Anets MX-14M Installation guide

Anets, Inc PO Box 501, Concord, NH 03302-0501
Tel: [phone] Fax: [phone]
FRYER
Models
MX-14E,MX-14-2E,
MX-7E,
MX-14AA,MX-14-2AA,
MX-7A
Installation,
User Operation,
&
Maintenance
Manual
MX-14E shown with optional casters
DANGER
Improperinstallation,adjustment,alteration,service,ormaintenancecan
cause property damage, injury or death. Read the installation, operating
andmaintenanceinstructionsthoroughlybeforeinstallingorservicingthis
equipment.
WARNING
After installation of this equipment, immediately contact your local gas
supplier to obtain information about what action to take whenever any
person smells gas. Post this information in a prominent location.
Keep this Manual in a Convenient Location for Reference
The Anets GoldenLine
Quality Equipment For The Restaurant, Supermarket, and Bakery Industries
L20-341 Rev 3
! FOR YOUR SAFETY
DONOTstoreor usegasolineorother flammablevapors
or liquids inthevicinityofthisoranyotherappliance.
!
!

CONTENTS
ShippingContainerInspection ....................................................... 3
FryerGasSupplySpecifications.................................................... 4
FryerElectricalSpecifications ....................................................... 5
Figure1 -FryerMX-14EWiringDiagram ............................ 5
CodeRequirements ...................................................................... 6
Figure2-FryerSiteInstallationRequirements ....................... 6
InstallationRequirements ............................................................... 7
InstallationInstructions .................................................................. 7
LegInstallationInstructions ..................................................... 7
Figure3- TypicalLeg Installation ......................................... 8
LegLevelingInstructions......................................................... 8
CasterInstallationInstructions ................................................. 8
Figure4- TypicalCaster Installation ..................................... 9
CasterLevelingInstructions .................................................... 9
FryerRestrainingDeviceInstallationInstructions ..................... 10
Gas&Electric ConnectionInstructions ....................................... 10
FryerOperatingInstructions........................................................ 11
FryerPreparationForUse(“BoilOut”Instructions) .............. 12
Figure5 - Draining the Kettle ............................................... 12
LightingProcedure ................................................................ 13
Figure6 -GasControlValve& KnobPositions................... 13
ShutdownProcedure ............................................................ 14
Food Product FryingTime Charts .................................... 15, 16
DailyCleaningProcedure....................................................... 17
MonthlyMaintenanceInstructions .......................................... 18
FryerTroubleshootingGuide ................................................. 19 - 26
FryerWarranty ............................................................................ 27
2

SHIPPING CONTAINER INSPECTION
1 . Carefullyexaminetheshippingcontainerforexternaldamage. Whendamageisnoted,notifythe
deliverycarrierimmediately. Save allpackingmaterialsfordamageclaimexamination.
2 . If no external damage is noted, remove the shippingcontainerfromthefryerandexaminethefryer
carefullyfordamage. Placethefryerin asafelocation,ifdamageisnoted,sothatthefreightdamage
claimsadjustercanexaminethefryer.
3 . Savetheshippingcontainerforuseduringleg/casterinstallation. RefertotheInstallationInstructions
forthat procedure.
Models Covered By This Manual
Standard Accessories furnished in the shipping carton with this fryer include:
ModelsMX-14AA,-14-2AA,MX-14E,andMX-14-2E ModelsMX-7AandMX-7E
2 Fryer Baskets 1 Screen 1 Fryer Basket 1 Screen
4 Adjustable Legs 1 Basket Hanger* 4 Adjustable Legs 1 Basket Hanger*
1 Drain Valve Extension 2 Basket Lift Frames ** 1 Drain Valve Extension 1 Basket Lift Frame **
1 Cleanout Rod 1 Cleanout Rod
*-BasketHanger for MX-14E,MX-14-2E,orMX-7E only.
**-BasketLiftFrameforMX-14AA,MX-14-2AA,or MX-7Aonly.
NOTE: Other available optional equipment may include a sediment tray; a microprocessor-based cooking
computerwithshorteningmelter,boil-outmode,anddigitaltimers(Fri-tronic®);abuilt-infiltersystem
(Filtronic
™
II or Filter Mate
™
); a fryer cover; a drain table; a front drain tray; or four casters.
NOTE: A Parts List for each
Anets Fryer is among the items shipped with each fryer. If an addi-
tional copy of this list is needed, please contact the factory as directed on the back cover.
3
!DANGER
Read these specifications, Code Requirements, Installation Requirements, Instal-
lation Instructions, and Operating Instructions very carefully. Failure to follow the
Instructions could cause the fryer to malfunction . A fryer malfunction can result in
property damage, serious bodily injury, or death.
MX-14E HighEfficiencyStainlessSteelFryer
MX-14-2E
MX-14-7E
Hig
h
Efficie
n
cyStainlessStee
l
Spl
i
tPotFrye
r
HighEfficiencyStainlessSteelHalfSizeFryer
M
X
-14
A
A
Hig
h
E
ff
i
ciencyStainlessStee
l
F
r
ye
r
W
i
t
h
Autom
a
ticLifts
MX-14-2AA HighEfficiencyStainlessSteelSplitPotFryerWithAutomaticLifts
M
X
-7
A
H
i
g
h
E
ff
i
ci
e
n
cySt
a
i
n
l
e
ssSt
e
e
l
H
a
lfSizeF
r
y
e
r
W
i
t
h
A
utom
a
t
i
c
L
i
fts

FRYER GAS SUPPLY SPECIFICATIONS
Please make sure that your desired fryer location has gas
supply factors that are suitable for this product:
Models MX-14E, MX-14-2E, MX-14AA, &MX-14-2AA
Models MX-7E & MX-7A
* -BTU/Hr Ratingis based on sealevel operation.Forsites above2000 feet, reducethis rating4% for
each 1000 feet
above sea level.
** - “ W.C. = Inches, Water Column.
*** -MeasureSupplyPressurewhenallothergas-poweredequipmentisoperating.
GasSupplyInlet Pipemustbe ¾” NPT(NationalPipeThread)standardgasline. Thegassupplyinlet
lineshouldbeasstraight aspossible(fewestbendsorelbows)toobtainthehighest availablegaspressureat
theappliance. Locatethisinletlinehorizontallyat thecenterofthedesiredfryer location,approximately
8¼”above the floor.
NOTE: Usingaflexibleinletlinepermitsvariationinthegassupplylinelocation,bothhorizontallyand
vertically.
Anetsfryersare onlyforuse withthetypeofgasspecifiedonthespecplate.Ifafryerrequiresmodification
touseagasotherthanthat whichis identifiedonthefryerspec plate,contact yourAnets representativeor
call(
4
1-603-225-6684.
INPUT REQUIRED:
111,000BTU/Hr* NaturalGas PropaneGas
MANIFOLDPRESSURE 3½“W.C. ** 10“W.C.
SUPPLYPRESSURE***
6 “ W.C., minimum 11“W.C., minimum
INPUT REQUIRED:
55,000BTU/Hr* NaturalGas PropaneGas
MANIFOLDPRESSURE 3½
“ W.C. **
10 “ W.C.
SUPPLYPRESSURE*** 6
“ W.C., minimum 11 “ W.C., mini-

FRYER ELECTRICAL SPECIFICATIONS
Please make sure that your desired fryer location has electrical
supply factors that are suitable for this product:
120Volts,60Hz,(RefertoTable1foramperage requirements),1-phase,three-wireconnection,including
an electricalground, viaa dedicatedcircuitbreaker. Amodel-specificelectricalcircuitdiagramis
mountedinsidethefrontdoorofeachfryer.
Table 1. Fryer Amperage
Requirements
!
Installadedicated,three-prong,outlet/receptacle
within5 feet of the desired fryer location to allow
the fryer’spower cable to be connected. Ensure
that the green (ground) wire of the fryer’s power
cableisattachedtothefryer’sstructure, providing
anelectricalground in accordance withapplicable
localcodes,orintheabsenceof local codes,with
the NationalElectricalCode,ANSI/NFPA70
(latestedition)or theCanadianElectrical Code,
CSAC22.1 (latest edition)andCSA C22.2(latest
edition).
Figure1isthebasicwiringdiagramofan
MX-seriesfryer showingatypicalcircuit.
Somefryersmayhaveotheroptionsthat do
notappearinthisbasicwiringdiagram. A
model-specificwiringdiagramincludedwith
eachfryershowsall theactualpartsand
theirassociatedwiringconnections. In
addition,fryersequippedwithabuilt-infilter
system(FiltronicIIorFilter Mate)and/or
built-incomputercontrols(Fri-tronic)have
asupplementarymanualincludedforeach
option.
Electrical Grounding Instructions
(See inside of door for wiring diagram.)
Thisapplianceisequippedwith a three-
prong (grounding) plug for your protec-
tion against shock hazard, and should
be plugged directly into a properly
grounded, three-prong receptacle . DO
NOT cutorremovethegroundingprong
from this plug.
Figure 1. Fryer Model MX-14E Wiring Diagram
5
WA
RNIN
G
Model Amperage
MX-14E
MX-14-2E
MX-7E
MX-14AA
MX-14-2AA
MX-7A
2 A.
4 A.
2 A.
7 A.
9 A.
5 A.

CODE REQUIREMENTS
IMPORTANT: Read the Code Requirements
and the Installation Requirements and Iinstruc-
tions carefully, before starting the installation.
Contact the factory
problems or questions arise.
Thefryerinstallationmustconformwith local
codes,orin the absenceoflocalcodes,withthe
NationalFuelGasCode,ANSIZ223.1(latest
edition);theNaturalGasInstallationCode,CAN/
CGA-B149.1(latestedition); orthePropaneGas
InstallationCode, CAN/CGA-B149.2(latest
edition),asapplicable,including:
a . Disconnectthefryeranditsindividualshutoff
valvefromthegassupplypipingsystemduring
anypressuretestingofthegassupplysystemat
testpressures inexcessof½psig(3.45kPa).
b. Isolatethefryerfromthegas supplypiping
systemduringanypressuretestingofthegas
supplysystemattestpressuresequaltoorless
than½psig (3.45 kPa).
c . Forfryersutilizingfloorcasters,thefryerinstal-
lationshall bemadewith aconnectorthat
complieswith theStandardfor Connectorsfor
MovableGasAppliances, ANSIZ21.69
(latestedition)orCAN/CGA6.16(latest
edition),and aquick-disconnectdevicethat
complieswiththe StandardforQuick-Discon-
nectDevicesforUse with Gas Fuel, ANSI
Z21.41orCAN/CGA1-6.9(latestedition).
From the top of the flue on
the fryer, allow a minimum
of at least 10 inches verti-
cal clearance beneath a
ventilating hood.
Figure 2. Fryer Site Installation Requirements
6
d. Restrictthemovementofacaster-equipped
fryerbyusingalimitingdevice(forexample,a
cableattachedboth tothefryerandto afix-
tureattachedtothesitestructure)toavoid
dependingon theconnectorand thequick-
disconnectdeviceoritsassociatedpipingto
limitfryermovement.
e . Installthisfryeronanon-combustiblefloor
withits backand sidesat least6”awayfrom
a
n
ycombust
i
b
lewall,asshow
n
i
n
Figu
r
e2.
if any
1-603-225-6684
W
ARNIN
G
!
Install this fryer under a ventilation
hood that conducts combustion pro-
ducts outside the building. Venting
must comply with ANSI/NFPA 96
(latest edition).
f. Installthisfryerinalocationwhereadequate
combustionandventilationairisavailable.
Keepthearea directlyinfront ofthefryeropen
foradequateairflowtotheburners. DO
NOTobstructthe flowofcombustion and
ventilationair.
g. Keepthefryerarea freeandclear from
combustiblesanddebris.
h. Attacharestrainingdevicetoeachfryer,to
preventtheunitfromtipping,whichcould
causesplashingofhotliquid.

INSTALLATION
Installthefryerinaccordancewiththepreceding
CodeRequirements,aswellasthefollowing
InstallationRequirements.
1. DONOTinstallthisfryerinamobilehome,
trailer,orrecreationalvehicle.
2. Installthisfryerinalocationthathasthefryer’s
electricalreceptacle nearby(5 feetorless
away)toavoidstrainingthefryer’spower
cord . (SeeFigure2.)
3. Installthisfryerinalocationthatallowsittobe
movedawayfromotheradjacentappliances
forcleaningandmaintenance.
NOTE: Ifthefryerisinstalledamong
arow ofappliances(“banked”),with
itsonlyconvenientmovementforward,
sufficientroommustbeavailablein
frontofthe fryertopermit itssepara-
tion fromadjacent appliancesfor
cleaningandmaintenance.
INSTALLATION
LEG INSTALLATION
INSTRUCTIONS
1 . Flattentheshippingcarton(afterunpackingthe
fryerand itspartsand accessories)forfryer
surfaceprotectionduringleginstallation.
2. Positionthesideofthefryerflatonthecarton,
exposingthefryerbottommountingbrackets
forleginstallation,asshowninFigure3.
3 . Placethelegmountingplateflushagainstthe
mountingbracketonthefryerbottom,while
aligningthemountingholes.
4.Insertonemountingboltthroughaflatwasher
andthenthroughtheproperholeinthefryer
mountingbracketandthroughthelegmounting
plate.
REQUIREMENTS
4. Tightlyfastenthelegs (orcasters)tothebot-
tomofthefryerusingthesuppliedhardware,to
preventthefryerfromtipping,wobblingor
rockingwhenitisinitsdesiredlocation. Refer
tothefollowingLegInstallationInstructions
or CasterInstallationInstructionsfor leg
orcasterattachmentandlevelinginformation.
CAUTION: Hoodmake-up air
MUSTNOTflowinamannertha
t
restrictsorimpedesthenaturalflo
w
ofcombustionorventilationair.
!
5. Confirmthattheairfromtheventilationhood
flowingnearthefryerafterinstallationisNOT
blowingontherearoftheunit,toprevent
affectingtheburnerflamesandpossiblycausing
damagetoplastic parts.
INSTRUCTIONS
5. Screwalockingnutseveralturnsontothe
mountingbolt.
6. Repeatsteps4and5untilallfourmounting
boltsforalegareinplacewithlockingnuts.
7. Tightenthefourlockingnutsevenlyandse-
curelytoholdthelegmountingplateagainstthe
fryer bottommountingbracket.
7

INSTALLATION INSTRUCTIONS
Figure 3. Typical Leg Installation
LEG LEVELING INSTRUCTIONS
1. Movethefryertoitsdesiredlocation.
WARNING
The fryer MUST NOT tip, rock or wob-
ble,toavoidsplashingor spillingits HOT
shortening contents during operation.
CASTER INSTALLATION
INSTRUCTIONS
1 . Flattentheshippingcarton(afterunpackingthe
fryer anditsparts and accessories)forsurface
protectionduringcasterinstallation.
2. Positionthesideofthefryerflatonthecarton,
exposingthefryerbottommountingbrackets
forcasterinstallation,asshowninFigure4.
3. Mountlockingcastersonthefrontofthefryer
andfixedcasters ontherear,byplacing each
castermountingplateflushagainstthemounting
bracketonthe fryerbottom.
4. Insertonemountingboltthroughaflatwasher
8
(Continued)
2. Turnthescrew-typelegadjustmentendsas
necessarytolevel thefryer,untilNOtipping,
rocking,orwobblingisevident.
3. Performthe FryerRestrainingDevice
InstallationInstructions,referringto
Figure2.
(supplied)andthe mountingbracket,then
throughthecastermountingplate.
5. Screwalockingnutseveralturnsontothe
mountingbolt.
6. Repeatsteps4and5untilallfourmounting
boltsforacasterareinplacewithlockingnuts.
7 . Tightenthefourboltsevenlyandsecurelyto
holdthecastermountingplateagainstthefryer
mountingbracket.
!

INSTRUCTIONS (Continued)
Figure 4. Typical Caster Installation
CASTER LEVELING
INSTRUCTIONS
Reinserteachboltthroughitsflatwasherand
thefryermountingbracket;next,placea
spaceroftherequired sizeontheboltbefore
insertingtheboltthroughitsmountingholeon
thecastermountingplateandscrewinga
lockingnutontothebolt.
Repeatstep 6 forall remainingbolts.
Tightenallfourlockingnutsevenlyandse-
curelyagainstthecastermountingplateand
thefryerbottommountingbracket.
Returnthe fryertoits desiredlocation. Lock
thefrontcasterstopreventfryermovement
andcheckagainforwobblingorrocking.
Repeatsteps3 through9until no wobbl-
ingorrockingoccurs. Whenthefryerno
longerwobblesorrocks,performstep 10.
10. Performthe FryerRestrainingDevice
InstallationInstructions,referringto
Figure2.
9
INSTALLATION
CASTER LEVELING INSTRUC-
TIONS
1.
2.
3.
4.
5.
(Continued)
Ifitdoes
Movethefryertoitsdesiredlocation.
Determinewhetherthefryertendstowobble
orrock wheninits desiredlocation. Ifit
does, perform steps 3through9.
not,skip tostep10, thenproceed tothe
InstallationInstructions.
6.
!
The fryer MUST NOT tip, rock or wob-
ble,toavoidsplashingor spillingits HOT
shortening contents during operation.
Determinewhichcasterrequiresadjustment
andtheapproximateamountofchange
requiredtolevelthefryer.
Positionthesideofthefryerontheship-
p
i
n
gcarton,exposingthe bottomofthefryer
withthecastermountingplates(Figure4).
Completelyunscrewtheboltsholdingthe
castermountingplatethatrequirestheleveling
adjustment. Retainthelockingnutsforlater
reassembly.
8.
9.
7.
W
ARNIN
G

INSTALLATION INSTRUCTIONS (Continued)
FRYERRESTRAININGDEVICEINSTALLATIONINSTRUCTIONS
1 . Installonerestrainingdeviceconnectorinto
thestructurewalldirectlybehindthefryer’s
desiredlocation,asshowninFigure2.
2
. Installonerestrainingdevice connectoronthe
rearpanelofthe fryerverycloseto thequick-
disconnectdeviceontheend ofthefryer’sgas
line.
NOTE: Avoidinterferingwiththelift
mechanism, onAAmodels.
3 . Attachoneendoftherestrainingcabletothe
wallconnector. Attach theother endtothe
fryerconnector.
4 . Confirmthatthefryercannotmovefarenough
awayfromthewalltocauseexcessivemove-
mentoftheflexiblegaslineoritsassociated
connectors.
GAS & ELECTRIC CONNECTION INSTRUCTIONS
Installingyour ANETS Fryerrequires thefol-
lowingprocedure, afterits legs orcastersarepro-
perlyattachedand itisin itsdesired location.
1 . Ensurethatthegascontrolvalveknobinthe
fryerhasitsOFFpositionnexttothevalve
mark.
2
. Ensurethatthegassupplyinletlinevalveis
closed(handlecrosswisetothe linedirection).
3 . Ensurethatthecircuit breakerdedicated to
thisfryeris OFFandthatallfryercontrolsare
set to OFF.
4 . Connectthe¾”gassupplylinetothegasline
adapteron thelowerrear ofthefryer.
10
! WARNING
Fryers MUST have a movement-
limiting(restrainingcable)device
installed to prevent tipping that
causes splashing or spilling its HOT
contents.
NOTE: Thismovement-limitingde
-
vice is to be furnished and in-
s
talled by the fryer’s installin
g
contractorbeforethe fryeris con-
nectedtothegas line at its desire
d
location.
! WARNING
DO NOT use a flame to check for leaks.
5 . Openthegassupplylinevalve(handlein-line
withlinedirection);then,confirmthatallgas
supplylinejointsand couplingsarefreeof
leaksusingsoap sudsora leak-check solu-
tion,afterthefryerisinitsdesiredlocation.
6 . Plugthefryer’selectricpowercordplug into
thereceptaclespecifiedforthisfryer. Switch
the circuit breaker to ON.
7 . RefertoFryerOperatingInstructionsto
beginusingyour
A
NE
T
S
Fryer.
