Anchor DigiPure AF-9000 Series User manual

SMART LCD COUNTERTOP
WATER FILTER SYSTEM
User Guide
DigiPure AF-9000 Series

All systems are made with highest quality NSF approved material
Filter System in Chrome
Anchor Smart Countertop Water Filters are
innovative systems featuring LCD display and
alarm for filter life.
These systems are:
•Perfect solution for
household of any size.
•Slim, portable, compact
in design. Easy to install.
•Designed to be used in
most standard sized
housings.
•Battery operated LCD
for remaining capacity
display.
•Alarm for end of filter
life.
The attractively designed unit sits right on your
countertop and completes the filtration process.
Water flow is instantaneous, dispense the water
you need and enjoy the refreshing taste right
away.
It comes with: 5, 7, or 10 stage filter cartridge

Your Box Contains:
Filter System +
Cartridge*
Adapters +
Gasket kit Wrench
User Guide 2 AAA
Batteries
Supported Countertop Water Filter Systems
The information in this guide applies only to the following products:
* Filter
cartridge
will depend
on the order
ATTRIBUTE VALUE
Temperature Range 39°F -100°F (4°C -38°C)
Service Flow 1 gpm (3.8L/min)
Rated Capacity 1500 gallons or 6 months (whichever is earlier)
Operating Pressure 10 - 90 psi
Specifications
FILTER SYSTEM MODEL REPLACEMENT FILTER MODEL
AF-9500 -5-Stage Filter AF-1003 -5-Stage Filter
AF-9700 -7-Stage Filter AF-1007 -7-Stage Filter
AF-9110 -10-Stage Filter AF-1110 -10-Stage Filter

1. Installing Batteries
From base of the filter unit, remove
the protective sticker (used to protect
from water) and slide off the battery
cover. Install the 2 AAA batteries
(included) in the battery compartment
and slide back and fix both, cover and
sticker.
We have made it easy for you to install the Anchor Countertop Water
Filter. The shipped unit comes pre-installed with filter cartridge, faucet,
diverter valve, and tube. The only thing you need to do is to install
batteries, connect diverter valve to your faucet, and start enjoying the
clean refreshing water.
Installing Your Filter
This is the
diverter valve
Steps for installation:
Push & Pull Type
OUTSIDE INSIDE
- OR -
i. Remove existing aerator from the faucet. Note the threads in your
faucet. If the threads are on the:
Aerator
2. Connecting Faucet

ii. Based on your faucet threads described above, connect the divertor
on the faucet as shown in the image below:
Faucet with
outside thread
- the diverter
valve should
screw right on
a.
Faucet with
inside thread
- enclosed
adapter ring
and gasket
must be used
b.
If your faucet has non-standard threads, try the
supplied universal adapter or purchase a special
adapter from your local hardware store.
After setting up the faucet, do the following:
1. Once the diverter valve is well
connected with the faucet, the
filter is ready to operate. Place
the filter unit in a convenient
location with the spout
positioned over your sink. The
spout is designed to swivel. Countertop with filter installed

2. Turn on the faucet and pull out the
stick of the diverter valve as shown
in the image. The diverter valve will
divert water to the filter unit and
water will come out of the spout in
the filter.
3. Allow it to run for several minutes to flush out the carbon fines
(blackish specs). Initially, the water may contain tiny air bubbles
and taste slightly sweet - this is normal and harmless, and will
clear up after flushing.
4. To stop the flow from the filter and for normal unfiltered water
flow through your kitchen faucet, push the diverter valve knob
back in.
1. The electronic filter monitor
automatically shows remaining
filter capacity on the LCD when
filter is used. LCD automatically
turns off in 3 seconds to save
battery power when not in use.
2. The electronic filter LCD monitor
blinks 0 and generates an audible
sound to notify that the filter has
reached end of life. The filter
cartridge should be changed at
this point.
LCD Display

Replacing the Filter Cartridge
6. Reset the LCD gallon count from 0 to 1500 gallons by following
steps in ‘battery replacement’ section on next page, step 3.
7. Place the system on flat surface and turn on the water supply. Let
the water run for several minutes to flush out normal carbon fines.
1. Turn off water. Unscrew the housing
from base by turning it
counterclockwise using the supplied
filter wrench.
2. Remove the old cartridge and discard.
At this point, it is recommended to
clean the housing from inside.
3. Check the O-ring for wear & tear. O-
ring rests above the thread in the
base.
-If it is worn, replace it.
- If it is in good working condition,
lubricate it with food-grade
petroleum jelly to ensure it lies flat
and prevents leaking.
5. Pick up the base and screw the housing tight enough with hand
first. Doing it this way will prevent the O-ring from slipping loose
and causing the filter to leak. Once the filter housing is hand tight,
tighten it an additional 1/4 to 1/2 turn with the supplied filter
wrench to prevent any leakage.
4. Unwrap new filter cartridge from plastic wrap
and place it on the filter base with side marked
up facing up (see picture on the right). Put the
housing back on. Apply some petroleum jelly on
housing threads for easier unscrewing next time.

Battery Replacement
1. Low Battery Power Alert
When the battery power is low,
the electronic filter monitor
generates an audible sound and a
battery symbol blinks on the top
right corner of the LCD. When this
2. Last data Automatically Memorized
The Anchor DigiPure 9000s is operated by 2AAA alkaline
batteries. The batteries last more than a year. When not in use,
LCD automatically turns off in 3 seconds to save battery power
after displaying the remaining capacity.The last data displayed
is automatically memorized after the display turns off.
3. Reset after replacing filter cartridge
After the filter cartridge is replaced, press the ‘Reset’ button on
the unit to reset the remaining capacity of the filter to default
value.
happens, replace the batteries. After the batteries are replaced,
the sound and blinking will stop.
For resetting monitoring
capacity when the remaining
capacity shown is not 0, press
and hold the ‘Display’ button
and then press ‘Reset’. The LCD
will blink for 10 seconds and
then stop. This will reset the
capacity.

All rights reserved. No part of this user guide may be
reproduced, distributed, or transmitted in any form or
by any means, including photocopying, recording, or
other electronic or mechanical methods, without the
prior written permission of Anchor USA.
Register Your Product
Give yourself complete peace of mind and register product online to
receive timely reminders for filter replacements & for quick support.
SN0190EN2020
Technical Support
At Anchor USA, we are always here to help you. With 24-hour access
to our company contact web page, you can drop a message or email us
directly anytime, and one of our representatives will respond to your
query in less than 24-hrs.
Web: https://www.anchorfilters.com/contact-us
Email: [e-mail]
Register here:
https://www.anchorfilters.com/pr
oduct-registration
OR
IMPORTANT!
Run only cold water through the unit.
WARNING!
Do not use this filter for water that is
microbiologically unsafe or of unknown quality.
