FD40 Series 2
Dehumidier
Operating Instructions
& Safety Guide
Getting started and operation
General Safety
Electrical Safety
0800 211 611
Dehumidiers are for internal use only.
This equipment should only be used by a competent
person who has read and understood these instructions.
Check condition of equipment before use. If unit is
showing any signs of damage contact your supplier
immediately.
Never operate this equipment if you are ill, feeling tired or
under the inuence of alcohol or drugs.
Keep all vents and grills clear of obstructions.
Keep children and animals away from the dehumidifer.
Never leave them alone in a room where the units are in
use.
Make sure equipment is switched o and unplugged after
use.
This unit is dual voltage and can be used via a standard domestic
13 amp 230 volt socket or 110 volt power supply.
THE FD40 SERIES 2 HAS AN AUTOMATIC CHANGEOVER
TRANSFORMER NO NEED TO SELECT THE REQUIRED VOLTAGE
Always inspect plugs and power cables for damage before
plugging into power supply.
DO NOT USE IF ANY DAMAGE IS FOUND.
Ensure cables are installed to prevent hazards.
If an extension lead is used, ensure it is of the correct standard
and fully uncoiled before use.
Cables must not be laid in wet or damp areas.
Do not move equipment while operating.
Do not pull equipment by the power lead.
It is recommended that the electrical supply to this equipment is
protected by an RCD.
Fit correct plug top to power input
lead to suit operating voltage
selected.
13 amp BS1363 230volt or 16 amp
BS4343 Blue plug
16 amp BS4343 110 volt Yellow
plug.
No requirement to select voltage as
the unit has an automatic
changeover transformer.
Fig 1
Position equipment on level
ground, position centrally in the
area allowing fr ee air flow.
230 V 110 V

Fig 2 : Condensate will drain into the 14
liter internal tank Fig 6 :
This automatically starts and stops the
machines compressor when pre-set
humidity levels are reached.
Many dehumidifying applications require
humidity to be controlled at set relative
humidity levels (RH) to avoid shrinkage of
materials, cracking plaster, furniture etc.
The FD40 S2 has been designed taking this
into account and thanks to the built in
humidistat you will be able to control the
humidity levels as desired in the room.
Fig 3 :
Switch on the unit via the front panel
and set the desired humidity via the up
and down arrows
Disconnect from electrical supply when not in use.
Fig 5 : The condensate pump is close
coupled electrically to the machine via a built
in auxiliary connection. Remove the internal
tank at the back of the unit and then the
power plug can be seen. On the front control
panel you must push the button that says
pump. This will avoid the unit from stopping
when you remove the internal tank.
Humidity Control
Set the Humidistat using the up and down
arrows to the desired RH%. The lowest set
RH% is 30% but if you require the RH% to
be lower push the arrow button two times
below 30% and the display will change to
CONT which means continuous running
ig 2
Fig 4 :
The FD40 S2 can be supplied with a separate
condensate pump.
