analog Devices is believed to be accurate and reliable. However, no responsibility is assumed by Analog
Devices for its use, nor for any infringements of patents or other rights of third parties that may result from its use. Specifications
subject to change without notice. No license is granted by implication or otherwise under any patent or patent rights of Analog Devices.
SCHEMATIC DIAGRAM
AUXVCC
EEWP
EESDA EESCL
3V3_LDO
3V3_LDO
3V3
3V3
VOUT0 VOUT1
3V3
/ALERT SDA SCL
RUN0 RUN1
PGOOD1
PGOOD0
SYNC
SHARE_CLK
PGOOD0
PGOOD1PGOOD0 RUN1
RUN0
/FAULT1
/FAULT0
VPULLUP
VPULLUP VPULLUP
VPULLUP VPULLUP
VPULLUP
VPULLUPVPULLUP /ALERT
/FAULT1/FAULT0
PGOOD1
VEMI
VEMI
ALL PARTS ON THIS PAGE ARE FOR DEMO ONLY, NOT NEEDED IN CUSTOMER DESIGN
TO DC1613A
ON OFF
ON
OFF
RUN0
RUN1
1206
LOAD TRANSIENT CIRCUIT
1. ALL RESISTORS AND CAPACITORS ARE 0603. 2 FOR SINGLE OUTPUT CONFIGURATION.
NOTE: UNLESS OTHERWISE SPECIFIED
J12
VOUT1
R42 OPT
R38 0
J11
VOUT0
R46 4.99k 1%
C29 0.01uF
R50 OPT
R35
0
U3 LTC4413-DD
GND
3
STAT 9
INB
5
ENBB
4
INA
1OUTA 10
ENBA
2
OUTB 6
NC 8 NC 7
GND
11
JP3/FAULT0-/FAULT1
NCC
1
3
2
Q4 SUD50N04-8m8P
2
1
3
C30 0.01uF
C4 4.7uF 0805
R57 0.01
1%
2512
U4 LT1761-S5-3.3
GND
2
BYP 4
IN
1VOUT 5
SHDN
3
R63 OPT
E17
GND
C32 1uF
R45 10
E15
SHARE_CLK
C34 0.01uF
R40 OPT
R1 0
C52 4.7uF
R52
866
R54 OPT
2010
R39 10k 1%
C35
0.01uF
E18 PGOOD0
R51
866
SW1
1
2
3
4
5
6
R33
OPT
E12
/ALERT
Q2
2N7002
3
1
2
R66
866
D6
RED
HSMH-C190
21
D5
GREEN
HSMG-C190
21
J13
IOSTEP
C51 4.7uF
R64
866
D2 OPT
21
JP2RUN0-RUN1
NCC
1
3
2
R48
OPT
J10
FAULTB 1
CTRL 2
ALERTB 3
SDA 4
SHARE_CLK 5
SCL 6
RESETB 7
AUXP 8
UNUSED 9 UNUSED 10
GND 11 GND 12
12V 13 12V 14
D7
RED
HSMH-C190
21
C1 1uF
C50 4.7uF
C33 1uF
C2 0.01uF
R49 OPT
C31
0.1uF
R34
OPT
R44 10
E20
IOSTEP CLK
E21 GND
Q3
2N7002
3
1
2
R37 10k 1%
R56 10k
1%
E16
SYNC/PWM_CFG
D4
GREEN
HSMG-C190
21
R41
0
J8
AUXP 1
SDA 2
GND 3
SCL 4
LGKPWR 5
ALERTB 6
GPIO_1 7
OUTEN_0 8 OUTEN_1 9
GND 10
AUXSCL 11
AUXSDA 12
JP1PGOOD0-PGOOD1
NCC
1
3
2
R53
0
2010
SW2
1
2
3
4
5
6
D8
RED
HSMH-C190
21
R43 OPT
E14
SCL
U2
24LC025-I/ST
SDA 5
VCC 8
A0
1
A1
2
A2
3
VSS
4
WP 7
SCL 6
J9
HDR
FAULTB
1
CTRL
2
ALERTB
3
SDA
4
SHARE_CLK
5
SCL
6
RESETB
7
AUXP
8
UNUSED
9
UNUSED
10
GND
11
GND
12
12V
13
12V
14
R65
866
R36 OPT
E19 PGOOD1
E13
SDA
D1 OPT
21
R61 4.99k 1%

12
DEMO MANUAL DC2836A
Rev. 0
 ANALOG DEVICES, INC. 2021
09/21
www.analog.com
ESD Caution
ESD (electrostatic discharge) sensitive device. Charged devices and circuit boards can discharge without detection. Although this product features patented or proprietary protection
circuitry, damage may occur on devices subjected to high energy ESD. Therefore, proper ESD precautions should be taken to avoid performance degradation or loss of functionality.
Legal Terms and Conditions
By using the evaluation board discussed herein (together with any tools, components documentation or support materials, the “Evaluation Board”), you are agreeing to be bound by the terms and
conditions set forth below (“Agreement”) unless you have purchased the Evaluation Board, in which case the Analog Devices Standard Terms and Conditions of Sale shall govern. Do not use the Evaluation
Board until you have read and agreed to the Agreement. Your use of the Evaluation Board shall signify your acceptance of the Agreement. This Agreement is made by and between you (“Customer”)
and Analog Devices, Inc. (“ADI”), with its principal place of business at One Technology Way, Norwood, MA 02062, USA. Subject to the terms and conditions of the Agreement, ADI hereby grants to
Customer a free, limited, personal, temporary, non-exclusive, non-sublicensable, non-transferable license to use the Evaluation Board FOR EVALUATION PURPOSES ONLY. Customer understands and
agrees that the Evaluation Board is provided for the sole and exclusive purpose referenced above, and agrees not to use the Evaluation Board for any other purpose. Furthermore, the license granted
is expressly made subject to the following additional limitations:Customer shall not (i) rent, lease, display, sell, transfer, assign, sublicense, or distribute the Evaluation Board;and (ii) permit any Third
Party to access the Evaluation Board. As used herein, the term “Third Party”includes any entity other than ADI, Customer, their employees, affiliates and in-house consultants. The Evaluation Board is
NOT sold to Customer;all rights not expressly granted herein, including ownership of the Evaluation Board, are reserved by ADI. CONFIDENTIALITY. This Agreement and the Evaluation Board shall all
be considered the confidential and proprietary information of ADI. Customer may not disclose or transfer any portion of the Evaluation Board to any other party for any reason. Upon discontinuation of
use of the Evaluation Board or termination of this Agreement, Customer agrees to promptly return the Evaluation Board to ADI. ADDITIONAL RESTRICTIONS. Customer may not disassemble, decompile
or reverse engineer chips on the Evaluation Board. Customer shall inform ADI of any occurred damages or any modifications or alterations it makes to the Evaluation Board, including but not limited
to soldering or any other activity that affects the material content of the Evaluation Board. Modifications to the Evaluation Board must comply with applicable law, including but not limited to the RoHS
Directive. TERMINATION. ADI may terminate this Agreement at any time upon giving written notice to Customer. Customer agrees to return to ADI the Evaluation Board at that time. LIMITATION OF
LIABILITY. THE EVALUATION BOARD PROVIDED HEREUNDER IS PROVIDED “AS IS”AND ADI MAKES NO WARRANTIES OR REPRESENTATIONS OF ANY KIND WITH RESPECT TO IT. ADI SPECIFICALLY
DISCLAIMS ANY REPRESENTATIONS, ENDORSEMENTS, GUARANTEES, OR WARRANTIES, EXPRESS OR IMPLIED, RELATED TO THE EVALUATION BOARD INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTY OF MERCHANTABILITY, TITLE, FITNESS FOR A PARTICULAR PURPOSE OR NONINFRINGEMENT OF INTELLECTUAL PROPERTY RIGHTS. IN NO EVENT WILL ADI AND ITS
LICENSORS BE LIABLE FOR ANY INCIDENTAL, SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES RESULTING FROM CUSTOMER’S POSSESSION OR USE OF THE EVALUATION BOARD, INCLUDING
BUT NOT LIMITED TO LOST PROFITS, DELAY COSTS, LABOR COSTS OR LOSS OF GOODWILL. ADI’S TOTAL LIABILITY FROM ANY AND ALL CAUSES SHALL BE LIMITED TO THE AMOUNT OF ONE
HUNDRED US DOLLARS ($100.00). EXPORT. Customer agrees that it will not directly or indirectly export the Evaluation Board to another country, and that it will comply with all applicable United States
federal laws and regulations relating to exports. GOVERNING LAW. This Agreement shall be governed by and construed in accordance with the substantive laws of the Commonwealth of Massachusetts
(excluding conflict of law rules). Any legal action regarding this Agreement will be heard in the state or federal courts having jurisdiction in Suffolk County, Massachusetts, and Customer hereby submits
to the personal jurisdiction and venue of such courts. The United Nations Convention on Contracts for the International Sale of Goods shall not apply to this Agreement and is expressly disclaimed.
