DEMO MANUAL DC2668A
DESCRIPTION ABSOLUTE MAXIMUM INPUTS
LTC5552
3GHz to 20GHz Microwave Mixer
with Wideband DC to 6GHz IF
Demonstration circuit 2668A is optimized for evaluation
of the LT C
®
5552 passive double-balanced mixer. Its RF
port is broadband matched from 3GHz to 20GHz, and the
internal LO amplifier, requiring only a 0dBm drive level,
is broadband matched to 50Ω from 1GHz to 20GHz with
10dB Return Loss. The differential IF output is usable
from DC to 6GHz. The LTC5552 can be used for upcon-
verting and downconverting applications.
Design files for this circuit board are available at
http://www.linear.com/demo/DC2668A
L, LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks of Analog
Devices, Inc. All other trademarks are the property of their respective owners.
BOARD PHOTO
Figure 1. DC2668A
Supply Voltage (VCC)...............................................4.0V
Enable Input Voltage (EN) ................. –0.3V to VCC+0.3V
LO Input Power (1GHz to 20GHz).........................10dBm
RF Power (3GHz to 20GHz)..................................20dBm
RF DC Voltage........................................................ ±0.1V
IF+/IF–Power (LF to 6GHz)..................................20dBm
IF+/IF–DC Voltage..................................................±0.3V
Operating Temperature Range (TC)........ –40°C to 105°C
Junction Temperature (TJ).................................... 150°C
Storage Temperature Range .................. –65°C to 150°C
CAUTION: THIS PART IS SENSITIVE TO ELECTROSTATIC
DISCHARGE (ESD). OBSERVE PROPER ESD PRECAU-
TIONS WHEN HANDLING THE LTC5552.

2
dc2668afa
DEMO MANUAL DC2668A
PROPER TEST SETUPS
Figure 3. Test Setup for Upconverting Mixer Two-Tone Measurements
Figure 2. Test Setup for Downconverting Mixer Two-Tone Measurements

3
dc2668afa
DEMO MANUAL DC2668A
NOTES ON TEST EQUIPMENT SETUP
QUICK START PROCEDURE
•High performance signal generators with low harmonic
outputs should be used for 2-tone measurements. Oth-
erwise, low-pass filters at the signal generator outputs
should be used to suppress harmonics.
•High quality combiners should be used to present a
broadband 50Ω termination on all ports as well as
provide good port-to-port isolation. Adding attenua-
tor pads further improves source isolation and helps
prevent the signal generators from producing inter-
modulation products.
•Spectrum analyzers can produce significant internal
distortion products if they are overdriven. Generally,
spectrum analyzers are designed to operate at their
best with about –30dBm to –40dBm at their input. The
spectrum analyzer’s input attenuation setting should be
used to avoid saturating the instrument.
•Set the spectrum analyzer’s input attenuation depend-
ing on the spectrum analyzer used.
•Before performing measurements on the DUT, the sys-
tem performance should be evaluated to ensure that
a clean input signal is obtained and that the spectrum
analyzer’s internal distortion is minimized.
1. Connect all test equipment as shown in Figure 2.
2. Set the power supply output voltage to 3.3V and set
the current limit to 200mA.
3. Connect the ground and V
CC
turrets to the power supply.
BE SURE TO CONNECT THE VCC TURRET BEFORE THE
EN TURRET TO ENSURE THAT THE PART DOES NOT
GET DAMAGED. ALSO, REMOVE POWER FROM EN
TURRET BEFORE REMOVING POWER FROM THE VCC
TURRET.
4. Connect the EN turret to the power supply.
5. Set the LO signal generator to provide a 9560MHz CW
signal at about 0dBm to the demo board’s LO port.
6. Set the RF signal generators to provide one 9799MHz
CW signal and one 9801MHz CW signal. The signals
should be applied to the 2-way combiner. The output
of the combiner should be applied to the demo board’s
RF input port. The two tones should be set to –5dBm
each at the mixer’s RF input port.
7. Set the spectrum analyzer’s center frequency to
240MHz.
8. Perform various measurements (Conversion Gain,
OIP3, LO leakage, etc.).

4
dc2668afa
DEMO MANUAL DC2668A
PARTS LIST
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
Required Circuit Components
1 1 C1 CAP., 18pF, C0G, 10V, 2%, 0402 AVX, 0402ZK180GBSTR
2 1 C2 CAP., 18pF, C0G, 50V, 1%, 0402 MURATA, GJM1555C1H180FB01
3 1 C3 CAP., 1μF, X7R, 10V, 10%, 0603 MURATA, GRM188R71A105KA61
4 3 E1-E3 TEST POINT, TURRET, 0.061" MTG. HOLE MILL-MAX, 2308-2-00-80-00-00-07-0
5 2 J1, J2 CONN., SMA, 50Ω, EDGE-LAUNCH E.F. JOHNSON, 142-0761-881
6 1 J3 CONN., SMA, 50Ω, EDGE-LAUNCH E.F. JOHNSON, 142-0701-851
7 1 T1 XFMR., 1:1, 4.5-3000MHz MINI-CIRCUITS, TC1-1-13M+
8 1 U1 I.C., LTC5552IUDB, QFN 12 PIN, 3mm × 2mm LINEAR TECHNOLOGY, LTC5552IUDB#PBF

5
dc2668afa
DEMO MANUAL DC2668A
