Analytic Systems VTC1505 SERIES User manual

INSTALLATION &
OPERATION MANUAL
VTC1505 SERIES VOLTAGE CONVERTER

2
IMPORTANT & SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS — This manual contains important safety and operating
instructions for the battery charger.
VOLTAGE CONVERTER PRECAUTIONS
1. Do not expose the voltage converter to rain or snow unless it is a sealed model.
2. Use of an attachment not recommended or sold by the manufacturer may result in a risk
of re, electric shock, or injury to persons.
3. Do not disassemble the voltage converter; return it to the manufacturer or an authorized
service center when service or repair is required. Incorrect reassembly may result in a
risk of electric shock or re. Voltages of up to 350 volts are present inside the voltage
converter anytime it is connected to input power, even if it is switched off.
4. To reduce risk of electric shock, unplug the voltage converter from the DC power source
before attempting any maintenance or cleaning. Turning off controls will not reduce this
risk.
5. Never place the voltage converter directly above a battery; gases from battery will
corrode and damage the voltage converter.
6. Never allow battery acid to drip on the voltage converter.
Medical Equipment Notice
Analytic Systems does not recommend the use of their products in life support
applications where failure or malfunction of this product can be reasonably
expected to cause failure of the life support device or to signicantly affect its
safety or effectiveness. Analytic Systems does not recommend the use of any
of its products in direct patient care. Examples of devices considered to be life
support devices are neonatal oxygen analyzers, nerve stimulators (whether
used for anesthesia, pain relief, or other purposes), auto-transfusion devices,
blood pumps, debrillators, arrhythmia detectors and alarms, pacemakers,
hemodialysis systems, peritoneal dialysis systems, neonatal ventilator
incubators, ventilators for both adults and infants, anesthesia ventilators, and
infusion pumps as well as any other devices designated as “critical” by the U.S.
FDA.

3
TABLE OF CONTENTS
• Front Cover, Product Photo and Title
• Product warnings and advisories
• Table of Contents
• Description/Overview of product
• Main Parts
• Operation instructions
• Mounting Instructions
• Connection instructions
• Conguration instructions
• Options
• Faults
• Specications
• Warranty
Revised - September 16, 2016
Copyright (2005-2016) Analytic Systems Ware (1993) Ltd.

4
Introduction
The VTC1505 Voltage Convertery provides up to 1500 watts continuous and 1800 watts
intermittent to power one or more loads from a 110, 250 or 300 VDC source. Two positive and
two negative output connections are provided for easy connection to multiple devices. The
recently updated single board design incorporates state of the art switch- mode technology
for unmatched efciency and ultra-quiet operation. Multiple stages of ltering reduce radiated
and conducted noise to MIL461 levels.
Safety features include over-temperature shutdown, current limiting, short circuit protection
with automatic recovery, input under voltage shutdown and output over-voltage protection.
Extra features include visual indicators for low input voltage, overload and overtemperature,
dry contact output fail output and remote control connection.
Main Parts
Front Panel
1. Output Negative Connection x 2
2. Output Positive Connections x 2
3. Output Voltage Adjust
4. DC Power Cord
5. DC Input Fuse
6. Power On / Off Toggle Switch
3
2
4
6
5
1

5
Rear Panel
1. Thermostatically controlled cooling fans x 2
2. Dry Contact Output Fail Relay Connection
3. Remote Control Connection
Top of Chassis (not shown)
1. Carrying Handle (Optional)
2. Digital Voltage Current Display (Optional, not shown). Adds three inches to chassis length
3
2
1

6
Operation
To turn the unit on, simply press the Power push button. The alarm buzzer will sound and the
Low Output LED will come on briey, and then the green OUTPUT ON LED will illuminate.
The unit will provide the regulated voltage from no load to the maximum load shown in the
specications section. You may check this voltage at the output terminals of the unit with a
good digital voltmeter. As shipped from the factory, the unit is preset to the voltage listed in
the specications, but it can be adjusted by approximately +/- 5 percent. If you wish to adjust
the output voltage, rotate the output adjust potentiometer with a at blade screwdriver.
Clockwise increases the output voltage, and counter clockwise decreases it.
Digital Meter Option (V Option)
A high quality digital meter can be added to the charger (factory installed only). Both outputs
can be monitored for current and voltage. The Digital Meter option adds 3 inches to the overall
length of the unit
Steel Mill Option (S Option)
The Steel Mill Option adds a robust surge supressor to the input of the voltage converter to
protect it from the high voltage spikes that can be present in this environment.
Load Share Option (D Option)
Two or more units may be congured for load sharing if they are equipped with the optional
output isolation diodes. To conrm that your unit has these diodes, use an ohmmeter to
measure the resistance between the two positive output terminals. If the diodes are present
the terminals will measure as not connected. If the diodes are NOT present, the terminals
will measure as a short circuit. Assuming the output isolation diodes are present, connect
a one-foot piece of red wire of the appropriate gauge from each positive output terminal to
a common connection point to further assist in even load sharing. Either using the optional
digital meter display, or with a good quality clamp on ammeter, use the output voltage adjust
potentiometers to ne tune the load sharing. Please not the the maximum current is reduced
to the Continuous Rating for any units equipped with the D Option.
OUTPUT 1
OUTPUT 1
OUTPUT 2
OUTPUT 2

7
The relay is factory preset to fail when the low output LED and buzzer come on. Both normally
open and normally closed contacts are available on the connector. If your system detects
an alarm condition when the voltage converter is operating normally, simply move the wire
connected to Pin 1 of the dry contact terminal block to Pin 3, or vice versa as needed.
Remote Control Option
A high quality digital meter can be added to the charger (factory installed only). Both outputs
can be monitored for current and voltage. The Digital Meter option adds 3 inches to the overall
length of the unit
A remote control panel may be connected to the voltage converter using a 9-pin D-connector,
which attaches to the rear of the voltage converter. The remote control panel and D connector
are part of the remote control option. The remote control panel allows the unit to be operated
remotely as well as duplicating all the diagnostic indicators and audible alarm.
REMOTE CONNECTOR
This connector is located on the rear of the unit. Important: To prevent the possibility of High
Voltage Electrical Shock, do not power up the voltage converter unless all wiring from the unit
to the remote is securely connected. Do not remove the dust cover from the DB-9 connector if
the remote is not being used.
Dry Contact Relay
IMPORTANT: This remote is to be used only with
Voltage Converters manufactured by Analytic
Systems

8
0.25
12.00
2.39
3.76
16.80
Mounting
Mount the unit and allow at least 1 inch
of clearance around the heat sink ns for
adequate cooling.
Input Connection
This unit is equipped with a 1.0 m AWG12
cable (approx. length) for connection to the
DC power source. Red or White is Positive
and Black is Negative.
Output Connection
This unit has two pairs of color coded Phoenix VDFK6 terminal blocks, 60 Amp rated. Red is
Positive and Black is Negative. Connect to the load an appropriate sized cable. AWG6 is the
recommended size for these terminals.
For 12V models, the output current capability exceeds the rating of an individual connector. If
the load is greater than 60 amps, split the output cable into two and connect half the cable to
each output terminal to ensure safe operation.
If multiple loads are connected to the voltage converter, but none are greater than 60 amps,
then share the connections to ensure that no more than 60 amps of load is connected to any
one output terminal.
Installation

9
Troubleshooting
This unit provides LED indicators and a buzzer to help diagnose any problems. The unit should
sound the buzzer to alert you prior to shutting itself down. You should immediately check the
indicators to determine the cause of the shutdown.
OVERLOAD Indicates that the load connected to the voltage converter exceeds the
continuous rating.
LOW OUTPUT Indicates that the output voltage is below normal because:
The current demanded by the devices connected to the unit exceeds the
maximum output current rating, causing the output voltage to drop to
maintain the current at the maximum level.
The input voltage is not high enough for unit to operate.
LOW INPUT Indicates that the input voltage is below normal because:
The input voltage is not in the correct range for proper operation of the
unit.
OVERTEMP Indicates that the Battery Charger is running too hot because:
The Battery Charger is located in a poorly ventilated area or the ambient
temperature is too high.
One or both of the cooling fans have failed. Return to an authorized
service center to have the fans replaced.
If the voltage converter gets too hot, the temperature sensor inside
the unit will turn off the outputs. After the unit cools sufciently, it
will automatically come back on. If this happens frequently,
remount the unit for increased airow so it cools better.

10
Mechanical
Dimensions 17.4 in / 44.2 cm Long x 8.35 in/ 21.2 cm Wide x 4.0 in / 10.2 cm High
Clearance 1.0 in / 2.5 cm all around
Weight 18.0 lb / 8.2 kg
Material and Finish Marine Grade Black Anodized Aluminum with 18-8 Stainless Fasteners
Connections Input-1m AWG12 cable (approx. length). Red or White for Positive, Black for Negative
Output - Color coded Phoenix VDFK6 terminal blocks, 60 Amp rated
Environmental and Safety
Operating Temperature Range -25°C to +40°C @ maximum output. Derate Linearly 2.5% per °C from 40°C
(Optional -40°C extra wide temperature operation available)
Humidity 0 - 95% Relative Humidity (non-condensing) with standard conformal coating
Isolation Input-Case, Input-Output and Output-Case 1500 VDC
Audible Noise 40 dB when fans operating
Typical Service Life > 10 years (87,600 hrs)
Warranty Three years parts and labor
Safety Built to meet CSA 22.2.107.1 & UL458
Specications
Input Voltages
Input Volts Nominal 110 VDC 250 VDC 300 VDC
Input Volts Actual 100 - 140 VDC 230 - 280 VDC 280 - 360 VDC
Input Amps 21 Amps Max 10 Amps Max 8 Amps Max
Input Fuse - 1/4 x 1 1/4 Slo Blow 25 Amps 15 Amps 10 Amps
Noise on Input < 50 mV
Output Voltagesw
Output Volts Nominal 12 24 32 48 72(rail)
Output Volts Actual 13.6 27.2 36.3 54.4 72.6
Output Adjust +/- 0.5 V +/- 1.0 V +/- 1.5 V +/- 2.0 V +/- 3.0 V
Continuous Amps 100 60 45 30 20
Maximum Amps (except D Option) 120 72 54 36 24
Output Overvoltage Protection
Crowbar 17.0 ± 0.05 V 34.0 ±1.0 V 45.0 ± 0.5 V 68.0 ± 2.0 V 90.0 ± 0.3 V
Efciency > 80% @ Maximum Output
Stages 2 or 3

11
Limited Warranty
1. The equipment manufactured by Analytic Systems Ware (1993) Ltd. (the “Warrantor”) is warranted to be free
from defects in workmanship and materials under normal use and service.
2. This warranty is in effect for:
a. 3 Years from date of purchase by the end user for standard products offered in our catalog.
b. 2 Years from date of manufacture for non-standard or OEM products
c. 1 Year from date of manufacture for encapsulated products.
3. Analytic Systems will determine eligibility for warranty from the date of purchase shown on the warranty card
when returned within 30 days, or
a. The date of shipment by Analytic Systems, or
b. The date of manufacture coded in the serial number, or
c. From a copy of the original purchase receipt showing the date of purchase by the user.
4. In case any part of the equipment proves to be defective, the Purchaser should do the following:
a. Prepare a written statement of the nature of the defect to the best of the Purchasers knowledge, and
include the date of purchase, the place of purchase, and the Purchasers name, address and telephone
number.
b. Call Analytic Systems at 800-668-3884 or 604-946-9981 and request a return material authorization
number (RMA).
c. Return the defective part or unit along with the statement at the Purchasers expense to the Warrantor;
Analytic Systems Ware (1993) Ltd., 8128 River Way, Delta, B.C., V4G 1K5, Canada.
5. If upon the Warrantor’s examination the defect proves to be the result of defective material or workmanship,
the equipment will be repaired or replaced at the Warrantor’s option without charge, and returned to the
Purchaser at the Warrantor’s expense by the most economical means. Requests for a different method of return
or special handling will incur additional charges and are the responsibility of the Purchaser.
6. Analytic Systems reserves the right to void the warranty if:
a. Labels, identication marks or serial numbers are removed or altered in any way.
b. Our invoice is unpaid.
c. The defect is the result of misuse, neglect, improper installation, environmental conditions, non-
authorized repair, alteration or accident.
7. No refund of the purchase price will be granted to the Purchaser, unless the Warrantor is unable to remedy the
defect after having a reasonable number of opportunities to do so.
8. Only the Warrantor shall perform warranty service. Any attempt to remedy the defect by anyone else shall
render this warranty void.
9. There shall be no warranty for defects or damages caused by faulty installation or hook-up, abuse or misuse of
the equipment including exposure to excessive heat, salt or fresh water spray, or water immersion except for
equipment specically stated to be waterproof.
10. No other express warranty is hereby given and there are no warranties that extend beyond those described
herein. This warranty is expressly in lieu of any other expressed or implied warranties, including any implied
warranty of merchantability, tness for the ordinary purposes for which such goods are used, or tness for a
particular purpose, or any other obligations on the part of the Warrantor or its employees and representatives.
11. There shall be no responsibility or liability whatsoever on the part of the Warrantor or its employees and
representatives for injury to any person or persons, or damage to property, or loss of income or prot, or any
other consequential or resulting damage which may be claimed to have been incurred through the use or sale of
the equipment, including any possible failure of malfunction of the equipment, or part thereof.
12. The Warrantor assumes no liability for incidental or consequential damages of any kind

DESIGNED AND MANUFACTURED BY
800-668-3884
604-946-9983
[email protected]
www.AnalyticSystems.com
8128 River Way
Delta, BC V4G 1K5 | Canada
Battery Chargers •Inverters •Power Supplies •Voltage Converters
